Summary of Contents for Vivreau Vi Tap

  • Page 1 Owner’s Manual Vi Tap Dispensing System...
  • Page 2: Table Of Contents

    This manual and all material provided with your system should be retained in a convenient location for future reference. Contact Vivreau if you have any questions regarding the information contained in this manual. © 2020 Vivreau Water Systems All rights reserved.
  • Page 3: Safety Precautions

    • The use of spare parts and accessories not • Keep safety labels in good condition and recommended by Vivreau may cause damage replace missing or damaged items. and/or injuries. • Learn how to operate the unit and how to use •...
  • Page 4: General Information

    This manual is solely for the use of personnel Vivreau Vi tap 2, Vi Tap 2H, Vi Tap 1, and Vi Tap trained in the operation of the ViVreau Vi Tap 1H Dispensing Systems.
  • Page 5: Technical Specifications

    Technical Specifications GENERAL DESCRIPTION The system is made up of several components The Vi tap is a self-service water dispensing system (depending on model) that will fit under a standard designed for under-counter installation with the base-cabinet section that is 30” wide (min.) dispenser head mounted to the countertop directly above the unit.
  • Page 6 Cooler/Carbonator Specifications Specification Description ViTap-2 ViTap-2H ViTap-1 ViTap-1H ü ü Width 15” 8.25” 8.25” ü ü Height 20” 19” 19” ü ü Depth 18.5” 14" 14” ü ü Weight 39.6 lb. 44.6 lb 44.6 lb ü ü ü ü Voltage 110/120 VAC/60 Hz ü...
  • Page 7: Pre-Installation Requirements

    Below are the services required to be in place prior selected based on available space. to the installation of the Vivreau ViTAP Dispensing System. If you have any questions regarding these NOTE: If connecting to a bulk or existing CO...
  • Page 8 LOCATION DISPENSING HEAD A suitable location should be chosen within 40” of The Dispensing Head with Integral Drip Tray is the electrical and water supply connections. installed into a countertop directly over the Chiller/ Carbonator and Boiler (if equipped) using the Installation Clearance for Chiller Unit supplied template.
  • Page 9: Operating Instructions

    Cylinder. CALL SERVICE: If there is a problem, a Red LED will illuminate and the unit will beep. Please contact Vivreau Service Toll-Free at 877-999- 1044 immediately. EMPTY DRIP TRAY: (Not Activated on this Unit): When the Drip Tray Container is FULL, a Red LED will illuminate and the unit will beep;...
  • Page 10: After Daily Use

    DISPENSING IMPORTANT ________________________ Ensure the ViTAP Dispensing System and IMPORTANT ________________________ surrounding areas are kept clean and sanitary Before operating the ViTap Dispensing System, at all times. make sure the Water Supply Valve is open and the unit is plugged in. FOR UNITS WITH Hot Water (if supplied) OPTIONAL HOT WATER BOILER...
  • Page 11: Eco Mode

    ECO MODE All Boilers incorporate an ECO Mode function. To Enable ECO Mode: Press the ECO Mode Button located below the Ready indicator so that the leaf symbol illuminates green. ECO Mode This mode saves energy by minimizing the energy wasted during unit down-time.
  • Page 12: Maintenance

    PROCEDURE Keep the unit at peak efficiency by performing all scheduled maintenance procedures that are WARNING Before performing recommended by Vivreau. Proper maintenance will maintenance service procedure that allow the best performance and a longer working involves electrical connection or disconnection life.
  • Page 13: Stainless Steel Care

    The ViTAP Dispensing System should be cleaned once a day. CAUTION Never use steel wool, which will Vivreau recommends using disinfectant spray or a leave behind particles that rust. sanitizing wipe for cleaning. If the Dispensing Head becomes soiled with...
  • Page 14: Cleaning Schedule

    CLEANING SCHEDULE Cleaning Schedule Component Task Frequency Personnel Dispensing Head/Nozzle Cleaning & Sanitizing Daily End-User Drip Tray Draining, Cleaning Daily End-User Fill Level Weekly End-User Cylinder Replace As Needed Chiller Condenser Grille Cleaning, Degreasing Weekly End-User Chiller Exterior Cleaning Weekly End-User Authorized Service Water Filter...
  • Page 15: Exterior Cleaning

    CLEANING THE COOLING SYSTEM CHANGING THE CO CYLINDER CONDENSER GRILLE WARNING Wear protective gloves and The Cooling System Condenser Grille is located on safety glasses when changing CO Cylinders. the front side of the Cooler/Carbonator. WARNING is a colorless, odorless gas. A danger of suffocation exists when in high concentration.
  • Page 16 Loosen the connection to the Cylinder with the wrench provided and remove the Regulator from the Cylinder. WARNING line pressurized. Pressure will be released while performing this procedure. Handle carefully. Checking for Leaks Refer to your local CO supplier for complete handling and safety instructions.
  • Page 17: Electric Shock

    DO NOT USE sign on the sanitization! Dispensing Head. Bacteria and germs can form if the water Contact Vivreau Service Toll-Free at 877-999-1044. dispenser has been disconnected from the power supply for longer than 72 hours. After a longer idle period or a power failure,...
  • Page 18: Troubleshooting

    Power Switch is ON. WARM WATER (Still and Sparkling) Make sure Chiller/Carbonator is plugged in and operating. Make sure the Condenser Grille is not clogged or blocked. If these Troubleshooting procedures do not resolve the issue, contact Vivreau Service Toll- Free at 877-999-1044.
  • Page 19: Contact Info

    Contact Info Phone Number: +1 877 999 1044 Email: InfoUSA@vivreau.com InfoCanada@vivreau.com Or visit vivreauwater.com...
