Storage Electric Water Heater
Instruction Manual
For Model: D30-15A6
The diagram above is just for reference. Please take the
appearance of the actual product as the standard.
Thank you very much for purchasing our water heater.
Before installing and operating your water heater, please
read this manual carefully and keep it for future reference.
D50-15A6
D80-15A6
D100-15A6
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Midea D50-15A6
Summary of Contents for Midea D50-15A6
- Page 1 Storage Electric Water Heater Instruction Manual For Model: D30-15A6 D50-15A6 D80-15A6 D100-15A6 The diagram above is just for reference. Please take the appearance of the actual product as the standard. Thank you very much for purchasing our water heater. Before installing and operating your water heater, please...
-
Page 2: Table Of Contents
General Remark ● The installation and maintenance has to be carried out by qualified professionals or Midea authorized technicians. ● The manufacturer shall not be held responsible for any damage or malfunction caused by wrong installation or failing to comply with following instructions included in this pamphlet. -
Page 3: Cautions
1. CAUTIONS Before installing this water heater,check and confirm that the earthing on the supply socket is reliably grounded. Otherwise, the electrical water heater can not be installed and used. Do not use extension boards. Incorrect installation and use of this electrical water heater may result in serious injuries and loss of property. -
Page 4: Product Introduction
2.2 Technical Performance Parameters Rated Rated Rated Max Of Water Volume Protection Waterproof Model Power Voltage Pressure Temperature Class Grade (ACV) (MPa) (℃) 220-240 D30-15A6 1500 0.75 IPX4 D50-15A6 1500 220-240 0.75 IPX4 220-240 D80-15A6 1500 0.75 IPX4 D100-15A6 1500 220-240 0.75 IPX4... -
Page 5: Internal Wire Diagram
Thermometer Shell Control-box Installation-cover Right cover Power cord Anode Inner tank Cold water inlet Thermal insulation Heating Element Hot water outlet D30-15A6 D50-15A6 D80-15A6 D100-15A6 (Note:All dimensions are in mm) 2.4 Internal Wire Diagram Thermal Thermostat Cut Out Brown Blue Yellow/Green... -
Page 6: Unit Installation
3. UNIT INSTALLATION 3.1 Installation Instruction This electrical water heater shall be installed on a solid wall. If the strength of the wall cannot bear ① the load equal to two times of the total weight of the heater filled fully with water, it is then necessary to install a special support. -
Page 7: Methods Of Using
Power cord Rubber seal gaskets Sewerage exit Cold water inlet Rubber seal gaskets Pressure relief valve Hot water outlet Pressure release hole Adjusting handle for Joint screw for cold water inlet (Fig.4) mixing valve Hot water ④ If the users want to realize a multi-way supply system, refer to the method shown in fig.5 for connection of the pipelines. -
Page 8: Maintenance
NOTE During normal operation, the inlet valve shall be always kept open. ● If the “Power” indicator lights up, the thermostat will automatically control the temperature. When the water temperature inside the heater has reached the set temperature, it will switch off automatically, when the water temperature falls below the set point the heater will be turned on automatically to restore the heating. -
Page 9: Troubleshooting
● The water heater is equipped with a thermal switch, which cuts off power supply of the heating element upon water overheating or its absence in the water heater. If the water heater is connected to the mains, but water is not heated and the indicator doesn’t light up, then the thermal switch was switched off or not switched on. - Page 10 The product is subject to change without notice. Please keep this manual properly. Wuhu Midea Kitchen & Bath Appliances Mfg. Co., Ltd. Address: East Road Wanchun, East Area Economic & Technological Development Area, Wuhu City, Anhui Province, P.R.China. Web site: www.midea.com/global...
