  • Page 1 FLAIR Installation Instructions...
  • Page 2 Please read and save these instructions before installation...
  • Page 3: Fan Support

    FAN SUPPORT For fast service have the following information below when you call: • Model Name and Number • Part Number and Part Description • Date Of Purchase and Purchase Location 1-800-526-2588 option MON-FRI 8AM-8PM EST Email: fansupport@waclighting.com For all questions about your ceiling fan please read all included instructions, installation procedures, trouble- shooting guidelines and warranty information before starting installation.
  • Page 4: Safety Rules

    SAFETY RULES For operation, maintenance, and troubleshooting information, visit http://waclighting.com To avoid personal injury or damage to the fan and at the circuit breaker before beginning. other items, please be cautious when working around or cleaning the fan. All wiring must be in accordance with the National Electrical Code “ANSI/ NFPA 70”...
  • Page 5 Substitution of parts or accessories not designated for use with this product by WAC could result in personal injury or property damage and will void the outlet box is to be sealed such that no water enters the outlet box.
  • Page 6 SAFETY RULES Remove and immediately recycle or dispose of used batteries according to local regulations and Retirez les piles usagées et recyclez-les ou mettez-les au rebut immédiatement, conformément aux keep away from children. Do NOT dispose of batteries in household trash or incinerate. réglementations locales.
  • Page 7 Coordinates with smart devices safety regulations for voice-activated control MOTOR Wi-Fi and Bluetooth enabled Compatible with our WAC app for unlimited control The WAC app synchronizes seamlessly with smart home devices you already own WALL CONTROL REMOTE CONTROL WC20-WT RC20-WT White Optional accessory...
  • Page 8: Table Of Contents

    TABLE OF CONTENTS Package Contents Mounting Options Installing the Mounting Bracket Attaching the Fan Blades Hanging the Fan Making the Electrical Connections Installing the Optional Wall Control Finishing the Installation Installing the Adapter Plate Installing the Luminaire Cover Installing the Luminaire Module Controlling the Fan Reset Application...
  • Page 9: Tools And Materials Required

    TOOLS & MATERIALS REQUIRED Wire cutters Electrical tape Phillips screwdriver Step ladder Hanging Weight: 5.4 kgs/ 11.9 lbs. NOTE: Before discarding packaging materials, be certain all parts have been removed. NOTE: Place the parts from the hardware bag into a small container to keep them from being lost. MAC ID IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place.
  • Page 10: Package Contents

    PACKAGE CONTENTS Fan Blade Canopy Ring RPL-F103-56-** RPL-CAN-OCT-** Downrod Coupling Assembly Cover RPL-HGR-ASM-6-** Motor Housing Mounting Canopy RPL-CAN-OCT-** Bracket RPL-HGR-ASM-6-** Hardware Bag Remote Control RPL-F103-PARTS RC20-WT Luminaire Cover Luminaire Module RPL-F103-COVER-** F4IN-120V-R1-CS-H Junction Box Safety Cable Pan Head Phillips Screw (2) Flat Washer (1) Flat Washers (2) Spring Washer (1)
  • Page 11: Mounting Options

    MOUNTING OPTIONS INSTALLING THE MOUNTING BRACKET Standard Ceiling Slope Ceiling Caution: Remember to disconnect the power at the circuit breaker. CAUTION: To prevent electrical shock, ensure electricity has been Remove 1 set screw from mounting bracket and set aside for use in Finishing the Installation.
  • Page 12: Attaching The Fan Blades

    ATTACHING THE FAN BLADES Place blade on motor assembly hole. Slide blade underneath the blade arms. Secure blade with blade attachment screws - repeat for remaining blades. hardware with x 3 attachment screws. F-103L...
  • Page 13: Hanging The Fan

    HANGING THE FAN Remove screw from hanger ball. Remove hanger ball Install coupling cover, canopy screw ring, canopy and and cross pin. downrod assembly into motor housing as shown. Loosen 2 screws, clevis pin and cotter pin. F-103L...
  • Page 14 HANGING THE FAN Align downrod and motor collar holes, re-insert pins and screws. Seat all into the mounting bracket. Rotate until ball drops and locks into hanger bracket screw. Slip up canopy and canopy screw cover. Re-install hanger ball with cross pin in correct place. F-103L...
  • Page 15: Making The Electrical Connections

    HANGING THE FAN MAKING THE ELECTRICAL CONNECTIONS Outlet Box Hanger Ball & Downrod Connect the labled wires from fan to the corresponding wires on the receiver. Secure the safety cable into the structure beams using the Connect the labeled wires from the outlet box to the wood screw, washers, and spring washers provided.
  • Page 16: Installing The Optional Wall Control

    INSTALLING THE OPTIONAL WALL CONTROL NOTE: Wall control not included. A Bluetooth wall control accessory can be purchased separately. NOTE: For multi-location wiring, skip to the next step. Connect the green wire marked “GROUND” from the wall control to the copper wire from the wall outletbox that feeds back to the circuit breaker –...
  • Page 17 INSTALLING THE OPTIONAL WALL CONTROL Wall Control 1 Wall Control 2 Wall Control 3 Install the wall control using the wiring diagram above. Individually pair each of the wall controls with the fan receiver using the pairing instruction. F-103L...
  • Page 18: Finishing The Installation

    FINISHING THE INSTALLATION Secure wire connectors with supplied wire ties. Install canopy screw ring as shown. Install canopy to mounting bracket with the screw removed in section 2. F-103L...
  • Page 19: Installing The Adapter Plate

    INSTALLING THE ADAPTER PLATE Remove 1 of 3 screws from the mounting ring and loosen the Twist and lock the adapter plate into place by following the others (do not remove). arrows above. Using the screw from the previous step, install the adapter plate. F-103L...
  • Page 20: Installing The Luminaire Cover

    INSTALLING THE OPTIONAL LUMINAIRE COVER 1. Twist the luminaire shade on tightly if you do not plan on using the LED module. F-103L...
  • Page 21: Installing The Luminaire Module

    INSTALLING THE LUMINAIRE MODULE NOTE: Before installing the LED module - please note your Fan comes standard as 3000K (neutral white color). You can preset your Fan to 2700K, 4000K, or 5000K (pure white - daylight color) by adjusting the switch on the module. 17.a 17.b 1.
  • Page 22 INSTALLING THE LUMINAIRE MODULE Install shade rmly by twisting it onto the grooves. You are now ready to Power ON your Fan. F-103L...
  • Page 23: Controlling The Fan

    NOTE: Pairing must be completed within 3 minutes of turning the power on to the fan receiver. If you wish to pair your remote to another WAC Smart Fan or if you ever need to re-pair your remote to its original C: Season (Summer/Winter)
  • Page 24 CONTROLLING THE FAN Controlling Multiple Fans with Remote or Wall Controls Breeze Mode Your remote and wall controls are capable of controlling Breeze Mode mimics the natural ebb and flow of winds in multiple fans. A remote or wall control has the ability to control nature by varying the fan speed.
  • Page 25 CONTROLLING THE FAN Fan Direction Press and hold Press and hold Press and hold button for 4 seconds. button for 4 seconds. button for 4 seconds. Press and hold Press and hold Fan Direction: Press and hold beep to indicate the message has been received. All fans will be set to summer mode (CCW rotation). This will bring all fans controlled by the remote into sync.
  • Page 26: Reset

    10 seconds. The light on the remote NOTE: Factory reset will remove remote control(s), wall control(s) and WAC long beeps. You can then use the WAC app connections.
  • Page 27: Application

    Wi-Fi. For more detailed app Instructions and Smart Home Device Integration http://www.waclighting.com/SmartFanStart To use the WAC app, download it from the App Store or Google Play. Open the app to create your account. You can also log in using your Facebook or Google account.
  • Page 28 APPLICATION The WAC app will walk you through the main screen and show you how to create schedules, change fan speeds, dim the light, switch between Summer and Winter Modes, invite users, create groups and much more. Please refer to the WAC app instructions for more details.
  • Page 29: Accessories

    Description Finish Bluetooth 6 fan speeds, dims light to 1% Wall Control WC20- Works in conoutlet with WAC Smart Fan receiver (not included) Coupler Connects two downrods Designed to accommodate buildings with steeper Slope Ceiling Kit sloped ceilings up to 45° or 12/12 pitch...
  • Page 30 ACCESSORIES Product Model Description Downrod DR12-** 12” downrod DR18-** 18” downrod DR24-** 24” downrod All our downrods are 1” O.D. and are threaded on the motor DR36-** 36” downrod end to create an extra layer of security to allow for adjustments DR48-** 48”...
  • Page 31: Troubleshooting

    TROUBLESHOOTING My Fan Will Not Start Check main and branch circuit fuses or circuit breakers. Check line wire connections to fan and switch wire connections in the switch housings. WARNING My Fan is Noisy Allow for 24-hour break-in period. Most noises associated with a new fan will go away during this time period. Check to make sure the screws which attached to the blades (and blade arms when applicable) are tight.
  • Page 32 TROUBLESHOOTING My Fan is not producing Enough Air Movement If possible, please consider using a longer than included downrod. My remote or wall control is not controlling my fan Verify that the fan is receiving power by power cycling the fan. To do this: Wait at least 10 seconds, and then restore power.
  • Page 33 What is Pairing? Pairing is the process of connecting your WAC remote or wall control to your fan. Your fan comes pre-paired to your included remote control. However, if you want additional controls for your fan or if you’re replacing a control, refer to the pairing and unpairing section of the instructions.
  • Page 34: Certificate Of Warranty

    (or according period of time as outlined by material). Excluded from warranty defecto por escrito debe ser recibida por WAC dentro de los cinco (5) años a partir de are any 3rd party component which carries its own manufacturer’s warranty. Note: WAC la fecha de compra (o según el período de tiempo indicado en el material).
  • Page 35 Cette garantie ne inappropriée. WAC doit recevoir un avis écrit du défaut dans un délai de cinq (5) ans à compter de la date d’achat (ou selon la période précisée dans les informations fabricant.
