Summary of Contents for WAC HUG
- Page 1 Installation Instructions works with the Google Assistant...
- Page 2 Please read and review instructions before installation...
- Page 3 GENERAL INQUIRIES FAN SUPPORT For all questions about your ceiling fan please read all For fast service have the following information below included instructions, installation procedures, trouble- when you call: shooting guidelines and warranty information before starting installation • Model Name and Number For missing parts or general inquiries •...
- Page 4 SAFETY RULES For operation, maintenance, and troubleshooting information, visit waclighting.com/help. To reduce the risk of electric shock, ensure electricity has been turned off To avoid personal injury or damage to the fan and at the circuit breaker before beginning. other items, please be cautious when working around or cleaning the fan.
- Page 5 WAC. Substitution of parts WARNING: Do not operate fan unless fan blades are in place. or accessories not designated for use with this product by WAC could result Noise and fan damage can occur in personal injury or property damage and will void the warranty.
- Page 6 UL/cUL safety regulations for voice-activated control Wi-Fi and Bluetooth enabled Compatible with our WAC app for unlimited control The WAC app synchronizes seamlessly with smart home devices you already own works with the Google Assistant WALL CONTROL APP DOWNLOAD...
-
Page 7: Table Of Contents
TABLE OF CONTENTS Package Contents Mounting Options Installing the Mounting Bracket Attaching the Fan Blades Hanging the Fan Making the Electrical Connections Installing the Optional Wall Control Installing the Adapter Plate Installing the Luminaire Module Finishing the Installation Controlling the Fan Factory Reset App Instructions Accessories... - Page 8 TOOLS & MATERIALS REQUIRED Electrical tape Wire cutters Phillips screwdriver Step ladder NOTE: Before discarding packaging materials, be certain all parts have been removed. NOTE: Place the parts from the hardware bag into a small container to keep them from being lost. MAC ID IMPORTANT: Please make note of the MAC ID on the receiver and keep it in a safe place.
-
Page 9: Package Contents
PACKAGE CONTENTS Adapter Plate Motor Housing Fan Blade RPL-F036-BD-44-** Mounting Bracket Remote Control RPL-F037-BD-52-** RPL-HUG-HGR RC20-WT Hardware Bag RPL-HUG-PARTS Glass Shade Cap RPL-HUG-GLA Junction Box Safety Cable #10 x 38mm Pan Head Phillip Screws (2) Φ6.5x19x2mm Flat Washer (1pc) Ø5 x 14 x 1mm Flat Washer (2) 3/16"(Φ5.2x8.4x1.0mm) Spring Washer (1) -
Page 10: Mounting Options
MOUNTING OPTIONS INSTALLING THE MOUNTING BRACKET Standard Ceiling To Switch To Switch Neutral) Caution: To prevent electrical shock, ensure electricity has been turned off at the circuit (HOT) (Ground) breaker before beginning. (Ground) (HOT)/ (Neutral) *Bare or *Bare or Switch Green Green 1. -
Page 11: Attaching The Fan Blades
ATTACHING THE FAN BLADES Insert blades in slots, aligning with motor assembly holes. Secure blades with blade attachment screws & washers as shown. For Blade installation, use parts: 3/16"x13mm Head Screws (10) Φ5x14x1.5mm Paper Washer (10) -
Page 12: Hanging The Fan
MAKING THE ELECTRICAL CONNECTIONS HANGING THE FAN Outlet Box (Mounting Bracket Ground) Mounting Bracket (Mounting Bracket Ground) 1. Remove 1 opposing screw and loosen the other 2 for the mounting bracket. 2. Pass supply wires through mounting bracket. 3. Lift motor as- semby and hang it on the hook on the mounting bracket using one 1. -
Page 13: Installing The Optional Wall Control
INSTALLING THE OPTIONAL WALL CONTROL NOTE: Wall control not included. A Bluetooth wall control accessory can be purchased separately. NOTE: For multi-location wiring, skip to the next step. Connect the green wire marked “GROUND” from the wall control to the copper wire from the wall outlet box that feeds back to the circuit breaker –... - Page 14 HANGING THE FAN / INSTALLING THE ADAPTER PLATE 1. Secure wire connectors with supplied wire ties. Double-check the wire connections before finalizing hanging the fan. 2. Remove the motor from the hook on the mounting bracket. Slide the motor up to the mounting bracket and place the key hole on the motor over the screw on the mounting bracket.
-
Page 15: Installing The Luminaire Module
INSTALLING THE LUMINAIRE MODULE & GLASS Connect white wire to white wire and blue wire to blue wire. Remove 3 screws from the outer perimeter of the adapter plate. NOTE: Do not screw in luminaire plate until LED wires are connected. Using the screws from the previous step, install the luminaire module. -
Page 16: Finishing The Installation
FINISHING THE INSTALLATION 1. Install glass shade into the grooves without over-tightening. -
Page 17: Controlling The Fan
CONTROLLING THE FAN Summer Mode (Counter-Clockwise) Air-Gap Switch* Wall Control Remote Pairing Unpairing Winter Mode * Air-Gap Switch only included Control Press and hold buttons To purge, press and hold buttons for 4 seconds. (Clockwise) with wall control for 10-15 seconds. Your fan was delivered to you with the included control already NOTE: Your fan features 6 speeds. - Page 18 CONTROLLING THE FAN Breeze Mode Controlling Multiple Fans with Remote or Wall Controls Your remote and wall controls are capable of controlling multiple fans. A remote or wall control has the ability to control Breeze Mode mimics the natural ebb and flow of winds in an unlimited number of fans with the only limitation being the nature by varying the fan speed.
- Page 19 CONTROLLING THE FAN Fan On/Off Light On/Off Fan Direction Press and hold Press and hold Press and hold button for 4 seconds. button for 4 seconds. button for 4 seconds. Fan On/Off: Press and hold button for 4 seconds. The LED on the remote will flash green and all connected fans will beep to indicate the message has been received.
-
Page 20: Factory Reset
NOTE: Factory reset will remove remote control(s), wall NOTE: If you change your Wi-Fi settings (SSID or Security control(s) and WAC Smart Fan app connections. Passphrase you will need to perform a Wi-Fi reset on the fan by holding down the fan speed up and fan speed down buttons NOTE: You may need to factory reset your receiver if you on the remote control for 10 seconds. - Page 21 NOTE: Press light toggle and season toggle and hold for 4 seconds if you prefer not using the app or broadcasting Wi-Fi. For more detailed app Instructions and Smart Home Device Integration To use the WAC Smafrt Fan app, download it from the App http://www.waclighting.com/SmartFanStart Store or Google Play.
- Page 22 APPLICATION The WAC Smart Fan app will walk you through the main screen and show you how to create schedules, change fan speeds, dim the light, switch between Summer and Winter Modes, invite users, create groups and much more. Please refer to the WAC Smart Fan app instructions for more details.
-
Page 23: Accessories
Model Description Finish 6 fan speeds, dims light to 1% Bluetooth Wall Control WC20 Works in conjunction with WAC Smart Fan receiver (not included) Compatible with WAC Smart Fans Bluetooth Remote Control RC20 6 fan speeds, dims light to 1%... -
Page 24: Troubleshooting
TROUBLESHOOTING My Fan Will Not Start Check main and branch circuit fuses or circuit breakers. Check line wire connections to fan and switch wire connections in the switch housings. WARNING: Make sure the main power is turned off! My Fan is Noisy Allow for 24-hour break-in period. - Page 25 TROUBLESHOOTING My remote or wall control is not controlling my fan Verify that the fan is receiving power by power cycling the fan. To do this: Cut power to the fan via standard On/Off wall switch, or the breaker if standard wall switch is not applicable. Wait at least 10 seconds, and then restore power.
- Page 26 What is Pairing? Pairing is the process of connecting your WAC remote or wall control to your fan. Your fan comes pre-paired to your included remote control. However, if you want additional controls for your fan or if you’re replacing a control, refer to the pairing and unpairing section of the instructions.
- Page 28 If the problem cannot be resolved, an RGA number will be issued. WAC de WAC se limita expresamente a la reparación o el reemplazo, sin cargo, en la fábrica de WAC después obligation is expressly limited to repair or replacement, without charge, at the WAC factory after prior de que se haya otorgado una autorización previa por escrito.
- Page 29 à la réparation ou au remplacement, sans frais, dans l’usine de WAC après autorisation écrite préalable du retour. L’obligation de WAC au titre de cette garantie ne s’étendra pas au-delà du prix d’achat initial du produit par le distributeur. En conséquence, tout dommage indirect ou tout coût de main-d’œuvre résultant d’un défaut est expressément exclu.
- Page 32 F-0 36L & F -037 L waclighting.com...
