Vivreau V3-202 Owner's Manual

Dispensing system
Hide thumbs Also See for V3-202:

Advertisement

Quick Links

Freshly-drawn
Traditionally Served
Environmentally Friendly
Specially Branded
Owner's Manual
V3 Dispensing System
MODEL
V3-202
Model V3-202
170205

Advertisement

loading
Need help?

Need help?

Do you have a question about the V3-202 and is the answer not in the manual?

Questions and answers

Related Manuals for Vivreau V3-202

Summary of Contents for Vivreau V3-202

  • Page 1 Freshly-drawn Traditionally Served Environmentally Friendly Specially Branded Owner’s Manual V3 Dispensing System MODEL V3-202 Model V3-202 170205...
  • Page 2 This manual and all material provided with your system should be retained in a convenient location for future reference. Contact Vivreau if you have any questions regarding the information contained in this manual. © 2017 Vivreau USA All rights reserved.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SAFETY PRECAUTIONS ............5 GENERAL INFORMATION ............7 TECHNICAL SPECIFICATIONS ..........9 PRE-INSTALLATION REQUIREMENTS ........11 OPERATING INSTRUCTIONS ..........13 MAINTENANCE ................17 TROUBLESHOOTING ...............23 V3-202 Dispensing System Owner’s Manual...
  • Page 4 V3-202 Dispensing System Owner’s Manual...

  • Page 5: Safety Precautions

    Save these instructions. • service this unit. WARNING ALL WIRING AND PLUMBING MUST CONFORM TO NATIONAL AND LOCAL CODES. FAILURE TO COMPLY COULD RESULT IN SERIOUS INJURY, DEATH OR EQUIPMENT DAMAGE. V3-202 Dispensing System Owner’s Manual 5...
  • Page 6 Section 1 Safety Precautions V3-202 Dispensing System Owner’s Manual...

  • Page 7: General Information

    This manual is solely for the use of personnel servicing of the Vivreau V3-202 Dispensing trained in the operation of the Vivreau V3-202 System. Dispensing System only. • Information contained in this manual will help prevent risks to health and safety, and the risk of economic losses.
  • Page 8 Section 2 General Information V3-202 Dispensing System Owner’s Manual...

  • Page 9: Technical Specifications

    Section 3 Technical Specifications TECHNICAL SPECIFICATIONS GENERAL DESCRIPTION The Vivreau V3-202 Dispensing System is The system has been designed for operation at designed to provide Chilled Still and Sparkling ambient temperatures up to 90ºF . Water on demand. Dispensing Specifications...
  • Page 10 Section 3 Technical Specifications Cooler/Carbonator Specifications Description Specification V3-202 ü Width 23.4” ü Height 33.4” ü Depth 23.2” ü Weight Empty 164 lbs. ü Weight Operational 201 lbs. ü Voltage 110/120 VAC/60 Hz ü Amperage 10 V3-202 Dispensing System Owner’s Manual...

  • Page 11: Pre-Installation Requirements

    PRE-INSTALLATION REQUIREMENTS ELECTRICAL OUTLET INTRODUCTION Model V3-202 The Vivreau V3-202 Dispensing System is an under- counter Water Dispensing System. Chilled water (1) 15 Amp Electrical Receptacle (NEMA 5-15R) is available from Dispensers that provide Still 120V, 60 Hz (11 Amps) and Carbonated Water from individual faucets.
  • Page 12 Section 4 Pre-Installation Requirements 12 V3-202 Dispensing System Owner’s Manual...

  • Page 13: Operating Instructions

    Section 5 Operation OPERATING INSTRUCTIONS The V3-202 Dispensing System is designed for LED DISPLAY PANEL ease of use. The LED Display Panel indicates the status of the unit and is located on the front panel of the IMPORTANT _________________________ Chiller/Carbonator.
  • Page 14 Bottle at a time. System, make sure the Water Supply Valve is open and the unit is plugged in. Vivreau Bottles should be filled to the line in the neck just below the Cap. Place appropriate container on Drip Tray beneath Dispensing Head.
  • Page 15 Section 5 Operation Empty Drip Tray Container and wipe clean with DO NOT empty into V3-202 Dispensing System Sanitizing Solution. Drip Tray. New Bottles MUST be sanitized before first use. ALWAYS inspect Bottles for damage. Any Bottles showing signs of damage or cracks should be discarded and recycled appropriately.
  • Page 16 Water is filtered on demand using advanced micro-filtration eliminating 99.99% of bacteria, contaminants, additives, such as chlorine, odors and other impurities while allowing the natural minerals to remain for a clean, clear taste. 16 V3-202 Dispensing System Owner’s Manual...

  • Page 17: Maintenance

    General check of the unit • Identify and replace worn parts IMPORTANT _________________________ Record all yearly inspections. IMPORTANT _________________________ Contact the factory, the factory representative or an authorized service agent to perform maintenance and repairs. V3-202 Dispensing System Owner’s Manual...
  • Page 18 DAILY CLEANING CAUTION Never use any metal tools. Scrapers, files, wire brushes or scouring pads (except for The Vivreau V3-202 Dispensing System should stainless steel scouring pads) will mar the surface. be cleaned once a day. Vivreau recommends using disinfectant spray CAUTION Never use steel wool, which will or a sanitizing wipe for cleaning.
  • Page 19 Replacement Twice Yearly Dealer CLEANING THE DISPENSING NOZZLES CLEANING THE DRIP TRAY The Vivreau V3-202 Dispensing System is Lift Drip Tray Lid from Unit. equipped with removable Nozzles for ease of cleaning and sanitizing. IMPORTANT _________________________ The Nozzles must be cleaned separately in Sanitizing Solution.
  • Page 20 Gauge will be in the Red Zone. WARNING Wear protective gloves and safety glasses when changing CO Cylinders. Regulator Gauge Close the Valve on top of the empty Cylinder. Regulator Gauge Replace Cylinder if needed. Close Empty Cylinder Valve 20 V3-202 Dispensing System Owner’s Manual...
  • Page 21 Handle carefully. Checking for Leaks STANDING IDLE Before Long Idle Periods Disconnect High-Pressure Hose If the V3-202 Dispensing System will be idle for Place the Regulator within safe reach. more than 3 days: Unplug the Unit. SECURE CYLINDER Close the Water Supply Valve.
  • Page 22 Water Supply Valve. Clean up the leaked water from the area. WARNING Danger to health from a lack of Indicate the V3-202 Dispensing System is out sanitization! of service by hanging a DO NOT USE sign on Bacteria and germs can form if the water the Dispensing Head.

  • Page 23: Troubleshooting

    WARM WATER (Still and Sparkling) Make sure Chiller/Carbonator is plugged in and operating. Make sure the Condenser Grille is not clogged or blocked. If these Troubleshooting procedures do not resolve the issue, contact Vivreau Service Toll-Free at 877-999-1044. V3-202 Dispensing System Owner’s Manual...
  • Page 24 Section 7 Troubleshooting NOTES 24 V3-202 Dispensing System Owner’s Manual...
  • Page 25 Section 7 Troubleshooting NOTES V3-202 Dispensing System Owner’s Manual...
  • Page 26 Section 7 Troubleshooting NOTES 26 V3-202 Dispensing System Owner’s Manual...
  • Page 27 V3-202 Dispensing System Owner’s Manual...
  • Page 28 +1 877 999 1044 email: infocanada@vivreau.com email: infousa@vivreau.com A S I A N PA C I F I C A F R I C A VIVREAU South Africa VIVREAU Australia VIVREAU New Zealand +27 21 671 6306 Tel: +61 3 9590 0886 Tel.
