- Page 2 Full Bed Assembly Instructions WII-0419 Assembled View Use 2 People Note: Do not assemble using power tools. This can cause the bolts to be overtightened Parts List Side Rail x 2 Post Post (Left hand) (Right hand) Long Support x 1 Extra Holes Headboard Panel x 1 Support Leg...
- Page 3 0005 Full Bed Assembly Instructions WII-0419 Fix the Adjustable foot to the bottom of the Support Leg (G). Assemble the Post (A & B) to the Headboard / Footboard Panel (C & D). Fit the Center Rail Bracket to the Headboard / Footboard Panel (C &...
- Page 4 0005 Full Bed Assembly Instructions WII-0419 Assemble the Side Rail (E) to the Headboard & Footboard Panel (C & D). Bolt the Long Support (F) to the Center Rail Brackets (2) on the Headboard & Footboard Panel (C & D). Page 3 of 5...
- Page 5 0005 Full Bed Assembly Instructions WII-0419 Fit the first 3 Slats and assemble the Support Leg (G) to the Bed Slat (H). Bolt & screw the Bed Slats (H) to the Side Rail (E) & Long Support (F). Fit the other Slats out and assemble the Support Leg (G) to the Bed Slat (H).
- Page 6 0005 Full Bed Assembly Instructions WII-0419 Fit the other Slats out and assemble the Support Leg (G) to the Bed Slat (H). Bolt & screw the Bed Slats (H) to the Side Rail (E) & Long Support (F). Bolt & screw the remaining Bed Slats (H) to the Side Rail (E).
