Baxton Studio BBT61266 Assembly Instructions

MODEL : BBT61266 KING BED
Read this instruction carefully. See hardware and furniture part list for guidance.
Be sure all parts are complete, before you assemble. Place all wooden furniture
parts on a clean and flat soft surface to prevent from being scratched.
Follow the figure to start assembling.
CAUTIONS
: 1. Do not FULLY - TIGHTEN the nut or nut bolt until all nut or bolt is ready assembed.
2. Do not OVER - TIGHTEN the nut or bolt to avoid causing damages to the thread.
3. Keep all hardware parts out of reach of children.
NOTE : THE LIST AND QUANTITY SHOWN ARE FOR 1 UNIT ASSEMBLY.
Tool needed : Screwdriver (not provider).
STEP 1
ASSEMBLY INSTRUCTIONS
A
PART LIST
QTY
ITEM DESCRIPTION
ITEM
A
HEADBOARD 1 PC
1
B HEADBOARD PANEL 2 PCS
2
C
FOOTBOARD 1 PC
3
D
SIDE RAIL 2 PCS
4
E
CENTER RAIL 2 PCS
5
F
CENTER SUPPORT LEG 6 PCS
6
G BED SLAT 1 SET
7
H
BED LEG 2 PCS
8
9
10
11
12
13
14
15
Take out HEADBOARD PANEL (B) & VMB3172 (10)
for the HEADBOARD BACK (A).
A
1 OF 4
HARDWARE LIST
DESCRIPTION
JCBC BOLT M6 x 20mm
JCBC BOLT M6 x 35mm
JCBC BOLT M6 x 45mm
M6 FLAT WASHER
M6 SPRING WASHER
M8 FLAT WASHER
M8 SPRING WASHER
5/16 HEX NUT
LB 001 CONNER BRACKET
VMB 3172
SPANNER 13mm
WOOD SCREW M4 X 20mm
WOOD SCREW M4 X 38mm
M4 ALLEN KEY (BALL SHAPE)
M5 ALLEN KEY (BALL SHAPE)
10
B
QTY
16 PCS
2 PCS
3 PCS
19 PCS
19 PCS
2 PCS
2 PCS
2 PCS
2 PCS
2 PCS
1 PC
2 PCS
16 PCS
1 PC
1 PC
