Owner's Manual

V3 Dispensing System

MODEL

V3-205

170501

Freshly-drawn

Traditionally Served

Environmentally Friendly

Specially Branded

Model V3-205

Table of Contents

Need help?

Do you have a question about the V3-205-I and is the answer not in the manual?

Questions and answers

Summary of Contents for Vivreau V3-205-I

Page 1 Freshly-drawn Traditionally Served Environmentally Friendly Specially Branded Owner’s Manual V3 Dispensing System MODEL V3-205 Model V3-205 170501...
Page 2 This manual and all material provided with your system should be retained in a convenient location for future reference. Contact Vivreau if you have any questions regarding the information contained in this manual. © 2017 Vivreau USA All rights reserved.
Page 3: Table Of Contents
TABLE OF CONTENTS SAFETY PRECAUTIONS ............5 GENERAL INFORMATION ............7 TECHNICAL SPECIFICATIONS ..........9 PRE-INSTALLATION REQUIREMENTS ........11 OPERATING INSTRUCTIONS ..........13 MAINTENANCE ................17 TROUBLESHOOTING ...............23 V3-205 Dispensing System Owner’s Manual...
Page 4 V3-205 Dispensing System Owner’s Manual...
Page 5: Safety Precautions
Learn how to operate the unit and how to use • The use of spare parts and accessories the controls properly. not recommended by Vivreau may cause Do not let anyone operate the unit without • damage and/or injuries. proper training. This unit is intended for use Do not operate any unit with damaged •...
Page 6 Section 1 Safety Precautions V3-205 Dispensing System Owner’s Manual...
Page 7: General Information
This manual is solely for the use of personnel the Vivreau V3-205 Dispensing System. trained in the operation of the Vivreau V3-205 Dispensing System only. • Information contained in this manual will help prevent risks to health and safety, and the risk of economic losses.
Page 8 Section 2 General Information V3-205 Dispensing System Owner’s Manual...
Page 9: Technical Specifications
This unit can be connected to a bulk CO system, in lieu of a CO Cylinder and regulator. The Vivreau V3-205 Dispensing System is designed to provide Chilled Still and Sparkling This system is made up of several components Water on demand.
Page 10 Section 3 Technical Specifications Dispenser Head Specifications Description Requirements Height 19.3” Distance Nozzle to Drip Tray 12.3” Weight 7.4 lbs. Cooler/Carbonator Specifications Description Specification 14.7” Width Height 18.5” Depth 17.0” Weight 72.6 lbs. Voltage 110/120 VAC/60 Hz Amperage NA = Not Available 10 V3-205 Dispensing System Owner’s Manual...
Page 11: Pre-Installation Requirements
Carbonator. PRE-INSTALLATION " Below are the services required to be in place prior to the installation of the Vivreau V3-205 Dispensing System. If you have any questions regarding these or other services, please contact Vivreau Service Toll-Free at 877-999-1044. WATER SUPPLY One (1) potable 1/2”...
Page 12 All vents must open to fresh air 11" in a free and unobstructed area. Front Ventilation Cut-out detail for the VIVREAU grille, shown in Showing ventilation grilles cut in a standard a 23.5" (24") wide door door panel Side Ventilation Ventilation grilles cut in the side of a standard 24"...
Page 13: Operating Instructions
Bottles of up to one (1) liter, one Bottle at a time. Pull DOWN on Blue Dispenser Handle. Push Vivreau Bottles should be filled to the line in the Dispenser Handle UP when full. neck just below the Cap.
Page 14 CALL SERVICE: If there is a problem, a Red LED System clean and in hygienic condition. will illuminate and the unit will beep. Please contact Vivreau Service Toll-Free at 877-999- 1044 immediately. EMPTY DRIP TRAY (Not Activated on this unit): When the Drip Tray Container is FULL, a Red LED will illuminate and the unit will beep;...
Page 15 ALWAYS use Vivreau Storage and Dishwasher ALWAYS place Bottles upright in Blue Storage Racks. Racks. DO NOT empty into Vivreau V3-205 Dispensing Storage Racks can be stacked. System Drip Tray. ALWAYS place plastic film over the top crate to New Bottles MUST be sanitized before first use.
Page 16 Section 5 Operation 16 V3-205 Dispensing System Owner’s Manual...
Page 17: Maintenance
Section 6 Maintenance MAINTENANCE MAINTENANCE RECOMMENDATIONS ELECTRICAL LOCKOUT/TAGOUT PROCEDURE Keep the unit at peak efficiency by performing all scheduled maintenance procedures that are WARNING Before performing any service recommended by the manufacturer. Proper that involves electrical connection maintenance will allow the best performance disconnection and/or exposure to electrical and a longer working life.
Page 18 DAILY CLEANING CAUTION Never use any metal tools. Scrapers, files, wire brushes or scouring pads (except for The Vivreau V3-205 Dispensing System should stainless steel scouring pads) will mar the surface. be cleaned once a day. Vivreau recommends using disinfectant spray CAUTION Never use steel wool, which will or a sanitizing wipe for cleaning.
Page 19 Replacement Twice Yearly Dealer CLEANING THE DISPENSER NOZZLES CLEANING THE DRIP TRAY The Vivreau V3-205 Dispensing System is Lift Drip Tray Lid from unit. equipped with removable Nozzles for ease of cleaning and sanitizing. IMPORTANT _________________________ The Nozzles must be cleaned separately in Sanitizing Solution.
Page 20 Section 6 Maintenance INSPECTING THE CO CYLINDER EXTERIOR CLEANING Open the Front Door and inspect the CO Wipe all surfaces with a soft cloth and non- Regulator Gauge. abrasive cleaner. Make sure Cylinder Valve is open. IMPORTANT _________________________ If the CO Cylinder is nearly empty, the Needle Never use abrasive cleaners to clean the equipment.
Page 21 To reset the unit, unplug the Power Cord and plug it back in. STANDING IDLE Before Long Idle Periods If the Vivreau V3-205 Dispensing System will be idle for more than 3 days: Unplug the unit. Close the Water Supply Valve.
Page 22 Water Supply Valve. Clean the following areas with antibacterial Clean up the leaked water from the area. cloths and Sanitizing Spray: Indicate the Vivreau V3-205 Dispensing System • Dispensing Nozzle is out of service by hanging a DO NOT USE •...
Page 23: Troubleshooting
CALL SERVICE: Unplug unit and check still water. If still water is not working, check Water Block and Water Supply Valve. Plug in unit. If Service Light returns, please contact Vivreau Service Toll- Free at 877-999-1044. EMPTY DRIP TRAY (Not Activated on this unit): Empty the Drip Tray Container.
Page 24 Section 7 Troubleshooting NOTES 24 V3-205 Dispensing System Owner’s Manual...
Page 25 Section 7 Troubleshooting NOTES V3-205 Dispensing System Owner’s Manual...
Page 26 Section 7 Troubleshooting NOTES 26 V3-205 Dispensing System Owner’s Manual...
Page 27 V3-205 Dispensing System Owner’s Manual...
Page 28 +1 877 999 1044 email: infocanada@vivreau.com email: infousa@vivreau.com A S I A N PA C I F I C A F R I C A VIVREAU South Africa VIVREAU Australia VIVREAU New Zealand +27 21 671 6306 Tel: +61 3 9590 0886 Tel.
