Cleveland SteamCraft 10 Operation Installation Maintenance Manual

Direct steam convection steamer with easy timer
Hide thumbs Also See for SteamCraft 10:
Table of Contents

Advertisement

Quick Links

Download this manual
Visit www.clevelandrange.com to locate a
service or sales representative in your area.
SteamCraft®10
Direct Steam Convection Steamer with Easy
Timer
Operation, Installation & Maintenance Manual
This manual is updated as new information and models are released. Visit our website for the latest manual.
MODEL:
24CDP10
!
Read the manual thoroughly.
Improper installation, operation or
maintenance can cause property
damage, injury, or death.
Cleveland
For your future reference.
Model #
Serial #
Part # KE004030-2 Rev A
February 2024

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SteamCraft 10 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cleveland SteamCraft 10

Summary of Contents for Cleveland SteamCraft 10

  • Page 1 Cleveland Visit www.clevelandrange.com to locate a service or sales representative in your area. SteamCraft®10 Direct Steam Convection Steamer with Easy Timer Operation, Installation & Maintenance Manual This manual is updated as new information and models are released. Visit our website for the latest manual.
  • Page 2 Cleveland Range, LLC has aux biens résultant de l'utilisation, de la fallecimiento, lesiones, daños al equipo o made every effort to provide accurate mauvaise utilisation ou du manquement daños a la propiedad resultantes de la...
  • Page 3 FOR YOUR SAFETY / POUR VOTRE SÉCURITÉ / PARA SU SEGURIDAD FOR YOUR SAFETY POUR VOTRE SÉCURITÉ PARA SU SEGURIDAD Do not store or use gasoline or any Ne pas entreposer ou utiliser No guarde ni use gasolina o other flammable liquids and vapours d'essence ou d'autres liquides ou cualesquiera otros líquidos o in the vicinity of this or any other...
  • Page 4 WARNING / AVERTISSEMENT / ADVERTENCIA Inspect unit daily for proper Heavy. / Lourd. / Pesado. operation. / Inspecter le bloc quotidiennement pour garantir le fonctionnement normal. / Team or mechanical lift. / Levage en équipe ou Inspeccione diariamente el mécanique. / Levantamiento en equipo o funcionamiento correcto de la mecánico.

  • Page 5: Table Of Contents

    OPERATION, INSTALLATION & MAINTENANCE MANUAL STEAMCRAFT MODEL 24CDP10 Table of Contents CHAPTER 1 GENERAL INFORMATION ......................5 Laws, Codes, and Regulations ......................5 Operational Safety ..........................5 Inspect for Shipping Damage ......................5 CHAPTER 2 PRODUCT INFORMATION ......................6 Product Information ..........................6 Model Numbers and Serial Numbers ....................

  • Page 6: Chapter 1 General Information

    This appliance must be level both front-to-back and side-to-side in all installations. NEVER operate this appliance out of level. If this appliance is suspected to be out of level, shut it down at once and call your qualified Cleveland Range authorized service agency immediately.

  • Page 7: Chapter 2 Product Information

    Figures 2-1 and 2-2 illustrate the major external features of 24CDP10’s. B. Model Numbers and Serial Numbers 1. Cleveland Range, LLC assigns two product identification numbers to each appliance: a model number and a serial number. 2. Please provide the model number and serial number when you contact Cleveland Range or a qualified Cleveland Range authorized service representative.

  • Page 8: Product Views

    D. Product Views Figure 2-1 24CDP10 Product Views Plan, Front, and Side Views Dimensions in Inches...
  • Page 9 Figure 2-2 24CDP10 Utility Locations...

  • Page 10: Chapter 3 Installation

    This appliance must be level both front-to-back and side-to-side in all installations. NEVER operate this appliance out of level. If this appliance is suspected to be out of level, shut it down at once and call your qualified Cleveland Range authorized service agency immediately.

  • Page 11: Slide Racks (Pan Racks)

    E. Water Supply 1. Water Supply Requirements ⚠ CAUTION Using water not within the limits specified in this manual could void or reduce Cleveland Range’s warranty coverage of the steamer. a) Water Quality As with any steam generating equipment, poor water quality degrades the performance of the steamer.
  • Page 12 • A 40 mesh water strainer (dirt filter), Cleveland Range Part Number 19870, is factory installed. • Flush the water supply line before connecting the line to the appliance.

  • Page 13: Electric Power Supply

    This unit is not suitable for connection to a GFCI (Ground fault Circuit Interrupter). • Cleveland Range recommends that the unit be connected to the electrical system, using a flexible conduit system compliant with the applicable codes. 3. A main disconnect switch and a separate fuse or breaker should be installed near the unit as shown in Figure 3-3.
  • Page 14 1. The drain lines must be installed in compliance with the Food Code (latest edition) of the Food and Drug Administration (FDA), and any other applicable national, state, or local codes and regulations. 2. The drain line must be free air vented, have gravity flow from the appliance, and terminate outside the perimeter of the appliance.

  • Page 15: Installation Checklist

    H. Installation Checklist Installation Checklist TASK REFERENCE COMPLETED Chapter Number (initial and Date) Preparation Check Operating Location Clearances Chapter 2 Section D Test Supply Water Quality Chapter 3 Section E Water Supply Requirements Met Chapter 3 Section E Electric Power Requirements Met Chapter 3 Section F Installation Check Level Front-to-Back and Side-to-Side...

  • Page 16: Chapter 4 Cooking With The 24Cdp10

    If the steamer door is stuck shut: • Turn OFF the steamer. • Call a qualified Cleveland Range authorized service technician. • Wait for the steamer to cool before servicing. ⚠ CAUTION Some foods drip juices. Use a solid catch pan under perforated pans when cooking food that drips juices.
  • Page 17 c. Slide pans of food into the slide racks in the cooking compartment d. Do not place pans or anything else on the bottom of the compartment. e. Close the compartment door. 2. Refer to Easy Timer Operating Instructions in Chapter 5 to start cooking. •...

  • Page 18: Chapter 5 Easy Timer Operating Instructions

    CHAPTER 5 EASY TIMER OPERATING INSTRUCTIONS DIGITAL DISPLAY CONTROL KNOB Enabled with TIMED mode TIMER START/STOP BUTTON in TIMED mode TIMED/MANUAL SWITCH BUTTON (Press for 5 sec) ON-OFF SWITCH ⚠ CAUTION Press switch and button with fingertips only. INJURY and EQUIPMENT DAMAGE can result from pressing switches and buttons with anything else.

  • Page 19: Main External Power Switch

    A. Main External Power Switch Usually, the steamers main external power switch is left ON. If the main external power switch was left in the OFF position, turn it 24CDP10 ON as follows. 1. Check that the water supply valves are open. 2.

  • Page 20: Preheat Steamer

    e) Steamer will stop heating and require prompt when the timer reaches 0:00. 4. Manual Mode (Continuous Steaming) a) Press and hold “TIMER-START STOP” button for 5 seconds until switches to Manual mode. b) “MAN” will appear on the digital display when activated and control knob disabled. c) Note: steamer will go into “Standby”...

  • Page 21: Chapter 6 Shutdown And Cleaning Procedure

    CHAPTER 6 SHUTDOWN AND CLEANING PROCEDURE A. Shutdown and Cleaning • Perform the Shutdown and Cleaning Procedure at the end of each shift or more often if needed. ⚠ WARNING ELECTRIC SHOCK HAZARD Do not clean this appliance with hoses or water jets. Doing so can cause INJURY and EQUIPMENT DAMAGE.

  • Page 22: Chapter 7 Operating Tests And Final Shutdown Procedure

    CHAPTER 7 OPERATING TESTS AND FINAL SHUTDOWN PROCEDURE A. Startup Procedure with the Appliance De-Energized 1. Start with or the Main External Power Switch OFF. 2. Check the fuses or circuit breakers for proper size. 3. Make sure the water supply line valve is open. 4.

  • Page 23: Optional Compartment Door Steam Shut Off Switch (Scs)

    3. Stand to the hinge side and back from the upper door and carefully open the upper door. 4. Steaming stops within a minute. 5. If steaming does not stop within a minute: Shut down the appliance and call your qualified Cleveland Range authorized service representative.
  • Page 24 8. If steaming does not start: Shut down appliance and call your qualified Cleveland Range authorized service representative. 9. Repeat this test with the lower cooking compartment door. 10. Repeat this test with both cooking compartment doors at the same time.

  • Page 25: Chapter 8 Preventative Maintenance

    • Increase the frequency of maintenance as needed depending on use and water quality. • Contact your qualified Cleveland Range authorized service agency or Cleveland Range for more information about maintenance scheduling, products, and services. B. Maintenance and Service Records 1.

  • Page 26: Chapter 9 Operator's Troubleshooting Guide

    “Remedy/Reference” (right column) lists fixes for problems from easiest to hardest. • “Notes” in “Remedy/Reference” column are at the end of the Troubleshooting Guide. ATTEMPTING TO REPAIR OR CORRECT PROBLEMS REQUIRING A QUALIFIED CLEVELAND RANGE AUTHORIZED SERVICE REPRESENTATIVE VOIDS THE WARRANTY PROBLEM...
  • Page 27 Notes 1. If the problem is inside the appliance, call a qualified Cleveland Range authorized service representative or Cleveland Range (Please have the model number and serial number ready when calling). Cleveland Range will not pay for warranty repairs by unauthorized maintenance and repair centers.
  • Page 28 • Inspect the drain(s) before each use and clean them if needed. Failure to follow these precautions can cause BURNS, SCALDS, and EQUIPMENT DAMAGE. 10. Order replacement descale caps and gaskets from a Cleveland Range authorized maintenance and repair center.
  • Page 29 Cleveland Cleveland Range, LLC 760 Beta Drive, Unit D Mayfield Village, Ohio 44143 216.481.4900 800.338.2204 Every new piece of Welbilt Foodservice equipment comes with KitchenCare® and you choose the level of service that meets your operational needs from one restaurant to multiple locations StarCare –...
