Baxton Studio BSBBT61266 Assembly Instructions

MODEL : BBT61266 QUEEN BED
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : Screwdriver (not provider).
STEP 1
ASSEMBLY INSTRUCTIONS
A
PART LIST
QTY
ITEM DESCRIPTION BOX
A
HEADBOARD 1 PC
1
B HEADBOARD PANEL 1 2 PCS
C
FOOTBOARD 2 1 PC
D
SIDE RAIL 2 2 PCS
E
CENTER RAIL 2 1 PC
F
CENTER SUPPORT LEG 2 3 PCS
G BED SLAT 3 1 SET
H
BED LEG 2 2 PCS
Take out HEADBOARD PANEL (B) & VMB3172 (10)
for the HEADBOARD BACK (A).
A
1 OF 4
HARDWARE LIST (BOX : 2 )
ITEM DESCRIPTION
1
JCBC BOLT M6 x 20mm
2 JCBC BOLT M6 x 35mm
3
JCBC BOLT M6 x 45mm
4 M6 FLAT WASHER
5 M6 SPRING WASHER
6
M8 FLAT WASHER
7 M8 SPRING WASHER
8 5/16 HEX NUT
9 LB 001 CONNER BRACKET
10
VMB 3172
11 SPANNER 13mm
12
WOOD SCREW M4 X 20mm
13 WOOD SCREW M4 X 38mm
14 M4 ALLEN KEY (BALL SHAPE)
15 M5 ALLEN KEY (BALL SHAPE)
10
B
QTY
16 PCS
1 PC
3 PCS
19 PCS
19 PCS
2 PCS
2 PCS
2 PCS
2 PCS
2 PCS
1 PC
1 PC
14 PCS
1 PC
1 PC
