- Page 1 EN User Manual | Cooker CGB6131ACM aeg.com\register...
- Page 2 Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................8 4. PRODUCT DESCRIPTION................11 5. BEFORE FIRST USE..................12 6.
- Page 3 be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use.
- Page 4 • CAUTION: The cooking process has to be supervised. A short term cooking process has to be supervised continuously. • WARNING: Danger of fire: Do not store items on the cooking surfaces. • Do not use a steam cleaner to clean the appliance. •...
- Page 5 2. SAFETY INSTRUCTIONS electrical ratings of the mains power This appliance is suitable for the following supply. markets: GB IE • Always use a correctly installed shockproof socket. 2.1 Installation • Do not use multi-plug adapters and extension cables. • Do not let mains cables touch or come WARNING! near the appliance door or the niche below Only a qualified person must install this...
- Page 6 installation regulations. Follow the WARNING! requirements for adequate ventilation. Risk of fire and explosion. 2.4 Use • Fats and oil when heated can release flammable vapours. Keep flames or WARNING! heated objects away from fats and oils Risk of injury and burns. when you cook with them.
- Page 7 • Cookware made of cast iron, aluminium or • Do not clean the burners in the with a damaged bottom can cause dishwasher. scratches. Always lift these objects up 2.6 Lid when you have to move them on the cooking surface. •...
- Page 8 • Contact your municipal authority for • Cut off the mains electrical cable close to information on how to dispose of the the appliance and dispose of it. appliance. • Flat the external gas pipes. • Disconnect the appliance from the mains supply.
- Page 9 3.5 Other technical data WARNING! These instructions are only valid in the countries whose symbols appear on this booklet's cover. 180 mm Gas category: 30 mm Gas supply: G20 (2H) 20 mbar Voltage: 220-240 V Frequency: 50 Hz 3.6 Gas burners BURNER NORMAL POWER Natural Gas...
- Page 10 2. Put on the burner crowns and caps. Make sure that they are correctly seated. 3. Put on the pan supports. Use flexible tubing, which comply with 4. Light one of the hob burners. the BS.669 current edition. To light the hob burner refer to the "Ignition of the hob burners".
- Page 11 4. PRODUCT DESCRIPTION 4.1 General overview Control panel and hob Air vents for the cooling fan Grill Lamp Shelf support, removable Shelf positions 4.2 Hob overview Auxiliary burner Multicrown burner Semi-rapid burner 4.3 Cooker control panel Knob for the top oven Knobs for the hob Steam outlet - number and position depend on the model...
- Page 12 4.4 Accessories For roasting and grilling. • Wire shelf For cookware, cake tins, roasts. Use the trivet only with the Grill- / • Grill- / Roasting pan roasting pan. To bake and roast or as pan to collect fat. • Trivet 5.
- Page 13 knob, the spark generator activates automatically. 2. Keep the knob for the hob pushed for It is not possible to use the hob without equal or less than 10 seconds to let the electricity. thermocouple warm up. If not, the gas supply is interrupted.
- Page 14 A. Burner cap B. Burner crown C. Ignition candle D. Thermocouple 6.3 Replacing burner parts WARNING! 1. Put carefully the burner crown on the Always turn the flame down or switch it burner body. Let the crown fall freely onto off before you remove the pans from the the body.
- Page 15 7.2 Diameters of cookware WARNING! Do not put unstable or damaged pots on WARNING! the burner to prevent spills and injuries. Use cookware with diameters applicable to the size of burners. CAUTION! Make sure that pot handles are not Burner Diameter of cook‐...
- Page 16 8.4 Cleaning the spark plug stains, shiny metallic discoloration. Clean the hob with a moist cloth and a non- This feature is obtained through a ceramic abrasive detergent. After cleaning, wipe ignition candle with a metal electrode. Keep the hob dry with a soft cloth. these components well clean to prevent •...
- Page 17 9.5 Using the grill 1. Turn the knob for the oven functions You cannot operate the top oven burner, clockwise to when the grill is active. 2. Adjust the deep pan runner position to fit 1. Open the oven door. in different portions of food.
- Page 18 • All accessories have small indentations at the top of the right and left side to increase safety. The indentations are also anti-tip devices. • The high rim around the shelf is a device which prevents cookware from slipping. 9.8 Trivet and Grill- / Roasting pan Step 1 Put the trivet into a deep pan.
- Page 19 A. Minute minder indicator C. Time of day indicator B. Time display 10.2 Buttons Button Function Description MINUS To set the time. CLOCK To set a clock function. PLUS To set the time. 10.3 Setting the MINUTE MINDER 10.4 Cancelling the clock functions 1.
- Page 20 Food Preheating Heat setting Time (min) Shelf position Accessories time (min) Fatless sponge 25 - 35 1 tin (Ø 26 cm) cake on wire shelf Apple pie 80 - 100 2 tins (Ø 20 cm) on wire shelf Pastry stripes / 15 -20 Patisserie tray short bread...
- Page 21 Before activating the catalytic cleaning remove all the accessories from the oven. The walls with catalytic coating are self- cleaning. They absorb fat which collects on the walls while the appliance operates. To support the self-cleaning procedure, heat the empty oven on a regular basis. Install the shelf supports in the opposite The oven cavities must be cleaned sequence.
- Page 22 12.7 Removing and cleaning the 12.8 Replacing the lamp door glasses - main oven WARNING! Risk of electric shock. The lamp can be hot. The door glass in your product can be different in type and shape from the 1. Turn off the oven. Wait until the oven is example you see in the image.
- Page 23 13.1 What to do if... Problem Possible cause Remedy You cannot activate the appliance. The appliance is not connected to Check if the appliance is correctly an electrical supply or it is connec‐ connected to the electrical supply. ted incorrectly. You cannot activate the appliance.
- Page 24 14.3 Product Information Sheet and Product Information according to EU and UK Energy Labelling and Ecodesign Regulations for Oven Supplier's name Model identification CGB6131ACM 948905189 Top oven: 95.1 Energy Efficiency Index Main oven: 90.0 Top oven: A Energy efficiency class...
- Page 25 Heat source Top oven: 36 l Volume Main oven: 83 l Type of oven Oven inside Freestanding Cooker Mass 59.8 kg EN 15181 Measuring method of the energy consumption of gas fired ovens. 14.4 Oven - Energy saving Residual heat When the cooking duration is longer than 30 Following tips below will help you save min, reduce the appliance temperature to...
- Page 28 867364145-A-292024...
