User's Manual of IGS-5225 series
L2+ Multi-port Full Gigabit
Industrial Managed Switch
IGS-5225 Switch Series
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IGS-5225 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Planet IGS-5225 Series

Summary of Contents for Planet IGS-5225 Series

  • Page 1 User’s Manual of IGS-5225 series L2+ Multi-port Full Gigabit Industrial Managed Switch IGS-5225 Switch Series...
  • Page 2 Information in this User's Manual is subject to change without notice and does not represent a commitment on the part of PLANET. PLANET assumes no responsibility for any inaccuracies that may be contained in this User's Manual. PLANET makes no commitment to update or keep current the information in this User's Manual, and reserves the right to make improvements to this User's Manual and/or to the products described in this User's Manual, at any time without notice.
  • Page 3 User’s Manual of IGS-5225 series Revision User's Manual of PLANET Industrial L2+ Multi-port Full Gigabit Industrial Managed Switch For Models: ■ IGS-5225-8P2T4Sv2 ■ IGS-5225-8P2T2Sv4 ■ IGS-5225-8P4Sv5 ■ IGS-5225-8P4S-12V ■ IGS-5225-4UP1T2Sv5 ■ IGS-5225-4P2Sv2 ■ IGS-5225-4T2Sv3 ■ IGS-5225-4UP1T2S-12V REVISION: 2.6 (Jan. 2025 )

  • Page 4: Table Of Contents

    3.3.2 Remote Telnet ..............................85 3.4 Web Management ............................. 86 3.5 SNMP-based Network Management ....................... 87 3.6 PLANET Smart Discovery Utility ........................88 4. WEB CONFIGURATION ...................... 90 4.1 Logging in to the Industrial Managed Switch ....................91 4.1.1 Main Web page ..............................94 4.2 System ................................
  • Page 5 User’s Manual of IGS-5225 series 4.2.1.2 IP Configuration ............................98 4.2.1.3 IP Status ..............................100 4.2.1.4 ARP ................................. 101 4.2.1.5 Users Configuration ..........................102 4.2.1.6 Privilege Levels ............................105 4.2.1.7 NTP Configuration ........................... 107 4.2.1.8 Time Configuration ..........................108 4.2.1.9 UPnP ............................... 111 4.2.1.10 CPU Load ..............................
  • Page 6 User’s Manual of IGS-5225 series 4.2.4.4 DHCPv6 Relay Statistics ......................... 152 4.2.5 DHCP server ..............................153 4.2.5.1 Mode ............................... 153 4.2.5.2 Excluded IP ............................. 154 4.2.5.3 Pool ................................. 155 4.2.5.4 Statistics ..............................156 4.2.5.5 Binding ..............................158 4.2.5.6 Declined IP .............................. 159 4.2.5.7 Detail Statistics ............................
  • Page 7 User’s Manual of IGS-5225 series 4.3.4.1 Port to Group Configuration ........................202 4.3.4.2 VLAN Translation Mappings ........................203 4.3.4.3 VLAN setting example: ..........................204 4.3.4.3.1 Two Separate 802.1Q VLANs ....................... 204 4.3.4.3.2 VLAN Trunking between two 802.1Q aware switches ..............207 4.3.4.3.3 Port Isolate ............................
  • Page 8 User’s Manual of IGS-5225 series 4.3.11 MLD Snooping ............................... 255 4.3.11.1 MLD Snooping Configuration ......................... 255 4.3.11.2 MLD Snooping VLAN Configuration ...................... 256 4.3.11.3 MLD Snooping Port Group Filtering ....................... 258 4.3.11.4 MLD Snooping Status ..........................259 4.3.11.5 MLD Group Information ......................... 260 4.3.11.6 MLDv2 Information ..........................
  • Page 9 User’s Manual of IGS-5225 series 4.3.18.5 Status ..............................313 4.3.19 sFlow (Only applies to switches installed with firmware after v1.2103bxxxxxx) ........315 4.3.19.1 sFlow Configuration ..........................315 4.3.19.2 sFlow Statistics ............................317 4.3.20 PTP ................................. 319 4.3.20.1 PTP Configuration ..........................320 4.3.20.2 PTP Status ............................
  • Page 10 User’s Manual of IGS-5225 series 4.5.2.3 TACACS+ ..............................371 4.5.2.4 RADIUS Overview ........................... 373 4.5.2.5 RADIUS Details ............................374 4.5.3 Port Authentication ............................380 4.5.3.1 Network Access Server Configuration ..................... 380 4.5.3.2 Network Access Overview ........................384 4.5.3.3 Network Access Statistics ........................385 4.5.4 Port Security ..............................
  • Page 11 User’s Manual of IGS-5225 series 4.6.5 Schedule................................448 4.6.6 PoE Alive Check Configuration ........................451 4.6.7 Port Power Consumption[graphic 1~8] ......................453 4.6.8 LLDP PoE Neighbors............................454 4.7 Ring .................................. 455 4.7.1 Ring Wizard ..............................455 4.7.2 ERPS ................................. 459 4.7.2.1 ERPS-- ERPS Configuration ........................
  • Page 12 User’s Manual of IGS-5225 series 5. SWITCH OPERATION ....................... 498 5.1 Address Table ..............................498 5.2 Learning ................................498 5.3 Forwarding & Filtering ........................... 498 5.4 Store-and-Forward ............................498 5.5 Auto-Negotiation ............................. 498 6. TROUBLESHOOTING ....................... 499 APPENDIX A: Networking Connection ................500 A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T ..............

  • Page 13: Introduction

    User’s Manual of IGS-5225 series 1. INTRODUCTION The descriptions of PLANET L2+ Industrial Managed Switch Series, such as IGS-5225-8P2T4S and IGS-5225-4T2S, are as follows: Industrial L2+ 8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/1000T + 2-Port 100/1000X SFP IGS-5225-8P2T4S + 2-Port 100/1000/2500X SFP Managed Ethernet Switch Industrial L2+ 8-Port 10/100/1000T 802.3at PoE + 2-Port 10/100/100T + 2-Port 100/1G/2.5G SFP...

  • Page 14: Product Description

    Advanced Manageable PoE Solution for Hardened Environment PLANET IGS-5225 L2+ Industrial Managed Switch series is specially designed to build a full Gigabit network infrastructure to transmit reliable and high-speed data in heavy industrial demanding environments and forward data to remote network through fiber optic cabling.
  • Page 15 TLSv1.2 protocols to provide strong protection against advanced threats. Served as a key point to transmit data to customer's critical equipment in a business network, the cybersecurity feature of the IGS-5225 series protects the switch management and enhances the security of the mission-critical network without any extra deployment cost and effort.
  • Page 16 User’s Manual of IGS-5225 series Digital Input and Digital Output for External Alarm The Industrial Managed Switch supports Digital Input and Digital Output on its upper panel. The external alarm enables users to use Digital Input to detect external device’s status (such as door intrusion detector), and send event alarm to the administrators.
  • Page 17 User’s Manual of IGS-5225 series Intelligent Powered Device Alive Check The IGS-5225 PoE series can be configured to monitor connected PD (powered device) status in real-time via ping action. Once the PD stops working and responding, the IGS-5225 PoE series will recycle the PoE port power and bring the PD back to work.
  • Page 18 User’s Manual of IGS-5225 series IPv4 and IPv6 VLAN Routing for Secure and Flexible Management The Industrial Managed Switch offers IPv4/IPv6 VLAN routing feature which allows to crossover different VLANs and different IP addresses for the purpose of having a highly-secured, flexible management and simpler networking application.
  • Page 19 User’s Manual of IGS-5225 series 1588 Precision Time Protocol for Industrial Computing Networks The Industrial Managed Switch is intended for telecom and carrier Ethernet applications, supporting MEF service delivery and timing over packet solutions for the IEEE 1588 Precision Time Protocol and synchronous Ethernet.

  • Page 20: How To Use This Manual

    User’s Manual of IGS-5225 series 1.3 How to Use This Manual This User’s Manual is structured as follows: Section 2, INSTALLATION The section explains the functions of the Industrial Managed Switch and how to physically install the Industrial Managed Switch.

  • Page 21: Product Features

    User’s Manual of IGS-5225 series 1.4 Product Features  Physical Port  10/100/1000BASE-T RJ45 copper  100/1000BASE-X SFP ports for SFP type auto detection  100/1000/2500BASE-X SFP ports (For IGS-5225-8P2T4S/IGS-5225-8P2T2S/IGS-5225-8P4S/ IGS-5225-8P4S- 12V/IGS-5225-4UP1T2S/IGS-5225-4UP1T2S-12V/IGS-5225-4T2S/IGS-5225-4P2S)  RJ45 type Console interface for basic management and setup ...
  • Page 22 User’s Manual of IGS-5225 series PoE Management   PoE management features  Total PoE power budget control  Per port PoE function enable/disable  PoE admin-mode control  PoE port power feeding priority  Per PoE port power limit ...
  • Page 23  Link Layer Discovery Protocol (LLDP) and LLDP-MED  Provides ONVIF for co-operating with PLANET video IP surveillances  Layer 3 IP Routing Features ...
  • Page 24 User’s Manual of IGS-5225 series  Multicast  Supports IPv4 IGMP snooping v1, v2 and v3  Supports IPv6 MLD snooping v1 and v2  Querier mode support  IPv4 IGMP snooping port filtering  IPv6 MLD snooping port filtering ...
  • Page 25 Cable diagnostic technology provides the mechanism to detect and report potential cabling issues  SFP-DDM (Digital Diagnostic Monitor)  SMTP, Syslog and SNMP trap remote alarm  System Log  SFP-DDM (Digital Diagnostic Monitor)  PLANET Smart Discovery Utility for deployment management  PLANET NMS/NMSViewerPro and CloudViewerPro apps for deployment management...

  • Page 26: Product Specifications

    User’s Manual of IGS-5225 series 1.5 Product Specifications IGS-5225-8P2T2S / IGS-5225-8P2T4S / IGS-5225-8P4S / IGS-5225-8P4S-12V Product IGS-5225-8P2T2S IGS-5225-8P2T4S IGS-5225-8P4S IGS-5225-8P4S-12V Hardware Specifications 10/100/1000BASE-T 10/100/1000BASE-T 10/100/1000BASE-T 10/100/1000BASE-T Copper Ports RJ45 auto-MDI/MDI-X RJ45 auto-MDI/MDI-X RJ45 RJ45 ports ports auto-MDI/MDI-X ports auto-MDI/MDI-X ports...
  • Page 27 User’s Manual of IGS-5225 series Weight 1103g 1100g 1104g 1128g Installation DIN-rail kit and wall-mount kit Power Requirements Dual 48~56V DC (>52V DC for PoE+ output recommended) Dual 12~54V DC Without Max. 6.48 Max. 12.2 Max. 6.48 Max. 7.28 watts/22.11BTU watts/41.63BTU...
  • Page 28 User’s Manual of IGS-5225 series - Per port 48V~51V DC (depending on the power supply), max. 15.4 watts IEEE 802.3at Standard - Per port 52V~54V DC (depending on the power supply), max. 36 watts Power Pin Assignment 1/2(+), 3/6(-) 60W maximum (DC 12V...
  • Page 29 User’s Manual of IGS-5225 series TX/RX/both Port Mirroring Many-to-1 monitor Up to 5 sessions IEEE 802.1Q tag-based VLAN IEEE 802.1ad Q-in-Q tunneling Private VLAN Edge (PVE) MAC-based VLAN VLAN Protocol-based VLAN Voice VLAN MVR (Multicast VLAN Registration) GVRP Up to 4K VLAN groups, out of 4095 VLAN IDs IEEE 802.3ad LACP/static trunk...
  • Page 30 User’s Manual of IGS-5225 series - MAC Address - IP Address - Ethertype - Protocol Type - VLAN ID - DSCP - 802.1p Priority Up to 256 entries Port security IP source guard, up to 256 entries Dynamic ARP inspection, up to 1K entries...
  • Page 31 User’s Manual of IGS-5225 series IEEE 802.1X PAE LLDP MIB MAU-MIB Power over Ethernet MIB Standards Conformance Regulatory Compliance FCC Part 15 Class A, CE IEC60068-2-32 (free fall) Stability Testing IEC60068-2-27 (shock) IEC60068-2-6 (vibration) IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX/100BASE-FX IEEE 802.3z Gigabit SX/LX...
  • Page 32 User’s Manual of IGS-5225 series IGS-5225-4UP1T2S/IGS-5225-4UP1T2S-12V/IGS-5225-4P2S/IGS-5225-4T2S IGS-5225- IGS-5225- IGS-5225- IGS-5225- Product 4UP1T2S-12V 4UP1T2S 4P2S 4T2S Hardware Specifications 5 10/100/1000BASE-T RJ45 auto-MDI/MDI- 4 10/100/1000BASE-T RJ45 auto-MDI/MDI-X Copper Ports X ports ports 2 1000/2500BASE-X SFP ports (Port 6 and 2 1000/2500BASE-X SFP ports (Port 5 and...
  • Page 33 User’s Manual of IGS-5225 series DC for PoE+ and for PoE+ output 24V AC PoE++ output recommended) recommended) Max. 7.6 Max. 8.64 Max. 5.6 watts/19BTU Max. 6.3 watts/25.9BTU(Power watts/29BTU (Power on without any watts/21.6BTU on without any (Power on without...
  • Page 34 User’s Manual of IGS-5225 series Per port 54V DC IEEE 802.3af Standard  802.3bt mode, Ports 1 to 4: maximum - Per port 48V~51V 95 watts DC, max. 15.4 watts PoE Power Output  End-span mode: maximum 36 watts IEEE 802.3at Standard...
  • Page 35 User’s Manual of IGS-5225 series Enhanced PoE Mode Standard/Legacy/Force Per port remote PD IP address 4 actions PoE Device Live - None - PD reboot Detection - PR reboot and alarm - Alarm PoE Power Recycling Daily or predefined schedule...
  • Page 36 User’s Manual of IGS-5225 series Ipv4 IGMP (v1/v2 /v3) Snooping IGMP Snooping Ipv4 IGMP Querier mode support Up to 255 multicast Groups Ipv6 MLD (v1/v2) Snooping MLD Snooping Ipv6 MLD Querier mode support Up to 255 multicast Groups Supports ERPS, and complies with ITU-T G.8032 Recovery time <...
  • Page 37 User’s Manual of IGS-5225 series Secure Management SSHv2,TLSv1.2, SNMP v3 Interfaces Firmware upgrade by HTTP protocol through Ethernet network Configuration upload/download through HTTP Remote syslog System log LLDP protocol System Management PLANET Smart Discovery Utility PLANET NMS PLANET NMSViewerPro App...
  • Page 38 User’s Manual of IGS-5225 series IEEE 802.1s Multiple Spanning Tree Protocol IEEE 802.1p Class of Service IEEE 802.1Q VLAN tagging IEEE 802.1ad Q-in-Q VLAN stacking IEEE 802.1x Port Authentication Network Control IEEE 802.1ab LLDP IEEE 802.3at Power over Ethernet Plus(For IGS-5225-4UP1T2S/IGS-5225-4UP1T2S- 12V/IGS-5225-4P2S) IEEE 802.3bt Power over Ethernet Plus Plus(For IGS-5225-4UP1T2S/IGS-5225-4UP1T2S-...

  • Page 39: Installation

    User’s Manual of IGS-5225 series 2. INSTALLATION 2.1 Hardware Description The Industrial Managed Switch provides different running speeds – 10Mbps, 100Mbps, 1000Mbps and 2500Mbps – and is able to automatically distinguishes the speed of incoming connection. This section describes the hardware features of Industrial Managed Switch. For easier management and control of the Industrial Managed Switch, familiarize yourself with its display indicators and ports.
  • Page 40 User’s Manual of IGS-5225 series IGS-5225-4UP1T2S-12V Dimensions (W x D x H): 76 x 135 x 152 mm...
  • Page 41 User’s Manual of IGS-5225 series IGS-5225-8P2T2S  Dimensions (W x D x H): 76 x 107 x 152 mm...
  • Page 42 User’s Manual of IGS-5225 series IGS-5225-8P4S  Dimensions (W x D x H): 76 x 107 x 152 mm...
  • Page 43 User’s Manual of IGS-5225 series IGS-5225-8P4S-12V  Dimensions (W x D x H): 76 x 107 x 152 mm...
  • Page 44 User’s Manual of IGS-5225 series IGS-5225-8P2T4S  Dimensions (W x D x H): 76 x 107 x 152 mm...
  • Page 45 User’s Manual of IGS-5225 series IGS-5225-4P2S  Dimensions (W x D x H): 50 x 87 x 135 mm...
  • Page 46 User’s Manual of IGS-5225 series IGS-5225-4T2S  Dimensions (W x D x H): 32 x 87x 135 mm...

  • Page 47: Front Panels

    User’s Manual of IGS-5225 series 2.1.2 Front Panels IGS-5225-8P2T4S IGS-5225-8P2T2S IGS-5225-8P4S IGS-5225-8P4S-12V Figure 2-1: Figure 2-2: Figure 2-3: IGS-5225-8P2T4S Switch Front Panel IGS-5225-8P2T2S Switch Front Panel IGS-5225-8P4S/IGS-5225-8P4S-12V Switch Front Panel...
  • Page 48 User’s Manual of IGS-5225 series IGS-5225-4UP1T2S IGS-5225-4UP1T2S-12V Figure 2-4: Figure 2-5: IGS-5225-4UP1T2S S witch Front Panel IGS-5225-4UP1T2S-12V Switch Front Panel...
  • Page 49 User’s Manual of IGS-5225 series IGS-5225-4P2S IGS-5225-4T2S Figure 2-6: Figure 2-7: IGS-5225-4P2S Switch Front Panel IGS-5225-4T2S Switch Front Panel...
  • Page 50 User’s Manual of IGS-5225 series ■ Gigabit TP Interface 10/100/1000BASE-T Copper, RJ45 Twisted-pair: Up to 100 meters. ■ SFP Slot 100/1000/2500BASE-X slot, SFP (Small-form Factor Pluggable) transceiver module: From 300 meters to 2km (multi-mode fiber) and to 10/20/30/40/60/70/80/120 kilometers (single-mode fiber or WDM fiber).
  • Page 51 User’s Manual of IGS-5225 series IGS-5225-4P2S IGS-5225-4T2S Figure 2-10: IGS-5225-4P2S Reset Button Figure 2-11: IGS-5225-4T2S Reset Button Please refer to Chapter 3.3 Reset Button Pressed and Released Function < 5 sec: System Reboot Reboot the Industrial Managed Switch. Reset the Industrial Managed Switch to Factory Default configuration.

  • Page 52: Led Indications

    User’s Manual of IGS-5225 series 2.1.3 LED Indications IGS-5225-4UP1T2S  System Color Function Green Lights to indicate DC power input 1 has power. Green Lights to indicate DC power input 2 has power. Alarm Lights to indicate that Switch power or port has failed.
  • Page 53 User’s Manual of IGS-5225 series  Per 10/100/1000T RJ45 Ports (Port 5) Color Function Lights: To indicate the port is successfully established. 1000 Green LNK/ACT Blinks: To indicate that the switch is actively sending or receiving data over that port.
  • Page 54 User’s Manual of IGS-5225 series IGS-5225-4UP1T2S-12V  System Color Function Green Lights to indicate DC power input 1 has power. Green Lights to indicate DC power input 2 has power. Alarm Lights to indicate that Switch power or port has failed.
  • Page 55 User’s Manual of IGS-5225 series  10/100/1000T RJ45 Ports (Port 5) Color Function Lights: To indicate the port is successfully established. 1000 Green LNK/ACT Blinks: To indicate that the switch is actively sending or receiving data over that port. 10/100 Lights: To indicate the port is successfully established.
  • Page 56 User’s Manual of IGS-5225 series IGS-5225-8P2T2S IGS-5225-8P2T4S  System Color Function PWR 1 Green Lights to indicate DC power input 1 has power. PWR 2 Green Lights to indicate DC power input 2 has power. Alarm Lights to indicate that Switch power input or port has failed.
  • Page 57 User’s Manual of IGS-5225 series  Per 10/100/1000BASE-T Port with PoE (Port-1~Port-8) Color Function Lights To indicate the link through that port is successfully established. 10/100/1000 Green To indicate that the switch is actively sending or receiving data LNK/ACT Blinks over that port.
  • Page 58 User’s Manual of IGS-5225 series IGS-5225-8P4S/IGS-5225-8P4S-12V  System Color Function PWR 1 Green Lights to indicate DC power input 1 has power. PWR 2 Green Lights to indicate DC power input 2 has power. Alarm Lights to indicate that Switch power input or port has failed.
  • Page 59 User’s Manual of IGS-5225 series  Per 10/100/1000BASE-T Port with PoE (Port-1~Port-8) Color Function Lights Indicating the port is running at 1000Mbps speed and successfully established. 10/100/1000 Green LNK/ACT Blinks Indicating that the switch is actively sending or receiving data over that port.
  • Page 60 User’s Manual of IGS-5225 series IGS-5225-4P2S  System Color Function Green PWR1 Lights to indicate that the switch has power. Green PWR2 Lights to indicate that the switch has power. Alarm Lights to indicate Power failure. Lights to indicate that the ERPS Ring has been created...
  • Page 61 User’s Manual of IGS-5225 series ■ PoE Power Usage (Unit: Watt) Color Function Blinks To indicate the system consumes between 15 watts and 30 watts of PoE power Amber Lights To indicate the system consumes over 30 watts of PoE power...
  • Page 62 User’s Manual of IGS-5225 series IGS-5225-4T2S  System Color Function PWR 1 Green Lights to indicate power input 1 has power. PWR 2 Green Lights to indicate power input 2 has power. Fault Lights to indicate that Switch power input or port has failed.

  • Page 63: Switch Upper Panel

    User’s Manual of IGS-5225 series 2.1.4 Switch Upper Panel The Upper Panel of the Industrial Managed Switch comes with a DC inlet power socket and one terminal block connector with 6 contacts. Insert positive/negative DC power wires into contacts 1 and 2 for DC Power 1, or 5 and 6 for DC Power 2.
  • Page 64 User’s Manual of IGS-5225 series Figure 2-15: IGS-5225-4T2S Upper Panel Tighten the wire-clamp screws for preventing the wires from loosening. PWR 1 PWR 2 Figure 2-16: 6-Pin Terminal Block Power Wiring Input Model Name Positive (+) Pin Negative (-) Pin...
  • Page 65 For the IGS-5225-4UP1T2S-12V, the wire gauge for the terminal block should be in the range from 12 to 20 AWG. Please check the wire’s AWG and ampere specification before connecting PLANET Industrial Managed Switch. Please pay attention to the electrical wire thickness and refer to Appendix B: "Recommended Use of Connected Wires"...

  • Page 66: Wiring The Fault Alarm Contact

    User’s Manual of IGS-5225 series 2.1.5 Wiring the Fault Alarm Contact The fault alarm contacts are in the middle (3 & 4) of the terminal block connector as the picture shows below. Inserting the wires, the Industrial Managed Switch will detect the fault status of the power failure, or port link failure (available for managed model).

  • Page 67: Wiring The Digital Input/Output

    User’s Manual of IGS-5225 series 2.1.6 Wiring the Digital Input/Output The 6-contact terminal block connector on the rear panel of IGS Series is used for Digital Input and Digital Output. Please follow the steps below to insert wire. The IGS-5225-4UP1T2S/ IGS-5225-8P2T2S/ IGS-5225-8P4S/ IGS-5225-8P4S-12V offers two DI and DO groups. 1 and 2 are DI groups;...
  • Page 68 User’s Manual of IGS-5225 series Tighten the wire-clamp screws for preventing the wires from loosening. DI1 DO0 DO1 GND GND Figure 2-20: 6-pin Terminal Block for DI and DO Wiring Input There are two Digital Input groups for you to monitor two different devices. The following topology shows how to wire DI0 and DI1.
  • Page 69 User’s Manual of IGS-5225 series There are two Digital Output groups for you to sense IGS-5225-4UP1T2S/ IGS-5225-4UP1T2S-12V/ IGS-5225-8P2T2S/ IGS-5225-8P4S/ IGS-5225-8P4S-12V port failure or power failure and issue a high or low signal to external device. The following topology shows how to wire DO0 and DO1.

  • Page 70: Installing The Industrial Managed Switch

    User’s Manual of IGS-5225 series 2.2 Installing the Industrial Managed Switch This section describes how to install your Industrial Managed Switch and make connections to the Industrial Managed Switch. Please read the following topics and perform the procedures in the order being presented. To install your Industrial Managed Switch on a desktop or shelf, simply complete the following steps.

  • Page 71: Din-Rail Mounting

    User’s Manual of IGS-5225 series 2.2.2 DIN-rail Mounting This section describes how to install the Industrial Managed Switch. There are two methods to install the Industrial Managed Switch -- DIN-rail mounting and wall-mount plate mounting. Please read the following topics and perform the procedures in the order being presented.
  • Page 72 User’s Manual of IGS-5225 series Step 3: Check whether the DIN-rail bracket is tightly on the track. Please refer to the following procedures to remove the Industrial Managed Switch from the track. Step 4: Lightly remove the DIN-rail bracket from the track.
  • Page 73 User’s Manual of IGS-5225 series IGS-5225-4UP1T2S-12V DIN-rail mounting Installation:...

  • Page 74: Wall Mount Plate Mounting

    User’s Manual of IGS-5225 series 2.2.3 Wall Mount Plate Mounting To install the Industrial Managed Switch on the wall, please follow the instructions below. Follow all the DIN-rail installation steps as shown in the example. Step 1: Remove the DIN-rail bracket from the Industrial Managed Switch. Use the screwdriver to loosen the screws to remove the DIN-rail bracket.

  • Page 75: Cabling

    User’s Manual of IGS-5225 series 2.3 Cabling 10/100/1000BASE-T All 10/100/1000BASE-T ports come with auto-negotiation capability. They automatically support 1000BASE-T, 100BASE- TX and 10BASE-T networks. Users only need to plug a working network device into one of the 10/100/1000BASE-T ports, and then turn on the Industrial Managed Switch. The port will automatically run at 10Mbps, 20Mbps, 100Mbps or 200Mbps and 1000Mbps or 2000Mbps after negotiating with the connected device.

  • Page 76: Installing The Sfp Transceiver

    Figure 2-23: Plugging in the SFP/SFP+ Transceiver  Approved PLANET SFP Transceivers PLANET Industrial Managed PoE+ Switch supports both single mode and multi-mode SFP transceivers. The following list of approved PLANET SFP transceivers is correct at the time of publication: Fast Ethernet Transceiver (100BASE-X SFP)
  • Page 77 User’s Manual of IGS-5225 series Fast Ethernet Transceiver (100BASE-BX, Single Fiber Bi-directional SFP) Speed Connector Model Fiber Mode Distance Wavelength (TX) Wavelength (RX) Operating Temp. Interface (Mbps) 0 ~ 60℃ MFB-FA20 WDM (LC) Single Mode 20km 1310nm 1550nm 0 ~ 60℃...
  • Page 78 WDM(LC) Single Mode 20km 1550nm 1310nm It is recommended to use PLANET SFP on the Industrial Managed Switch. If you insert an SFP/SFP+ transceiver that is not supported, the Industrial Managed Switch will not recognize it. Please choose the SFP/SFP+ transceiver which can be operated under -40~85 degrees C temperature if the switch device is working in a 0~50 degrees C temperature environment.

  • Page 79: Removing The Sfp/Sfp+ Transceiver

    User’s Manual of IGS-5225 series 2.3.2 Removing the SFP/SFP+ Transceiver Make sure there is no network activity by consulting or checking with the network administrator. Or through the management interface of the switch/converter (if available) to disable the port in advance.

  • Page 80: Switch Management

    User’s Manual of IGS-5225 series 3. SWITCH MANAGEMENT This chapter explains the methods that you can use to configure management access to the Industrial Managed Switch. It describes the types of management applications and the communication and management protocols that deliver data between your management device (workstation or personal computer) and the system.

  • Page 81: Management Access Overview

    User’s Manual of IGS-5225 series 3.2 Management Access Overview The Industrial Managed Switch gives you the flexibility to access and manage it using any or all of the following methods:  Remote Telnet Interface  Web browser Interface  An external SNMP-based network management application The remote Telnet and Web browser interfaces are embedded in the Industrial Managed Switch software and are available for immediate use.

  • Page 82: Cli Mode Management

    User’s Manual of IGS-5225 series 3.3 CLI Mode Management There are two ways for CLI mode management, one is remote telnet and the other operated from console port. Remote telnet is an IP-based protocol and console port is for user to operate the Industrial Managed Switch locally only; however, their operations are the same.

  • Page 83: Logging On To The Console

    Once the terminal has been connected to the device, power on the Industrial Managed Switch and the terminal will display “running testing procedures”. The following console screen is based on the IGS-5225-4P2S. The display of the other IGS-5225 series is the same as that of the IGS-5225-4P2S.
  • Page 84 User’s Manual of IGS-5225 series The following console screen is based on the firmware version of February of 2024 or after. User name: admin Password: sw + the last 6 characters of the MAC ID in lowercase Find the MAC ID on your device label. The default password is "sw" or “mc” followed by the last six lowercase characters of the MAC ID.

  • Page 85: Remote Telnet

    User’s Manual of IGS-5225 series 3.3.2 Remote Telnet In Windows system, you may click “Start” and then choose “Accessories” and “Command Prompt”. Please input “telnet 192.168.0.100” and press “enter’ from your keyboard. You will see the following screen appears as Figure 3-2 shows.

  • Page 86: Web Management

    User’s Manual of IGS-5225 series 3.4 Web Management The Industrial Managed Switch offers management features that allow users to manage the Industrial Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. After you set up your IP address for the Industrial Managed Switch, you can access the Industrial Managed Switch’s Web interface applications...

  • Page 87: Snmp-Based Network Management

    User’s Manual of IGS-5225 series 3.5 SNMP-based Network Management You can use an external SNMP-based application to configure and manage the Industrial Managed Switch, such as SNMP Network Manager, HP Openview Network Node Management (NNM) or What’s Up Gold. This management method requires the SNMP agent on the Industrial Managed Switch and the SNMP Network Management Station to use the same community string.

  • Page 88: Planet Smart Discovery Utility

    To easily list the Industrial Managed Switch in your Ethernet environment, the Planet Smart Discovery Utility from user’s manual CD-ROM is an ideal solution. The following install instructions guide you to running the Planet Smart Discovery Utility. Open the Planet Smart Discovery Utility in administrator PC.
  • Page 89 To click the “Control Packet Force Broadcast” function, it allows new setting value to be assigned to the Web Smart Switch under a different IP subnet address. Press the “Connect to Device” button and then the Web login screen appears. Press the “Exit” button to shut down Planet Smart Discovery Utility.

  • Page 90: Web Configuration

    User’s Manual of IGS-5225 series 4. WEB CONFIGURATION This section introduces the configuration and functions of the Web-based management. About Web-based Management The Industrial Managed Switch offers management features that allow users to manage the Industrial Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer.

  • Page 91: Logging In To The Industrial Managed Switch

    User’s Manual of IGS-5225 series 4.1 Logging in to the Industrial Managed Switch Use Chrome 98.0.xxx or above for Web browser and enter IP address https://192.168.0.100 (the factory default IP address) to access the Web interface. The following web screen is based on the firmware version before February of 2024.
  • Page 92 User’s Manual of IGS-5225 series After logging in, you will be prompted to change the initial password to a permanent one. Figure 4-1-3: Create a New Password Once the password change is complete, re-enter the web interface using your new password and the main screen appears as below shows.
  • Page 93 User’s Manual of IGS-5225 series Web Configuration PoE+ PoE++ E.R.P.S (Ring) DIDO IGS-5225-4T2S ■ IGS-5225-4P2S ■ ■ IGS-5225-8P4S ■ ■ ■ IGS-5225-8P4S-12V ■ ■ ■ IGS-5225-8P2T2S ■ ■ ■ IGS-5225-8P2T4S ■ ■ ■ IGS-5225-4UP1T2S ■ ■ ■ ■ IGS-5225-4UP1T2S-12V ■...

  • Page 94: Main Web Page

    User’s Manual of IGS-5225 series 4.1.1 Main Web page The Industrial Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you to access the Industrial Managed Switch using the Web browser of your choice. This chapter describes how to use the Industrial Managed Switch’s Web browser interface to configure and manage it.
  • Page 95 User’s Manual of IGS-5225 series Main Menu Using the onboard web agent, you can define system parameters, manage and control the Industrial Managed Switch, and all its ports, or monitor network conditions. Via the Web-Management, the administrator can set up the Industrial Managed Switch by selecting the functions those listed in the Main Function.

  • Page 96: System

    User’s Manual of IGS-5225 series 4.2 System Use the System menu items to display and configure basic administrative details of the Industrial Managed Switch. Under the System, the following topics are provided to configure and view the system information. This section has the following items: ■...

  • Page 97: Management

    User’s Manual of IGS-5225 series 4.2.1 Management 4.2.1.1 System Information The System Infomation page provides information for the current device information. System Information page helps a switch administrator to identify the hardware MAC address, software version and system uptime. The screen in Figure 4-2-1 appears.

  • Page 98: Ip Configuration

    User’s Manual of IGS-5225 series 4.2.1.2 IP Configuration The IP Configuration includes the IP Configuration, IP Interface and IP Routes. The configured column is used to view or change the IP configuration. The maximum number of interfaces supported is 128 and the maximum number of routes is 32.
  • Page 99 User’s Manual of IGS-5225 series  IP Interface Delete Select this option to delete an existing IP interface. The VLAN associated with the IP interface. Only ports in this VLAN will be VLAN able to access the IP interface. This field is only available for input when creating a new interface.

  • Page 100: Ip Status

    User’s Manual of IGS-5225 series 4.2.1.3 IP Status IP Status displays the status of the IP protocol layer. The status is defined by the IP interfaces, the IP routes and the neighbor cache (ARP cache) status. The screen in Figure 4-2-3 appears.

  • Page 101: Arp

    User’s Manual of IGS-5225 series 4.2.1.4 ARP his page provides ARP configuration settings. press the “Apply” button to take effect, the screen in Figure 4-2-1-21 appears. Figure 4-2-1-21: ARP Table Configuration Page Screenshot The page includes the following fields: Object Description ...

  • Page 102: Users Configuration

    User’s Manual of IGS-5225 series 4.2.1.5 Users Configuration This page provides an overview of the current users. Currently the only way to login as another user on the web server is to close and reopen the browser. After setup is completed, press the “Apply” button to take effect. Please login web interface with new user name and password;...
  • Page 103 User’s Manual of IGS-5225 series Add / Edit User This page configures a user – add, edit or delete user. Figure 4-2-5: Add / Edit User Configuration Page Screenshot The page includes the following fields: Object Description  Username A string identifying the user name that this entry should belong to. The allowed string length is 1 to 31.
  • Page 104 User’s Manual of IGS-5225 series Once the new user is added, the new user entry is shown on the Users Configuration page. Figure 4-2-6: User Configuration Page Screenshot If you forget the new password after changing the default password, please press the “Reset”...

  • Page 105: Privilege Levels

    User’s Manual of IGS-5225 series 4.2.1.6 Privilege Levels This page provides an overview of the privilege levels. After setup is completed, please press the “Apply” button to take effect. Please login web interface with new user name and password and the screen in Figure 4-2-7 appears.
  • Page 106 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Group Name The name identifying the privilege group. In most cases, a privilege level group consists of a single module (e.g. LACP, RSTP or QoS), but a few of them contain more than one.

  • Page 107: Ntp Configuration

    User’s Manual of IGS-5225 series 4.2.1.7 NTP Configuration Configure NTP on this page. NTP is an acronym for Network Time Protocol, a network protocol for synchronizing the clocks of computer systems. NTP uses UDP (data grams) as transport layer. You can specify NTP Servers. The NTP Configuration...

  • Page 108: Time Configuration

    User’s Manual of IGS-5225 series 4.2.1.8 Time Configuration Configure Time Zone on this page. A Time Zone is a region that has a uniform standard time for legal, commercial, and social purposes. It is convenient for areas in close commercial or other communication to keep the same time, so time zones tend to follow the boundaries of countries and their subdivisions.
  • Page 109 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Time Zone Lists various Time Zones worldwide. Select appropriate Time Zone from the drop-down and click Save to set.  Acronym User can set the acronym of the time zone. This is a User configurable acronym to identify the time zone.
  • Page 110 User’s Manual of IGS-5225 series System Time Correction Manually Configure NTP on this page. NTP is an acronym for Network Time Protocol, a network protocol for synchronizing the clocks of computer systems. NTP uses UDP (data grams) as transport layer. You can specify NTP Servers. The NTP Configuration...

  • Page 111: Upnp

    User’s Manual of IGS-5225 series 4.2.1.9 UPnP Configure UPnP on this page. UPnP is an acronym for Universal Plug and Play. The goals of UPnP are to allow devices to connect seamlessly and to simplify the implementation of networks in the home (data sharing, communications, and entertainment) and in corporate environments for simplified installation of computer components.

  • Page 112: Cpu Load

    User’s Manual of IGS-5225 series 4.2.1.10 CPU Load This page displays the CPU load, using an SVG graph. The load is measured as average over the last 100ms, 1 sec and 10 seconds intervals. The last 120 samples are graphed, and the last numbers are displayed as text as well. In order to display the SVG graph, your browser must support the SVG format.

  • Page 113: System Log

    User’s Manual of IGS-5225 series 4.2.1.11 System Log The Industrial Managed Switch system log information is provided here. The System Log screen in Figure 4-2-15 appears. Figure 4-2-15: System Log Page Screenshot The page includes the following fields: Object Description ...

  • Page 114: Detailed Log

    User’s Manual of IGS-5225 series 4.2.1.12 Detailed Log The Industrial Managed Switch system detailed log information is provided here. The Detailed Log screen in Figure 4-2-16 appears. Figure 4-2-16: Detailed Log Page Screenshot The page includes the following fields: Object Description ...

  • Page 115: Remote Syslog

    User’s Manual of IGS-5225 series 4.2.1.13 Remote Syslog Configure remote syslog on this page. The Remote Syslog screen in Figure 4-2-17 appears. Figure 4-2-17: Remote Syslog Page Screenshot The page includes the following fields: Object Description  Mode Indicates the server mode operation. When the mode operation is enabled, the syslog message will send out to syslog server.

  • Page 116: Smtp Configuration

    User’s Manual of IGS-5225 series 4.2.1.14 SMTP Configuration This page facilitates an SMTP Configuration on the switch. The SMTP Configure screen in Figure 4-2-18 appears. Figure 4-2-18: SMTP Configuration Page Screenshot...
  • Page 117 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  SMTP Mode Controls whether SMTP is enabled on this switch.  SMTP Server Type the SMTP server name or the IP address of the SMTP server.

  • Page 118: Fault Alarm

    User’s Manual of IGS-5225 series 4.2.1.15 Fault Alarm The Industrial Managed Switch supports a Fault Alarm feature which can alert the users when there is something wrong with the switches. With this ideal feature, the users would not have to waste time finding where the problem is. It will help to save time and human resource.

  • Page 119: Digital Input/Output

    User’s Manual of IGS-5225 series 4.2.1.16 Digital Input/Output Digital Input allows user to log external device (such as industrial cooler) dead or alive or something else. System will log a user customized message into system log and syslog, and issue SNMP trap or issue an alarm E-mail.
  • Page 120 User’s Manual of IGS-5225 series The Configuration screen in Figure 4-2-20 appears. Figure 4-2-20 Digital Input/Output Control Configuration page Screenshot The page includes the following fields: Object Description  Check the Enable checkbox to enable Digital Input function. Enable Uncheck the Enable checkbox to disable Digital Input function.
  • Page 121 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Enable Check the Enable checkbox to enable Digital Output function. Uncheck the Enable checkbox to disable Output function.  Action As Digital Output: Allows user to monitor an alarm from port failure, power failure, Digital...

  • Page 122: Dhcp Relay

    User’s Manual of IGS-5225 series 4.2.1.17 DHCP Relay Configure DHCP Relay on this page. DHCP Relay is used to forward and transfer DHCP messages between the clients and the server when they are not on the same subnet domain. The DHCP option 82 enables a DHCP relay agent to insert specific information into a DHCP request packets when forwarding client DHCP packets to a DHCP server and remove the specific information from a DHCP reply packets when forwarding server DHCP packets to a DHCP client.
  • Page 123 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Relay Mode Indicates the DHCP relay mode operation. Possible modes are:  Enabled: Enable DHCP relay mode operation. When enabling DHCP relay mode operation, the agent forwards and transfers DHCP messages between the clients and the server when they are not on the same subnet domain.

  • Page 124: Dhcp Relay Statistics

    User’s Manual of IGS-5225 series 4.2.1.18 DHCP Relay Statistics This page provides statistics for DHCP relay. The DHCP Relay Statistics screen in Figure 4-2-13 appears. Figure 4-2-13: DHCP Relay Statistics Page Screenshot The page includes the following fields: Server Statistics...

  • Page 125: Simple Network Management Protocol

    User’s Manual of IGS-5225 series 4.2.2 Simple Network Management Protocol 4.2.2.1 SNMP Overview The Simple Network Management Protocol (SNMP) is an application layer protocol that facilitates the exchange of management information between network devices. It is part of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suite.

  • Page 126: System Configuration

    User’s Manual of IGS-5225 series Use the SNMP Menu to display or configure the Industrial Managed Switch 's SNMP function. This section has the following items:  System Configuration Configure SNMP on this page.  Trap Configuration Configure SNMP trap on this page.

  • Page 127: System Information

    User’s Manual of IGS-5225 series 4.2.2.3 System Information The switch system information is provided here. The SNMP System Information screen in Figure 4-2-2-3 appears. Figure 4-2-2-3: System Information Configuration Page Screenshot The page includes the following fields: Object Description ...

  • Page 128: Snmp Trap Configuration

    User’s Manual of IGS-5225 series 4.2.2.4 SNMP Trap Configuration Configure SNMP trap on this page. The SNMP Trap Configuration screen in Figure 4-2-2-4 appears. Click ‘Add New Entry” and then the SNMP Trap Configuration page appears. Figure 4-2-2-4: SNMP Trap Configuration Page Screenshot...
  • Page 129 User’s Manual of IGS-5225 series  Indicates the community access string when send SNMP trap packet. The Trap Community allowed string length is 0 to 255, and the allowed content is the ASCII characters from 33 to 126.  Trap Destination Indicates the SNMP trap destination address.

  • Page 130: Trap Configuration

    User’s Manual of IGS-5225 series 4.2.2.5 Trap Configuration This page provides SNMP trap source configurations. A trap is sent for the given trap source if at least one filter with filter type included matches the filter, and no filters with filter type excluded matches.
  • Page 131 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Name Indicates the name for the entry.  Type The filter type for the entry. Possible types are: ■ included: An optional flag to indicate a trap is sent for the given trap source is matched.

  • Page 132: Snmpv3 Communities

    User’s Manual of IGS-5225 series 4.2.2.6 SNMPv3 Communities Configure SNMPv3 communities table on this page. The entry index key is Community. The SNMPv3 Communities screen in Figure 4-2-2-7 appears. Figure 4-2-2-7: SNMPv3 Communities Configuration Page Screenshot The page includes the following fields:...

  • Page 133: Snmpv3 Users

    User’s Manual of IGS-5225 series 4.2.2.7 SNMPv3 Users Configure SNMPv3 users table on this page. The entry index keys are Engine ID and User Name. The SNMPv3 Users screen Figure 4-2-2-8 appears. Figure 4-2-2-8: SNMPv3 Users Configuration Page Screenshot The page includes the following fields:...
  • Page 134 User’s Manual of IGS-5225 series  None: None authentication protocol.  MD5: An optional flag to indicate that this user using MD5 authentication protocol.  SHA: An optional flag to indicate that this user using SHA authentication protocol. The value of security level cannot be modified if entry already exist. That means must first ensure that the value is set correctly.

  • Page 135: Snmpv3 Groups

    User’s Manual of IGS-5225 series 4.2.2.8 SNMPv3 Groups Configure SNMPv3 groups table on this page. The entry index keys are Security Model and Security Name. The SNMPv3 Groups screen in Figure 4-2-2-9 appears. Figure 4-2-2-9: SNMPv3 Groups Configuration Page Screenshot...

  • Page 136: Snmpv3 Views

    User’s Manual of IGS-5225 series 4.2.2.9 SNMPv3 Views Configure SNMPv3 views table on this page. The entry index keys are View Name and OID Subtree. The SNMPv3 Views screen in Figure 4-2-2-10 appears. Figure 4-2-2-10: SNMPv3 Views Configuration Page Screenshot...

  • Page 137: Snmpv3 Access

    User’s Manual of IGS-5225 series 4.2.2.10 SNMPv3 Access Configure SNMPv3 accesses table on this page. The entry index keys are Group Name, Security Model and Security Level. The SNMPv3 Access screen in Figure 4-2-2-11 appears. Figure 4-2-2-11: SNMPv3 Accesses Configuration Page Screenshot...

  • Page 138: Rmon

    User’s Manual of IGS-5225 series 4.2.3 RMON RMON is the most important expansion of the standard SNMP. RMON is a set of MIB definitions, used to define standard network monitor functions and interfaces, enabling the communication between SNMP management terminals and remote monitors.
  • Page 139 User’s Manual of IGS-5225 series  InNUcastPkts: The number of broadcast and multi-cast packets delivered to a higher-layer protocol.  InDiscards: The number of inbound packets that are discarded even the packets are normal.  InErrors: The number of inbound packets that contains errors preventing them from being deliverable to a higher-layer protocol.

  • Page 140: Rmon Alarm Status

    User’s Manual of IGS-5225 series 4.2.3.2 RMON Alarm Status This page provides an overview of RMON Alarm entries. Each page shows up to 99 entries from the Alarm table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Alarm table.

  • Page 141: Rmon Event Configuration

    User’s Manual of IGS-5225 series 4.2.3.3 RMON Event Configuration Configure RMON Event table on this page. The entry index key is ID; screen in Figure 4-2-3-3 appears. Figure 4-2-3-3 RMON Event Configuration Page Screenshot The page includes the following fields:...

  • Page 142: Rmon Event Status

    User’s Manual of IGS-5225 series 4.2.3.4 RMON Event Status This page provides an overview of RMON Event table entries. Each page shows up to 99 entries from the Event table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Event table.

  • Page 143: Rmon History Configuration

    User’s Manual of IGS-5225 series 4.2.3.5 RMON History Configuration Configure RMON History table on this page. The entry index key is ID; screen in Figure 4-2-3-5 appears. Figure 4-2-3-5: RMON History Configuration Page Screenshot The page includes the following fields:...

  • Page 144: Rmon History Status

    User’s Manual of IGS-5225 series 4.2.3.6 RMON History Status This page provides an detail of RMON history entries; screen in Figure 4-2-3-6 appears. Figure 4-2-3-6: RMON History Overview Page Screenshot The page includes the following fields: Object Description  History Index Indicates the index of History control entry.

  • Page 145: Rmon Statistics Configuration

    User’s Manual of IGS-5225 series 4.2.3.7 RMON Statistics Configuration Configure RMON Statistics table on this page. The entry index key is ID; screen in Figure 4-2-3-7 appears. Figure 4-2-3-7: RMON Statistics Configuration Page Screenshot The page includes the following fields:...

  • Page 146: Rmon Statistics Status

    User’s Manual of IGS-5225 series 4.2.3.8 RMON Statistics Status This page provides an overview of RMON Statistics entries. Each page shows up to 99 entries from the Statistics table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Statistics table.
  • Page 147 User’s Manual of IGS-5225 series  64 Bytes The total number of packets (including bad packets) received that were 64 octets in length.  65~127 The total number of packets (including bad packets) received that were between 65 to 127 octets in length.

  • Page 148: Dhcp Relay

    User’s Manual of IGS-5225 series 4.2.4 DHCP Relay (Only applies to switches installed with firmware after vx.2103bxxxxxx ) 4.2.4.1 DHCPv4 Relay A DHCP relay agent is used to forward and to transfer DHCP messages between the clients and the server when they are not in the same subnet domain.
  • Page 149 User’s Manual of IGS-5225 series  Relay Server Indicates the DHCP relay server IP address. Indicates the DHCP relay information mode option operation. The option 82 circuit ID format as "[vlan_id][module_id][port_no]". The first four characters represent the VLAN ID, the fifth and sixth characters are the module ID(in standalone device it always equal 0, in stackable device it means switch ID), and the last two characters are the port number.

  • Page 150: Dhcpv4 Relay Statistics

    User’s Manual of IGS-5225 series 4.2.4.2 DHCPv4 Relay Statistics Figure 4-2-4-2: DHCPv4 Relay Statistics The first part of this page provides statistics for the DHCP server. Object Description  Transmit to Server The number of packets that are relayed from client to server.

  • Page 151: Dhcpv6 Relay

    User’s Manual of IGS-5225 series 4.2.4.3 DHCPv6 Relay Figure 4-2-4-3: DHCPv6 Relay Configuration This table is used to configure DHCPv6_Relay for a specific VLAN. Object Description  Interface Interface identification.  Relay Interface Interface identification. The id of the interface used for relaying.

  • Page 152: Dhcpv6 Relay Statistics

    User’s Manual of IGS-5225 series 4.2.4.4 DHCPv6 Relay Statistics Figure 4-2-4-3: DHCPv6 Relay Statistics The table below shows the current , configured relay agents and their statistics. Object Description  Interface Interface identification. The id of the interface that receives client requests.

  • Page 153: Dhcp Server

    User’s Manual of IGS-5225 series 4.2.5 DHCP server 4.2.5.1 Mode Configure DHCP server mode on this page. The entry index key is ID.; screen in Figure 4-2-4-1 appears. Figure 4-2-4-1: DHCP server mode Page Screenshot The page includes the following fields: Global Mode Configure operation mode to enable/disable DHCP server per system.

  • Page 154: Excluded Ip

    User’s Manual of IGS-5225 series  Mode  Indicate the operation mode per VLAN. Possible modes are: Enabled: Enable DHCP server per VLAN. Disabled: Disable DHCP server pre VLAN. Buttons : Click to add a new VLAN range. : Click to apply changes Click to undo any changes made locally and revert to previously saved values.

  • Page 155: Pool

    User’s Manual of IGS-5225 series 4.2.5.3 Pool This page manages DHCP pools. According to the DHCP pool, DHCP server will allocate IP address and deliver configuration parameters to DHCP client. screen in Figure 4-2-4-3 appears. Figure 4-2-4-3: DHCP server pool Page Screenshot...

  • Page 156: Statistics

    User’s Manual of IGS-5225 series 4.2.5.4 Statistics This page displays the database counters and the number of DHCP messages sent and received by DHCP server. . screen in Figure 4-2-4-4 appears. Figure 4-2-4-4: DHCP server Statistics Page Screenshot The page includes the following fields:...
  • Page 157 User’s Manual of IGS-5225 series DHCP message Received Counters Object Description  Discover Number of DHCP DISCOVER messages received.  Request Number of DHCP REQUEST messages received.  Decline Number of DHCP DECLINE messages received.  Release Number of DHCP RELEASE messages received.

  • Page 158: Binding

    User’s Manual of IGS-5225 series 4.2.5.5 Binding This page displays bindings generated for DHCP clients. screen in Figure 4-2-4-5 appears. Figure 4-2-4-5: DHCP server Binding IP page Screenshot The page includes the following fields: Object Description  IP Display IP address allocated to DHCP client.

  • Page 159: Declined Ip

    User’s Manual of IGS-5225 series 4.2.5.6 Declined IP This page displays declined IP addresses. screen in Figure 4-2-4-6 appears. Figure 4-2-4-6: DHCP server Declined IP Page Screenshot The page includes the following fields: Object Description  Delined IP Display List of IP addresses declined.
  • Page 160 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Rx and Tx Discover Display the number of discover (option 53 with value 1) packets received and transmitted.  Rx and Tx Offer Display the number of offer (option 53 with value 2) packets received and transmitted.

  • Page 161: Industrial Protocol

    User’s Manual of IGS-5225 series 4.2.6 Industrial Protocol With the supported Modbus TCP/IP protocol, the IGS-5225 series can easily integrate with SCADA systems, HMI systems and other data acquisition systems in factory floors. It enable administrators to remotely monitor the industrial Ethernet switch’s operating information, port information and communication status, thus easily achieving enhanced monitoring...

  • Page 162: Remote Management

    Planet provides two ways to remotely manage all kinds of devices: a smartphone application (CloudViewer) designed to monitor network status from the cloud, and a Network Management System (PLANET NMS) designed to monitor all deployed network devices, such as managed switches, media converters, routers, smart APs, VoIP phones, and IP cameras.
  • Page 163 Failed: The authorization of NMS controller is failed.  Disabled: The function of remote NMS management is disabled.  Email and Password Fill in PLANET CloudViewer account(e-mail address) and password.  Connection Status  Success- If Cloudviewer server is connected, the connection status show success.

  • Page 164: Switching

    User’s Manual of IGS-5225 series 4.3 Switching 4.3.1 Port Management Use the Port Menu to display or configure the Industrial Managed Switch's ports. This section has the following items:  Port Configuration Configures port connection settings  Port Statistics Overview Lists Ethernet and RMON port statistics ...
  • Page 165 User’s Manual of IGS-5225 series  Select any available link speed for the given switch port. Draw the menu bar to Configured Link Speed select the mode.  Auto – Set up Auto negotiation for copper interface.  10Mbps HDX - Force sets 10Mbps/Half-Duplex mode.

  • Page 166: Port Statistics Overview

    User’s Manual of IGS-5225 series 4.3.1.2 Port Statistics Overview This page provides an overview of general traffic statistics for all switch ports. The Port Statistics Overview screen in Figure 4- 3-1-2 appears. Figure 4-3-1-2: Port Statistics Overview Page Screenshot The displayed counters are:...

  • Page 167: Port Statistics Details

    User’s Manual of IGS-5225 series 4.3.1.3 Port Statistics Details This page provides detailed traffic statistics for a specific switch port. Use the port select box to select which switch port details to display. The displayed counters are the totals for receive and transmit, the size counters for receive and transmit, and the error counters for receive and transmit.
  • Page 168 User’s Manual of IGS-5225 series Receive and Transmit Size Counters The number of received and transmitted (good and bad) packets split into categories based on their respective frame sizes. Receive and Transmit Queue Counters The number of received and transmitted packets per input and output queue.

  • Page 169: Sfp Module Information

    User’s Manual of IGS-5225 series 4.3.1.4 SFP Module Information The Industrial Managed Switches have supported the SFP module with digital diagnostics monitoring (DDM) function. This feature is also known as digital optical monitoring (DOM). You can check the physical or operational status of an SFP module via the SFP Module Information page.
  • Page 170 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Type Display the type of current SFP module; the possible types are:  10GBASE-SR  10GBASE-LR  1000BASE-SX  1000BASE-LX  100BASE-FX  Speed Display the speed of current SFP module; the speed value or description is got from the SFP module.

  • Page 171: Mirror Port Configuration

    User’s Manual of IGS-5225 series 4.3.1.5 Port Mirror Configure port Mirroring on this page. This function provides monitoring network traffic that forwards a copy of each incoming or outgoing packet from one port of a network Switch to another port where the packet can be studied. It enables the manager to keep close track of switch performance and alter it if necessary.
  • Page 172 User’s Manual of IGS-5225 series Figure 4-3-1-7: Mirror Configuration Page Screenshot The page includes the following fields: Object Description  Session Select session id to configure.  To Enabled/Disabled the mirror or Remote Mirroring function Mode  Type Mirror The switch is running on mirror mode.
  • Page 173 User’s Manual of IGS-5225 series  Reflector Port The reflector port is a method to redirect the traffic to Remote Mirroring VLAN. Any device connected to a port set as a reflector port loses connectivity until the Remote Mirroring is disabled.

  • Page 174: Name Map

    User’s Manual of IGS-5225 series 4.3.1.6 Name Map Interface Name to Port Number Map Help er to express an interface, whereas CLI uses interface names. The table on this Many Web pages use a port numb page provides a means to convert from one to the other.

  • Page 175: Ddmi Over View

    User’s Manual of IGS-5225 series 4.3.1.8 DDMI Over View Display DDMI overview information on this page. The displayed settings are: Object Description  Port DDMI port.  Vendor Indicates Vendor name SFP vendor name.  Part Number Indicates Vendor PN Part number provided by SFP vendor.

  • Page 176: Ddmi Detailed

    User’s Manual of IGS-5225 series 4.3.1.9 DDMI Detailed Display DDMI detailed information on this page. The displayed settings are: Object Description  Vendor Indicates SFP vendor name.  Part Number Indicates part number provided by SFP vendor.  Serial Number Indicates part number provided by SFP vendor.

  • Page 177: Link Aggregation

    User’s Manual of IGS-5225 series 4.3.2 Link Aggregation Port Aggregation optimizes port usage by linking a group of ports together to form a single Link Aggregated Groups (LAGs). Port Aggregation multiplies the bandwidth between the devices, increases port flexibility, and provides link redundancy.
  • Page 178 User’s Manual of IGS-5225 series The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems that require high speed redundant links. Link aggregation lets you group up to eight consecutive ports into a single dedicated connection.

  • Page 179: Common

    User’s Manual of IGS-5225 series 4.3.2.1 Common This page is used to configure the Aggregation hash mode and the aggregation group. The aggregation hash mode settings are global. Hash Code Contributors The Static Aggregation screen in Figure 4-3-2-2 appears. Figure 4-3-2-2 : Aggregation Mode Configuration Page Screenshot...

  • Page 180: Group

    User’s Manual of IGS-5225 series 4.3.2.2 Group The Aggregation Group Configuration screen in Figure 4-3-2-3 appears. Figure 4-3-2-3: Aggregation Group Configuration Page Screenshot The page includes the following fields: .Object Description  Group ID Indicates the group ID for the settings contained in the same row. Group ID "Normal"...

  • Page 181: Aggregation Status

    User’s Manual of IGS-5225 series 4.3.2.3 Aggregation Status This page is used to see the staus of ports in Aggregation group. The Static Aggregation Status screen in Figure 4-3-2-4 appears. Figure 4-3-2-4 : LACP Port Configuration Page Screenshot The page includes the following fields:...

  • Page 182: Lacp Configuration

    User’s Manual of IGS-5225 series 4.3.2.4 LACP Configuration Link Aggregation Control Protocol (LACP) - LACP LAG negotiate Aggregated Port links with other LACP ports located on a different device. LACP allows switches connected to each other to discover automatically whether any ports are member of the same LAG.

  • Page 183: Lacp System Status

    User’s Manual of IGS-5225 series 4.3.2.5 LACP System Status This page provides a status overview of all LACP instances. The LACP Status Page display the current LACP aggregation Groups and LACP Port status. The LACP System Status screen in Figure 4-3-2-6 appears.

  • Page 184: Lacp Internal Status

    User’s Manual of IGS-5225 series 4.3.2.6 LACP Internal Status This page provides a status overview of LACP status for all ports. The LACP Port Status screen in Figure 4-3-2-7 appears. Figure 4-3-2-7: LACP Status Page Screenshot The page includes the following fields:...

  • Page 185: Lacp Neighbor Port Statistics

    User’s Manual of IGS-5225 series 4.3.2.7 LACP Neighbor Port Statistics This page provides a status overview for the LACP neighbor status for all ports. Only ports that are part of an LACP group are shown. For details on the shown parameters please refer to IEEE 801.AX-2014.

  • Page 186: Lacp Port Status

    User’s Manual of IGS-5225 series 4.3.2.8 LACP Port Status This page provides a status overview of LACP status for all ports. The LACP Internal Port Status screen in Figure 4-3-2-9 appears. Figure 4-3-2-9: LACP Neighbor Port Status Page Screenshot The page includes the following fields:...

  • Page 187: Lacp Port Statistics

    User’s Manual of IGS-5225 series 4.3.2.9 LACP Port Statistics This page provides an overview for LACP statistics for all ports. The LACP Port Status screen in Figure 4-3-2-8 appears. Figure 4-3-2-8: LACP Port Statistics Page Screenshot The page includes the following fields:...

  • Page 188: Vlans

    User’s Manual of IGS-5225 series 4.3.3 VLANs 4.3.3.1 VLAN Overview A Virtual Local Area Network (VLAN) is a network topology configured according to a logical scheme rather than the physical layout. VLAN can be used to combine any collection of LAN segments into an autonomous user group that appears as a single LAN.

  • Page 189: Ieee 802.1Q Vlan

    User’s Manual of IGS-5225 series 4.3.3.2 IEEE 802.1Q VLAN In large networks, routers are used to isolate broadcast traffic for each subnet into separate domains. This Industrial Managed Switch provides a similar service at Layer 2 by using VLANs to organize any group of network nodes into separate broadcast domains.
  • Page 190 User’s Manual of IGS-5225 series ■ 802.1Q VLAN Tags The figure below shows the 802.1Q VLAN tag. There are four additional octets inserted after the source MAC address. Their presence is indicated by a value of 0x8100 in the Ether Type field. When a packet's Ether Type field is equal to 0x8100, the packet carries the IEEE 802.1Q/802.1p tag.
  • Page 191 User’s Manual of IGS-5225 series ■ Port VLAN ID Packets that are tagged (are carrying the 802.1Q VID information) can be transmitted from one 802.1Q compliant network device to another with the VLAN information intact. This allows 802.1Q VLAN to span network devices (and indeed, the entire network –...
  • Page 192 User’s Manual of IGS-5225 series ■ VLAN Classification When the switch receives a frame, it classifies the frame in one of two ways. If the frame is untagged, the switch assigns the frame to an associated VLAN (based on the default VLAN ID of the receiving port). But if the frame is tagged, the switch uses the tagged VLAN ID to identify the port broadcast domain of the frame.
  • Page 193 User’s Manual of IGS-5225 series The Managed Switch supports multiple VLAN tags and can therefore be used in MAN applications as a provider bridge, aggregating traffic from numerous independent customer LANs into the MAN (Metro Access Network) space. One of the purposes of the provider bridge is to recognize and use VLAN tags so that the VLANs in the MAN space can be used independent of the customers’...

  • Page 194: Vlan Port Configuration

    User’s Manual of IGS-5225 series 4.3.3.3 VLAN Port Configuration This page is used for configuring the Industrial Managed Switch port VLAN. The VLAN per Port Configuration page contains fields for managing ports that are part of a VLAN. The port default VLAN ID (PVID) is configured on the VLAN Port Configuration page.
  • Page 195 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Allowed Access This field shows the allowed Access VLANs, it only affects ports configured as VLANs Access ports. Ports in other modes are members of all VLANs specified in the Allowed VLANs field.
  • Page 196 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Port This is the logical port number for this row.  Mode Access Access ports are normally used to connect to end stations. Dynamic features like Voice VLAN may add the port to more VLANs behind the scenes. Access ports have the following characteristics: ...
  • Page 197 User’s Manual of IGS-5225 series Native VLAN for ports in Trunk or Hybrid mode.  Port Type Ports in hybrid mode allow for changing the port type, that is, whether a frame's VLAN tag is used to classify the frame on ingress to a particular VLAN, and if so, which TPID it reacts on.
  • Page 198 User’s Manual of IGS-5225 series discarded. Egress Tagging This option is only available for ports in Hybrid mode. Ports in Trunk and Hybrid mode may control the tagging of frames on egress. Untag Port VLAN ■ Frames classified to the Port VLAN are transmitted untagged. Other frames are transmitted with the relevant tag.

  • Page 199: Vlan Membership Status

    User’s Manual of IGS-5225 series 4.3.3.4 VLAN Membership Status This page provides an overview of membership status for VLAN users. The VLAN Membership Status screen in Figure 4-3-3-3 appears. Figure 4-3-3-3: VLAN Membership Status for Static User Page Screenshot The page includes the following fields:...

  • Page 200: Vlan Port Status

    User’s Manual of IGS-5225 series Buttons : Select VLAN Users from this drop down list. Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. : Click to refresh the page immediately. : Updates the table starting from the first entry in the VLAN Table, i.e. the entry with the lowest VLAN ID.
  • Page 201 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Port The logical port for the settings contained in the same row.  Port Type Show the VLAN Awareness for the port. If VLAN awareness is enabled, the tag is removed from tagged frames received on the port.

  • Page 202: Vlan Translation

    User’s Manual of IGS-5225 series 4.3.4 VLAN Translation 4.3.4.1 Port to Group Configuration This page allows you to configure switch Ports to use a given VLAN Translation Mapping Group. This will enable all VLAN Translation mappings of that group (if any) on the selected switch port.

  • Page 203: Vlan Translation Mappings

    User’s Manual of IGS-5225 series 4.3.4.2 VLAN Translation Mappings This page allows you to create mappings of VLANs -> Translated VLANs and organize these mappings into global Groups. Figure 4-3-3-6: VLAN Translation Mapping Table Page Screenshot The displayed settings are:...

  • Page 204: Vlan Setting Example

    User’s Manual of IGS-5225 series 4.3.4.3 VLAN setting example:  Separate VLAN  802.1Q VLAN Trunk  Port Isolate 4.3.4.3.1 Two Separate 802.1Q VLANs The diagram shows how the Industrial Managed Switch handle Tagged and Untagged traffic flow for two VLANs. VLAN Group 2 and VLAN Group 3 are separated VLAN.
  • Page 205 User’s Manual of IGS-5225 series While the packet leaves Port-3, it will keep as a tagged packet with VLAN Tag=2.  Tagged packet entering VLAN 2 While [PC-3] transmit a tagged packet with VLAN Tag=2 enters Port-3, [PC-1] and [PC-2] will received the packet through Port-1 and Port-2.
  • Page 206 User’s Manual of IGS-5225 series Figure 4-3-3-9: Change Port VLAN of Port 1~3 to be VLAN2 and Port VLAN of Port 4~6 to be VLAN3 Enable VLAN Tag for specific ports Link Type: Port-3 (VLAN-2) and Port-6 (VLAN-3) Change Port 3 Mode as Trunk, Selects Egress Tagging as Tag All and Types 2 in the Allowed VLANs column.

  • Page 207: Vlan Trunking Between Two 802.1Q Aware Switches

    User’s Manual of IGS-5225 series 4.3.4.3.2 VLAN Trunking between two 802.1Q aware switches The most cases are used for “Uplink” to other switches. VLANs are separated at different switches, but they need to access with other switches within the same VLAN group. The screen in Figure 4-3-3-11 appears.
  • Page 208 User’s Manual of IGS-5225 series Figure 4-3-3-13: Changes Port VLAN of Port 1~3 to be VLAN2 and Port VLAN of Port 4~6 to be VLAN3 For the VLAN ports connecting to the hosts, please refer to 4.6.10.1 examples. The following steps will focus on the VLAN Trunk port configuration.

  • Page 209: Port Isolate

    User’s Manual of IGS-5225 series 4.3.4.3.3 Port Isolate The diagram shows how the Industrial Managed Switch handles isolated and promiscuous ports, and the each PC is not able to access the isolated port of each other’s PCs. But they all need to access with the same server/AP/Printer. This section will show you how to configure the port for the server –...

  • Page 210: Private Vlans

    User’s Manual of IGS-5225 series 4.3.5 Private VLANs The Private VLAN membership configurations for the switch can be monitored and modified here. Private VLANs can be added or deleted here. Port members of each Private VLAN can be added or removed here.

  • Page 211: Port Isolation

    User’s Manual of IGS-5225 series The table below explains the manageable items shown on this page. Object Description  Delete To delete a Group Name to VLAN map entry, check this box. The entry will be deleted on the switch during the next Save ...

  • Page 212: Vcl

    User’s Manual of IGS-5225 series 4.3.6 VCL 4.3.6.1 MAC-Based VLAN The MAC address to VLAN ID mappings can be configured here. This page allows adding and deleting MAC- based VLAN Classification List entries and assigning the entries to different ports.

  • Page 213: Ip Subnet-Based Vlan

    User’s Manual of IGS-5225 series 4.3.6.2 IP Subnet-based VLAN The IP subnet to VLAN ID mappings can be configured here. This page allows adding, updating and deleting IP subnet to VLAN ID mapping entries and assigning them to different ports.

  • Page 214: Protocol-Based Vlan

    User’s Manual of IGS-5225 series 4.3.6.3 Protocol-based VLAN This page allows you to add new Protocol to Group Name (each protocol can be part of only one Group) mapping entries as well as allow you to see and delete already mapped entries for the switch .
  • Page 215 User’s Manual of IGS-5225 series b. PID: PID (Protocol ID). If OUI is hexadecimal 000000, then the protocol ID is the Ethernet type (EtherType) field value for the protocol running on top of SNAP; if OUI is an OUI for a particular organization, the protocol ID is a value assigned by that organization to the protocol running on top of SNAP.

  • Page 216: Protocol-Based Vlan Membership

    User’s Manual of IGS-5225 series 4.3.6.4 Protocol-based VLAN Membership This page allows you to map a Group Name (already configured or to be configured in the future) to a VLAN for the switch . Figure 4-3-6-4: Group Name to VLAN Mapping Table The following table shows the items on this page.

  • Page 217: Gvrp

    User’s Manual of IGS-5225 series 4.3.7 GVRP GVRP (GARP VLAN Registration Protocol or Generic VLAN Registration Protocol) is a protocol that facilitates control of virtual local area networks (VLANs) within a larger network 4.3.7.1 Global Configuration This page allows you to configure the global GVRP configuration settings that are commonly applied to all GVRP enabled ports.

  • Page 218: Port Configuration

    User’s Manual of IGS-5225 series 4.3.7.2 Port Configuration This configuration can be performed either before or after GVRP is configured globally - the protocol operation will be the same. as well. as screen in Figure 4-3-6-2 appears. Figure 4-3-7-2: GVRP Port Configuration Page Screenshot...

  • Page 219: Mrp

    User’s Manual of IGS-5225 series 4.3.8 MRP 4.3.8.1 Port Configuration This page allows you to configure the generic settings for all switch ports. Figure 4-3-8-1: MRP Overall Port Configuration The Table below shows the settings can be made on this page.

  • Page 220: Mvrp Global Configuration

    User’s Manual of IGS-5225 series 4.3.8.2 MVRP Global Configuration This page allows you to configure the MVRP global and per port settings altogether. The page is divided into a global section and a per-port configuration section. Figure 4-3-8-2: MVRP Global Configuration The following table shows the adjustable settings on this page.

  • Page 221: Mvrp Statistics

    User’s Manual of IGS-5225 series 4.3.8.3 MVRP Statistics This page provides statistics for the MVRP protocol for all switch ports. Figure 4-3-8-3: MVRP Statistics The following table explains the information shown on this page. Object Description  Port The logical port for the statistics contained in the same row.

  • Page 222: Spanning Tree Protocol

    User’s Manual of IGS-5225 series 4.3.9 Spanning Tree Protocol 4.3.9.1 Theory The Spanning Tree protocol can be used to detect and disable network loops, and to provide backup links between switches, bridges or routers. This allows the switch to interact with other bridging devices in your network to ensure that only one route exists between any two stations on the network, and provide backup links which automatically take over when a primary link goes down.
  • Page 223 User’s Manual of IGS-5225 series The switch sends BPDUs to communicate and construct the spanning-tree topology. All switches connected to the LAN on which the packet is transmitted will receive the BPDU. BPDUs are not directly forwarded by the switch, but the receiving switch uses the information in the frame to calculate a BPDU, and, if the topology changes, initiates a BPDU transmission.
  • Page 224 User’s Manual of IGS-5225 series Figure 4-3-9-1: STP Port State Transitions You can modify each port state by using management software. When you enable STP, every port on every switch in the network goes through the blocking state and then transitions through the states of listening and learning at power up. If properly configured, each port stabilizes to the forwarding or blocking state.
  • Page 225 User’s Manual of IGS-5225 series The following are the user-configurable STP parameters for the switch level: Parameter Description Default Value Bridge Identifier(Not user A combination of the User-set priority and 32768 + MAC configurable the switch’s MAC address. except by setting priority...
  • Page 226 User’s Manual of IGS-5225 series User-Changeable STA Parameters The Switch’s factory default setting should cover the majority of installations. However, it is advisable to keep the default settings as set at the factory; unless, it is absolutely necessary. The user changeable parameters in the Switch are as follows: Priority –...
  • Page 227 User’s Manual of IGS-5225 series Figure 4-3-9-2: Before Applying the STA Rules In this example, only the default STP values are used. Figure 4-3-9-3: After Applying the STA Rules The switch with the lowest Bridge ID (switch C) was elected the root bridge, and the ports were selected to give a high port cost between switches B and C.

  • Page 228: Stp System Configuration

    User’s Manual of IGS-5225 series 4.3.9.2 STP System Configuration This page allows you to configure STP system settings. The settings are used by all STP Bridge instances in the Switch. The Industrial Managed Switch support the following Spanning Tree protocols: ‧...

  • Page 229: Basic Settings

    User’s Manual of IGS-5225 series The page includes the following fields: Basic Settings Object Description  Protocol Version The STP protocol version setting. Valid values are:  STP (IEEE 802.1D Spanning Tree Protocol)  RSTP (IEEE 802.2w Rapid Spanning Tree Protocol) ...

  • Page 230: Advanced Settings

    User’s Manual of IGS-5225 series Advanced Settings Object Description  Edge Port BPDU Control whether a port explicitly configured as Edge will transmit and receive Filtering BPDUs.  Edge Port BPDU Control whether a port explicitly configured as Edge will disable itself upon Guard reception of a BPDU.

  • Page 231: Bridge Status

    User’s Manual of IGS-5225 series 4.3.9.3 Bridge Status This page provides a status overview for all STP bridge instances. The displayed table contains a row for each STP bridge instance, where the column displays the following information: The Bridge Status screen in Figure 4-3-9-5 appears.

  • Page 232: Cist Port Configuration

    User’s Manual of IGS-5225 series 4.3.9.4 CIST Port Configuration This page allows the user to inspect the current STP CIST port configurations, and possibly change them as well. The CIST Port Configuration screen in Figure 4-3-9-6 appears. Figure 4-3-9-6 : STP CIST Port Configuration Page Screenshot...
  • Page 233 User’s Manual of IGS-5225 series  AdminEdge Controls whether the operEdge flag should start as being set or cleared. (The initial operEdge state when a port is initialized).  AutoEdge Controls whether the bridge should enable automatic edge detection on the bridge port.
  • Page 234 User’s Manual of IGS-5225 series By default, the system automatically detects the speed and duplex mode used on each port, and configures the path cost according to the values shown below. Path cost “0” is used to indicate auto-configuration mode. When the short path cost method is selected and the default path cost recommended by the IEEE 8021w standard exceeds 65,535, the default is set to 65,535.

  • Page 235: Msti Priorities

    User’s Manual of IGS-5225 series 4.3.9.5 MSTI Priorities This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. The MSTI Priority screen in Figure 4-3-9-7 appears. Figure 4-3-9-7: MSTI Priority Page Screenshot...

  • Page 236: Msti Configuration

    User’s Manual of IGS-5225 series 4.3.9.6 MSTI Configuration This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. The MSTI Configuration screen in Figure 4-3-9-8 appears. Figure 4-3-9-8: MSTI Configuration Page Screenshot...

  • Page 237: Msti Ports Configuration

    User’s Manual of IGS-5225 series MSTI Mapping Object Description  MSTI The bridge instance. The CIST is not available for explicit mapping, as it will receive the VLANs not explicitly mapped.  VLANs Mapped The list of VLAN's mapped to the MSTI. The VLANs must be separated with comma and/or space.
  • Page 238 User’s Manual of IGS-5225 series Figure 4-3-9-10 : MST1 MSTI Port Configuration Page Screenshot The page includes the following fields: MSTx MSTI Port Configuration Object Description  Port The switch port number of the corresponding STP CIST (and MSTI) port.

  • Page 239: Port Status

    User’s Manual of IGS-5225 series 4.3.9.8 Port Status This page displays the STP CIST port status for port physical ports in the currently selected switch. The STP Port Status screen in Figure 4-3-9-11 appears. Figure 4-3-9-11: STP Port Status Page Screenshot...

  • Page 240: Port Statistics

    User’s Manual of IGS-5225 series 4.3.9.9 Port Statistics This page displays the STP port statistics counters for port physical ports in the currently selected switch. The STP Port Statistics screen in Figure 4-3-9-12 appears. Figure 4-3-9-12: STP Statistics Page Screenshot...

  • Page 241: Igmp Snooping

    User’s Manual of IGS-5225 series 4.3.10 IGMP Snooping 4.3.10.1 IGMP Snooping The Internet Group Management Protocol (IGMP) lets host and routers share information about multicast groups memberships. IGMP snooping is a switch feature that monitors the exchange of IGMP messages and copies them to the CPU for feature processing.
  • Page 242 User’s Manual of IGS-5225 series Figure 4-3-10-2: Multicast Flooding Figure 4-3-10-3: IGMP Snooping Multicast Stream Control...
  • Page 243 User’s Manual of IGS-5225 series IGMP Versions 1 and 2 Multicast groups allow members to join or leave at any time. IGMP provides the method for members and multicast routers to communicate when joining or leaving a multicast group. IGMP version 1 is defined in RFC 1112. It has a fixed packet size and no optional data.
  • Page 244 User’s Manual of IGS-5225 series The states a computer will go through to join or to leave a multicast group are shown below: Figure 4-3-10-4: IGMP State Transitions  IGMP Querier – A router, or multicast-enabled switch, can periodically ask their hosts if they want to receive multicast traffic. If there is more than one router/switch on the LAN performing IP multicasting, one of these devices is elected “querier”...

  • Page 245: Profile Table

    User’s Manual of IGS-5225 series 4.3.10.2 Profile Table This page provides IPMC Profile related configurations. The IPMC profile is used to deploy the access control on IP multicast streams. It is allowed to create at maximum 64 Profiles with at maximum 128 corresponding rules for each. The Profile Table...

  • Page 246: Address Entry

    User’s Manual of IGS-5225 series 4.3.10.3 Address Entry This page provides address range settings used in . The address entry is used to specify the address IPMC profile range that will be associated with Profile. It is allowed to create at maximum 128 address entries in the IPMC system.

  • Page 247: Igmp Snooping Configuration

    User’s Manual of IGS-5225 series 4.3.10.4 IGMP Snooping Configuration This page provides IGMP Snooping related configuration. The IGMP Snooping Configuration screen in Figure 4-3-10-7 appears. Figure 4-3-10-7: IGMP Snooping Configuration Page Screenshot The page includes the following fields: Object Description ...
  • Page 248 User’s Manual of IGS-5225 series  Router Port Specify which ports act as IGMP router ports. A router port is a port on the Ethernet switch that leads towards the Layer 3 multicast device or IGMP querier. The Switch forwards IGMP join or leave packets to an IGMP router port.

  • Page 249: Igmp Snooping Vlan Configuration

    User’s Manual of IGS-5225 series 4.3.10.5 IGMP Snooping VLAN Configuration Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found in the VLAN Table.
  • Page 250 User’s Manual of IGS-5225 series  PRI (PRI) Priority of Interface. It indicates the IGMP control frame priority level generated by the system. These values can be used to prioritize different classes of traffic. The allowed range is 0 (best effort) to 7 (highest), default interface priority value is 0 ...

  • Page 251: Igmp Snooping Port Group Filtering

    User’s Manual of IGS-5225 series 4.3.10.6 IGMP Snooping Port Group Filtering In certain switch applications, the administrator may want to control the multicast services that are available to end users. For example, an IP/TV service based on a specific subscription plan. The IGMP filtering feature fulfills this requirement by restricting access to specified multicast services on a switch port, and IGMP throttling limits the number of simultaneous multicast groups a port can join.

  • Page 252: Igmp Snooping Status

    User’s Manual of IGS-5225 series 4.3.10.7 IGMP Snooping Status This page provides IGMP Snooping status. The IGMP Snooping Status screen in Figure 4-3-10-10 appears. Figure 4-3-10-10: IGMP Snooping Status Page Screenshot The page includes the following fields: Object Description ...

  • Page 253: Igmp Group Information

    User’s Manual of IGS-5225 series 4.3.10.8 IGMP Group Information Entries in the IGMP Group Table are shown on this Page. The IGMP Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the IGMP Group table, default being 20, selected through the "entries per page" input field.

  • Page 254: Igmpv3 Sfm Information

    User’s Manual of IGS-5225 series 4.3.10.9 IGMPv3 SFM Information Entries in the IGMP SFM Information Table are shown on this page. The IGMP SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by Port.

  • Page 255: Mld Snooping

    User’s Manual of IGS-5225 series 4.3.11 MLD Snooping 4.3.11.1 MLD Snooping Configuration This page provides MLD Snooping related configuration. The MLD Snooping Configuration screen in Figure 4-3-11-1 appears. Figure 4-3-11-1: MLD Snooping Configuration Page Screenshot The page includes the following fields:...

  • Page 256: Mld Snooping Vlan Configuration

    User’s Manual of IGS-5225 series  Router Port Specify which ports act as router ports. A router port is a port on the Ethernet switch that leads towards the Layer 3 multicast device or MLD querier. If an aggregation member port is selected as a router port, the whole aggregation will act as a router port.
  • Page 257 User’s Manual of IGS-5225 series  Querier Election Enable to join MLD Querier election in the VLAN. Disable to act as a MLD Non- Querier.  Compatibility Compatibility is maintained by hosts and routers taking appropriate actions depending on the versions of MLD operating on hosts and routers within a network.

  • Page 258: Mld Snooping Port Group Filtering

    User’s Manual of IGS-5225 series 4.3.11.3 MLD Snooping Port Group Filtering In certain switch applications, the administrator may want to control the multicast services that are available to end users. For example, an IP/TV service based on a specific subscription plan. The MLD filtering feature fulfills this requirement by restricting access to specified multicast services on a switch port, and MLD throttling limits the number of simultaneous multicast groups a port can join.

  • Page 259: Mld Snooping Status

    User’s Manual of IGS-5225 series 4.3.11.4 MLD Snooping Status This page provides MLD Snooping status. The IGMP Snooping Status screen in Figure 4-3-11-4 appears. Figure 4-3-11-4: MLD Snooping Status Page Screenshot The page includes the following fields: Object Description ...

  • Page 260: Mld Group Information

    User’s Manual of IGS-5225 series 4.3.11.5 MLD Group Information Entries in the MLD Group Table are shown on this page. The MLD Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the MLD Group table, default being 20, selected through the "entries per page" input field.

  • Page 261: Mldv2 Information

    User’s Manual of IGS-5225 series 4.3.11.6 MLDv2 Information Entries in the MLD SFM Information Table are shown on this page. The MLD SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by Port.

  • Page 262: Mvr (Multicast Vlan Registration)

    User’s Manual of IGS-5225 series 4.3.12 MVR (Multicast VLAN Registration) The MVR feature enables multicast traffic forwarding on the Multicast VLANs. In a multicast television application, a PC or a network television or a set-top box can receive the multicast stream.

  • Page 263: Mvr Configuration

    User’s Manual of IGS-5225 series 4.3.12.1 MVR Configuration . This page provides MVR related configuration. The MVR screen in Figure 4-3-12-1 appears Figure 4-3-12-1: MVR Configuration Page Screenshot The page includes the following fields: Object Description  MVR Mode Enable/Disable the Global MVR.
  • Page 264 User’s Manual of IGS-5225 series  IGMP Address Define the IPv4 address as source address used in IP header for IGMP control frames. The default IGMP address is not set (0.0.0.0). When the IGMP address is not set, system uses IPv4 management address of the IP interface associated with this VLAN.

  • Page 265: Mvr Status

    User’s Manual of IGS-5225 series 4.3.12.2 MVR Status This page provides MVR status. The MVR Status screen in Figure 4-3-12-2 appears. Figure 4-3-12-2: MVR Status Page Screenshot The page includes the following fields: Object Description  VLAN ID The Multicast VLAN ID.

  • Page 266: Mvr Groups Information

    User’s Manual of IGS-5225 series 4.3.12.3 MVR Groups Information Entries in the MVR Group Table are shown on this page. The MVR Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the MVR Group table, default being 20, selected through the "entries per page" input field.

  • Page 267: Mvr Sfm Information

    User’s Manual of IGS-5225 series 4.3.12.4 MVR SFM Information Entries in the MVR SFM Information Table are shown on this page. The MVR SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by Port.

  • Page 268: Lldp

    User’s Manual of IGS-5225 series 4.3.13 LLDP 4.3.13.1 Link Layer Discovery Protocol Link Layer Discovery Protocol (LLDP) is used to discover basic information about neighboring devices on the local broadcast domain. LLDP is a Layer 2 protocol that uses periodic broadcasts to advertise information about the sending device.

  • Page 269: Lldp Port Configuration

    User’s Manual of IGS-5225 series The page includes the following fields: LLDP Parameters Object Description  Tx Interval The switch is periodically transmitting LLDP frames to its neighbors for having the network discovery information up-to-date. The interval between each LLDP frame is determined by the Tx Interval value.
  • Page 270 User’s Manual of IGS-5225 series information received from neighbors.  Enabled The switch will send out LLDP information, and will analyze LLDP information received from neighbors.  CDP Aware Select CDP awareness. The CDP operation is restricted to decoding incoming CDP frames...

  • Page 271: Lldp Neighbor

    User’s Manual of IGS-5225 series 4.3.13.3 LLDP Neighbor This page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected. The LLDP Neighbor Information screen in Figure 4-3-13-2 appears.

  • Page 272: Lldp Med Configuration

    User’s Manual of IGS-5225 series 4.3.13.4 LLDP MED Configuration This page allows you to configure the LLDP-MED. The LLDPMED Configuration screen in Figure 4-3-13-3 appears. Figure 4-3-13-3: LLDPMED Configuration Page Screenshot The page includes the following fields: Fast start repeat count...
  • Page 273 User’s Manual of IGS-5225 series Device is detected, will an LLDP-MED capable Network Connectivity Device start to advertise LLDP-MED TLVs in outgoing LLDPDUs on the associated port. The LLDP-MED application will temporarily speed up the transmission of the LLDPDU to start within a second, when a new LLDP-MED neighbour has been detected in order share LLDP-MED information as fast as possible to new neighbours.
  • Page 274 User’s Manual of IGS-5225 series 3. IEEE 802.3 Repeater (included for historical reasons) 4. IEEE 802.11 Wireless Access Point 5. Any device that supports the IEEE 802.1AB and MED extensions that can relay IEEE 802 frames via any method. An Endpoint Device a LLDP-MED Device that sits at the network edge and provides some aspect of IP communications service, based on IEEE 802 LAN technology.
  • Page 275 User’s Manual of IGS-5225 series American Vertical Datum of 1988 (NAVD88). This datum pair is to be used when referencing locations on land, not near tidal water (which would use Datum = NAD83/MLLW).  NAD83/MLLW: North American Datum 1983, CRS Code 4269, Prime Meridian Name: Greenwich;...

  • Page 276: Emergency Call Service

    User’s Manual of IGS-5225 series Emergency Call Service Emergency Call Service (e.g. E911 and others), such as defined by TIA or NENA. Object Description  Emergency Call Emergency Call Service ELIN identifier data format is defined to carry the ELIN...
  • Page 277 User’s Manual of IGS-5225 series Object Description  Delete Check to delete the policy. It will be deleted during the next save.  Policy ID ID for the policy. This is auto generated and shall be used when selecting the polices that shall be mapped to the specific ports.
  • Page 278 User’s Manual of IGS-5225 series 'untagged’ VLAN.  Untagged indicates that the device is using an untagged frame format and as such does not include a tag header as defined by IEEE 802.1Q-2003. In this case, both the VLAN ID and the Layer 2 priority fields are ignored and only the DSCP value has relevance.

  • Page 279: Lldp-Med Neighbor

    User’s Manual of IGS-5225 series 4.3.13.5 LLDP-MED Neighbor This page provides a status overview for all LLDP-MED neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected. The LLDP-MED Neighbor Information screen in Figure 4-3-13-4 appears.
  • Page 280 User’s Manual of IGS-5225 series support all aspects of TIA-1057 applicable to Generic Endpoints (Class I), and any LLDP-MED Endpoint Device claiming compliance as a Communication Device (Class III) will also support all aspects of TIA-1057 applicable to both Media Endpoints (Class II) and Generic Endpoints (Class I).
  • Page 281 User’s Manual of IGS-5225 series 5. Extended Power via MDI - PD 6. Inventory 7. Reserved  Application Type Application Type indicating the primary function of the application(s) defined for this network policy, advertised by an Endpoint or Network Connectivity Device.
  • Page 282 User’s Manual of IGS-5225 series 2003. A value of 1 through 4094 is used to define a valid VLAN ID. A value of 0 (Priority Tagged) is used if the device is using priority tagged frames as defined by IEEE 802.1Q-2003, meaning that only the IEEE 802.1D priority level is significant and the default PVID of the ingress port is used instead.

  • Page 283: Port Statistics

    User’s Manual of IGS-5225 series 4.3.13.6 Port Statistics This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to the whole switch, while local counters refers to counters for the currently selected switch. The LLDP Statistics screen in...
  • Page 284 User’s Manual of IGS-5225 series LLDP Statistics Local Counters The displayed table contains a row for each port. The columns hold the following information: Object Description  Local Port The port on which LLDP frames are received or transmitted. ...

  • Page 285: Mac Address Table

    User’s Manual of IGS-5225 series 4.3.14 MAC Address Table Switching of frames is based upon the DMAC address contained in the frame. The Industrial Managed Switch builds up a table that maps MAC addresses to switch ports for knowing which ports the frames should go to (based upon the DMAC address in the frame ).

  • Page 286: Aging Configuration

    User’s Manual of IGS-5225 series The page includes the following fields: Aging Configuration By default, dynamic entries are removed from the MAC table after 300 seconds. This removal is also called aging. Object Description  Disable Automatic Aging Enables/disables the automatic aging of dynamic entries ...

  • Page 287: Mac Address Table Status

    User’s Manual of IGS-5225 series 4.3.14.2 MAC Address Table Status Dynamic MAC Table Entries in the MAC Table are shown on this page. The MAC Table contains up to 8192 entries, and is sorted first by VLAN ID, then by MAC address. The MAC Address Table screen in Figure 4-3-14-2 appears.
  • Page 288 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Type Indicates whether the entry is a static or dynamic entry.  The VLAN ID of the entry. VLAN  MAC Address The MAC address of the entry.

  • Page 289: Loop Protection

    User’s Manual of IGS-5225 series 4.3.15 Loop Protection This chapter describes enabling loop protection function that provides loop protection to prevent broadcast loops in Industrial Managed Switch. 4.3.15.1 Configuration This page allows the user to inspect the current Loop Protection configurations, and possibly change them as well as screen in Figure 4-3-15-1 appears.

  • Page 290: Loop Protection Status

    User’s Manual of IGS-5225 series 4.3.15.2 Loop Protection Status This page displays the loop protection port status of the switch; screen in Figure 4-3-15-2 appears. Figure 4-3-15-2: Loop Protection Status Screenshot The page includes the following fields: Object Description  Port The Industrial Managed Switch port number of the logical port.

  • Page 291: Udld

    User’s Manual of IGS-5225 series 4.3.16 UDLD Unidirectional Link Detection (UDLD) is a data link layer protocol from Cisco Systems to monitor the physical configuration of the cables and detect unidirectional links. UDLD complements the Spanning Tree Protocol which is used to eliminate switching loops..

  • Page 292: Udld Status

    User’s Manual of IGS-5225 series 4.3.16.2 UDLD Status This page displays the UDLD status of the ports as well. as screen in Figure 4-3-16-2 appears. Figure 4-3-16-2: UDLD status Page Screenshot The page includes the following fields: UDLD port status...

  • Page 293: Link Oam

    User’s Manual of IGS-5225 series 4.3.17 Link OAM 4.3.17.1 Port Settings This page allows the user to inspect the current Link OAM port configurations, and change them as well, as screen in Figure 4- 3-17-1 appears. Figure 4-3-17-1: Port Status Page Screenshot...
  • Page 294 User’s Manual of IGS-5225 series The page includes the following fields: General Settings Object Description  Port The switch port number.  OAM Enabled Controls whether Link OAM is enabled on this switch port. Enabling Link OAM provides the network operators the ability to monitor the health of the network and quickly determine the location of failing links or fault conditions.

  • Page 295: Port Status

    User’s Manual of IGS-5225 series 4.3.17.2 Port Status This page provides Link OAM configuration operational status. The displayed fields shows the active configuration status for the selected port. as well. as screen in Figure 4-3-17-2 appears. Figure 4-3-17-2: Port Status Page Screenshot...
  • Page 296 User’s Manual of IGS-5225 series  Remote Loopback If status is enabled, DTE is capable of OAM remote loopback mode. Support  Link Monitoring If status is enabled, DTE supports interpreting Link Events. Support  MIB Retrieval Support If status ie enabled DTE supports sending Variable Response OAMPDUs.

  • Page 297: Statistics

    User’s Manual of IGS-5225 series 4.3.17.3 Statistics This page provides detailed OAM traffic statistics for a specific switch port. Use the port select box to select which switch port details to display.The displayed counters represent the total number of OAM frames received and transmitted for the selected port.

  • Page 298: Event Settings

    User’s Manual of IGS-5225 series transmitted Event Notification OAMPDU Sequence Number.  Rx and Tx Loopback A count of the number of Loopback Control OAMPDUs received and transmitted Control on this interface.  Rx and Tx Variable A count of the number of Variable Request OAMPDUs received and transmitted Request on this interface.
  • Page 299 User’s Manual of IGS-5225 series The page includes the following fields: General Settings Object Description  Port The switch port number.  Event Name Name of the Link Event which is being configured.  Error Window Represents the window period in the order of 1 sec for the observation of various link events.

  • Page 300: Event Status

    User’s Manual of IGS-5225 series 4.3.17.5 Event Status This page allows the user to inspect the current Link OAM Link Event configurations, and change them as well. as screen in Figure 4-3-17-5 appears. Figure 4-3-17-5: Link OAM Statistic Page Screenshot...
  • Page 301 User’s Manual of IGS-5225 series  Frame errors This four-octet field indicates the number of detected errored frames in the period.  Total frame errors This eight-octet field indicates the sum of errored frames that have been detected since the OAM sublayer was reset.

  • Page 302: Mib Retrieval

    User’s Manual of IGS-5225 series  Total Error Frame This four-octet field indicates the sum of errored frame seconds that have been Seconds Summary detected since the OAM sublayer was reset. Errors  Total Error Frame This four-octet field indicates the number of Errored Frame Seconds Summary...

  • Page 303: Link-Oam Example

    User’s Manual of IGS-5225 series 4.3.17.7 Link-OAM Example CE and PE devices with point-to-point link enable EFM OAM to monitor “the First Mile” link performance. It will report the log information to network management system when occurring fault event and use remote loopback function to detect the link in...

  • Page 304: Cfm

    User’s Manual of IGS-5225 series 4.3.18 CFM 4.3.18.1 CFM Global Configuration CFM stands for Connectivity Fault Management. It is a protocol used in network switches to detect connectivity issues and faults in the network. It can detect faults such as link failures, and it can also locate the source of the fault.

  • Page 305: Port Status

    User’s Manual of IGS-5225 series switch.  Organisation This is the three-bytes OUI transmitted with the Organization-Specific TLVs. Enter Specific TLV OUI as 6 characters 0-9, a-f.  Organisation This is the subtype transmitted with the Organization-Specific TLV. Can be any Specific TLV value in range [0;...
  • Page 306 User’s Manual of IGS-5225 series String  Name The contents of this pamameter depends on the value of the format member. If format is None: Name is not used, but will be set to all-zeros behind the scenes. This format is typically used by Y.1731-kind-of-PDUs.
  • Page 307 User’s Manual of IGS-5225 series Chassis Enable Sender ID TLV and send Chassis ID (MAC Address). Manage Enable Sender ID TLV and send Management address (IPv4 Address). ChassisManage Enable Sender ID TLV and send both Chassis ID (MAC Address) and Management Address (IPv4 Address).

  • Page 308: Service

    User’s Manual of IGS-5225 series 4.3.18.3 Service Configure CFM Service parameters on this page. Figure 4-3-18-3: CFM Service Configuration Configure CFM Service parameters on this page. Object Description  Delete Check to delete the entry. It will be deleted during the next save.
  • Page 309 User’s Manual of IGS-5225 series If Format is Two Octets, the following applies: Name[0] and Name[1] will both be interpreted as unsigned 8-bit integers (allowing a range of [0; 255]). Name[0] will be placed in the PDU before Name[1]. The remaining available bytes in name will not be used.
  • Page 310 User’s Manual of IGS-5225 series Defer Let the Domain configuration decide if Sender ID TLVs shall be included. Port Status: Include or exclude Port Status TLV in CCMs generated by this Service or let higher level determine. Disable Do not include Port Status TLVs.

  • Page 311: Mep

    User’s Manual of IGS-5225 series 4.3.18.4 MEP This switch supports two types of MEP: Port Down-MEPs and VLAN Down-MEPs. Port Down-MEPs In 802.1Q terminology, Port MEPs are located below the EISS entity, that is, closest to the physical port. Port MEPs are used by e.g.
  • Page 312 User’s Manual of IGS-5225 series The following explains the settings when configuring the MEP. Object Description  Delete Check to delete the entry. It will be deleted during the next save.  Domain Name of Domain under which this Service resides.

  • Page 313: Status

    User’s Manual of IGS-5225 series 4.3.18.5 Status Monitor CFM Status on this page. Figure 4-3-18-5: CFM MEP Status Monitor CFM Status on this page. Object Description  Domain Name of Domain under which this Service resides.  Service Name of Service under which this MEP resides.
  • Page 314 User’s Manual of IGS-5225 series Defects : A MEP can detect and report a number of defects, and multiple defects can be present at the same time. This is indicated the following letter code. Code Defect Description Defect not present...

  • Page 315: Sflow (Only Applies To Switches Installed With Firmware After V1.2103Bxxxxxx)

    User’s Manual of IGS-5225 series 4.3.19 sFlow (Only applies to switches installed with firmware after v1.2103bxxxxxx) 4.3.19.1 sFlow Configuration This page allows for configuring sFlow. The configuration is divided into two parts: Configuration of the sFlow receiver (a.k.a. sFlow collector) and configuration of per-port flow and counter samplers.
  • Page 316 User’s Manual of IGS-5225 series Receiver Configuration Object Description  Onwer Basically, sFlow can be configured in two ways: Through local management using the Web or CLI interface or through SNMP. This read-only field shows the owner of the current sFlow configuration and assumes values as follows: •...

  • Page 317: Sflow Statistics

    User’s Manual of IGS-5225 series bytes larger than the maximum header size. If the maximum datagram size does not take into account the maximum header size, samples may be dropped.  Counter Poller Enables/disables counter polling on this port. Enabled ...
  • Page 318 User’s Manual of IGS-5225 series Receiver Statistics Object Description  Owner This field shows the current owner of the sFlow configuration. It assumes one of three values as follows: • If sFlow is currently unconfigured/unclaimed, Owner contains <none>. • If sFlow is currently configured through Web or CLI, Owner contains <Configured through local management>.

  • Page 319: Ptp

    User’s Manual of IGS-5225 series 4.3.20 PTP The Precision Time Protocol (PTP) is a protocol used to synchronize clocks throughout a computer network. On a local area network, it achieves clock accuracy in the sub-microsecond range, making it suitable for measurement and control systems.

  • Page 320: Ptp Configuration

    User’s Manual of IGS-5225 series 4.3.20.1 PTP Configuration This page allows the user to configure and inspect the current PTP clock settings as screen in Figure 4-3-20-1 appears. Figure 4-3-20-1: PTP Configuration Page Screenshot Object Description  Delete Check this box and click on 'Save' to delete the clock instance.
  • Page 321 User’s Manual of IGS-5225 series The page includes the following fields: Clock Type and Profile Object Description  Clock Instance Indicates the instance number of a particular Clock Instance [0..3].  HW Domain Indicates the HW clock domain used by the clock.
  • Page 322 User’s Manual of IGS-5225 series Port Enable and Configuration Object Description  Port Enable Set check mark for each port configured for this Clock Instance.  Configuration Click 'Ports Configuration' to edit the port data set for the ports assigned to this clock instance.
  • Page 323 User’s Manual of IGS-5225 series  MPR The interval for issuing Delay_Req messages for the port in E2e mode. This value is announced from the master to the slave in an announce message. The value is reflected in the MDR field in the Slave The interval for issuing Pdelay_Req messages for the port in P2P mode Range is -7 to 5.
  • Page 324 User’s Manual of IGS-5225 series Object Description  Enable Disabled or Enabled.  I/O Pin Virtual Port I/O Pin. The valid range is 0 to 3.  Class Clock class value for clock as defined in IEEE Std 1588. The valid range is from 0 to 255.
  • Page 325 User’s Manual of IGS-5225 series Clock Parent Data Set The clock parent data set is defined in the IEEE 1588 standard. The parent data set is dynamic. Object Description  Parent Port Identity Clock identity for the parent clock, if the local clock is not a slave, the value is the clocks own id.
  • Page 326 User’s Manual of IGS-5225 series  2 Step Flag Static member: defined by the system, true if two-step Sync events and Pdelay_Resp events are used  Ports The total number of physical ports in the node  Clock Identity It shows unique clock identifier ...
  • Page 327 User’s Manual of IGS-5225 series Object Description  UtcOffset In systems whose epoch is UTC, it is the offset between TAI and UTC  Valid When true, the value of currentUtcOffset is valid  leap59 When true, this field indicates that last minute of the current UTC day has only 59 seconds.

  • Page 328: Ptp Status

    User’s Manual of IGS-5225 series 4.3.20.2 PTP Status This page allows the user to inspect the current PTP clock settings in Figure 4-3-20-2 appears. Figure 4-3-20-2: PTP Clock Monitor Page Object Description  Inst Indicates the Instance of a particular Clock Instance [0..3].

  • Page 329: Qos

    User’s Manual of IGS-5225 series 4.4 QoS 4.4.1 General Quality of Service (QoS) is an advanced traffic prioritization feature that allows you to establish control over network traffic. QoS enables you to assign various grades of network service to different types of traffic, such as multi-media, video, protocol- specific, time critical, and file-backup traffic.

  • Page 330: Port Classification

    User’s Manual of IGS-5225 series 4.4.1.1 Port Classification This page allows you to configure the basic QoS Classification settings for all switch ports. The Port classification screen in Figure 4-4-1-1 appears. Figure 4-4-1-1: QoS Ingress Port Policers Page Screenshot The page includes the following fields:...
  • Page 331 User’s Manual of IGS-5225 series  DEI Controls the default value. All frames are classified to a DEI value. If the port is VLAN aware and the frame is tagged, then the frame is classified to the DEI value in the tag. Otherwise the frame is classified to the default DEI value.

  • Page 332: Queue Policing

    User’s Manual of IGS-5225 series 4.4.1.2 Queue Policing This page allows you to configure the Queue Policer settings for all switch ports.. The Queue Policing screen in Figure 4-4-1-2 appears. Figure 4-4-1-2 : QoS Ingress Port Classification Page Screenshot The page includes the following fields:...

  • Page 333: Port Tag Remarking

    User’s Manual of IGS-5225 series 4.4.1.3 Port Tag Remarking This page provides an overview of QoS Egress Port Tag Remarking for all switch ports. The Port tag remarking screen in Figure 4-4-1-3 appears. Figure 4-4-1-3: Port Tag Remarking Page Screenshot...

  • Page 334: Statistics

    User’s Manual of IGS-5225 series 4.4.1.4 Statistics This page provides statistics for the different queues for all switch ports. The statistics screen in Figure 4-4-1-5 appears. Figure 4-4-1-5: QoS Statistics Page Screenshot The page includes the following fields: Object Description ...

  • Page 335: Bandwidth Control

    User’s Manual of IGS-5225 series 4.4.2 Bandwidth Control 4.4.2.1 Port Policing This page allows you to configure the Policer settings for all switch ports. The Port Policing screen in Figure 4-4-2-1 appears. Figure 4-4-2-1: QoS Ingress Port Policers Page Screenshot...

  • Page 336: Port Schedule

    User’s Manual of IGS-5225 series 4.4.2.2 Port Schedule The Port Scheduler and Shapers for a specific port are configured on this page. The QoS Egress Port Schedule and Shaper screen in Figure 4-4-2-2 appears. Figure 4-4-2-2: QoS Egress Port Schedule and Shapers Page Screenshot...
  • Page 337 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Schedule Mode Controls whether the scheduler mode is "Strict Priority" or "Weighted" on this switch port.  Queue Shaper Enable Controls whether the queue shaper is enabled for this queue on this switch port.

  • Page 338: Port Shaping

    User’s Manual of IGS-5225 series 4.4.2.3 Port Shaping This page provides an overview of QoS Egress Port Shapers for all switch ports. The Port shaping screen in Figure 4-4-2-3 appears. Figure 4-4-2-3: QoS Egress Port Schedule and Shapers Page Screenshot...
  • Page 339 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Schedule Mode Controls whether the scheduler mode is "Strict Priority" or "Weighted" on this switch port.  Queue Shaper Enable Controls whether the queue shaper is enabled for this queue on this switch port.

  • Page 340: Storm Control

    User’s Manual of IGS-5225 series 4.4.3 Storm Control 4.4.3.1 Storm Policing Storm control for the switch is configured on this page. There is a unicast storm rate control, multicast storm rate control, and a broadcast storm rate control. These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC Address table.

  • Page 341: Differentiated Service

    User’s Manual of IGS-5225 series 4.4.4 Differentiated Service 4.4.4.1 Port DSCP This page allows you to configure the basic QoS Port DSCP Configuration settings for all switch ports. The Port DSCP screen Figure 4-9-8 appears. Figure 4-4-4-1: QoS Port DSCP Configuration Page Screenshot...

  • Page 342: Dscp-Based Qos

    User’s Manual of IGS-5225 series always taken from the 'DSCP Translation->Egress Remap DP0' table.  Remap DP Aware: DSCP from analyzer is remapped and frame is remarked with remapped DSCP value. Depending on the DP level of the frame, the remapped DSCP value is either taken from the 'DSCP Translation->Egress Remap DP0' table or from the 'DSCP Translation-...

  • Page 343: Dscp Translation

    User’s Manual of IGS-5225 series 4.4.4.3 DSCP Translation This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in Ingress or Egress. The DSCP Translation screen in Figure 4-4-4-3 appears.

  • Page 344: Dscp Classification

    User’s Manual of IGS-5225 series 4.4.4.4 DSCP Classification This page allows you to map DSCP value to a QoS Class and DPL value. The DSCP Classification screen in Figure 4-4-4-4 appears. Figure 4-4-4-4: DSCP Classification Page Screenshot The page includes the following fields:...

  • Page 345: Qcl

    User’s Manual of IGS-5225 series 4.4.5 QCL 4.4.5.1 QoS Control List This page shows the QoS Control List(QCL), which is made up of the QCEs. Each row describes a QCE that is defined. The maximum number of QCEs is 256 on each switch.
  • Page 346 User’s Manual of IGS-5225 series  Frame Type Indicates the type of frame to look for incoming frames. Possible frame types are: Any: The QCE will match all frame type. ■ Ethernet: Only Ethernet frames (with Ether Type 0x600-0xFFFF) ■...

  • Page 347: Qos Control Entry Configuration

    User’s Manual of IGS-5225 series 4.4.5.2 QoS Control Entry Configuration The QCE Configuration screen in Figure 4-4-5-2 appears. Figure 4-4-5-2: QCE Configuration Page Screenshot The page includes the following fields: Object Description Check the checkbox button in case you what to make any port member of the ...
  • Page 348 User’s Manual of IGS-5225 series Allow all types of frames.  Any Ethernet Type Valid Ethernet type can have value within 0x600-0xFFFF or 'Any'  EtherType but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is 'Any'. SSAP Address Valid SSAP(Source Service Access Point) can vary from ■...

  • Page 349: Qcl Status

    User’s Manual of IGS-5225 series 4.4.5.3 QCL Status This page shows the QCL status by different QCL users. Each row describes the QCE that is defined. It is a conflict if a specific QCE is not applied to the hardware due to hardware limitations. The maximum number of QCEs is 256 on each switch. The...

  • Page 350: Voice Vlan

    User’s Manual of IGS-5225 series 4.4.6 Voice VLAN 4.4.6.1 Voice VLAN Configuration The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can classify and schedule network traffic. It is recommended that there be two VLANs on a port - one for voice, one for data.
  • Page 351 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Mode Indicates the Voice VLAN mode operation. We must disable MSTP feature before we enable Voice VLAN. It can avoid the conflict of ingress filter. Possible modes are: Enabled: Enable Voice VLAN mode operation.

  • Page 352: Voice Vlan Oui Table

    User’s Manual of IGS-5225 series 4.4.6.2 Voice VLAN OUI Table Configure VOICE VLAN OUI table on this page. The maximum entry number is 16. Modifying the OUI table will restart auto detection of OUI process. The Voice VLAN OUI Table screen in Figure 4-4-6-2 appears.

  • Page 353: Security

    User’s Manual of IGS-5225 series 4.5 Security 4.5.1 Access Security 4.5.1.1 Authentication Method The authentication section allows you to configure how a user is authenticated when he logs into the switch via one of the management client interfaces. The table has one row for each client type and a number of columns, which are:...
  • Page 354 User’s Manual of IGS-5225 series Command Authorization Method Configuration The command authorization section allows you to limit the CLI commands available to a user. The table has one row for each client type and a number of columns, which are:...
  • Page 355 User’s Manual of IGS-5225 series The displayed settings are: Object Description  Client The management client for which the configuration below applies.  Method Method can be set to one of the following values:  no: Accounting is disabled. ...

  • Page 356: Access Management

    User’s Manual of IGS-5225 series 4.5.1.2 Access Management Configure access management table on this page. The maximum entry number is 16. If the application's type match any one of the access management entries, it will allow access to the switch. The Access Management Configuration screen in...

  • Page 357: Access Management Statistics

    User’s Manual of IGS-5225 series 4.5.1.3 Access Management Statistics This page provides statistics for access management. The Access Management Statistics screen in Figure 4-5-1-2 appears. Figure 4-5-1-2: Access Management Statistics Overview Page Screenshot The page includes the following fields: Object Description ...

  • Page 358: Ssh

    User’s Manual of IGS-5225 series 4.5.1.4 SSH Configure SSH on this page. This page shows the Port Security status. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.

  • Page 359: Https

    User’s Manual of IGS-5225 series 4.5.1.5 HTTPs Configure HTTPS on this page. The HTTPS Configuration screen in Figure 4-5-1-4 appears. Figure 4-5-1-4: HTTPS Configuration Screen Page Screenshot The page includes the following fields: Object Description  Mode Indicates the HTTPS mode operation. When the current connection is HTTPS, to apply HTTPS disabled mode operation will automatically redirect web browser to an HTTP connection.
  • Page 360 User’s Manual of IGS-5225 series  Certificate Upload Upload a certificate PEM file into the switch. The file should contain the certificate and private key together. If you have two separated files for saving certificate and private key. Use the Linux cat command to combine them into a single PEM file.

  • Page 361: Aaa

    User’s Manual of IGS-5225 series 4.5.2 AAA This section is to control the access to the Industrial Managed Switch, including the user access and management control. The Authentication section contains links to the following main topics:  User Authentication ...

  • Page 362: Understanding Ieee 802.1X Port-Based Authentication

    User’s Manual of IGS-5225 series Overview of User Authentication It is allowed to configure the Industrial Managed Switch to authenticate users logging into the system for management access using local or remote authentication methods, such as telnet and Web browser. This Industrial Managed Switch provides secure network management access using the following options: ...
  • Page 363 User’s Manual of IGS-5225 series Device Roles  With 802.1X port-based authentication, the devices in the network have specific roles as shown below. Figure 4-5-2-1  Client—the device (workstation) that requests access to the LAN and switch services and responds to requests from the switch.
  • Page 364 User’s Manual of IGS-5225 series Authentication Initiation and Message Exchange  The switch or the client can initiate authentication. If you enable authentication on a port by using the dot1x port-control auto interface configuration command, the switch must initiate authentication when it determines that the port link state transitions from down to up.
  • Page 365 User’s Manual of IGS-5225 series Ports in Authorized and Unauthorized States  The switch port state determines whether or not the client is granted access to the network. The port starts in the unauthorized state. While in this state, the port disallows all ingress and egress traffic except for 802.1X protocol packets. When a client is successfully authenticated, the port transitions to the authorized state, allowing all traffic for the client to flow normally.

  • Page 366: Authentication Configuration

    User’s Manual of IGS-5225 series 4.5.2.1 Authentication Configuration This page allows you to configure how a user is authenticated when he logs into the switch via one of the management client interfaces. The Authentication Method Configuration screen in Figure 4-5-2-3 appears.
  • Page 367 User’s Manual of IGS-5225 series  Methods Method can be set to one of the following values:  no: Authentication is disabled and login is not possible.  local: Use the local user database on the switch for authentication. ...
  • Page 368 User’s Manual of IGS-5225 series Accounting Method Configuration The accounting section allows you to configure command and exec (login) accounting. The table has one row for each client type and a number of columns, which are: Object Description  Client The management client for which the configuration below applies.

  • Page 369: Radius

    User’s Manual of IGS-5225 series 4.5.2.2 RADIUS This page allows you to configure the RADIUS Servers. The RADIUS Configuration screen in Figure 4-5-2-4 appears. Figure 4-5-2-4: RADIUS Server Configuration Page Screenshot The page includes the following fields: Global Configuration These setting are common for all of the RADIUS Servers.

  • Page 370: Server Configuration

    User’s Manual of IGS-5225 series  NAS-Identifier The identifier - up to 253 characters long - to be used as attribute 32 in RADIUS (Attribute 32) Access-Request packets. If this field is left blank, the NAS-Identifier is not included in the packet.

  • Page 371: Tacacs

    User’s Manual of IGS-5225 series 4.5.2.3 TACACS+ This page allows you to configure the TACACS+ Servers. The TACACS+ Configuration screen in Figure 4-5-2-5 appears. Figure 4-5-2-5: TACACS+ Server Configuration Page Screenshot The page includes the following fields: Global Configuration These setting are common for all of the TACACS+ Servers.
  • Page 372 User’s Manual of IGS-5225 series Server Configuration The table has one row for each TACACS+ server and a number of columns, which are: Object Description  Delete To delete a TACACS+ server entry, check this box. The entry will be deleted during the next Save.

  • Page 373: Radius Overview

    User’s Manual of IGS-5225 series 4.5.2.4 RADIUS Overview This page provides an overview of the status of the RADIUS servers configurable on the authentication configuration page. The RADIUS Authentication/Accounting Server Overview screen in Figure 4-5-2-6 appears. Figure 4-5-2-6: RADIUS Authentication/Accounting Server Overview Page Screenshot...

  • Page 374: Radius Details

    User’s Manual of IGS-5225 series Dead (X seconds left): Access attempts were made to this server, but it did not reply within the configured timeout. The server has temporarily been disabled, but will get re-enabled when the dead-time expires. The number of seconds left before this occurs is displayed in parentheses.

  • Page 375: Radius Authentication Statistics

    User’s Manual of IGS-5225 series The page includes the following fields: RADIUS Authentication Statistics The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client MIB. Use the server select box to switch between the backend servers to show details for.
  • Page 376 User’s Manual of IGS-5225 series Packets radiusAuthClientExt The number of RADIUS packets Dropped PacketsDropped that were received from the server on the authentication port and dropped for some other reason. Access radiusAuthClientExt The number of RADIUS Access- Requests AccessRequests Request packets sent to the server.

  • Page 377: Radius Accounting Statistics

    User’s Manual of IGS-5225 series  Disabled: The selected server is disabled.  Not Ready: The server is enabled, but IP communication is not yet up and running.  Ready: The server is enabled, IP communication is up and running, and the RADIUS module is ready to accept access attempts.
  • Page 378 User’s Manual of IGS-5225 series radiusAcctClientExt The number of RADIUS packets Authenticator BadAuthenticators containing invalid authenticators received from the server. Unknown radiusAccClientExt The number of RADIUS packets Types UnknownTypes of unknown types that were received from the server on the accounting port.
  • Page 379 User’s Manual of IGS-5225 series Name RFC4670 Name Description IP Address IP address and UDP port for the accounting server in question. State Shows the state of the server. It takes one of the following values:  Disabled: The selected server is disabled.

  • Page 380: Port Authentication

    User’s Manual of IGS-5225 series 4.5.3 Port Authentication 4.5.3.1 Network Access Server Configuration This page allows you to configure the IEEE 802.1X and MAC-based authentication system and port settings. The IEEE 802.1X standard defines a port-based access control procedure that prevents unauthorized access to a network by requiring users to first submit credentials for authentication.
  • Page 381 User’s Manual of IGS-5225 series The page includes the following fields: System Configuration Object Description  Mode Indicates if NAS is globally enabled or disabled on the switch. If globally disabled, all ports are allowed forwarding of frames.  Reauthentication...
  • Page 382 User’s Manual of IGS-5225 series the client is still attached or not, and the only way to free any resources is to age the entry.  Hold Time This setting applies to the following modes, i.e. modes using the Port Security functionality to secure MAC addresses: Single 802.1X...
  • Page 383 User’s Manual of IGS-5225 series timeout. The switch follows a set of rules for entering and leaving the Guest VLAN as listed below. The "Guest VLAN Enabled" checkbox provides a quick way to globally enable/disable Guest VLAN functionality. When checked, the individual ports' ditto setting determines whether the port can be moved into Guest VLAN.

  • Page 384: Network Access Overview

    User’s Manual of IGS-5225 series 4.5.3.2 Network Access Overview This page provides an overview of the current NAS port states for the selected switch. The Network Access Overview screen in Figure 4-5-3-2 appears. Figure 4-5-3-2: Network Access Server Switch Status Page Screenshot...

  • Page 385: Network Access Statistics

    User’s Manual of IGS-5225 series 4.5.3.3 Network Access Statistics This page provides detailed NAS statistics for a specific switch port running EAPOL-based IEEE 802.1X authentication. For MAC-based ports, it shows selected backend server (RADIUS Authentication Server) statistics, only. Use the port select box to select which port details to be displayed.

  • Page 386: Port Counters

    User’s Manual of IGS-5225 series Port Counters Object Description  EAPOL Counters These supplicant frame counters are available for the following administrative states: Force Authorized ■ Force Unauthorized ■ Port-based 802.1X ■ Single 802.1X ■ Multi 802.1X ■ Direction Name...
  • Page 387 User’s Manual of IGS-5225 series transmitted by the switch. Request ID dot1xAuthEapolR The number of EAPOL Request eqIdFramesTx Identity frames that have been transmitted by the switch. Requests dot1xAuthEapolR The number of valid EAPOL eqFramesTx Request frames (other than Request Identity frames) that have been transmitted by the switch.
  • Page 388 User’s Manual of IGS-5225 series Auth. dot1xAuthBackend 802.1X- and MAC-based: Successes AuthSuccesses Counts the number of times that the switch receives a success indication. Indicates that the supplicant/client has successfully authenticated to the backend server. Auth. dot1xAuthBackend 802.1X- and MAC-based:...
  • Page 389 User’s Manual of IGS-5225 series Address ameSource VLAN ID The VLAN ID on which the last frame from the last supplicant/client was received. Version dot1xAuthLastEapolFr 802.1X-based: ameVersion The protocol version number carried in the most recently received EAPOL frame. MAC-based: Not applicable.

  • Page 390: Port Security

    User’s Manual of IGS-5225 series 4.5.4 Port Security 4.5.4.1 Port Security Limit Control This page allows you to configure the Port Security global and per-port settings. Port Security allows for limiting the number of users on a given port. A user is identified by a MAC address and VLAN ID. If Port Security is enabled on a port, the limit specifies the maximum number of users on the port.
  • Page 391 User’s Manual of IGS-5225 series under Aging Period  Aging Period If Aging Enabled is checked, then the aging period is controlled with this input. If other modules are using the underlying port security for securing MAC addresses, they may have other requirements to the aging period. The underlying port security will use the shorter requested aging period of all modules that use the functionality.
  • Page 392 User’s Manual of IGS-5225 series The switch is "born" with a total number of MAC addresses from which all ports draw whenever a new MAC address is seen on a Port Security-enabled port. Since all ports draw from the same pool, it may happen that a configured maximum cannot be granted, if the remaining ports have already used all available MAC addresses.

  • Page 393: Port Security Status

    User’s Manual of IGS-5225 series 4.5.4.2 Port Security Status This page shows the Port Security status. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
  • Page 394 User’s Manual of IGS-5225 series  Abbr A one-letter abbreviation of the user module. This is used in the Users column in the port status table. Port Status The table has one row for each port on the selected switch in the switch and a number of columns, which are:...

  • Page 395: Port Security Detail

    User’s Manual of IGS-5225 series 4.5.4.3 Port Security Detail This page shows the MAC addresses secured by the Port Security module. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.

  • Page 396: Mac Address

    User’s Manual of IGS-5225 series 4.5.4.4 MAC Address On this page, you may add and delete static and sticky MAC addresses managed by Port Security. Port security defines three types of MAC addresses, of which static and sticky can be added and removed on this page: ...
  • Page 397 User’s Manual of IGS-5225 series The displayed settings are: Object Description  Delete Press this button to remove the entry from the MAC address table (if present) and the running-config. Notice that dynamic entries may be removed all-together on an interface through "Monitor→Security→Port Security→Switch"...

  • Page 398: Access Control Lists

    User’s Manual of IGS-5225 series 4.5.5 Access Control Lists ACL is an acronym for Access Control List. It is the list table of ACEs, containing access control entries that specify individual users or groups permitted or denied to specific traffic objects, such as a process or a program.
  • Page 399 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  User Indicates the ACL user.  ACE Indicates the ACE ID on local switch.  Frame Type Indicates the frame type of the ACE. Possible values are: Any: The ACE will match any frame type.

  • Page 400: Acl Configuration

    User’s Manual of IGS-5225 series 4.5.5.2 ACL Configuration This page shows the Access Control List (ACL), which is made up of the ACEs defined on this switch. Each row describes the ACE that is defined. The maximum number of ACEs is 512 on each switch.
  • Page 401 User’s Manual of IGS-5225 series  Rate Limiter Indicates the rate limiter number of the ACE. The allowed range is 1 to 16. When Disabled is displayed, the rate limiter operation is disabled.  Port Redirect Indicates the port redirect operation of the ACE. Frames matching the ACE are redirected to the port number.

  • Page 402: Ace Configuration

    User’s Manual of IGS-5225 series 4.5.5.3 ACE Configuration Configure an ACE (Access Control Entry) on this page. An ACE consists of several parameters. These parameters vary according to the frame type that you select. First select the ingress port for the ACE, and then select the frame type. Different parameter options are displayed depending on the frame type selected.
  • Page 403 User’s Manual of IGS-5225 series  Select the frame type for this ACE. These frame types are mutually exclusive. Frame Type Any: Any frame can match this ACE. ■ Ethernet Type: Only Ethernet Type frames can match this ACE. The IEEE ■...

  • Page 404: Mac Parameters

    User’s Manual of IGS-5225 series MAC Parameters  Object Description  SMAC Filter (Only displayed when the frame type is Ethernet Type or ARP.) Specify the source MAC filter for this ACE. Any: No SMAC filter is specified. (SMAC filter status is "don't-care".) ■...

  • Page 405: Arp Parameters

    User’s Manual of IGS-5225 series Object Description  802.1Q Tagged Specify whether frames can hit the action according to the 802.1Q tagged. The allowed values are: Any: Any value is allowed ("don't-care"). Enabled: Tagged frame only. Disabled: Untagged frame only.
  • Page 406 User’s Manual of IGS-5225 series Object Description  Specify the available ARP/RARP opcode (OP) flag for this ACE. ARP/RARP Any: No ARP/RARP OP flag is specified. (OP is "don't-care".) ■ ARP: Frame must have ARP/RARP opcode set to ARP. ■...
  • Page 407 User’s Manual of IGS-5225 series Any: Any value is allowed ("don't-care"). ■  IP/Ethernet Length Specify whether frames can hit the action according to their ARP/RARP hardware address length (HLN) and protocol address length (PLN) settings. 0: ARP/RARP frames where the HLN is equal to Ethernet (0x06) and the ■...
  • Page 408 User’s Manual of IGS-5225 series Object Description  Specify the IP protocol filter for this ACE. IP Protocol Filter Any: No IP protocol filter is specified ("don't-care"). ■ Specific: If you want to filter a specific IP protocol filter with this ACE, ■...

  • Page 409: Ipv6 Parameters

    User’s Manual of IGS-5225 series  SIP Filter Specify the source IP filter for this ACE. Any: No source IP filter is specified. (Source IP filter is "don't-care".) ■ Host: Source IP filter is set to Host. Specify the source IP address in the ■...
  • Page 410 User’s Manual of IGS-5225 series Object Description  Specify the IPv6 next header filter for this ACE. Next Header Filter Any: No IPv6 next header filter is specified ("don't-care"). ■ Specific: If you want to filter a specific IPv6 next header filter with this ■...

  • Page 411: Icmp Parameters

    User’s Manual of IGS-5225 series ICMP Parameters  Object Description  ICMP Type Filter Specify the ICMP filter for this ACE. Any: No ICMP filter is specified (ICMP filter status is "don't-care"). ■ Specific: If you want to filter a specific ICMP filter with this ACE, you can ■...
  • Page 412 User’s Manual of IGS-5225 series Object Description  Specify the TCP/UDP source filter for this ACE. TCP/UDP Source Filter Any: No TCP/UDP source filter is specified (TCP/UDP source filter status ■ is "don't-care"). Specific: If you want to filter a specific TCP/UDP source filter with this ■...
  • Page 413 User’s Manual of IGS-5225 series  TCP SYN Specify the TCP "Synchronize sequence numbers" (SYN) value for this ACE. 0: TCP frames where the SYN field is set must not be able to match this ■ entry. 1: TCP frames where the SYN field is set must be able to match this entry.
  • Page 414 User’s Manual of IGS-5225 series Object Description  Specify the Ethernet type filter for this ACE. EtherType Filter Any: No EtherType filter is specified (EtherType filter status is ■ "don't-care"). Specific: If you want to filter a specific EtherType filter with this ■...

  • Page 415: Acl Ports Configuration

    User’s Manual of IGS-5225 series 4.5.5.4 ACL Ports Configuration Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame matches a specific ACE. The ACL Ports Configuration screen in Figure 4-5-5-4 appears.
  • Page 416 User’s Manual of IGS-5225 series  Logging Specify the logging operation of this port. The allowed values are: Enabled: Frames received on the port are stored in the System Log. ■ Disabled: Frames received on the port are not logged.

  • Page 417: Acl Rate Limiters

    User’s Manual of IGS-5225 series 4.5.5.5 ACL Rate Limiters Configure the rate limiter for the ACL of the switch. The ACL Rate Limiter Configuration screen in Figure 4-5-5-5 appears. Figure 4-5-5-5: ACL Rate Limiter Configuration Page Screenshot The page includes the following fields:...

  • Page 418: Dhcp Snooping

    User’s Manual of IGS-5225 series 4.5.6 DHCP Snooping DHCP Snooping is used to block intruder on the untrusted ports of DUT when it tries to intervene by injecting a bogus DHCP reply packet to a legitimate conversation between the DHCP client and server.

  • Page 419: Dhcp Snooping Configuration

    User’s Manual of IGS-5225 series 4.5.6.1 DHCP Snooping Configuration Configure DHCP Snooping on this page. in Figure 4-5-6-1 appears. Figure 4-5-6-1: DHCP Snooping Configuration Screen Page Screenshot The page includes the following fields: Object Description  Snooping Mode Indicates the DHCP snooping mode operation. Possible modes are: ...

  • Page 420: Dynamic Dhcp Snooping Table

    User’s Manual of IGS-5225 series 4.5.6.2 Dynamic DHCP Snooping Table This page display the dynamic IP assigned information after DHCP Snooping mode is disabled. All DHCP clients obtained the dynamic IP address from the DHCP server will be listed in this table except for local VLAN interface IP addresses.

  • Page 421: Dhcpv6 Snooping

    User’s Manual of IGS-5225 series 4.5.7 DHCPv6 Snooping 4.5.7.1 DHCPv6 Snooping Configuration 4.5.8 IP Source Guard 4.5.8.1 IP Source Guard Configuration IP Source Guard is a secure feature used to restrict IP traffic on DHCP snooping untrusted ports by filtering traffic based on the DHCP Snooping Table or manually configured IP Source Bindings.

  • Page 422: Static Ip Source Guard Static Table

    User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Mode of IP Source Enable the Global IP Source Guard or disable the Global IP Source Guard. All Guard Configuration configured ACEs will be lost when the mode is enabled.

  • Page 423: Dynamic Ip Source Guard Table

    User’s Manual of IGS-5225 series 4.5.8.3 Dynamic IP Source Guard Table This page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-5-7-3 appears. Figure 4-5-7-3: Static IP Source Guard Table Screen Page Screenshot...

  • Page 424: Ipv6 Source Guard

    User’s Manual of IGS-5225 series 4.5.9 IPv6 Source Guard 4.5.9.1 IPv6 Source Guard Configuration This page provides IPv6 Source Guard related configuration. The IPv6 Source Guard Configuration screen in Figure 4-5-8-1 appears. Figure 4-5-8-1: IPv6 Source Guard Configuration Screen Page Screenshot...

  • Page 425: Ipv6 Source Guard Static Table

    User’s Manual of IGS-5225 series 4.5.9.2 IPv6 Source Guard Static Table This page shows the static IPv6 Source Guard entries. The maximum number of entries is 112 on the switch. The IPv6 Source Guard Static Table screen in Figure 4-5-8-2 appears.

  • Page 426: Ipv6 Source Guard Dynamic Table

    User’s Manual of IGS-5225 series 4.5.9.3 IPv6 Source Guard Dynamic Table All dynamic entries are shown in the table which can be scrolled up and down when the number of entries exeeds the space allotted for the table. The IPv6 Source Guard Dynamic Table screen in Figure 4-5-8-3 appears.

  • Page 427: Arp Inspection

    User’s Manual of IGS-5225 series 4.5.10 ARP Inspection 4.5.10.1 ARP Inspection Configuration ARP Inspection is a secure feature. Several types of attacks can be launched against a host or devices connected to Layer 2 networks by "poisoning" the ARP caches. This feature is used to block such attacks. Only valid ARP requests and responses can go through DUT.
  • Page 428 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Mode of ARP Inspection Enable the Global ARP Inspection or disable the Global ARP Inspection. Configuration  Port Mode Configuration Specify ARP Inspection is enabled on which ports. Only when both Global Mode and Port Mode on a given port are enabled, ARP Inspection is enabled on this given port.

  • Page 429: Vlan Configuration

    User’s Manual of IGS-5225 series 4.5.10.2 VLAN Configuration Each page shows up to 9999 entries from the VLAN table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found in the VLAN Table.

  • Page 430: Arp Inspection Static Table

    User’s Manual of IGS-5225 series 4.5.10.3 ARP Inspection Static Table This page provides Static ARP Inspection Table. The Static ARP Inspection Table screen in Figure 4-5-9-2 appears. Figure 4-5-9-2: Static ARP Inspection Table Screen Page Screenshot The page includes the following fields:...

  • Page 431: Dynamic Arp Inspection Table

    User’s Manual of IGS-5225 series 4.5.10.4 Dynamic ARP Inspection Table Entries in the Dynamic ARP Inspection Table are shown on this page. The Dynamic ARP Inspection Table contains up to 1024 entries, and is sorted first by port, then by VLAN ID, then by MAC address, and then by IP address. The Dynamic ARP...

  • Page 432: Poe

    User’s Manual of IGS-5225 series 4.6 PoE PoE Switch Introduction Providing IEEE 802.3at PoE+ or IEEE 802.3bt PoE++ in-line power interfaces, the IGS-5225 PoE Switch Series can easily build a power central-controlled IP phone system, IP Camera system, AP group for the enterprise. For instance, these cameras/APs can be easily installed around the corners of the company for surveillance demands or a wireless roaming environment in the office can be built.
  • Page 433 User’s Manual of IGS-5225 series PD Classifications A PD may be classified by the PSE based on the classification information provided by the PD. The intent of PD classification is to provide information about the maximum power required by the PD during operation. However, to improve power management at the PSE, the PD provides a signature about Class level.

  • Page 434: Poe System Configuration

    User’s Manual of IGS-5225 series 4.6.1 PoE System Configuration Under some conditions, the total output power required by PDs can exceed the maximum available power provided by the PSU. The system may come with a PSU capable of supplying less power than the total potential power consumption of all the PoE ports in the system.
  • Page 435 User’s Manual of IGS-5225 series For IGS-5225-4UP1T2S This section allows the user to inspect and configure the current PoE configuration settings, as Figure 4-6-1-2 appears. Figure 4-6-1-2: PoE Configuration Screenshot The page includes the following fields: Object Description  System PoE Admin Mode Allows user to enable or disable PoE function.
  • Page 436 User’s Manual of IGS-5225 series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. Dual power input is required for maximum PoE loading. PWR1 and PWR2 must provide the same DC voltage CAUTION for power load balance while operating with dual power input.
  • Page 437 User’s Manual of IGS-5225 series consumption.  Allocation mode: Users are allowed to assign how much PoE power for each port and system will reserve PoE power to PD.  Input Voltage Ste the Input Voltage: <= 24V DC (Factory default mode) 24V~48V DC >= 48V DC...
  • Page 438 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  System PoE Admin Mode This is PoE function administration mode for user to disable or enable PoE function.  PoE Management Mode There are two modes for configuring how the ports/PDs may reserve power and when to shut down ports.

  • Page 439: Port Configuration

    User’s Manual of IGS-5225 series 4.6.2 Port Configuration This section allows the user to inspect and configure the current PoE port settings as Figure 4-6-1-4 shows. 802.3bt PoE++ and Advanced PoE Power Output Mode Management  802.3bt PoE++ Switch – PoE Port Configuration...
  • Page 440 User’s Manual of IGS-5225 series  End-Span: Set inline mode to IEEE 802.3at PoE+ End-span PSE. Pins 1-2 (pair #2 in both T568A and T568B) form one side of the DC supply and pins 3-6 (pair #3 in both T568A and T568B) provide the return.
  • Page 441 PoE Extended Function In the “Extended” operation mode, the IGS-5225 series operates on a per-port basis at 10Mbps duplex operation but can support PoE power output over a distance of up to 250 meters overcoming the 100 meters limit on Ethernet UTP cable.
  • Page 442 User’s Manual of IGS-5225 series 802.3at PoE+ Switch – PoE Port Configuration  For IGS-5225-8P4S-12V Figure 4-6-1-4: Power over Ethernet Configuration Screenshot The page includes the following fields: Object Description  PoE Mode There are three modes for PoE mode.
  • Page 443 User’s Manual of IGS-5225 series  Force Power Once the force power is enabled, the PoE port will ignore the PoE classification behaviors and directly deliver power over UTP cable no matter what Ethernet device is attached, or even there is no Ethernet cable plugged.
  • Page 444 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Port This is the logical port number for this row.  PoE Mode For user to enable or disable per port PoE function. Default setting is "Enable".

  • Page 445: Status

    User’s Manual of IGS-5225 series 4.6.3 Status This page allows the user to inspect the total power consumption, total power reserved and current status for all PoE ports. The screen in Figure 4-6-1-5 appears. Figure 4-6-1-5:PoE Status Screenshot...
  • Page 446 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Sequential Power On Displays the current sequential power on mode.  PoE Voltage Displays the current PoE voltage.  Power Budget Displays the maximum PoE power budget.

  • Page 447: Port Sequential

    User’s Manual of IGS-5225 series 4.6.4 Port Sequential This page allows the user to configure the PoE Ports started up interval time. The PoE Port will start up one by one as Figure 4-6-1-6 shows. Figure 4-6-1-6: PoE Port Sequential Power Up Interval Configuration Screenshot The PoE port will start up after the whole system program has finished running.

  • Page 448: Schedule

    User’s Manual of IGS-5225 series 4.6.5 Schedule This page allows the user to define PoE schedule and schedule power recycle. PoE Schedule Besides being used as an IP Surveillance, the Managed PoE switch is certainly applicable to constructing any PoE network including VoIP and Wireless LAN.
  • Page 449 User’s Manual of IGS-5225 series Scheduled Power Recycling The Managed PoE switch allows each of the connected PoE IP cameras to reboot in a specific time each week. Therefore, it will reduce the chance of IP camera crash resulting from buffer overflow. The screen in Figure 4-6-1-7 appears.
  • Page 450 User’s Manual of IGS-5225 series Please press the Add New Rule button to start setting PoE Schedule function. You have to set PoE schedule to profile and then go back to PoE Port Configuration, and select “Schedule” mode from per port “PoE Mode” option. You can then indicate which schedule profile could be applied to the PoE port.

  • Page 451: Poe Alive Check Configuration

    User’s Manual of IGS-5225 series 4.6.6 PoE Alive Check Configuration The IGS-5225-4UP1T2S/IGS-5225-8P2T2S PoE Switch can be configured to monitor connected PD’s status in real-time via ping action. Once the PD stops working and without response, IGS-5225-4UP1T2S/IGS-5225-8P2T2S PoE Switch is going to restart PoE port port power, and bring the PD back to work.
  • Page 452 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Mode Allows user to enable or disable per port PD Alive Check function. As default value all ports are disabled.  Ping PD IP Address This coulumn allows user to set PoE device IP address here for system making ping to the PoE device.

  • Page 453: Port Power Consumption[Graphic 1~8]

    User’s Manual of IGS-5225 series 4.6.7 Port Power Consumption[graphic 1~8] This page shows user per port PoE power consumption status and PoE port setting. Figure: Port Power Consumption...

  • Page 454: Lldp Poe Neighbors

    User’s Manual of IGS-5225 series 4.6.8 LLDP PoE Neighbors This page provides a status overview for all LLDP PoE neighbors. The displayed table contains a row for each interface on which an LLDP PoE neighbor is detected. The columns hold the following information:: The screen in Figure 4-6-1-9 appears.

  • Page 455: Ring

    User’s Manual of IGS-5225 series 4.7 Ring 4.7.1 Ring Wizard This page is on ring wizard and it is an interface for user to configure ERPS ring feature. This wizard uses the fixed ring topology to indicate the ring owner, so if user needs to indicate the other switch to the ring owner or modify the ring topology, please modify MEP and ERPS settings manually.

  • Page 456: Ring Wizard Example

    User’s Manual of IGS-5225 series the configuration should be as follows: 2.We are creating a ring that it is built by 10 switches and we are configuring the 2nd switch. 3.We are creating a ring that it is built by 10 switches and we are configuring the 10th switch.
  • Page 457 User’s Manual of IGS-5225 series The scenario described as follows: Disable DHCP client and set proper static IP for Switch 1, 2 & 3. In this example, switch 1 is 192.168.0.101; switch 2 is 192.168.0.102 and switch 3 is 192.168.0.103.
  • Page 458 User’s Manual of IGS-5225 series Set ERPS Configuration on Switch 3 Connect PC to switch 3 directly; don’t connect to port 1 & 2 Logging on the Switch 3 and click “Ring > Ring Wizard” Set “All Switch Number” = 3 and “Number ID” = 3; click “Next” button to set the ERPS configuration for Switch 3.

  • Page 459: Erps

    User’s Manual of IGS-5225 series 4.7.2 ERPS The ERPS instances are configured here. ERPS Figure : configuration The page includes the following fields: Object Description  ERPS # The ID of ERPS. Valid range 1 - 64  RPL Mode Ring Protection Link mode.
  • Page 460 User’s Manual of IGS-5225 series  Node Id The Node ID is used inside the R-APS specific PDU to uniquely identify this node (switch) on the ring.  Level MD/MEG Level of R-APS PDUs we transmit.  Control VLAN The VLAN on which R-APS PDUs are transmitted and received on the ring ports.

  • Page 461: Erps-- Erps Configuration

    User’s Manual of IGS-5225 series 4.7.2.1 ERPS-- ERPS Configuration ERPS is an abbreviation for Ethernet Ring Protection Switching defined in ITU/T G.8032. It provides fast protection and recovery switching for Ethernet traffic in a ring topology while also ensuring that the Ethernet layer remains loop-free.

  • Page 462: Erps--Signal Fail Trigger

    User’s Manual of IGS-5225 series 4.7.2.2 ERPS--Signal Fail Trigger Object Description  Type Selects whether Signal Fail (SF) comes from the link state of a given interface, or from a Down-MEP.  Domain, Service, Identification of the MEP instance to provide Signal Fail, if Type is MEP.

  • Page 463: Erps-- Erps Status

    User’s Manual of IGS-5225 series 4.7.2.4 ERPS-- ERPS Status This table shows the current configuration for this ERPS instance. Go to the ERPS Configuration help page for further explanation. ERPS Figure : Status Configuration...
  • Page 464 User’s Manual of IGS-5225 series The displayed settings are: Object Description  Status This shows the current status of the ERPS instance. Go to the ERPS Status help page for further explanation.  Status Ports This shows the current status of the ERPS instance. Go to the ERPS Status help page for further explanation.

  • Page 465: Erps--Erps Command

    User’s Manual of IGS-5225 series 4.7.2.5 ERPS--ERPS Command Object Description  Command No request: There is no active local command on this instance. Issuing this command has no effect. Clear: Clear a switchover (FS or MS) request and a WTB/WTR condition and force reversion even if not revertive.

  • Page 466: Erps Status

    User’s Manual of IGS-5225 series 4.7.3 ERPS Status This shows the current status of the ERPS instances. screen in below appears. This shows ERPS current status Figure: The page includes the following fields: Object Description  ERPS # The ID of the ERPS. Click on link to get to ERPS detailed instance page, you can reset counters and issue commands.

  • Page 467: Aps

    User’s Manual of IGS-5225 series 4.7.4 APS 4.7.4.1 APS Configuration The APS module implements the protocol and linear protection switching mechanisms for point-to-point VLAN- based ETH SNC in Ethernet transport networks. Automatic Protection Switching is defined by the ITU G.8031 standard.
  • Page 468 User’s Manual of IGS-5225 series  Level MD/MEG Level (0-7).  VLAN The VLAN ID used in the L-APS PDUs. 0 means untagged.  PCP PCP (priority) (default 7). The PCP value used in the VLAN tag unless the L-APS PDU is untagged.

  • Page 469: Aps Configuration Data

    User’s Manual of IGS-5225 series 4.7.4.2 APS Configuration Data The APS module implements the protocol and linear protection switching mechanisms for point-to-point VLAN-based ETH SNC in Ethernet transport networks. Automatic Protection Switching is defined by the ITU G.8031 standard. The displayed settings are:...
  • Page 470 User’s Manual of IGS-5225 series  VLAN The VLAN ID used in the L-APS PDUs. 0 means untagged.  PCP PCP (priority) (default 7). The PCP value used in the VLAN tag unless the L- APS PDU is untagged. Must be a value in range 0 - 7.

  • Page 471: Aps Status

    User’s Manual of IGS-5225 series 4.7.4.3 APS Status This shows the current status of the APS instances. The displayed settings are: Object Description  APS # The ID of the APS. Click on link to get to APS instance page, you can reset counters and issue commands.
  • Page 472 User’s Manual of IGS-5225 series  State, Warning If the operational state is Active, the APS instance is indeed active, but it may be that it doesn't run as the administrator thinks, because of configuration errors, which are reflected in the warnings below.
  • Page 473 User’s Manual of IGS-5225 series  TxAps, ReSignal Transmitted requested signal according to G.8031 figure 11-2  TxAps, BrSignal Transmitted bridged signal according to G.8031 figure 11-2  RxAps, ReSignal Received requested signal according to G.8031 figure 11-2  RxAps, BrSignal Received bridged signal according to G.8031 figure 11-2...

  • Page 474: Onvif

    User’s Manual of IGS-5225 series 4.8 ONVIF 4.8.1 ONVIF Switch Introduction ONVIF (Open Network Video Interface Forum) is a global and open industry forum with the goal of facilitating the development and use of a global open standard for the interface of physical IP-based security products – or, in other words, to create a standard for how IP products within video surveillance and other physical security areas can communicate with each other.

  • Page 475: Onvif Device Search

    User’s Manual of IGS-5225 series 4.8.2 ONVIF Device Search Entries in the ONVIF Devices Table are shown on this page. The ONVIF Devices Table can be sorted first by VLAN ID, model, MAC Address and then by IP Address. The ONVIF Devices Table screen in Figure 4-8-1-1 appears.

  • Page 476: Onvif Device List

    User’s Manual of IGS-5225 series 4.8.3 ONVIF Device List This page provides an overview of ONVIF Device entries. Each page shows up to 10 entries from the ONVIF Device table list, default being 10, selected through the "entries per page" input field. When first visited, the web page will show the first 10...

  • Page 477: Map Upload / Edit

    User’s Manual of IGS-5225 series Buttons : Click to refresh the page immediately. Auto-refresh Check this box to refresh the page automatically. Automatic refresh occurs every 30 seconds. : To update the ONVIF device entries, press to go to the first page.

  • Page 478: Floor Map

    User’s Manual of IGS-5225 series 4.8.5 Floor Map This page allows the clients for planning the ONVIF devices with the uploaded e-Map. It can select the ONVIF devices from Device List and it also can modify the e-Map’s Zoom and Scale as the screen in Figure 4-8-1-4 appears.
  • Page 479 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Summary Information Shows the number of Online and Offline ONVIF cameras.  Map Control Allows to choose Location of Map1/2/3 and zoom in/out of Map.  Device List...

  • Page 480: Maintenance

    User’s Manual of IGS-5225 series 4.9 Maintenance 4.9.1 Switch Maintenance This chapter shows how to upgrade the firmware, how to save the switch running configure and how to download/upload the configure file, etc. 4.9.1.1 Web Firmware Upgrade This page facilitates an update on the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-9-1-1 appears.

  • Page 481: Save Startup Config

    User’s Manual of IGS-5225 series 4.9.1.2 Save Startup Config This function allows to save the current configuration, thereby ensuring that the current active configuration can be used at the next reboot as the screen in Figure 4-9-1-3 appears. After saving the configuration, the screen in Figure 4-9-1-4 will appear.

  • Page 482: Configuration Upload

    User’s Manual of IGS-5225 series 4.9.1.4 Configuration Upload Configuration Upload page allows the upload of the running-config and startup-config on the switch. Please refer to Figure 4-9- shown below. Figure 4-9-1-6: Configuration Upload Page Screenshot If the destination is running-config, the file will be applied to the switch configuration. This can be done in two ways: ...

  • Page 483: Configuration Activate

    User’s Manual of IGS-5225 series 4.9.1.5 Configuration Activate Thje Configure Activate page allows to activate the startup-config and default-config files present on the switch. Please refer to Figure 4-9-1-7 shown below. Figure 4-9-1-7: Configuration Activate Page Screenshot It is possible to activate any of the configuration files present on the switch, except for running-config which represents the currently active configuration.

  • Page 484: Image Select

    User’s Manual of IGS-5225 series 4.9.1.7 Image Select This page provides information about the active and alternate (backup) firmware images in the device, and allows you to revert to the alternate image. The web page displays two tables with information about the active and alternate firmware images. The...

  • Page 485: Factory Default

    User’s Manual of IGS-5225 series 4.9.1.8 Factory Default You can reset the configuration of the Industrial Managed Switch on this page. Only the IP configuration is retained. The new configuration is available immediately, which means that no restart is necessary. The Factory Default screen in Figure 4-9-1-10 appears.

  • Page 486: Cable Diagnostics

    User’s Manual of IGS-5225 series 4.9.2 Diagnostics This section provides the Physical layer and IP layer network diagnostics tools for troubleshooting. The diagnostic tools are designed for network manager to help them quickly diagnose problems between point to point and better service customers.

  • Page 487: Ping

    User’s Manual of IGS-5225 series 4.9.2.1 Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press “Start”, 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply.
  • Page 488 User’s Manual of IGS-5225 series Note: You may only specify either the VID or the IP Address for the source interface.  Source Port Number This field can be used to force the test to use a specific local interface with the specified port number as the source interface.

  • Page 489: Ipv6 Ping

    User’s Manual of IGS-5225 series 4.9.2.2 IPv6 Ping This page allows you to issue ICMPv6 ping packets to troubleshoot IPv6 connectivity issues. After you press “Start”, 5 ICMPv6 packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs.
  • Page 490 User’s Manual of IGS-5225 series  Source Port Number This field can be used to force the test to use a specific local interface with the specified port number as the source interface. The specified port must be configured with a suitable IP address. Leave this field empty for automatic selection based on routing configuration.

  • Page 491: Remote Ip Ping

    User’s Manual of IGS-5225 series 4.9.2.3 Remote IP Ping This page allows you to issue ICMP ping packets to troubleshoot IP connectivity issues on special port. After you press “Test”, 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs.

  • Page 492: Cable Diagnostics

    User’s Manual of IGS-5225 series 4.9.2.4 Cable Diagnostics This page is used for running the Cable Diagnostics. Press to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds. When completed, the page refreshes automatically, and you can view the cable diagnostics results in the cable status table.
  • Page 493 User’s Manual of IGS-5225 series The page includes the following fields: Object Description  Port The port where you are requesting Cable Diagnostics.  Description Display per port description.  Cable Status Port: Port number. Pair: The status of the cable pair.

  • Page 494: Traceroute (Ipv4)

    User’s Manual of IGS-5225 series 4.9.2.5 Traceroute (IPv4) This page allows you to perform a traceroute test over IPv4 towards a remote host. traceroute is a diagnostic tool for displaying the route and measuring transit delays of packets across an IPv4 network.
  • Page 495 User’s Manual of IGS-5225 series You can configure the following parameters for the test: Object Description  Hostname or IP The destination IP Address. Address  DSCP Value This value is used for the DSCP value in the IPv4 header. The default value is 0.

  • Page 496: Traceroute (Ipv6)

    User’s Manual of IGS-5225 series 4.9.2.6 Traceroute (IPv6) This page allows you to perform a traceroute test over IPv6 towards a remote host. traceroute is a diagnostic tool for displaying the route and measuring transit delays of packets across an IPv6 network.
  • Page 497 User’s Manual of IGS-5225 series Note: You may only specify either the VID or the IP Address for the source interface.  IP Address for Source This field can be used to force the test to use a specific local interface with the Interface specified IP address as the source interface.

  • Page 498: Switch Operation

    User’s Manual of IGS-5225 series 5. SWITCH OPERATION 5.1 Address Table The Industrial Managed Switch is implemented with an address table. This address table is composed of many entries. Each entry is used to store the address information of some nodes in the network, including MAC address, port no, etc. This information comes from the learning process of Industrial Managed Switch.

  • Page 499: Troubleshooting

    User’s Manual of IGS-5225 series 6. TROUBLESHOOTING This chapter contains information to help you solve issues. If the Industrial Managed Switch is not functioning properly, make sure the Industrial Managed Switch was set up according to instructions in this manual.

  • Page 500: Appendix A: Networking Connection

    User’s Manual of IGS-5225 series APPENDIX A: Networking Connection A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T PIN NO MDI-X BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- Implicit implementation of the crossover function within a twisted-pair cable, or at a wiring panel, while not expressly forbidden, is beyond the scope of this standard.
  • Page 501 User’s Manual of IGS-5225 series The standard cable, RJ45 pin assignment The standard RJ45 receptacle/connector There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight-through cable and crossover cable connection:...

  • Page 502: Appendix B : Recommended Use Of The Connected Wires

    User’s Manual of IGS-5225 series APPENDIX B : Recommended Use of the Connected Wires The wire gauges for the current are shown below: Gauge Diameter AWG #16 1.295 10.00 AWG #17 1.143 8.40 AWG #18 1.016 6.40 AWG #19 0.914 5.20...

  • Page 503: Appendix C : Glossary

    User’s Manual of IGS-5225 series APPENDIX C : GLOSSARY ACE is an acronym for Access Control Entry. It describes access permission associated with a particular ACE ID. There are three ACE frame types (Ethernet Type, ARP, and IPv4) and two ACE actions (permit and deny).
  • Page 504 User’s Manual of IGS-5225 series AES is an acronym for Advanced Encryption Standard. The encryption key protocol is applied in 802.1x standard to improve WLAN security. It is an encryption standard by the U.S. government, which will replace DES and 3DES. AES has a fixed block size of 128 bits and a key size of 128, 192, or 256 bits.
  • Page 505 User’s Manual of IGS-5225 series CDP is an acronym for Cisco Discovery Protocol. DEI is an acronym for Drop Eligible Indicator. It is a 1-bit field in the VLAN tag. DES is an acronym for Data Encryption Standard. It provides a complete description of a mathematical algorithm for encrypting (enciphering) and decrypting (deciphering) binary coded information.
  • Page 506 User’s Manual of IGS-5225 series DHCP Snooping DHCP Snooping is used to block intruder on the untrusted ports of the switch device when it tries to intervene by injecting a bogus DHCP reply packet to a legitimate conversation between the DHCP client and server.
  • Page 507 User’s Manual of IGS-5225 series Fast Leave IGMP snooping Fast Leave processing allows the switch to remove an interface from the forwarding-table entry without first sending out group specific queries to the interface. The VLAN interface is pruned from the multicast tree for the multicast group specified in the original leave message.
  • Page 508 User’s Manual of IGS-5225 series IEEE 802.1X IEEE 802.1X is an IEEE standard for port-based Network Access Control. It provides authentication to devices attached to a LAN port, establishing a point-to-point connection or preventing access from that port if authentication fails.
  • Page 509 User’s Manual of IGS-5225 series IP Source Guard IP Source Guard is a secure feature used to restrict IP traffic on DHCP snooping untrusted ports by filtering traffic based on the DHCP Snooping Table or manually configured IP Source Bindings. It helps prevent IP spoofing attacks when a host tries to spoof and use the IP address of another host.
  • Page 510 User’s Manual of IGS-5225 series MEP is an acronym for Maintenance Entity Endpoint and is an endpoint in a Maintenance Entity Group (ITU-T Y.1731). MD5 is an acronym for Message-Digest algorithm 5. MD5 is a message digest algorithm, used cryptographic hash function with a 128-bit hash value.
  • Page 511 User’s Manual of IGS-5225 series NFS is an acronym for Network File System. It allows hosts to mount partitions on a remote system and use them as though they are local file systems. NFS allows the system administrator to store resources in a central location on the network, providing authorized users continuous access to them, which means NFS supports sharing of files, printers, and other resources as persistent storage over a computer network.
  • Page 512 User’s Manual of IGS-5225 series PING Ping is a program that sends a series of packets over a network or the Internet to a specific computer in order to generate a response from that computer. The other computer responds with an acknowledgment that it received the packets.
  • Page 513 User’s Manual of IGS-5225 series QCL is an acronym for QoS Control List. It is the list table of QCEs, containing QoS control entries that classify to a specific QoS class on specific traffic objects. Each accessible traffic object contains an identifier to its QCL. The privileges determine specific traffic object to specific QoS class.
  • Page 514 User’s Manual of IGS-5225 series RSTP In 1998, the IEEE with document 802.1w introduced an evolution of STP: the Rapid Spanning Tree Protocol, which provides for faster spanning tree convergence after a topology change. Standard IEEE 802.1D-2004 now incorporates RSTP and obsoletes STP, while at the same time being backwards-compatible with STP.
  • Page 515 User’s Manual of IGS-5225 series SNTP SNTP is an acronym for Simple Network Time Protocol, a network protocol for synchronizing the clocks of computer systems. SNTP uses UDP (datagrams) as transport layer. SPROUT Stack Protocol using ROUting Technology. An advanced protocol for almost instantaneous discovery of topology changes within a stack as well as election of a master switch.
  • Page 516 User’s Manual of IGS-5225 series TCP is an acronym for Transmission Control Protocol. It is a communications protocol that uses the Internet Protocol (IP) to exchange the messages between computers. The TCP protocol guarantees reliable and in-order delivery of data from sender to receiver and distinguishes data for multiple connections by concurrent applications (for example, Web server and e-mail server) running on the same host.
  • Page 517 User’s Manual of IGS-5225 series UDP is an acronym for User Datagram Protocol. It is a communications protocol that uses the Internet Protocol (IP) to exchange the messages between computers. UDP is an alternative to the Transmission Control Protocol (TCP) that uses the Internet Protocol (IP). Unlike TCP, UDP does not provide the service of dividing a message into packet datagrams, and UDP doesn't provide reassembling and sequencing of the packets.
  • Page 518 User’s Manual of IGS-5225 series VLAN ID VLAN ID is a 12-bit field specifying the VLAN to which the frame belongs. Voice VLAN Voice VLAN is VLAN configured specially for voice traffic. By adding the ports with voice devices attached to voice VLAN, we can perform QoS-related configuration for voice data, ensuring the transmission priority of voice traffic and voice quality.
  • Page 519 User’s Manual of IGS-5225 series WPS is an acronym for Wi-Fi Protected Setup. It is a standard for easy and secure establishment of a wireless home network. The goal of the WPS protocol is to simplify the process of connecting any home device to the wireless network (Wikipedia).

This manual is also suitable for:

Igs-5225-8p2t4sv2Igs-5225-8p2t2sv4Igs-5225-8p4sv5Igs-5225-8p4s-12vIgs-5225-4up1t2sv5Igs-52254p2sv2 ... Show all

Table of Contents
