IDTP-16
IDTP-22
GB
Operating Instructions
Industrial Drilling Tapping Machine
JPW Tool Group Hong Kong Limited
98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC
www.jettools.com
Импортёр в РФ: ООО «ИТА Технолоджи»
105082, Москва, Переведеновский пер., д. 17
www.jettools.ru
Made in PRC / Сделано в КНР
50000985T_ 50000990T
2022-09
Advertisement
Table of Contents
Troubleshooting
Related Manuals for Jet IDTP-16
Summary of Contents for Jet IDTP-16
- Page 1 IDTP-16 Industrial Drilling Tapping Machine IDTP-22 Operating Instructions JPW Tool Group Hong Kong Limited 98 Granville Road, Tsimshatsui East, Kowloon, Hong Kong, PRC www.jettools.com Импортёр в РФ: ООО «ИТА Технолоджи» 105082, Москва, Переведеновский пер., д. 17 www.jettools.ru Made in PRC / Сделано в КНР...
-
Page 2: Declaration Of Conformity
Operating Instruction Dear Customer, Many thanks for the confidence you have shown in us with the purchase of your new JET-machine. This manual has been prepared for the owner and operators of IDTP-16/IDTP-22 Industrial Drilling Tapping Machine to promote safety during installation, operation and maintenance procedures. Please read and understand the information contained in these operating instructions and the accompanying documents. -
Page 3: Table Of Contents
General Trouble Shooting ........................18 12. Exploded View & Parts List ........................... 19 12.1 IDTP-16 Assembly Breakdown ......................19 IDTP-16 Parts List for Breakdown ....................20 12.2 IDTP-22 Assembly Breakdown ......................23 IDTP-22 Parts List for Breakdown ....................24 12.3 IDTP-16/22 Accessories Parts List .................... -
Page 4: Warnings
Used makeshift repairs done to the machine. This properly, JET machinery is among the best in not only voids the warranty but also design and safety. However, any machine used renders the machine unsafe. -
Page 5: Safety Instructions For Drill Presses
13. Keep work area clean. Cluttered areas invite 4. Never brush away any chips while the accidents. machine is in operation. All clean up should 14. Remove adjusting keys and wrenches be done when the machine is stopped. before turning machine on. 5. -
Page 6: General Specifications
1. General Specifications IDTP-16 IDTP-22 Drilling Capacity Mild Steel 16mm 32mm Drilling Capacity Mild Steel Chuck Size Keytype B16 1-16mm Keytype B16 1-16mm Spindle Travel 98mm 134mm Distance chuck to Base 500mm 1100mm Distance Chuck to Table (max) 255mm 760mm Table Size Diameter 246×278mm... -
Page 7: Product Features And Terminology
Product Features and Terminology Pulley Cover Main Motor Control Panel Slide Bar Knob Safety guard Column Quill feed levers Column Lock Handle Work Table Crank Handle Base Mounting slots... -
Page 8: Getting To Know Your Machine
It allows more flexibilities in work piece machinery at different angle. Power ON Switch Power OFF Switch Note: Only the work table of IDTP-16 has Emergency Stop Switch tilting function. Drilling/Tapping Selector Indicating lamp of Spindle Reversing... -
Page 9: Transporting The Machine
4. Transporting the Machine The machine will be delivered in a closed crate. For transport use a forklift or hoist. Make sure the machine does not tip or fall off during transport. Danger of tipping due to high gravity center! During handling, the machine shall be lifted only in vertical direction. -
Page 10: Minimum Requirement For Housing The Machine
5.4. Assembling Loose Parts 6.2. Depth Indicator Attach Riser handle to the necessary crankshaft, and use Hex-wrench to tighten/loosen the machine head lock nut. 5.5. Electrical Connection of the Machine Make sure whether the voltage 400V matches the requirement for the machine, prior to connection to power supply. -
Page 11: Machine Adjustment
12. Select proper speed. 13. Begin drilling by using the quill feed lever. In Tapping Mode Note: Only the work table of IDTP-16 has tilting function. To tilt the table, loosen the nut first to adjust the table to desired angle, then lock the table in position. -
Page 12: Adjusting The Headstock Height
7.2. Adjusting the Headstock Height speed chart. 5. Manually push/pull out the motor along the Note: Only IDTP-16 has headstock height motor rods then thread the bolts (J) to be adjusting function. against the motor bracket letting the belt be tensioned. -
Page 13: Tool Installation And Uninstallation
chuck body and slightly hit the arbor onto the 7.5. Tool installation and Uninstallation chuck by rubber hammer. 4. Slide the assembled drill chuck and arbor into spindle taper, and slightly hit them by rubber hammer to fit in. 1. Clean the drill chuck, arbor and spindle taper thoroughly before installation. -
Page 14: The Spindle Shield
7.6. The Spindle Shield 8. Operating Precautions The following operating and safety precautions must be observed in order to avoid harm to the operator or damage to the drill press. 1. Make sure the power voltage is for the machine. Before connecting the plug to socket, it is necessary to check the power spec. -
Page 15: Maintenance
Note: Only eligible and qualified personnel can make electronic Annual Maintenance adjustments Replace the driving belt by using: 450J for IDTP-16, Disconnect machine from power 530J for IDTP-22. supply. Electronic parts are extremely Oils for Lubricating Coolant... - Page 16 lighted display completely before proceeding with any work to prevent any accidents or hazards from occurring. Pay close attention to the electronic circuit board so that they are free from any defects. Never connect the alternating current directly to the output connector (U/V/W) of the speed adjuster.
-
Page 17: General Trouble Shooting
11.2 General Trouble Shooting Trouble Probable Cause Remedy Let the motor cool down, and the overheat Motor overload protector tripped. switch would be reset by itself, then push the start button. Caused by chuck guard adjustment Please refer section 7.6 Spindle does not turn. -
Page 18: Exploded View & Parts List
12. Exploded View & Parts List 12.1 IDTP-16 Assembly Breakdown... -
Page 19: Idtp-16 Parts List For Breakdown
IDTP-16 Parts List for Breakdown (1/3) Index Part Description Size Qty. 1 ... IDTP16-001 ......Base ......................1 2 ... IDTP16-002 ......Cross Pan Head Screw ..........M4×10 ...... 4 3 ... IDTP16-003 ......Cover ......................1 4 ... IDTP16-004 ......Column ..................... 1 5 ... - Page 20 91 ..IDTP16-091 ......Cross Pan Head Screw ..........M4×16 ...... 2 92 ..IDTP16-092 ......Set screw ..............M6×8 ......1 93 ..JET-92 ........Logo ................ JET-92 ....... 1 94 ..IDTP16-094 ......Foam Pads ....................6 95 ..
- Page 21 IDTP-16 Parts List for Breakdown (3/3) Index Part Description Size Qty. 102 ..IDTP16-102 ......Locking Button ..................1 103 ..IDTP16-103 ......Hinge ......................1 104 ..IDTP16-104 ......Plate ......................1 105 ..IDTP16-105 ......Cross Pan Head Screw ..........M4×8 ......4 106 ..
-
Page 22: Idtp-22 Assembly Breakdown
12.2 IDTP-22 Assembly Breakdown... -
Page 23: Idtp-22 Parts List For Breakdown
IDTP-22 Parts List for Breakdown (1/3) Index Part Description Size Qty. 1 ... IDTP22-001 ......Base ......................1 2 ... IDTP22-002 ......Column support ..................1 3 ... IDTP22-003 ......Column ..................... 1 4 ... IDTP22-004 ......Rack......................1 5 ... - Page 24 76 ..IDTP22-076 ......Cross Pan Head Screw ..........M4×16 ...... 1 77 ..IDTP22-077 ......Socket Set Screw ............. M6×8 ......4 78 ..JET-113 ........JET Logo ..............JET-113 ..... 1 79 ..IDTP22-079 ......Foam Pads ....................6 80 ..
- Page 25 Index Part Description Size Qty. 103 ..IDTP22-103 ......Select Switch ............ZH-A ......1 104 ..IDTP22-104 ......Cross Pan Head Screw ..........M5×40 ...... 1 105 ..IDTP22-105 ......Block ......................1 106 ..TS-1504041 ......Hex Socket Cap Screw ..........M8×20 ...... 2 107 ..
-
Page 26: Idtp-16/22 Accessories Parts List
Description Size Qty. 1 ... IDTP16-024 ......Arbor (for IDTP-16) ..........MT2/B16 ....1 ..IDTP22-012 ......Arbor (for IDTP-22) ..........MT3/B16 ....1 2 ... IDTP16-023 ......Nut ......................1 3 ... IDTP16-022 ......Keytype Chuck ............B16 ......1 4 ... -
Page 27: Wiring Diagrams
13. Wiring Diagrams IDTP-16/22 ………………. ~3L/PE, 400V, 50Hz... -
Page 28: Electrical Parts List
Ui:690V Ith:20A Transformer In:400V Out:24V Plug HTN715 plug HTCN CE 415V 16A 550W , 400V , 50Hz , 3PH , 6P , IDTP-16-6P 1.8A , 910RPM Motor 750W , 400V , 50Hz , 3PH , 6P , IDTP-22-6P 2.6A , 910RPM...
