- Page 1 EN User Manual | Cooker CIB6734ACM aeg.com\register...
-
Page 2: Table Of Contents
Welcome to AEG! Thank you for choosing our appliance. Get usage advice, brochures, troubleshooting, service and repair information: www.aeg.com/support Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. SAFETY INSTRUCTIONS................5 3. INSTALLATION....................7 4. PRODUCT DESCRIPTION................9 5. BEFORE FIRST USE..................10 6. -
Page 3: General Safety
be kept away from the appliance unless continuously supervised. • Children should be supervised to ensure that they do not play with the appliance. • Keep all packaging away from children and dispose of it appropriately. • WARNING: The appliance and its accessible parts become hot during use. - Page 4 • WARNING: Unattended cooking on a hob with fat or oil can be dangerous and may result in fire. • Never use water to extinguish the cooking fire. Switch off the appliance and cover flames with e.g. a fire blanket or lid. •...
-
Page 5: Safety Instructions
• To remove the shelf supports first pull the front of the shelf support and then the rear end away from the side walls. Install the shelf supports in the opposite sequence. • The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. - Page 6 • The electrical installation must have an • Used oil, that can contain food remnants, isolation device which lets you disconnect can cause fire at a lower temperature than the appliance from the mains at all poles. oil used for the first time. The isolation device must have a contact •...
-
Page 7: Internal Lighting
2.4 Care and Cleaning • Concerning the lamp(s) inside this product and spare part lamps sold separately: These lamps are intended to withstand WARNING! extreme physical conditions in household Risk of injury, fire, or damage to the appliances, such as temperature, appliance. -
Page 8: Location Of The Appliance
This appliance is supplied without a main plug or a main cable. Dimensions Applicable types of cables for different Depth 600 mm phases: 3.2 Location of the appliance Phase Min. size cable You can install your freestanding appliance 3x6.0 mm² with cabinets on one or two sides and in the 3 with neutral 5x1.5 mm²... -
Page 9: Product Description
4. PRODUCT DESCRIPTION 4.1 General overview Control panel and hob Air vents for the cooling fan Heating element Lamp Shelf support, removable Cavity embossment Shelf positions 4.2 Hob overview Knobs for the hob Knob for the top oven functions Display Knob for the main oven functions Knob for the main oven temperature Temperature indicator / symbol for the... -
Page 10: Before First Use
5. BEFORE FIRST USE 5.2 Using the sensor fields WARNING! To activate the function press and hold the Refer to Safety chapters. selected symbol on the display for at least 1 second. 5.1 Initial preheating and cleaning 5.3 Setting and changing the time Preheat both empty appliances before the first use and contact with food. -
Page 11: Hob Control Panel
6.1 Hob control panel Use the sensor fields to operate the appliance. The displays, indicators and sounds tell which functions operate. Sensor Function Comment field Heat setting display To show the heat setting. Timer indicators of cooking zones To show for which zone you set the time. Timer display To show the time in minutes. -
Page 12: The Heat Setting
Display Description PowerBoost operates. There is a malfunction. + digit OptiHeat control (3 step Residual heat indicator): continue cooking / keep warm / resid‐ ual heat. Lock / Child safety device operates. Incorrect or too small cookware or no cookware on the cooking zone. Automatic switch off operates. -
Page 13: Automatic Heat Up
To activate the function: touch of the Heat setting The hob deactivates timer to set the time (00 - 99 minutes). When after the indicator of the cooking zone starts to flash slowly the time counts down. 4 hours To see the remaining time: set the cooking 6 - 9 1.5 hour zone with... -
Page 14: Child Safety Device
6.11 Child safety device To activate the function: touch . Touch This function prevents an accidental of the timer to set the time. Cooking operation of the hob. zones display deactivates automatically after 10 seconds. When the time comes to an end, To activate the function: the hob must be the sound operates and 00 flashes. -
Page 15: Power Management Function
mode activates automatically after 10 seconds. For most of the hoods the remote system is originally deactivated. Activate it before you use the function. For more To operate the hood directly on the hood information refer to hood user manual. panel deactivate the automatic mode of the function. -
Page 16: Hob - Hints And Tips
• The function activates when the total electricity load of the cooking zones is exceeded. • The function reduces the power of the other cooking zones. • The heat setting display of the reduced zones changes between two levels. 7. HOB - HINTS AND TIPS WARNING! Refer to Safety chapters. -
Page 17: Noises During Operation
7.3 Noises during operation • rhythmic sound: cookware is detected. 7.4 Öko Timer Eco timer To save energy, the heater of the cooking The noises are normal and do not zone deactivates before the count down timer indicate any malfunction. Cookware sounds. -
Page 18: Hob - Care And Cleaning
Heat setting Use to: Time Hints (min) Boil large quantities of water. PowerBoost is activated. 8. HOB - CARE AND CLEANING 8.2 Cleaning the hob WARNING! • Remove immediately: melted plastic, Refer to Safety chapters. plastic foil, salt, sugar and food with sugar, otherwise, the dirt can cause damage to 8.1 General information the hob. -
Page 19: Activating And Deactivating The Top / Main Oven
1. Turn the knob for the top / main oven functions to select an oven function. Conventional cooking 2. Turn the knob for the temperature to To bake and roast food on one shelf position. select a temperature. SteamBake 3. To deactivate the oven turn the knob for To add humidity during cooking. -
Page 20: Cooling Fan
WARNING! Make sure that the appliance is cold • All accessories have small before you remove the remaining indentations at the top of the right and water from the cavity embossment. left side to increase safety. The indentations are also anti-tip devices. 9.5 Cooling fan •... -
Page 21: Oven - Clock Functions
10. OVEN - CLOCK FUNCTIONS 10.1 Display A. Minute minder indicator B. Time display C. Time of day indicator 10.2 Buttons Button Function Description MINUS To set the time. CLOCK To set a clock function. PLUS To set the time. 10.3 Setting the MINUTE MINDER 10.4 Cancelling the clock functions 1. - Page 22 11.1 Moist fan baking Bread and pizza Food Temperature (°C) Time (min) Shelf position Buns 25 - 35 Frozen pizza 350 g 25 - 35 Cakes in baking tray Food Temperature (°C) Time (min) Shelf position Swiss roll 20 - 30 Brownie 30 - 40 Cakes in tin...
- Page 23 Vegetarian Food Temperature (°C) Time (min) Shelf position Mixed vegetables in pouch 400 g 25 - 35 Omelette 20 - 30 Vegetables on tray 700 g 25 - 35 11.2 SteamBake Bakery Food Temperature Water in the Preheating Time (min) Shelf (°C) cavity em‐...
-
Page 24: Information For Test Institutes
Food Temperature Water in the Preheating Time (min) Shelf (°C) cavity em‐ time (min) posi‐ bossment tion (ml) Rice 15 - 25 Pasta 15 - 25 Meat 15 - 25 Roasting Food Tempera‐ Water in the Preheating Time (min) Shelf ture (°C) cavity em‐... -
Page 25: Oven - Care And Cleaning
Food Function Tempera‐ Time (min) Accesso‐ Shelf po‐ ture (°C) ries sition Fatless sponge cake, 1 tin True fan cooking 25 - 35 Grid (ø 26 cm) on the grid Fatless sponge cake, 1 tin True fan cooking 30 - 40 Grid 1 / 4 (ø... -
Page 26: Catalytic Cleaning
12.2 Catalytic cleaning 3. Set the oven temperature to 250 °C and let the oven operate for 1 hour. 4. When the appliance is cool, clean it with a CAUTION! soft and moist sponge. Do not clean the catalytic surface with oven sprays, soap or other cleaning 12.5 Cleaning the cavity agents. -
Page 27: Removing And Cleaning The Door Glasses - Main Oven
12.8 Removing and cleaning the door glasses - main oven The door glass in your product can be different in type and shape from the example you see in the image. The number of glasses can also be different. 1. Push the door trim at one side to remove Install the shelf supports in the opposite sequence. -
Page 28: The Back Lamp
2. Clean the glass cover. The back lamp 3. Replace the oven lamp with a suitable 300 °C heat-resistant oven lamp. Use the same oven lamp type. The lamp glass cover is at the back of 4. Install the glass cover. the cavity. -
Page 29: Service Data
Problem Possible cause Remedy Automatic Switch Off operates. Deactivate the hob and activate it comes on the hob display. again. The Child Safety Device or the Lock Refer to "Hob - Daily use" chapter. comes on the hob display. function operates. There is no cookware on the zone. -
Page 30: Energy Efficiency
14.3 Product Information Sheet and Product Information according to EU and UK Energy Labelling and Ecodesign Regulations for Oven Supplier's name Model identification CIB6734ACM 948904350 Top oven: 105.6 Energy Efficiency Index Main oven: 95.3 Top oven: A Energy efficiency class Main oven: A Top oven: 0.75 kWh/cycle... -
Page 31: Oven - Energy Saving
Heat source Electricity Top oven: 39 l Volume Main oven: 73 l Type of oven Oven inside Freestanding Cooker Mass 64.6 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance. - Page 32 867364069-A-202024...
