User's Manual of IGS-5227-Series

Industrial IP67-rated 6-Port

10/100/1000T M12 Managed

Ethernet Switch

IGS-5227 Series

1

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the IGS-5227 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Planet IGS-5227 Series

Page 1 User’s Manual of IGS-5227-Series Industrial IP67-rated 6-Port 10/100/1000T M12 Managed Ethernet Switch IGS-5227 Series...
Page 2 PLANET is a registered trademark of PLANET Technology Corp. All other trademarks belong to their respective owners. Disclaimer PLANET Technology does not warrant that the hardware will work properly in all environments and applications, and makes no warranty and representation, either implied or expressed, with respect to the quality, performance, merchantability, or fitness for a particular purpose.
Page 3: Table Of Contents
User’s Manual of IGS-5227-Series TABLE OF CONTENTS 1. INTRODUCTION ........................10 1.1 Package Contents ............................10 1.2 Product Description ........................... 11 1.3 How to Use This Manual ..........................14 1.4 Product Features ............................15 1.5 Product Specifications ..........................18 2. INSTALLATION ........................21 2.1 Hardware Description ..........................
Page 4 User’s Manual of IGS-5227-Series 3.5 SNMP-based Network Management ......................46 3.6 PLANET Smart Discovery Utility ......................47 4. WEB CONFIGURATION ...................... 49 4.1 Main Web page ............................52 4.2 System ................................. 54 4.2.1 System Information .............................. 55 4.2.2 IP Configuration ..............................56 4.2.3 IP Status ................................
Page 5 User’s Manual of IGS-5227-Series 4.3.5.2 SNMPv3 Users ............................91 4.3.5.3 SNMPv3 Groups ............................92 4.3.5.4 SNMPv3 Views ............................93 4.3.5.5 SNMPv3 Access ............................94 4.4 Port Management ............................96 4.4.1 Port Configuration ..............................96 4.4.2 Port Statistics Overview ............................98 4.4.3 Port Statistics Detail ............................
Page 6 User’s Manual of IGS-5227-Series 4.7.9 Port Statistics ..............................155 4.8 Multicast ..............................157 4.8.1 IGMP Snooping ..............................157 4.8.2 Profile Table ............................... 161 4.8.3 Address Entry ..............................162 4.8.4 IGMP Snooping Configuration ........................... 163 4.8.5 IGMP Snooping VLAN Configuration ......................... 165 4.8.6 IGMP Snooping Port Group Filtering .........................
Page 7 User’s Manual of IGS-5227-Series 4.9.16 Voice VLAN OUI Table............................. 209 4.10 Access Control List ..........................210 4.10.1 Access Control List Status ..........................210 4.10.2 Access Control List Configuration ........................212 4.10.3 ACE Configuration ............................214 4.10.4 ACL Ports Configuration ..........................224 4.10.5 ACL Rate Limiter Configuration ........................
Page 8 User’s Manual of IGS-5227-Series 4.14 LLDP ................................ 293 4.14.1 Link Layer Discovery Protocol ......................... 293 4.14.2 LLDP Configuration ............................293 4.14.3 LLDP MED Configuration ..........................296 4.14.4 LLDP-MED Neighbor ............................303 4.14.5 Neighbor ................................307 4.14.6 Port Statistics ..............................308 4.15 Network Diagnostics ..........................
Page 9 User’s Manual of IGS-5227-Series 5.2 Learning ..............................349 5.3 Forwarding & Filtering ..........................349 5.4 Store-and-Forward ........................... 349 5.5 Auto-Negotiation ............................350 6. TROUBLESHOOTING ....................... 351 APPENDIX A: Networking Connection ................352 A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T ............352 A.2 10/100Mbps, 10/100BASE-TX .........................
Page 10: Introduction
User’s Manual of IGS-5227-Series 1. INTRODUCTION Thank you for purchasing PLANET Industrial L2+ Managed Ethernet Switch. “Industrial Managed Switch” is used as an alternative name in this user’s manual. The descriptions of these models are shown below: Model Name Gigabit RJ45 Ports...
Page 11: Product Description
1.2 Product Description Suitable for Industrial Environment PLANET IGS-5227-Series, an Industrial Layer 2+ Managed Ethernet Switch, comes with an IP67-rated industrial case, 6-port 10/100/1000T and static Layer 3 routing, providing a high level of immunity against electromagnetic interference and heavy electrical surges which are usually found on plant floors or in curb-side traffic control cabinets.
Page 12 User’s Manual of IGS-5227-Series SMTP/SNMP Trap Event Alert Though most NVR or camera management software offers SMTP email alert function, the IGS-5227-Series further provides event alert function to help to diagnose the abnormal device owing to whether or not there is a break of the network connection. IPv6/IPv4 Dual Stack Supporting both IPv6 and IPv4 protocols, the IGS-5227-Series helps data centers, campuses, telecoms, and more to experience the IPv6 era with the lowest investment as its network facilities need not be replaced or overhauled if the IPv6 FTTx...
Page 13 User’s Manual of IGS-5227-Series Powerful Security The IGS-5227-Series offers a comprehensive Layer 2 to Layer 4 Access Control List (ACL) for enforcing security to the edge. It can be used to restrict network access by denying packets based on source and destination IP address, TCP/UDP ports or defined typical network applications.
Page 14: How To Use This Manual
User’s Manual of IGS-5227-Series 1.3 How to Use This Manual This User’s Manual is structured as follows: Section 2, INSTALLATION The section explains the functions of the Industrial Managed Switch and how to physically install the Industrial Managed Switch. Section 3, SWITCH MANAGEMENT The section contains the information about the software function of the Industrial Managed Switch.
Page 15: Product Features
User’s Manual of IGS-5227-Series 1.4 Product Features Physical Port   6-port 10/100/1000BASE-T waterproof and dustproof RJ45 copper (IGS-5227-6T)  waterproof and dustproof M12 A-coded female connectors (IGS-5227-6MT)  waterproof and dustproof M12 X-coded female connectors (IGS-5227-6MT-X) Hardware Conformance  ...
Page 16 User’s Manual of IGS-5227-Series  Provides port mirror (many-to-1)  Port mirroring monitors the incoming or outgoing traffic on a particular port  Loop protection to avoid broadcast loops  Supports E.R.P.S. (Ethernet Ring Protection Switching)  IEEE 1588 and Synchronous Ethernet network timing Quality of Service ...
Page 17 Cable diagnostic technology provides the mechanism to detect and report potential cabling issues ICMPv6/ICMPv4 remote ping  SMTP/Syslog remote alarm  Four RMON groups (history, statistics, alarms and events)  SNMP trap for interface link up and link down notification  PLANET Smart Discovery Utility for deployment management...
Page 18: Product Specifications
User’s Manual of IGS-5227-Series 1.5 Product Specifications Product IGS-5227-6T IGS-5227-6MT IGS-5227-6MT-X Hardware Specifications 6 waterproof and dustproof 6 M12, 8-pin A-Coded female 6 M12, 8-pin X-Coded female RJ45 connector, connector, Copper Ports 10/100/1000BASE-T 10/100/1000BASE-T 10/100/1000BASE-T auto-MDI/MDI-X ports auto-MDI/MDI-X ports auto-MDI/MDI-X ports Store-and-Forward Switch Architecture 12Gbps/non-blocking...
Page 19 User’s Manual of IGS-5227-Series 3 groups with 2 port per trunk IEEE 802.1D Spanning Tree Protocol (STP) Spanning Tree IEEE 802.1w Rapid Spanning Tree Protocol (RSTP) Protocol IEEE 802.1s Multiple Spanning Tree Protocol (MSTP) Traffic classification based, strict priority and WRR 8-level priority for switching: - Port number - 802.1p priority...
Page 20 User’s Manual of IGS-5227-Series IEC60068-2-32 (free fall) Stability Testing IEC60068-2-27 (shock) IEC60068-2-6 (vibration) IEEE 802.3 10BASE-T IEEE 802.3u 100BASE-TX IEEE 802.3ab Gigabit 1000T IEEE 802.3x flow control and back pressure IEEE 802.3ad port trunk with LACP IEEE 802.1D Spanning Tree Protocol IEEE 802.1w Rapid Spanning Tree Protocol IEEE 802.1s Multiple Spanning Tree Protocol IEEE 802.1p Class of Service...
Page 21: Installation
User’s Manual of IGS-5227-Series 2. INSTALLATION 2.1 Hardware Description This section describes the hardware features of Industrial Managed Switch. For easier management and control of the Industrial Managed Switch, familiarize yourself with its display indicators and ports. Front panel illustrations in this chapter display the unit LED indicators.
Page 22 User’s Manual of IGS-5227-Series IGS-5227-6MT Dimensions (W x D x H) : 103 x 68.2 x 163 mm...
Page 23 User’s Manual of IGS-5227-Series IGS-5227-6MT-X Dimensions (W x D x H) : 103 x 68.2 x 163 mm...
Page 24: Front Panel
User’s Manual of IGS-5227-Series 2.1.2 Front Panel The front panel provides a simple interface monitoring the Managed Switch. Figure 2-1 shows the front panel of the Managed Switch. IGS-5227-6T Front Panel Figure 2-1: IGS-5227-6T Switch Front Panel ■ Gigabit TP Interface 10/100/1000BASE-T copper, RJ45 twisted-pair: Up to 100 meters.
Page 25 User’s Manual of IGS-5227-Series IGS-5227-6MT and IGS-5227-6MT-X Front Panel Figure 2-2 IGS-5227-6MT Switch Front Panel Figure 2-3 IGS-5227-6MT-X Switch Front Panel ■ Gigabit TP Interface 10/100/1000BASE-T M12 A-coded and X-coded connector: Up to 100 meters. ■ M12 DC Power Connector The front panel of the Managed Switch has an M12 DC power connector, which accepts DC power input voltage from 9V to 48V DC.
Page 26: Led Indications
User’s Manual of IGS-5227-Series 2.1.3 LED Indications The front panel LEDs indicate instant status of power and system status, port links, and data activity; they help monitor and troubleshoot when needed. Figure 2-2 shows the LED indications of the Managed Switch. LED Definition ■...
Page 27: Cabling
User’s Manual of IGS-5227-Series 2.2 Cabling 2.2.1 Wiring the DC Power Input The front panel of the Industrial Managed Switch provides one M12 DC power 5-pin male connector for DC power input. Please use the power cable with the M12 DC power 5-pin female connector from the Industrial Managed Switch package for DC power input.
Page 28: Making Waterproof Rj45 Cable (Igs-5227-6T)
User’s Manual of IGS-5227-Series 2.2.2 Making Waterproof RJ45 Cable (IGS-5227-6T) Please read the following instructions and follow the procedures in the order being presented: Step 1: Take a waterproof RJ45 jack out from the Industrial Managed Switch box and get hold of one RJ45 cable. Step 2: Insert the RJ45 cable through the waterproof RJ45 jack.
Page 29 User’s Manual of IGS-5227-Series The standard RJ45 receptacle/connector There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and colors of straight-through cable connection: Please make sure your waterproof RJ45 cables are with same pin assignment and colors as the above picture before deploying the cables into your network.
Page 30 If the new waterproof RJ45 connector is obtained from PLANET, make sure its dimensions are the same. Never use any waterproof RJ45 connector that is not purchased from PLANET or doesn’t have the same dimensions of the IGS-5227-6T; it will damage the device permanently.
Page 31: Connecting Waterproof Cable To The Igs-5227-6T
User’s Manual of IGS-5227-Series 2.2.3 Connecting Waterproof Cable to the IGS-5227-6T Follow all the connecting waterproof cable steps as shown in the example. Step 1: Turn counterclockwise to remove the waterproof screw nuts of a RJ45 port and power input. Step 2: Insert the waterproof RJ45 connector into the port of the Industrial Managed Switch.
Page 32 User’s Manual of IGS-5227-Series Step 4: Insert the waterproof M12 power connector into the port of the power input. Step 5: Turn clockwise to tighten the screw nut of the waterproof M12 power connector. Make sure to tightly close all interfaces to have waterproof effect. Before connecting the DC power cord, please check whether your local DC power source is stable.
Page 33: M12 A-Coded Connector Pin Assignment
User’s Manual of IGS-5227-Series 2.2.4. M12 A-coded Connector Pin Assignment The IGS-5227-6MT front panel provides six 10/100/1000BASE-T Ethernet ports in the form of M12 8-pin A-coded female connector. These ports are designed for Ethernet equipment connection through Cat5/5e UTP cables. The M12 8-pin A-coded input interface pinout is shown below: 8-pin M12 A-coded Female 10/100/1000T Connector Pin Assignment 2.2.5.
Page 34: M12 X-Coded Connector Pin Assignment
User’s Manual of IGS-5227-Series 2.2.6. M12 X-coded Connector Pin Assignment The IGS-5227-6MT-X front panel provides six 10/100/1000BASE-T Ethernet ports in the form of M12 8-pin X-coded female connector. These ports are designed for Ethernet equipment connection through Cat5/5e UTP cables. The M12 8-pin X-coded input interface pinout is shown below: 8-pin M12 X-coded Female 10/100/1000T Connector Pin Assignment 2.2.7.
Page 35: Connecting M12 Cable To The Igs-5227-6Mt/Igs-5227-6Mt-X
User’s Manual of IGS-5227-Series 2.2.8. Connecting M12 Cable to the IGS-5227-6MT/IGS-5227-6MT-X Follow all the connecting M12 cable to the IGS-5227-6MT/IGS-5227-6MT-X steps as shown in the example. Step 1: Turn counterclockwise to remove the waterproof screw nuts of an M12 connector and power input. Step 2: Insert the M12 UTP male connector into the M12 female Gigabit Ethernet port of the Industrial Managed Switch.
Page 36 User’s Manual of IGS-5227-Series Step 5: Turn clockwise to tighten the screw nut of the M12 power connector. Before connecting the DC power cord, please check whether your local DC power source is stable. Make sure to tightly close all interfaces to have waterproof effect.
Page 37: Installing The Industrial Managed Switch
User’s Manual of IGS-5227-Series 2.3 Installing the Industrial Managed Switch This section describes how to install your Industrial Managed Switch and make connections to the Industrial Managed Switch. Please read the following topics and perform the procedures in the order being presented. To install your Industrial Managed Switch on a desktop or shelf, simply complete the following steps.
Page 38 User’s Manual of IGS-5227-Series Follow all the DIN-rail installation steps as shown in the example. Step 1: Screw the DIN-rail on the Industrial Managed Switch. Step 2: Lightly slide the DIN-rail into the track. Step 3: Check whether the DIN-rail is tightly on the track.
Page 39: Wall-Mount Plate Mounting
User’s Manual of IGS-5227-Series Please refer to the following procedures to remove the Industrial Managed Switch from the track. Step 4: Lightly remove the DIN-rail from the track. 2.3.3 Wall-mount Plate Mounting To install the Industrial Managed Switch on the wall, please follow the instructions below. Follow all the DIN-rail installation steps as shown in the example.
Page 40 User’s Manual of IGS-5227-Series Step 2: Place the wall-mount plate on the rear panel of the Industrial Managed Switch. Step 3: Use the screwdriver to screw the wall-mount plate on the Industrial Managed Switch. Step 4: Use the hook holes at the corners of the wall mount plate to hang the Industrial Managed Switch on the wall. Step 5: To remove the wall-mount plate, reverse the steps above.
Page 41: Recovering Back To Default Configuration
User’s Manual of IGS-5227-Series 2.4 Recovering Back to Default Configuration IP address has been changed or admin password has been forgotten –  Power off the Industrial Managed Switch and remove all the existing connections. Use the straight RJ45 cable to connect to port 1 and port 2 in the loop topology as shown below: Power on the Industrial Managed Switch and 6 LNK/ACT LEDs will be lit.
Page 42: Switch Management
User’s Manual of IGS-5227-Series 3. SWITCH MANAGEMENT This chapter explains the methods that you can use to configure management access to the Industrial Managed Switch. It describes the types of management applications and the communication and management protocols that deliver data between your management device (workstation or personal computer) and the system.
Page 43: Management Access Overview
User’s Manual of IGS-5227-Series 3.2 Management Access Overview The Industrial Managed Switch gives you the flexibility to access and manage it using any or all of the following methods: Remote Telnet Interface  Web browser Interface  An external SNMP-based network management application ...
Page 44: Cli Mode Management
User’s Manual of IGS-5227-Series 3.3 CLI Mode Management Remote telnet is an IP-based protocol and console port is for user to operate the Industrial Managed Switch locally only; however, their operations are the same. The command line user interface is for performing system administration, such as displaying statistics or changing option settings.
Page 45: Web Management
User’s Manual of IGS-5227-Series 3.4 Web Management The Industrial Managed Switch offers management features that allow users to manage the Industrial Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. After you set up your IP address for the Industrial Managed Switch, you can access the Industrial Managed Switch’s Web interface applications directly in your Web browser by entering the IP address of the Industrial Managed Switch.
Page 46: Snmp-Based Network Management
User’s Manual of IGS-5227-Series 3.5 SNMP-based Network Management You can use an external SNMP-based application to configure and manage the Industrial Managed Switch, such as SNMP Network Manager, HP Openview Network Node Management (NNM) or What’s Up Gold. This management method requires the SNMP agent on the Industrial Managed Switch and the SNMP Network Management Station to use the same community string.
Page 47: Planet Smart Discovery Utility
To easily list the Industrial Managed Switch in your Ethernet environment, the Planet Smart Discovery Utility from user’s manual CD-ROM is an ideal solution. The following install instructions guide you to running the Planet Smart Discovery Utility. Open the Planet Smart Discovery Utility in administrator PC.
Page 48 To click the “Control Packet Force Broadcast” function, it allows new setting value to be assigned to the Web Smart Switch under a different IP subnet address. Press the “Connect to Device” button and then the Web login screen appears in Figure 3-6. Press the “Exit” button to shut down Planet Smart Discovery Utility.
Page 49: Web Configuration
User’s Manual of IGS-5227-Series 4. WEB CONFIGURATION This section introduces the configuration and functions of the Web-based management. About Web-based Management The Industrial Managed Switch offers management features that allow users to manage the Industrial Managed Switch from anywhere on the network through a standard browser such as Microsoft Internet Explorer. The Web-based Management supports Internet Explorer 8.0.
Page 50 User’s Manual of IGS-5227-Series http://192.168.0.100 When the following login screen appears, please enter the default username "admin" with password “admin” (or the username/password you have changed via console) to login the main screen of Industrial Managed Switch. The login screen in Figure 4-1-2 appears.
Page 51 User’s Manual of IGS-5227-Series Now, you can use the Web management interface to continue the switch management or manage the Industrial Managed Switch by Web interface. The Switch Menu on the left of the web page lets you access all the commands and statistics the Industrial Managed Switch provides.
Page 52: Main Web Page
User’s Manual of IGS-5227-Series 4.1 Main Web page The Industrial Managed Switch provides a Web-based browser interface for configuring and managing it. This interface allows you to access the Industrial Managed Switch using the Web browser of your choice. This chapter describes how to use the Industrial Managed Switch’s Web browser interface to configure and manage it.
Page 53 User’s Manual of IGS-5227-Series Main Menu Using the onboard web agent, you can define system parameters, manage and control the Industrial Managed Switch, and all its ports, or monitor network conditions. Via the Web-Management, the administrator can set up the Industrial Managed Switch by selecting the functions those listed in the Main Function.
Page 54: System
User’s Manual of IGS-5227-Series 4.2 System Use the System menu items to display and configure basic administrative details of the Industrial Managed Switch. Under System the following topics are provided to configure and view the system information. ■ System Information The Managed Switch system information is provided here.
Page 55: System Information
User’s Manual of IGS-5227-Series 4.2.1 System Information The System Info page provides information for the current device information. System Info page helps a switch administrator to identify the hardware MAC address, software version and system uptime. The screen in Figure 4-2-1 appears.
Page 56: Ip Configuration
User’s Manual of IGS-5227-Series 4.2.2 IP Configuration The IP Configuration includes the IP Configuration, IP Interface and IP Routes. The configured column is used to view or change the IP configuration. The maximum number of interfaces supported is 128 and the maximum number of routes is 32. The screen in Figure 4-2-2 appears.
Page 57 User’s Manual of IGS-5227-Series From this DHCP interface  Specify from which DHCP-enabled interface a provided DNS server should be preferred. When DNS proxy is enabled, system will relay DNS requests to the DNS Proxy currently configured DNS server, and reply as a DNS resolver to the client devices on the network.
Page 58: Ip Status
User’s Manual of IGS-5227-Series 4.2.3 IP Status IP Status displays the status of the IP protocol layer. The status is defined by the IP interfaces, the IP routes and the neighbour cache (ARP cache) status. The screen in Figure 4-2-3 appears.
Page 59: Users Configuration
User’s Manual of IGS-5227-Series 4.2.4 Users Configuration This page provides an overview of the current users. Currently the only way to login as another user on the web server is to close and reopen the browser. After the setup is completed, press the “Apply” button to take effect. Please login web interface with new user name and password as Figure 4-2-4 shows.
Page 60 User’s Manual of IGS-5227-Series Figure 4-2-5: Add/Edit User Configuration Screenshot The page includes the following fields: Object Description • Username A string identifying the user name that this entry should belong to. The allowed string length is 1 to 31. The valid user name is a combination of letters, numbers and underscores.
Page 61 User’s Manual of IGS-5227-Series Generally, the privilege level 15 can be used for an ad ministrator account, privilege level 10 for a standard user account and privilege level 5 for a guest account. Once the new user is added, the new user entry is shown on the Users Configuration page. Figure 4-2-6: User Configuration Screenshot If you forget the new password after changing the default password, please press the “Reset”...
Page 62: Privilege Levels
User’s Manual of IGS-5227-Series 4.2.5 Privilege Levels This page provides an overview of the privilege levels. After the setup is completed, please press the “Apply” button to take effect. Please login web interface with new user name and password and the screen in Figure 4-2-7 appears.
Page 63 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • Group Name The name identifying the privilege group. In most cases, a privilege level group consists of a single module (e.g. LACP, RSTP or QoS), but a few of them contain more than one.
Page 64: Ntp Configuration
User’s Manual of IGS-5227-Series 4.2.6 NTP Configuration Configure NTP on this page. NTP is an acronym for Network Time Protocol, a network protocol for synchronizing the clocks of computer systems. NTP uses UDP (data grams) as transport layer. You can specify NTP Servers. The NTP Configuration screen in Figure 4-2-8 appears.
Page 65: Time Configuration
User’s Manual of IGS-5227-Series 4.2.7 Time Configuration Configure Time Zone on this page. A Time Zone is a region that has a uniform standard time for legal, commercial, and social purposes. It is convenient for areas in close commercial or other communication to keep the same time, so time zones tend to follow the boundaries of countries and their subdivisions.
Page 66: Upnp
User’s Manual of IGS-5227-Series Daylight Saving Time duration to repeat the configuration every year. Select 'Non-Recurring' and configure the Daylight Saving Time duration for single time configuration. ( Default: Disabled ). Start Time Settings • Week - Select the starting week number. •...
Page 67 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description Indicates the UPnP operation mode. Possible modes are: • Mode Enabled: Enable UPnP mode operation.  Disabled: Disable UPnP mode operation.  When the mode is enabled, two ACEs are added automatically to trap UPnP related packets to CPU.
Page 68: Dhcp Relay
User’s Manual of IGS-5227-Series 4.2.9 DHCP Relay Configure DHCP Relay on this page. DHCP Relay is used to forward and to transfer DHCP messages between the clients and the server when they are not on the same subnet domain. The DHCP option 82 enables a DHCP relay agent to insert specific information into a DHCP request packets when forwarding client DHCP packets to a DHCP server and remove the specific information from a DHCP reply packets when forwarding server DHCP packets to a DHCP client.
Page 69: Dhcp Relay Statistics
User’s Manual of IGS-5227-Series they are not on the same subnet domain. • Relay Information Indicates the DHCP relay information mode option operation. Possible modes Mode are: Enabled: Enable DHCP relay information mode operation. When enabling  DHCP relay information mode operation, the agent inserts specific information (option82) into a DHCP message when forwarding to DHCP server and removing it from a DHCP message when transferring to DHCP client.
Page 70 User’s Manual of IGS-5227-Series The page includes the following fields: Server Statistics Object Description • Transmit to Server The packets number that is relayed from client to server. • Transmit Error The packets number whose errors are sending to clients. •...
Page 71: Cpu Load
User’s Manual of IGS-5227-Series 4.2.11 CPU Load This page displays the CPU load, using an SVG graph. The load is measured as average over the last 100ms, 1sec and 10 seconds intervals. The last 120 samples are graphed, and the last numbers are displayed as text as well. In order to display the SVG graph, your browser must support the SVG format.
Page 72: System Log
User’s Manual of IGS-5227-Series 4.2.12 System Log The Industrial Managed Switch system log information is provided here. The System Log screen in Figure 4-2-15 appears. Figure 4-2-15: System Log Screenshot The page includes the following fields: Object Description • ID The ID (>= 1) of the system log entry.
Page 73: Detailed Log
User’s Manual of IGS-5227-Series : Flushes the selected log entries. : Hides the selected log entries. : Downloads the selected log entries. : Updates the system log entries, starting from the first available entry ID. : Updates the system log entries, ending at the last entry currently displayed. : Updates the system log entries, starting from the last entry currently displayed.
Page 74: Remote Syslog
User’s Manual of IGS-5227-Series : Updates the system log entry to the last available entry ID. : Print the system log entry to the current entry ID. 4.2.14 Remote Syslog Configure remote syslog on this page. The Remote Syslog screen in Figure 4-2-17 appears.
Page 75: Smtp Configuration
User’s Manual of IGS-5227-Series 4.2.15 SMTP Configuration This page facilitates an SMTP Configuration on the switch. The SMTP Configure screen in Figure 4-2-18 appears. Figure 4-2-18: SMTP Configuration Screenshot The page includes the following fields: Object Description • SMTP Mode Controls whether SMTP is enabled on this switch.
Page 76: Fault Alarm
User’s Manual of IGS-5227-Series 4.2.16 Fault Alarm This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-19 appears. Figure 4-2-19: Fault Alarm Control Configuration Screenshot The page includes the following fields: Object Description •...
Page 77: Web Firmware Upgrade
User’s Manual of IGS-5227-Series 4.2.17 Web Firmware Upgrade This page facilitates an update of the firmware controlling the switch. The Web Firmware Upgrade screen in Figure 4-2-20 appears. Figure 4-2-20: Web Firmware Upgrade Screenshot To open Firmware Upgrade screen, perform the following: Click System ->...
Page 78: Tftp Firmware Upgrade
User’s Manual of IGS-5227-Series 4.2.18 TFTP Firmware Upgrade The Firmware Upgrade page provides the functions to allow a user to update the Industrial Managed Switch firmware from the TFTP server in the network. Before updating, make sure you have your TFTP server ready and the firmware image is on the TFTP server.
Page 79: Save Startup Config
User’s Manual of IGS-5227-Series 4.2.19 Save Startup Config This function allows to save the current configuration, thereby ensuring that the current active configuration can be used at the next reboot screen in Figure 4-2-23 as shown below. After saving the configuration, the screen in Figure 4-2-24 appears.
Page 80: Configuration Upload
User’s Manual of IGS-5227-Series 4.2.21 Configuration Upload Configuration Upload page allows the uploads of the running-config and startup-config on the switch. Please refer to Figure 4-2-26 shown below. Figure 4-2-26: Configuration Upload Screenshot If the destination is running-config, the file will be applied to the switch configuration. This can be done in two ways: •...
Page 81: Configuration Delete
User’s Manual of IGS-5227-Series It is possible to activate any of the configuration files present on the switch, except for running-config which represents the currently active configuration. Select the file to activate and click . This will initiate the process of completely replacing the existing configuration with that of the selected file.
Page 82: Factory Default
User’s Manual of IGS-5227-Series Figure 4-2-29: Software Image Selection Screenshot The page includes the following fields: Object Description • Image The flash index name of the firmware image. The name of primary (preferred) image is image, the alternate image is named image.bk. •...
Page 83: System Reboot
User’s Manual of IGS-5227-Series Buttons : Click to reset the configuration to Factory Defaults. : Click to return to the Port State page without resetting the configuration. To reset the Industrial Managed Switch to the Factory default setting, you can also press the hardware reset button on the front panel for about 10 seconds.
Page 84: Simple Network Management Protocol
User’s Manual of IGS-5227-Series 4.3 Simple Network Management Protocol 4.3.1 SNMP Overview The Simple Network Management Protocol (SNMP) is an application layer protocol that facilitates the exchange of management information between network devices. It is part of the Transmission Control Protocol/Internet Protocol (TCP/IP) protocol suite. SNMP enables network administrators to manage network performance, find and solve network problems, and plan for network growth.
Page 85: Snmp System Configuration
User’s Manual of IGS-5227-Series SNMP community An SNMP community is the group that devices and management stations running SNMP belong to. It helps define where information is sent. The community name is used to identify the group. A SNMP device or agent may belong to more than one SNMP community.
Page 86 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description Mode Indicates the SNMP mode operation. Possible modes are: • Enabled: Enable SNMP mode operation.  Disabled: Disable SNMP mode operation.  Version Indicates the SNMP supported version. Possible versions are: •...
Page 87: Snmp Trap Configuration
User’s Manual of IGS-5227-Series 4.3.3 SNMP Trap Configuration Configure SNMP trap on this page. The SNMP Trap Configuration screen in Figure 4-3-2 appears. Figure 4-3-2: SNMP Trap Configuration Screenshot The page includes the following fields: Object Description Trap Config Indicates which trap Configuration's name for configuring. The allowed string •...
Page 88 User’s Manual of IGS-5227-Series Trap Community Indicates the community access string when send SNMP trap packet. The • allowed string length is 0 to 255, and the allowed content is the ASCII characters from 33 to 126. Trap Destination Indicates the SNMP trap destination address. •...
Page 89: Snmp System Information
User’s Manual of IGS-5227-Series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. 4.3.4 SNMP System Information The switch system information is provided here. The SNMP System Information screen in Figure 4-3-3 appears.
Page 90: Snmpv3 Configuration
User’s Manual of IGS-5227-Series 4.3.5 SNMPv3 Configuration 4.3.5.1 SNMPv3 Communities Configure SNMPv3 communities table on this page. The entry index key is Community. The SNMPv3 Communities screen in Figure 4-3-4 appears. Figure 4-3-4: SNMPv3 Communities Configuration Screenshot The page includes the following fields: Object Description Delete...
Page 91: Snmpv3 Users
User’s Manual of IGS-5227-Series 4.3.5.2 SNMPv3 Users Configure SNMPv3 users table on this page. The entry index keys are Engine ID and User Name. The SNMPv3 Users screen in Figure 4-3-5 appears. Figure 4-3-5: SNMPv3 Users Configuration Screenshot The page includes the following fields: Object Description Delete...
Page 92: Snmpv3 Groups
User’s Manual of IGS-5227-Series protocol. SHA: An optional flag to indicate that this user using SHA authentication  protocol. The value of security level cannot be modified if entry already exist. That means must first ensure that the value is set correctly. •...
Page 93: Snmpv3 Views
User’s Manual of IGS-5227-Series The page includes the following fields: Object Description Delete Check to delete the entry. It will be deleted during the next save. • Security Model Indicates the security model that this entry should belong to. Possible security •...
Page 94: Snmpv3 Access
User’s Manual of IGS-5227-Series string length is 1 to 32, and the allowed content is the ASCII characters from 33 to 126. View Type Indicates the view type that this entry should belong to. Possible view type are: • included: An optional flag to indicate that this view subtree should be ...
Page 95 User’s Manual of IGS-5227-Series Security Model Indicates the security model that this entry should belong to. Possible security • models are: any: Accepted any security model (v1|v2c|usm).  v1: Reserved for SNMPv1.  v2c: Reserved for SNMPv2c.  usm: User-based Security Model (USM) ...
Page 96: Port Management
User’s Manual of IGS-5227-Series 4.4 Port Management Use the Port Menu to display or configure the Industrial Managed Switch's ports. This section has the following items: Port Configuration Configures port connection settings  Port Statistics Overview Lists Ethernet and RMON port statistics ...
Page 97 User’s Manual of IGS-5227-Series When Auto Speed is selected on a port, this section indicates the flow control Flow Control • capability that is advertised to the link partner. When a fixed-speed setting is selected, that is what is used. The Current Rx column indicates whether pause frames on the port are obeyed, and the Current Tx column indicates whether pause frames on the port are transmitted.
Page 98: Port Statistics Overview
User’s Manual of IGS-5227-Series 4.4.2 Port Statistics Overview This page provides an overview of general traffic statistics for all switch ports. The Port Statistics Overview screen in Figure 4-4-2 appears. Figure 4-4-2: Port Statistics Overview Screenshot The displayed counters are: Object Description Port...
Page 99: Port Statistics Detail
User’s Manual of IGS-5227-Series 4.4.3 Port Statistics Detail This page provides detailed traffic statistics for a specific switch port. Use the port select box to select which switch port details to display. The selected port belong to the currently selected stack unit, as reflected by the page header. The displayed counters are the totals for receive and transmit, the size counters for receive and transmit, and the error counters for receive and transmit.
Page 100 User’s Manual of IGS-5227-Series Receive and Transmit Size Counters The number of received and transmitted (good and bad) packets split into categories based on their respective frame sizes. Receive and Transmit Queue Counters The number of received and transmitted packets per input and output queue. Receive Error Counters Object Description...
Page 101: Port Mirror
User’s Manual of IGS-5227-Series 4.4.4 Port Mirror Configure port Mirroring on this page. This function provides monitoring network traffic that forwards a copy of each incoming or outgoing packet from one port of a network Switch to another port where the packet can be studied. It enables the manager to keep close track of switch performance and alter it if necessary.
Page 102 User’s Manual of IGS-5227-Series Figure 4-4-5: Mirror Configuration Screenshot The page includes the following fields: Object Description • Port to mirror on Frames from ports that have either source (rx) or destination (tx) mirroring enabled are mirrored to this port. Disabled disables mirroring. Port The logical port for the settings contained in the same row.
Page 103: Link Aggregation
User’s Manual of IGS-5227-Series 4.5 Link Aggregation Port Aggregation optimizes port usage by linking a group of ports together to form a single Link Aggregated Groups (LAGs). Port Aggregation multiplies the bandwidth between the devices, increases port flexibility, and provides link redundancy. Each LAG is composed of ports of the same speed, set to full-duplex operations.
Page 104 User’s Manual of IGS-5227-Series The Link Aggregation Control Protocol (LACP) provides a standardized means for exchanging information between Partner Systems that require high speed redundant links. Link aggregation lets you group up to eight consecutive ports into a single dedicated connection. This feature can expand bandwidth to a device on the network. LACP operation requires full-duplex mode, more detail information refer to the IEEE 802.3ad standard.
Page 105: Static Aggregation
User’s Manual of IGS-5227-Series 4.5.1 Static Aggregation This page is used to configure the Aggregation hash mode and the aggregation group. The aggregation hash mode settings are global, whereas the aggregation group relate to the currently selected stack unit, as reflected by the page header. Hash Code Contributors The Static Aggregation screen in Figure 4-5-2...
Page 106 User’s Manual of IGS-5227-Series Figure 4-5-3: Aggregation Group Configuration Screenshot The page includes the following fields: Description .Object Group ID Indicates the group ID for the settings contained in the same row. Group ID • "Normal" indicates there is no aggregation. Only one group ID is valid per port. Port Members Each switch port is listed for each group ID.
Page 107: Lacp Configuration
User’s Manual of IGS-5227-Series 4.5.2 LACP Configuration Link Aggregation Control Protocol (LACP) - LACP LAG negotiate Aggregated Port links with other LACP ports located on a different device. LACP allows switches connected to each other to discover automatically whether any ports are member of the same LAG.
Page 108: Lacp System Status
User’s Manual of IGS-5227-Series LACP packets each second, while Slow will wait for 30 seconds before sending a LACP packet. Priority The Prio controls the priority of the port. If the LACP partner wants to form a • larger group than is supported by this device then this parameter will control which ports will be active and which ports will be in a backup role.
Page 109: Lacp Port Status
User’s Manual of IGS-5227-Series 4.5.4 LACP Port Status This page provides a status overview for LACP status for all ports. The LACP Port Status screen in Figure 4-5-6 appears. Figure 4-5-6: LACP Status Screenshot The page includes the following fields: Object Description Port...
Page 110: Lacp Port Statistics
User’s Manual of IGS-5227-Series 4.5.5 LACP Port Statistics This page provides an overview for LACP statistics for all ports. The LACP Port Statistics screen in Figure 4-5-7 appears. Figure 4-5-7: LACP Statistics Screenshot The page includes the following fields: Object Description Port The switch port number.
Page 111: Vlan
User’s Manual of IGS-5227-Series 4.6 VLAN 4.6.1 VLAN Overview A Virtual Local Area Network (VLAN) is a network topology configured according to a logical scheme rather than the physical layout. VLAN can be used to combine any collection of LAN segments into an autonomous user group that appears as a single LAN.
Page 112: Ieee 802.1Q Vlan
User’s Manual of IGS-5227-Series 4.6.2 IEEE 802.1Q VLAN In large networks, routers are used to isolate broadcast traffic for each subnet into separate domains. This Industrial Managed Switch provides a similar service at Layer 2 by using VLANs to organize any group of network nodes into separate broadcast domains.
Page 113 User’s Manual of IGS-5227-Series ■ 802.1Q VLAN Tags The figure below shows the 802.1Q VLAN tag. There are four additional octets inserted after the source MAC address. Their presence is indicated by a value of 0x8100 in the Ether Type field. When a packet's Ether Type field is equal to 0x8100, the packet carries the IEEE 802.1Q/802.1p tag.
Page 114 User’s Manual of IGS-5227-Series Every physical port on a switch has a PVID. 802.1Q ports are also assigned a PVID, for use within the switch. If no VLAN are defined on the switch, all ports are then assigned to a default VLAN with a PVID equal to 1. Untagged packets are assigned the PVID of the port on which they were received.
Page 115: Vlan Port Configuration
User’s Manual of IGS-5227-Series ■ Port Overlapping Port overlapping can be used to allow access to commonly shared network resources among different VLAN groups, such as file servers or printers. Note that if you implement VLANs which do not overlap, but still need to communicate, you can connect them by enabled routing on this switch.
Page 116 User’s Manual of IGS-5227-Series ■ IEEE 802.1Q Tunneling (Q-in-Q) IEEE 802.1Q Tunneling (QinQ) is designed for service providers carrying traffic for multiple customers across their networks. QinQ tunneling is used to maintain customer-specific VLAN and Layer 2 protocol configurations even when different customers use the same internal VLAN IDs.
Page 117 User’s Manual of IGS-5227-Series Global VLAN Configuration The Global VLAN Configuration screen in Figure 4-6-1 appears. Figure 4-6-1 : Global VLAN Configuration Screenshot The page includes the following fields: Object Description This field shows the allowed Access VLANs, it only affects ports configured as •...
Page 118 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description Port This is the logical port number for this row. • Access • Mode Access ports are normally used to connect to end stations. Dynamic features like Voice VLAN may add the port to more VLANs behind the scenes. Access ports have the following characteristics: •...
Page 119 User’s Manual of IGS-5227-Series The Port VLAN is called an "Access VLAN" for ports in Access mode and Native VLAN for ports in Trunk or Hybrid mode. Port Type Ports in hybrid mode allow for changing the port type, that is, whether a frame's •...
Page 120 User’s Manual of IGS-5227-Series Only untagged frames are accepted on ingress. Tagged frames are discarded. Egress Tagging This option is only available for ports in Hybrid mode. Ports in Trunk and Hybrid mode may control the tagging of frames on egress. Untag Port VLAN ■...
Page 121: Vlan Membership Status
User’s Manual of IGS-5227-Series 4.6.4 VLAN Membership Status This page provides an overview of membership status for VLAN users. The VLAN Membership Status screen in Figure 4-6-4 appears. Figure 4-6-4: VLAN Membership Status for Static User Screenshot The page includes the following fields: Object Description VLAN User...
Page 122: Vlan Port Status
User’s Manual of IGS-5227-Series Buttons : Select VLAN Users from this drop-down list. Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. : Click to refresh the page immediately. : Updates the table starting from the first entry in the VLAN Table, i.e. the entry with the lowest VLAN ID. : Updates the table, starting with the entry after the last entry currently displayed.
Page 123: Private Vlan
User’s Manual of IGS-5227-Series • Port VLAN ID Shows the PVID setting for the port. • Tx Tag Shows egress filtering frame status whether tagged or untagged. Shows UVID (untagged VLAN ID). Port's UVID determines the packet's behavior • Untagged VLAN ID at the egress side.
Page 124 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • Delete To delete a private VLAN entry, check this box. The entry will be deleted during the next save. • Private VLAN ID Indicates the ID of this particular private VLAN. A row of check boxes for each port is displayed for each private VLAN ID.
Page 125: Port Isolation
User’s Manual of IGS-5227-Series 4.6.7 Port Isolation Overview When a VLAN is configured to be a private VLAN, communication between ports within that VLAN can be prevented. Two application examples are provided in this section: • Customers connected to an ISP can be members of the same VLAN, but they are not allowed to communicate with each other within that VLAN.
Page 126 User’s Manual of IGS-5227-Series The configuration of promiscuous and isolated ports applies to all private VLANs. When traffic comes in on a promiscuous port in a private VLAN, the VLAN mask from the VLAN table is applied. When traffic comes in on an isolated port, the private VLAN mask is applied in addition to the VLAN mask from the VLAN table.
Page 127: Vlan Setting Example
User’s Manual of IGS-5227-Series 4.6.8 VLAN setting example: Separate VLAN  802.1Q VLAN Trunk  Port Isolate  4.6.8.1 Two Separate 802.1Q VLANs The diagram shows how the Industrial Managed Switch handles Tagged and Untagged traffic flow for two VLANs. VLAN Group 2 and VLAN Group 3 are separated VLANs.
Page 128 User’s Manual of IGS-5227-Series The scenario is described as follows: Untagged packet entering VLAN 2  While [PC-1] transmit an untagged packet enters Port-1, the Industrial Managed Switch will tag it with a VLAN Tag=2. [PC-2] and [PC-3] will received the packet through Port-2 and Port-3. [PC-4],[PC-5] and [PC-6] received no packet.
Page 129 User’s Manual of IGS-5227-Series Assign VLAN Member and PVID to each port: VLAN 2: Port-1,Port-2 and Port-3 VLAN 3: Port-4, Port-5 and Port-6 VLAN 1: All other ports – Port-7~Port-28 Figure 4-6-10: Change Port VLAN of Port 1~3 to be VLAN2 and Port VLAN of Port 4~6 to be VLAN3 Enable VLAN Tag for specific ports Link Type: Port-3 (VLAN-2) and Port-6 (VLAN-3) Change Port 3 Mode as Trunk and select Egress Tagging as Tag All and Type 2 in the Allowed VLANs column.
Page 130: Vlan Trunking Between Two 802.1Q Aware Switches
User’s Manual of IGS-5227-Series 4.6.8.2 VLAN Trunking between two 802.1Q aware switches In most cases, they are used for “Uplink” to other switches. VLANs are separated at different switches, but they need to access to other switches within the same VLAN group. The screen in Figure 4-6-12 appears.
Page 131 User’s Manual of IGS-5227-Series Assign VLAN Member and PVID to each port: VLAN 2 : Port-1,Port-2 and Port-3 VLAN 3 : Port-4, Port-5 and Port-6 VLAN 1 : All other ports – Port-7~Port-48 Figure 4-6-14: Changes Port VLAN of Port 1~3 to be VLAN2 and Port VLAN of Port 4~6 to be VLAN3 For the VLAN ports connecting to the hosts, please refer to 4.6.10.1.
Page 132: Port Isolate
User’s Manual of IGS-5227-Series VLAN 2 members of Port-1 to Port-3 and VLAN 3 members of Port-4 to Port-6 also belong to VLAN 1. But with different PVID settings, packets from VLAN 2 or VLAN 3 are not able to access to the other VLAN. Repeat Steps 1 to 6 to set up the VLAN Trunk port at the partner switch.
Page 133: Mac-Based Vlan
User’s Manual of IGS-5227-Series Assign VLAN Member : VLAN 1 : Port-5 and Port-6 VLAN 2 : Port-1, Port-2, Port-5 and Port-6 VLAN 3: Port-3~Port-6. The screen in Figure 4-6-18 appears. Figure 4-6-17: Private VLAN Port Setting 4.6.9 MAC-based VLAN The MAC-based VLAN entries can be configured here.
Page 134 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • Delete To delete a MAC-based VLAN entry, check this box and press save. The entry will be deleted in the stack. • MAC Address Indicates the MAC address. •...
Page 135: Protocol-Based Vlan
User’s Manual of IGS-5227-Series 4.6.10 Protocol-based VLAN This page allows you to add new protocols to Group Name (unique for each Group) mapping entries as well as allow you to see and delete already mapped entries for the switch. The Protocol-based VLAN screen in Figure 4-6-19 appears.
Page 136 User’s Manual of IGS-5227-Series OUI: OUI (Organizationally Unique Identifier) is value in format of xx-xx-xx where each pair (xx) in string is a hexadecimal value ranges from 0x00-0xff. PID: If the OUI is hexadecimal 000000, the protocol ID is the Ethernet type (EtherType) field value for the protocol running on top of SNAP;...
Page 137: Protocol-Based Vlan Membership
User’s Manual of IGS-5227-Series 4.6.11 Protocol-based VLAN Membership This page allows you to map a already configured Group Name to a VLAN for the switch. The Group Name to VLAN Mapping Table screen in Figure 4-6-20 appears. Figure 4-6-20 Group Name to VLAN Mapping Table Screenshot The page includes the following fields: Object Description...
Page 138: Spanning Tree Protocol
User’s Manual of IGS-5227-Series 4.7 Spanning Tree Protocol 4.7.1 Theory The Spanning Tree protocol can be used to detect and disable network loops, and to provide backup links between switches, bridges or routers. This allows the switch to interact with other bridging devices in your network to ensure that only one route exists between any two stations on the network, and provide backup links which automatically take over when a primary link goes down.
Page 139 User’s Manual of IGS-5227-Series The path cost to the root from the transmitting port  The port identifier of the transmitting port  The switch sends BPDUs to communicate and construct the spanning-tree topology. All switches connected to the LAN on which the packet is transmitted will receive the BPDU.
Page 140 User’s Manual of IGS-5227-Series From forwarding to disabled  From disabled to blocking  Figure 4-7-1: STP Port State Transitions You can modify each port state by using management software. When you enable STP, every port on every switch in the network goes through the blocking state and then transitions through the states of listening and learning at power up.
Page 141 User’s Manual of IGS-5227-Series The following are the user-configurable STP parameters for the switch level: Parameter Description Default Value Bridge Identifier(Not user A combination of the User-set priority and the 32768 + MAC configurable switch’s MAC address. except by setting priority The Bridge Identifier consists of two parts: below) a 16-bit priority and a 48-bit Ethernet MAC address...
Page 142 User’s Manual of IGS-5227-Series User-Changeable STA Parameters The Switch’s factory default setting should cover the majority of installations. However, it is advisable to keep the default settings as set at the factory; unless, it is absolutely necessary. The user changeable parameters in the Switch are as follows: Priority –...
Page 143 User’s Manual of IGS-5227-Series Figure 4-7-2: Before Applying the STA Rules In this example, only the default STP values are used. Figure 4-7-3: After Applying the STA Rules...
Page 144: Stp System Configuration
User’s Manual of IGS-5227-Series The switch with the lowest Bridge ID (switch C) was elected the root bridge, and the ports were selected to give a high port cost between switches B and C. The two (optional) Gigabit ports (default port cost = 20,000) on switch A are connected to one (optional) Gigabit port on both switch B and C.
Page 145 User’s Manual of IGS-5227-Series The page includes the following fields: Basic Settings Object Description Protocol Version The STP protocol version setting. Valid values are: • STP (IEEE 802.1D Spanning Tree Protocol)  RSTP (IEEE 802.2w Rapid Spanning Tree Protocol)  MSTP (IEEE 802.1s Multiple Spanning Tree Protocol) ...
Page 146: Bridge Status
User’s Manual of IGS-5227-Series • Port Error Recovery Control whether a port in the error-disabled state automatically will be enabled after a certain time. If recovery is not enabled, ports have to be disabled and re-enabled for normal STP operation. The condition is also cleared by a system reboot.
Page 147: Cist Port Configuration
User’s Manual of IGS-5227-Series • Topology Flag The current state of the Topology Change Flag for this Bridge instance. • Topology Change Last The time since last Topology Change occurred. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. : Click to refresh the page immediately.
Page 148 User’s Manual of IGS-5227-Series path cost is used when establishing the active topology of the network. Lower path cost ports are chosen as forwarding ports in favor of higher path cost ports. Valid values are in the range 1 to 200000000. Priority Controls the port priority.
Page 149 User’s Manual of IGS-5227-Series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. By default, the system automatically detects the speed and duplex mode used on each port, and configures the path cost according to the values shown below.
Page 150: Msti Priorities
User’s Manual of IGS-5227-Series 4.7.5 MSTI Priorities This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. The MSTI Priority screen in Figure 4-7-7 appears. Figure 4-7-7: MSTI Priority Screenshot The page includes the following fields: Object Description...
Page 151: Msti Configuration
User’s Manual of IGS-5227-Series 4.7.6 MSTI Configuration This page allows the user to inspect the current STP MSTI bridge instance priority configurations, and possibly change them as well. The MSTI Configuration screen in Figure 4-7-8 appears. Figure 4-7-8: MSTI Configuration Screenshot The page includes the following fields: Configuration Identification Object...
Page 152: Msti Ports Configuration
User’s Manual of IGS-5227-Series MSTI Mapping Object Description • MSTI The bridge instance. The CIST is not available for explicit mapping, as it will receive the VLANs not explicitly mapped. • VLANs Mapped The list of VLAN's mapped to the MSTI. The VLANs must be separated with comma and/or space.
Page 153 User’s Manual of IGS-5227-Series Figure 4-7-10 : MST1 MSTI Port Configuration Screenshot The page includes the following fields: MSTx MSTI Port Configuration Object Description • Port The switch port number of the corresponding STP CIST (and MSTI) port. • Path Cost Controls the path cost incurred by the port.
Page 154: Port Status
User’s Manual of IGS-5227-Series 4.7.8 Port Status This page displays the STP CIST port status for port physical ports in the currently selected switch. The STP Port Status screen in Figure 4-7-11 appears. Figure 4-7-11: STP Port Status Screenshot The page includes the following fields: Object Description Port...
Page 155: Port Statistics
User’s Manual of IGS-5227-Series 4.7.9 Port Statistics This page displays the STP port statistics counters for port physical ports in the currently selected switch. The STP Port Statistics screen in Figure 4-7-12 appears. Figure 4-7-12: STP Statistics Screenshot The page includes the following fields: Object Description Port...
Page 156 User’s Manual of IGS-5227-Series...
Page 157: Multicast
User’s Manual of IGS-5227-Series 4.8 Multicast 4.8.1 IGMP Snooping The Internet Group Management Protocol (IGMP) lets host and routers share information about multicast groups memberships. IGMP snooping is a switch feature that monitors the exchange of IGMP messages and copies them to the CPU for feature processing.
Page 158 User’s Manual of IGS-5227-Series Figure 4-8-2: Multicast Flooding Figure 4-8-3: IGMP Snooping Multicast Stream Control...
Page 159 User’s Manual of IGS-5227-Series IGMP Versions 1 and 2 Multicast groups allow members to join or leave at any time. IGMP provides the method for members and multicast routers to communicate when joining or leaving a multicast group. IGMP version 1 is defined in RFC 1112. It has a fixed packet size and no optional data.
Page 160 User’s Manual of IGS-5227-Series The states a computer will go through to join or to leave a multicast group are shown below: Figure 4-8-4: IGMP State Transitions IGMP Querier –  A router, or multicast-enabled switch, can periodically ask their hosts if they want to receive multicast traffic. If there is more than one router/switch on the LAN performing IP multicasting, one of these devices is elected “querier”...
Page 161: Profile Table
User’s Manual of IGS-5227-Series 4.8.2 Profile Table This page provides IPMC Profile related configurations. The IPMC profile is used to deploy the access control on IP multicast streams. It is allowed to create a maximum of 64 Profiles with a maximum of 128 corresponding rules for each. The Profile Table screen in Figure 4-8-5 appears.
Page 162: Address Entry
User’s Manual of IGS-5227-Series Buttons : Click to add new IPMC profile. Specify the name and configure the new entry. Click "Save”. : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. 4.8.3 Address Entry This page provides address range settings used in IPMC profile.
Page 163: Igmp Snooping Configuration
User’s Manual of IGS-5227-Series Buttons : Click to add new address range. Specify the name and configure the addresses. Click "Save”. : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. : Refreshes the displayed table starting from the input fields.
Page 164 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description Enable the Global IGMP Snooping. • Snooping Enabled Unregistered IPMCv4 Enable unregistered IPMCv4 traffic flooding. • Flooding Enabled The flooding control takes effect only when IGMP Snooping is enabled. When IGMP Snooping is disabled, unregistered IPMCv4 traffic flooding is always active in spite of this setting.
Page 165: Igmp Snooping Vlan Configuration
User’s Manual of IGS-5227-Series 4.8.5 IGMP Snooping VLAN Configuration Each page shows up to 99 entries from the VLAN table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the VLAN Table. The first displayed will be the one with the lowest VLAN ID found in the VLAN Table.
Page 166 User’s Manual of IGS-5227-Series Default compatibility value is IGMP-Auto. • PRI (PRI) Priority of Interface. It indicates the IGMP control frame priority level generated by the system. These values can be used to prioritize different classes of traffic. The allowed range is 0 (best effort) to 7 (highest), default interface priority value is 0 •...
Page 167: Igmp Snooping Port Group Filtering
User’s Manual of IGS-5227-Series 4.8.6 IGMP Snooping Port Group Filtering In certain switch applications, the administrator may want to control the multicast services that are available to end users. For example, an IP/TV service based on a specific subscription plan. The IGMP filtering feature fulfills this requirement by restricting access to specified multicast services on a switch port, and IGMP throttling limits the number of simultaneous multicast groups a port can join.
Page 168: Igmp Snooping Status
User’s Manual of IGS-5227-Series 4.8.7 IGMP Snooping Status This page provides IGMP Snooping status. The IGMP Snooping Status screen in Figure 4-8-10 appears. Figure 4-8-10: IGMP Snooping Status Screenshot The page includes the following fields: Object Description VLAN ID The VLAN ID of the entry. •...
Page 169: Igmp Group Information
User’s Manual of IGS-5227-Series Buttons : Click to refresh the page immediately. : Clears all Statistics counters. Auto-refresh : Automatic refresh occurs every 3 seconds. 4.8.8 IGMP Group Information Entries in the IGMP Group Table are shown on this page. The IGMP Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the IGMP Group table, default being 20, selected through the "entries per page"...
Page 170: Igmpv3 Information
User’s Manual of IGS-5227-Series 4.8.9 IGMPv3 Information Entries in the IGMP SSM Information Table are shown on this page. The IGMP SSM Information Table is sorted first by VLAN ID, then by group, and then by Port No. Diffrent source addresses belong to the same group are treated as single entry. Each page shows up to 99 entries from the IGMP SSM (Source Specific Multicast) Information table, default being 20, selected through the "entries per page"...
Page 171: Mld Snooping Configuration
User’s Manual of IGS-5227-Series 4.8.10 MLD Snooping Configuration This page provides MLD Snooping related configuration. The MLD Snooping Configuration screen in Figure 4-8-13 appears. Figure 4-8-13: MLD Snooping Configuration Screenshot The page includes the following fields: Object Description Enable the Global MLD Snooping. •...
Page 172: Mld Snooping Vlan Configuration
User’s Manual of IGS-5227-Series will act as a router port. The allowed selection is Auto, Fix, Fone, default compatibility value is Auto. • Fast Leave Enable the fast leave on the port. • Throtting Enable to limit the number of multicast groups to which a switch port can belong. Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values.
Page 173 User’s Manual of IGS-5227-Series network. The allowed selection is MLD-Auto, Forced MLDv1, Forced MLDv2, default compatibility value is MLD-Auto. • PRI (PRI) Priority of Interface. It indicates the MLD control frame priority level generated by the system. These values can be used to prioritize different classes of traffic.
Page 174: Mld Snooping Port Group Filtering
User’s Manual of IGS-5227-Series 4.8.12 MLD Snooping Port Group Filtering In certain switch applications, the administrator may want to control the multicast services that are available to end users. For example, an IP/TV service based on a specific subscription plan. The MLD filtering feature fulfills this requirement by restricting access to specified multicast services on a switch port, and MLD throttling limits the number of simultaneous multicast groups a port can join.
Page 175: Mld Snooping Status
User’s Manual of IGS-5227-Series 4.8.13 MLD Snooping Status This page provides MLD Snooping status. The IGMP Snooping Status screen in Figure 4-8-16 appears. Figure 4-8-16: MLD Snooping Status Screenshot The page includes the following fields: Object Description VLAN ID The VLAN ID of the entry. •...
Page 176: Mld Group Information
User’s Manual of IGS-5227-Series Buttons : Click to refresh the page immediately. : Clears all Statistics counters. Auto-refresh : Automatic refresh occurs every 3 seconds. 4.8.14 MLD Group Information Entries in the MLD Group Table are shown on this page. The MLD Group Table is sorted first by VLAN ID, and then by group.Each page shows up to 99 entries from the MLD Group table, default being 20, selected through the "entries per page"...
Page 177: Mldv2 Information
User’s Manual of IGS-5227-Series 4.8.15 MLDv2 Information Entries in the MLD SFM Information Table are shown on this page. The MLD SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by Port.
Page 178: Mvr (Multicast Vlan Registration)
User’s Manual of IGS-5227-Series 4.8.16 MVR (Multicast VLAN Registration) The MVR feature enables multicast traffic forwarding on the Multicast VLANs. In a multicast television application, a PC or a network television or a set-top box can receive the multicast stream. ■...
Page 179 User’s Manual of IGS-5227-Series This page provides MVR related configuration. The MVR screen in Figure 4-8-19 appears. Figure 4-8-19: MVR Configuration Screenshot The page includes the following fields: Object Description • MVR Mode Enable/Disable the Global MVR. The Unregistered Flooding control depends on the current configuration in IGMP/MLD Snooping.
Page 180 User’s Manual of IGS-5227-Series MVR VLAN entries or it can be added to the new entries. • IGMP Address Define the IPv4 address as source address used in IP header for IGMP control frames. The default IGMP address is not set (0.0.0.0). When the IGMP address is not set, system uses IPv4 management address of the IP interface associated with this VLAN.
Page 181: Mvr Status
User’s Manual of IGS-5227-Series Buttons : Click to add new MVR VLAN. Specify the VID and configure the new entry. Click "Save" : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. 4.8.17 MVR Status This page provides MVR status.
Page 182: Mvr Groups Information
User’s Manual of IGS-5227-Series 4.8.18 MVR Groups Information Entries in the MVR Group Table are shown on this page. The MVR Group Table is sorted first by VLAN ID, and then by group. Each page shows up to 99 entries from the MVR Group table, default being 20, selected through the "entries per page" input field.
Page 183: Mvr Sfm Information
User’s Manual of IGS-5227-Series 4.8.19 MVR SFM Information Entries in the MVR SFM Information Table are shown on this page. The MVR SFM (Source-Filtered Multicast) Information Table also contains the SSM (Source-Specific Multicast) information. This table is sorted first by VLAN ID, then by group, and then by Port.
Page 184: Quality Of Service
User’s Manual of IGS-5227-Series 4.9 Quality of Service 4.9.1 Understanding QoS Quality of Service (QoS) is an advanced traffic prioritization feature that allows you to establish control over network traffic. QoS enables you to assign various grades of network service to different types of traffic, such as multi-media, video, protocol-specific, time critical, and file-backup traffic.
Page 185: Port Policing
User’s Manual of IGS-5227-Series 4.9.2 Port Policing This page allows you to configure the Policer settings for all switch ports. The Port Policing screen in Figure 4-9-1 appears. Figure 4-9-1: QoS Ingress Port Policers Screenshot The page includes the following fields: Object Description Port...
Page 186: Port Classification
User’s Manual of IGS-5227-Series 4.9.3 Port Classification This page allows you to configure the basic QoS Ingress Classification settings for all switch ports. The Port Classification screen in Figure 4-9-2 appears. Figure 4-9-2 : QoS Ingress Port Classification Screenshot The page includes the following fields: Object Description •...
Page 187 User’s Manual of IGS-5227-Series Controls the default value. All frames are classified to a PCP value. • PCP If the port is VLAN aware and the frame is tagged, then the frame is classified to the PCP value in the tag. Otherwise the frame is classified to the default PCP value.
Page 188: Port Scheduler
User’s Manual of IGS-5227-Series 4.9.4 Port Scheduler This page provides an overview of QoS Egress Port Schedulers for all switch ports. The Port Scheduler screen in Figure 4-9-3 appears. Figure 4-9-3: QoS Egress Port Schedule Screenshot The page includes the following fields: Object Description •...
Page 189: Port Shaping
User’s Manual of IGS-5227-Series 4.9.5 Port Shaping This page provides an overview of QoS Egress Port Shapers for all switch ports. The Port Shapping screen in Figure 4-9-4 appears. Figure 4-9-4: QoS Egress Port Shapers Screenshot The page includes the following fields: Object Description •...
Page 190: Qos Egress Port Schedule And Shapers
User’s Manual of IGS-5227-Series 4.9.5.1 QoS Egress Port Schedule and Shapers The Port Scheduler and Shapers for a specific port are configured on this page. The QoS Egress Port Schedule and Shaper screen in Figure 4-9-5 appears. Figure 4-9-5: QoS Egress Port Schedule and Shapers Screenshot The page includes the following fields: Object Description...
Page 191 User’s Manual of IGS-5227-Series The default value is "kbps". • Queue Shaper Excess Controls whether the queue is allowed to use excess bandwidth. • Queue Scheduler Controls the weight for this queue. Weight This value is restricted to 1-100. This parameter is only shown if "Scheduler Mode"...
Page 192: Port Tag Remarking
User’s Manual of IGS-5227-Series 4.9.6 Port Tag Remarking This page provides an overview of QoS Egress Port Tag Remarking for all switch ports. The Port Tag Remarking screen in Figure 4-9-6 appears. Figure 4-9-6: QoS Egress Port Tag Remarking Screenshot The page includes the following fields: Object Description...
Page 193: Qos Egress Port Tag Remarking
User’s Manual of IGS-5227-Series 4.9.6.1 QoS Egress Port Tag Remarking The QoS Egress Port Tag Remarking for a specific port are configured on this page. The QoS Egress Port Tag Remarking screen in Figure 4-9-7 appears. Figure 4-9-7: QoS Egress Port Tag Remarking Screenshot The page includes the following fields: Object Description...
Page 194: Port Dscp
User’s Manual of IGS-5227-Series 4.9.7 Port DSCP This page allows you to configure the basic QoS Port DSCP Configuration settings for all switch ports. The Port DSCP screen in Figure 4-9-8 appears. Figure 4-9-8: QoS Port DSCP Configuration Screenshot The page includes the following fields: Object Description •...
Page 195 User’s Manual of IGS-5227-Series The Configuration All with available options will assign to whole ports. • Egress Port Egress Rewriting can be one of –. All means all ports will have one specific setting. Disable: No Egress rewrite.  Enable: Rewrite enabled without remapping. ...
Page 196: Dscp-Based Qos
User’s Manual of IGS-5227-Series 4.9.8 DSCP-based QoS This page allows you to configure the basic QoS DSCP-based QoS Ingress Classification settings for all switches. The DSCP-based QoS screen in Figure 4-9-9 appears. Figure 4-9-9: DSCP-based QoS Ingress Classification Screenshot The page includes the following fields: Object Description •...
Page 197: Dscp Translation
User’s Manual of IGS-5227-Series 4.9.9 DSCP Translation This page allows you to configure the basic QoS DSCP Translation settings for all switches. DSCP translation can be done in Ingress or Egress. The DSCP Translation screen in Figure 4-9-10 appears. Figure 4-9-10: DSCP Translation Screenshot The page includes the following fields: Object Description...
Page 198: Dscp Classification
User’s Manual of IGS-5227-Series • Classify Click to enable Classification at Ingress side. • Egress There are the following configurable parameters for Egress side – Remap DP0 Controls the remapping for frames with DP level 0. Remap DP1 Controls the remapping for frames with DP level 1. Remap DP0 Select the DSCP value from select menu to which you want to remap.
Page 199: Qos Control List
User’s Manual of IGS-5227-Series Figure 4-9-11: DSCP Classification Screenshot The page includes the following fields: Object Description • QoS Class Available QoS Class value ranges from 0 to 7. QoS Class (0-7) can be mapped to followed parameters. • DPL Actual Drop Precedence Level.
Page 200 User’s Manual of IGS-5227-Series Broadcast: Only Broadcast MAC addresses are allowedd. ■ The default value is 'Any'. • SMAC Displays the OUI field of Source MAC address, i.e. first three octet (byte) of MAC address. • Tag Type Indicates tag type. Possible values are: Any: Match tagged and untagged frames.
Page 201: Qos Control Entry Configuration
User’s Manual of IGS-5227-Series 4.9.11.1 QoS Control Entry Configuration The QCE Configuration screen in Figure 4-9-13 appears. Figure 4-9-13: QCE Configuration Screenshot The page includes the following fields: Object Description Port Members Check the checkbox button in case you what to make any port member of the •...
Page 202 User’s Manual of IGS-5227-Series SNAP IPv4 IPv6 Note: all frame types are explained below. • Any Allow all types of frames. Ethernet Type Valid ethernet type can have value within 0x600-0xFFFF or 'Any' • EtherType but excluding 0x800(IPv4) and 0x86DD(IPv6), default value is 'Any'. •...
Page 203: Qcl Status
User’s Manual of IGS-5227-Series DSCP Diffserv Code Point value(DSCP): It can be specific value, range of ■ value or 'Any'. DSCP values are in the range 0-63 including BE, CS1-CS7, EF or AF11-AF43 Sport Source TCP/UDP port:(0-65535) or 'Any', specific or port range ■...
Page 204 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • User Indicates the QCL user. QCE# Indicates the index of QCE. • • Port Indicates the list of ports configured with the QCE. Indicates the type of frame to look for incoming frames. Possible frame types are: •...
Page 205: Storm Control Configuration
User’s Manual of IGS-5227-Series 4.9.13 Storm Control Configuration Storm control for the switch is configured on this page. There is a unicast storm rate control, multicast storm rate control, and a broadcast storm rate control. These only affect flooded frames, i.e. frames with a (VLAN ID, DMAC) pair not present on the MAC Address table.
Page 206: Qos Statistics
User’s Manual of IGS-5227-Series 4.9.14 QoS Statistics This page provides statistics for the different queues for all switch ports. The QoS Statistics screen in Figure 4-9-17 appears. Figure 4-9-16: Queuing Counters Screenshot The page includes the following fields: Object Description Port The logical port for the settings contained in the same row.
Page 207: Voice Vlan Configuration
User’s Manual of IGS-5227-Series 4.9.15 Voice VLAN Configuration The Voice VLAN feature enables voice traffic forwarding on the Voice VLAN, then the switch can classify and schedule network traffic. It is recommended that there be two VLANs on a port - one for voice, one for data. Before connecting the IP device to the switch, the IP phone should configure the voice VLAN ID correctly.
Page 208 User’s Manual of IGS-5227-Series • Aging Time Indicates the Voice VLAN secure learning age time. The allowed range is 10 to 10000000 seconds. It used when security mode or auto detect mode is enabled. In other cases, it will based hardware age time. The actual age time will be situated in the [age_time;...
Page 209: Voice Vlan Oui Table
User’s Manual of IGS-5227-Series 4.9.16 Voice VLAN OUI Table Configure VOICE VLAN OUI table on this page. The maximum entry number is 16. Modifying the OUI table will restart auto detection of OUI process. The Voice VLAN OUI Table screen in Figure 4-9-18 appears.
Page 210: Access Control List
User’s Manual of IGS-5227-Series 4.10 Access Control List ACL is an acronym for Access Control List. It is the list table of ACEs, containing access control entries that specify individual users or groups permitted or denied to specific traffic objects, such as a process or a program. Each accessible traffic object contains an identifier to its ACL.
Page 211 User’s Manual of IGS-5227-Series frames. ARP: The ACE will match ARP/RARP frames. ■ IPv4: The ACE will match all IPv4 frames. ■ IPv4/ICMP: The ACE will match IPv4 frames with ICMP protocol. ■ IPv4/UDP: The ACE will match IPv4 frames with UDP protocol. ■...
Page 212: Access Control List Configuration
User’s Manual of IGS-5227-Series 4.10.2 Access Control List Configuration This page shows the Access Control List (ACL), which is made up of the ACEs defined on this switch. Each row describes the ACE that is defined. The maximum number of ACEs is 512 on each switch. Click on the lowest plus sign to add a new ACE to the list.
Page 213 User’s Manual of IGS-5227-Series • Port Redirect Indicates the port redirect operation of the ACE. Frames matching the ACE are redirected to the port number. The allowed values are Disabled or a specific port number. When Disabled is displayed, the port redirect operation is disabled. •...
Page 214: Ace Configuration
User’s Manual of IGS-5227-Series 4.10.3 ACE Configuration Configure an ACE (Access Control Entry) on this page. An ACE consists of several parameters. These parameters vary according to the frame type that you select. First select the ingress port for the ACE, and then select the frame type. Different parameter options are displayed depending on the frame type selected.
Page 215 User’s Manual of IGS-5227-Series Ethernet Type: Only Ethernet Type frames can match this ACE. The IEEE ■ 802.3 describes the value of Length/Type Field specifications to be greater than or equal to 1536 decimal (equal to 0600 hexadecimal). ARP: Only ARP frames can match this ACE. Notice the ARP frames won't ■...
Page 216 User’s Manual of IGS-5227-Series MAC Parameters  Object Description SMAC Filter (Only displayed when the frame type is Ethernet Type or ARP.) • Specify the source MAC filter for this ACE. Any: No SMAC filter is specified. (SMAC filter status is "don't-care".) ■...
Page 217 User’s Manual of IGS-5227-Series Tag Priority Specify the tag priority for this ACE. A frame that hits this ACE matches this tag priority. • The allowed number range is 0 to 7. The value Any means that no tag priority is specified (tag priority is "don't-care".) ARP Parameters ...
Page 218 User’s Manual of IGS-5227-Series • ARP Sender MAC Specify whether frames can hit the action according to their sender hardware Match address field (SHA) settings. 0: ARP frames where SHA is not equal to the SMAC address. ■ 1: ARP frames where SHA is equal to the SMAC address. ■...
Page 219 User’s Manual of IGS-5227-Series defining UDP parameters will appear. These fields are explained later in this help file. TCP: Select TCP to filter IPv4 TCP protocol frames. Extra fields for defining ■ TCP parameters will appear. These fields are explained later in this help file.
Page 220 User’s Manual of IGS-5227-Series Any: No destination IP filter is specified. (Destination IP filter is ■ "don't-care".) Host: Destination IP filter is set to Host. Specify the destination IP address ■ in the DIP Address field that appears. Network: Destination IP filter is set to Network. Specify the destination IP ■...
Page 221 User’s Manual of IGS-5227-Series SIPv6 mask. The field only supported last 32 bits for IPv6 address. Notice the usage of bitmask, if the binary bit value is "0", it means this bit is "don't-care". The real matched pattern is [sipv6_address & sipv6_bitmask] (last 32 bits). For example, if the SIPv6 address is 2001::3 and the SIPv6 bitmask is 0xFFFFFFFE(bit 0 is "don't-care"...
Page 222 User’s Manual of IGS-5227-Series TCP/UDP Parameters  Object Description TCP/UDP Source Filter Specify the TCP/UDP source filter for this ACE. • Any: No TCP/UDP source filter is specified (TCP/UDP source filter status ■ is "don't-care"). Specific: If you want to filter a specific TCP/UDP source filter with this ■...
Page 223 User’s Manual of IGS-5227-Series entry. 1: TCP frames where the SYN field is set must be able to match this entry. ■ Any: Any value is allowed ("don't-care"). ■ • TCP RST Specify the TCP "Reset the connection" (RST) value for this ACE. 0: TCP frames where the RST field is set must not be able to match this ■...
Page 224: Acl Ports Configuration
User’s Manual of IGS-5227-Series Buttons : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. : Return to the previous page. 4.10.4 ACL Ports Configuration Configure the ACL parameters (ACE) of each switch port. These parameters will affect frames received on a port unless the frame matches a specific ACE.
Page 225 User’s Manual of IGS-5227-Series value is "Disabled". • Mirror Specify the mirror operation of this port. The allowed values are: Enabled: Frames received on the port are mirrored. ■ Disabled: Frames received on the port are not mirrored. ■ The default value is "Disabled". •...
Page 226: Acl Rate Limiter Configuration
User’s Manual of IGS-5227-Series 4.10.5 ACL Rate Limiter Configuration Configure the rate limiter for the ACL of the switch. The ACL Rate Limiter Configuration screen in Figure 4-10-5 appears. Figure 4-10-5: ACL Rate Limiter Configuration Screenshot The page includes the following fields: Object Description Rate Limiter ID...
Page 227: Authentication
User’s Manual of IGS-5227-Series 4.11 Authentication This section is to control the access of the Industrial Managed Switch, including the user access and management control. The Authentication section contains links to the following main topics: IEEE 802.1X Port-based Network Access Control ...
Page 228: Understanding Ieee 802.1X Port-Based Authentication
User’s Manual of IGS-5227-Series software to authenticate. The disadvantage is that MAC addresses can be spoofed by malicious users, equipment whose MAC address is a valid RADIUS user can be used by anyone, and only the MD5-Challenge method is supported. The 802.1X and MAC-Based Authentication configuration consists of two sections, a system- and a port-wide.
Page 229 User’s Manual of IGS-5227-Series Figure 4-11-1 Client—the device (workstation) that requests access to the LAN and switch services and responds to requests from  the switch. The workstation must be running 802.1X-compliant client software such as that offered in the Microsoft Windows XP operating system.
Page 230 User’s Manual of IGS-5227-Series authentication server, the server's frame header is removed, leaving the EAP frame, which is then encapsulated for Ethernet and sent to the client. Authentication Initiation and Message Exchange  The switch or the client can initiate authentication. If you enable authentication on a port by using the dot1x port-control auto interface configuration command, the switch must initiate authentication when it determines that the port link state transitions from down to up.
Page 231: Authentication Configuration
User’s Manual of IGS-5227-Series Ports in Authorized and Unauthorized States  The switch port state determines whether or not the client is granted access to the network. The port starts in the unauthorized state. While in this state, the port disallows all ingress and egress traffic except for 802.1X protocol packets. When a client is successfully authenticated, the port transitions to the authorized state, allowing all traffic for the client to flow normally.
Page 232: Network Access Server Configuration
User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • Client The management client for which the configuration below applies. • Authentication Method Authentication Method can be set to one of the following values: None: authentication is disabled and login is not possible. ■...
Page 233 User’s Manual of IGS-5227-Series Figure 4-11-4: Network Access Server Configuration Screenshot The page includes the following fields: System Configuration Object Description • Mode Indicates if NAS is globally enabled or disabled on the switch. If globally disabled, all ports are allowed forwarding of frames. •...
Page 234 User’s Manual of IGS-5227-Series Period reauthenticated. This is only active if the Reauthentication Enabled checkbox is checked. Valid values are in the range 1 to 3600 seconds. • EAPOL Timeout Determines the time for retransmission of Request Identity EAPOL frames. Valid values are in the range 1 to 65535 seconds.
Page 235 User’s Manual of IGS-5227-Series Enabled which traffic coming from a successfully authenticated supplicant is assigned on the switch. The RADIUS server must be configured to transmit special RADIUS attributes to take advantage of this feature. The "RADIUS-Assigned QoS Enabled" checkbox provides a quick way to globally enable/disable RADIUS-server assigned QoS Class functionality.
Page 236 User’s Manual of IGS-5227-Series • Allow Guest VLAN if The switch remembers if an EAPOL frame has been received on the port for the EAPOL Seen life-time of the port. Once the switch considers whether to enter the Guest VLAN, it will first check if this option is enabled or disabled.
Page 237 User’s Manual of IGS-5227-Series MD5-Challenge, PEAP, and TLS. The important thing is that the authenticator (the switch) doesn't need to know which authentication method the supplicant and the authentication server are using, or how many information exchange frames are needed for a particular method. The switch simply encapsulates the EAP part of the frame into the relevant type (EAPOL or RADIUS) and forwards it.
Page 238 User’s Manual of IGS-5227-Series successfully authenticated. Multi 802.1X Multi 802.1X is - like Single 802.1X - not an IEEE standard, but a variant that features many of the same characteristics. In Multi 802.1X, one or more supplicants can get authenticated on the same port at the same time. Each supplicant is authenticated individually and secured in the MAC table using the Port Security module.
Page 239 User’s Manual of IGS-5227-Series The advantage of MAC-based authentication over port-based 802.1X is that several clients can be connected to the same port (e.g. through a 3rd party switch or a hub) and still require individual authentication, and that the clients don't need special supplicant software to authenticate.
Page 240 User’s Manual of IGS-5227-Series changed to this VLAN ID, the port will be set to be a member of that VLAN ID, and the port will be forced into VLAN unaware mode. Once assigned, all traffic arriving on the port will be classified and switched on the RADIUS-assigned VLAN ID.
Page 241 User’s Manual of IGS-5227-Series  Multi 802.1X For trouble-shooting VLAN assignments, use the "Monitor→VLANs→VLAN Membership and VLAN Port" pages. These pages show which modules have (temporarily) overridden the current Port VLAN configuration. Guest VLAN Operation: When a Guest VLAN enabled port's link comes up, the switch starts transmitting EAPOL Request Identity frames.
Page 242 User’s Manual of IGS-5227-Series EAPOL-based or MAC-based mode. Clicking these buttons will not cause settings changed on the page to take effect. Reauthenticate: Schedules a reauthentication to whenever the ■ quiet-period of the port runs out (EAPOL-based authentication). For MAC-based authentication, reauthentication will be attempted immediately. The button only has effect for successfully authenticated clients on the port and will not cause the clients to get temporarily unauthorized.
Page 243: Network Access Overview
User’s Manual of IGS-5227-Series 4.11.4 Network Access Overview This page provides an overview of the current NAS port states for the selected switch. The Network Access Overview screen in Figure 4-11-5 appears. Figure 4-11-5: Network Access Server Switch Status Screenshot The page includes the following fields: Object Description...
Page 244: Network Access Statistics
User’s Manual of IGS-5227-Series Buttons Click to refresh the page immediately. Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. 4.11.5 Network Access Statistics This page provides detailed NAS statistics for a specific switch port running EAPOL-based IEEE 802.1X authentication. For MAC-based ports, it shows selected backend server (RADIUS Authentication Server) statistics, only.
Page 245 User’s Manual of IGS-5227-Series Port Counters Object Description • EAPOL Counters These supplicant frame counters are available for the following administrative states: Force Authorized ■ Force Unauthorized ■ Port-based 802.1X ■ Single 802.1X ■ Multi 802.1X ■ Direction Name IEEE Name Description Total dot1xAuthEapolFrames...
Page 246 User’s Manual of IGS-5227-Series which the Packet Body Length field is invalid. Total dot1xAuthEapolFrames The number of EAPOL frames of any type that have been transmitted by the switch. Request ID dot1xAuthEapolReqIdFr The number of EAPOL amesTx Request Identity frames that have been transmitted by the switch.
Page 247 User’s Manual of IGS-5227-Series table). Other dot1xAuthBackendOther 802.1X-based: Requests RequestsToSupplicant Counts the number of times that the switch sends an EAP Request packet following the first to the supplicant. Indicates that the backend server chose an EAP-method. MAC-based: Not applicable. Auth.
Page 248 User’s Manual of IGS-5227-Series towards the backend server for a given port (left-most table) or client (right-most table). Possible retransmissions are not counted. • Last Supplicant/Client Information about the last supplicant/client that attempted to authenticate. This Info information is available for the following administrative states: Port-based 802.1X ■...
Page 249 User’s Manual of IGS-5227-Series no MAC address is currently selected. To populate the table, select one of the attached MAC Addresses from the table below. Attached MAC Address Object Description • Identity Shows the identity of the supplicant, as received in the Response Identity EAPOL frame. Clicking the link causes the supplicant's EAPOL and Backend Server counters to be shown in the Selected Counters table.
Page 250 User’s Manual of IGS-5227-Series : This button is available in the following modes: • Multi 802.1X • MAC-based Auth.X Click to clear both the port counters and all of the attached client's counters. The "Last Client" will not be cleared, however. : This button is available in the following modes: •...
Page 251: Radius
User’s Manual of IGS-5227-Series 4.11.6 RADIUS This page allows you to configure the RADIUS Servers. The RADIUS Configuration screen in Figure 4-11-7 appears. Figure 4-11-7: RADIUS Server Configuration Screenshot The page includes the following fields: Global Configuration These setting are common for all of the RADIUS Servers. Object Description •...
Page 252 User’s Manual of IGS-5227-Series • Key The secret key - up to 63 characters long - shared between the RADIUS server and the switch. • NAS-IP-Address The IPv4 address to be used as attribute 4 in RADIUS Access-Request packets. If this field is left blank, the IP address of the outgoing interface is used. •...
Page 253: Tacacs
User’s Manual of IGS-5227-Series 4.11.7 TACACS+ This page allows you to configure the TACACS+ Servers. The TACACS+ Configuration screen in Figure 4-11-8 appears. Figure 4-11-8: TACACS+ Server Configuration Screenshot The page includes the following fields: Global Configuration These setting are common for all of the TACACS+ Servers. Object Description •...
Page 254: Radius Overview
User’s Manual of IGS-5227-Series Server Configuration The table has one row for each TACACS+ server and a number of columns, which are: Object Description • Delete To delete a TACACS+ server entry, check this box. The entry will be deleted during the next Save.
Page 255 User’s Manual of IGS-5227-Series The page includes the following fields: RADIUS Authentication Server Status Overview Object Description • # The RADIUS server number. Click to navigate to detailed statistics for this server. • IP Address The IP address and UDP port number (in <IP Address>:<UDP Port> notation) of this server. •...
Page 256: Radius Details
User’s Manual of IGS-5227-Series 4.11.9 RADIUS Details This page provides detailed statistics for a particular RADIUS server. The RADIUS Authentication/Accounting for Server Overview screen in Figure 4-11-10 appears. Figure 4-11-10: RADIUS Authentication/Accounting for Server Overview Screenshot The page includes the following fields: RADIUS Authentication Statistics The statistics map closely to those specified in RFC4668 - RADIUS Authentication Client MIB.
Page 257 User’s Manual of IGS-5227-Series Access radiusAuthClientExtA The number of RADIUS Accepts ccessAccepts Access-Accept packets (valid or invalid) received from the server. Access Rejects radiusAuthClientExtA The number of RADIUS ccessRejects Access-Reject packets (valid or invalid) received from the server. Access radiusAuthClientExtA The number of RADIUS Challenges ccessChallenges...
Page 258 User’s Manual of IGS-5227-Series from the server on the authentication port and dropped for some other reason. Access radiusAuthClientExtA The number of RADIUS Requests ccessRequests Access-Request packets sent to the server. This does not include retransmissions. Access radiusAuthClientExtA The number of RADIUS Retransmissio ccessRetransmission Access-Request packets...
Page 259 User’s Manual of IGS-5227-Series IP Address IP address and UDP port for the authentication server in question. State Shows the state of the server. It takes one of the following values: Disabled: The selected server is disabled.  Not Ready: The server is enabled, but IP ...
Page 260 User’s Manual of IGS-5227-Series Malformed radiusAccClientExt The number of malformed Responses MalformedRespons RADIUS packets received from the server. Malformed packets include packets with an invalid length. Bad authenticators or or unknown types are not included as malformed access responses. radiusAcctClientExt The number of RADIUS Authenticators BadAuthenticators...
Page 261 User’s Manual of IGS-5227-Series retransmission. Timeouts radiusAccClientExt The number of accounting Timeouts timeouts to the server. After a timeout, the client may retry to the same server, send to a different server, or give up. A retry to the same server is counted as a retransmit as well as a timeout.
Page 262: Windows Platform Radius Server Configuration
User’s Manual of IGS-5227-Series The granularity of this measurement is 100 ms. A value of 0 ms indicates that there hasn't been round-trip communication with the server yet. Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. Click to refresh the page immediately.
Page 263 User’s Manual of IGS-5227-Series Add New RADIUS Client on the Windows 2003 server Figure 4-11-12: Windows Server – Add New RADIUS Client Setting Assign the client IP address to the Industrial Managed Switch Figure 4-11-13: Windows Server RADIUS Server Setting...
Page 264 User’s Manual of IGS-5227-Series The shared secret key should be the same as the key configured on the Industrial Managed Switch. Figure 4-11-14: Windows Server RADIUS Server Setting Configure ports attribute of 802.1X the same as “802.1X Port Configuration”. Figure 4-11-15: 802.1x Port Configuration...
Page 265 User’s Manual of IGS-5227-Series Create user data. The establishment of the user data needs to be created on the Radius Server PC. For example, the Radius Server is founded on Win2003 Server, and then: Figure 4-11-16: Windows 2003 AD Server Setting Path...
Page 266 User’s Manual of IGS-5227-Series Enter ” Active Directory Users and Computers”, create legal user data; next, right-click a user what you created to enter properties, and what to be noticed: Figure 4-11-17: Add User Properties Screen Figure 4-11-18: Add User Properties Screen...
Page 267: Client Configuration
User’s Manual of IGS-5227-Series Set the Port Authenticate Status to “Force Authorized” if the port is connected to the RADIUS server or the port is an uplink port that is connected to another switch. Or once the 802.1X starts to work, the switch might not be able to access the RADIUS server.
Page 268 User’s Manual of IGS-5227-Series Select “Authentication” tab. Select “Enable network access control using IEEE 802.1X” to enable 802.1x authentication. Select “MD-5 Challenge” from the drop-down list box for EAP type. Figure 4-11-20 Click “OK”. When client has associated with the Industrial Managed Switch, a user authentication notice appears in system tray. Click on the notice to continue.
Page 269 User’s Manual of IGS-5227-Series Enter the user name, password and the logon domain that your account belongs. 10. Click “OK” to complete the validation process. Figure 4-11-22...
Page 270: Security
User’s Manual of IGS-5227-Series 4.12 Security This section is to control the access of the Industrial Managed Switch, includes the user access and management control. The Security page contains links to the following main topics: Port Limit Control  Access Management ...
Page 271 User’s Manual of IGS-5227-Series The page includes the following fields: System Configuration Object Description • Mode Indicates if Limit Control is globally enabled or disabled on the switchstack. If globally disabled, other modules may still use the underlying functionality, but limit checks and corresponding actions are disabled.
Page 272 User’s Manual of IGS-5227-Series • Limit The maximum number of MAC addresses that can be secured on this port. This number cannot exceed 1024. If the limit is exceeded, the corresponding action is taken. The switch is "born" with a total number of MAC addresses from which all ports draw whenever a new MAC address is seen on a Port Security-enabled port.
Page 273: Access Management
User’s Manual of IGS-5227-Series • Re-open Button If a port is shutdown by this module, you may reopen it by clicking this button, which will only be enabled if this is the case. For other methods, refer to Shutdown in the Action section. Note, that clicking the reopen button causes the page to be refreshed, so non-committed changes will be lost.
Page 274: Access Management Statistics
User’s Manual of IGS-5227-Series • Start IP address Indicates the start IP address for the access management entry. • End IP address Indicates the end IP address for the access management entry. • HTTP/HTTPS Indicates the host can access the switch from HTTP/HTTPS interface that the host IP address matched the entry.
Page 275: Https
User’s Manual of IGS-5227-Series Buttons Auto-refresh : Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. : Click to refresh the page immediately. : Clears all statistics. 4.12.4 HTTPs Configure HTTPS on this page. The HTTPS Configuration screen in Figure 4-12-4 appears.
Page 276: Ssh
User’s Manual of IGS-5227-Series : Click to apply changes : Click to undo any changes made locally and revert to previously saved values. 4.12.5 SSH Configure SSH on this page. This page shows the Port Security status. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules.
Page 277 User’s Manual of IGS-5227-Series from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning. In this mode, frames from unknown MAC addresses are passed on to the port security module, which in turn asks all user modules whether to allow this new MAC address to forward or block it.
Page 278 User’s Manual of IGS-5227-Series Object Description • Port The port number for which the status applies. Click the port number to see the status for this particular port. • Users Each of the user modules has a column that shows whether that module has enabled Port Security or not.
Page 279: Port Security Detail
User’s Manual of IGS-5227-Series 4.12.7 Port Security Detail This page shows the MAC addresses secured by the Port Security module. Port Security is a module with no direct configuration. Configuration comes indirectly from other modules - the user modules. When a user module has enabled port security on a port, the port is set-up for software-based learning.
Page 280: Dhcp Snooping
User’s Manual of IGS-5227-Series 4.12.8 DHCP Snooping DHCP Snooping is used to block intruder on the untrusted ports of DUT when it tries to intervene by injecting a bogus DHCP reply packet to a legitimate conversation between the DHCP client and server. Configure DHCP Snooping on this page.
Page 281: Snooping Table
User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • Snooping Mode Indicates the DHCP snooping mode operation. Possible modes are: Enabled: Enable DHCP snooping mode operation. When enable DHCP  snooping mode operation, the request DHCP messages will be forwarded to trusted ports and only allowed reply packets from trusted ports.
Page 282: Ip Source Guard Configuration
User’s Manual of IGS-5227-Series 4.12.10 IP Source Guard Configuration IP Source Guard is a secure feature used to restrict IP traffic on DHCP snooping untrusted ports by filtering traffic based on the DHCP Snooping Table or manually configured IP Source Bindings. It helps prevent IP spoofing attacks when a host tries to spoof and use the IP address of another host.
Page 283: Ip Source Guard Static Table
User’s Manual of IGS-5227-Series Buttons : Click to translate all dynamic entries to static entries. : Click to apply changes Click to undo any changes made locally and revert to previously saved values. 4.12.11 IP Source Guard Static Table This page provides Static IP Source Guard Table. The Static IP Source Guard Table screen in Figure 4-12-11 appears.
Page 284: Dynamic Ip Source Guard Table
User’s Manual of IGS-5227-Series 4.12.12 Dynamic IP Source Guard Table Entries in the Dynamic IP Source Guard Table are shown on this page. The Dynamic IP Source Guard Table is sorted first by port, then by VLAN ID, then by IP address, and then by IP mask. The Dynamic IP Source Guard Table screen in Figure 4-12-12 appears.
Page 285: Arp Inspection
User’s Manual of IGS-5227-Series 4.12.13 ARP Inspection ARP Inspection is a secure feature. Several types of attacks can be launched against a host or devices connected to Layer 2 networks by "poisoning" the ARP caches. This feature is used to block such attacks. Only valid ARP requests and responses can go through DUT.
Page 286: Arp Inspection Static Table
User’s Manual of IGS-5227-Series to the port setting. And the setting of "Check VLAN" is enabled, the log type of ARP Inspection will refer to the VLAN setting. Possible setting of "Check VLAN" are: Enabled: Enable check VLAN operation.  Disabled: Disable check VLAN operation.
Page 287: Dynamic Arp Inspection Table
User’s Manual of IGS-5227-Series The logical port for the settings. • Port • VLAN ID The VLAN ID for the settings. Allowed Source MAC address in ARP request packets. • MAC Address Allowed Source IP address in ARP request packets. •...
Page 288 User’s Manual of IGS-5227-Series The “>>” will use the last entry of the currently displayed as a basis for the next lookup. When the end is reached the text "No more entries" is shown in the displayed table. Use the “|<<” button to start over. The page includes the following fields: Object Description Port...
Page 289: Mac Address Table
User’s Manual of IGS-5227-Series 4.13 MAC Address Table Switching of frames is based upon the DMAC address contained in the frame. The Industrial Managed Switch builds up a table that maps MAC addresses to switch ports for knowing which ports the frames should go to (based upon the DMAC address in the frame ).
Page 290 User’s Manual of IGS-5227-Series Object Description • Disable Automatic Enables/disables the the automatic aging of dynamic entries Aging • Aging Time The time after which a learned entry is discarded. By default, dynamic entries are removed from the MAC after 300 seconds. This removal is also called aging. (Range: 10-10000000 seconds;...
Page 291: Mac Address Table Status
User’s Manual of IGS-5227-Series 4.13.2 MAC Address Table Status Dynamic MAC Table Entries in the MAC Table are shown on this page. The MAC Table contains up to 8192 entries, and is sorted first by VLAN ID, then by MAC address. The MAC Address Table screen in Figure 4-13-2 appears.
Page 292 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description Type Indicates whether the entry is a static or dynamic entry. • VLAN The VLAN ID of the entry. • MAC Address The MAC address of the entry. •...
Page 293: Lldp
User’s Manual of IGS-5227-Series 4.14 LLDP 4.14.1 Link Layer Discovery Protocol Link Layer Discovery Protocol (LLDP) is used to discover basic information about neighboring devices on the local broadcast domain. LLDP is a Layer 2 protocol that uses periodic broadcasts to advertise information about the sending device. Advertised information is represented in Type Length Value (TLV) format according to the IEEE 802.1ab standard, and can include details such as device identification, capabilities and configuration settings.
Page 294 User’s Manual of IGS-5227-Series The page includes the following fields: LLDP Parameters Object Description Tx Interval The switch is periodically transmitting LLDP frames to its neighbors for having • the network discovery information up-to-date. The interval between each LLDP frame is determined by the Tx Interval value. Valid values are restricted to 5 - 32768 seconds.
Page 295 User’s Manual of IGS-5227-Series  Tx only The switch will drop LLDP information received from neighbors, but will send out LLDP information. Disabled The switch will not send out LLDP information, and will drop LLDP  information received from neighbors. Enabled The switch will send out LLDP information, and will analyze LLDP ...
Page 296: Lldp Med Configuration
User’s Manual of IGS-5227-Series Buttons : Click to apply changes Click to undo any changes made locally and revert to previously saved values. 4.14.3 LLDP MED Configuration This page allows you to configure the LLDP-MED. The LLDPMED Configuration screen in Figure 4-14-2 appears.
Page 297 User’s Manual of IGS-5227-Series come with inappropriate knowledge of the network policy. With this in mind LLDP-MED defines an LLDP-MED Fast Start interaction between the protocol and the application layers on top of the protocol, in order to achieve these related properties. Initially, a Network Connectivity Device will only transmit LLDP TLVs in an LLDPDU.
Page 298 User’s Manual of IGS-5227-Series Floors: Representing altitude in a form more relevant in buildings which have different floor-to-floor dimensions. An altitude = 0.0 is meaningful even outside a building, and represents ground level at the given latitude and longitude. Inside a building, 0.0 represents the floor level associated with ground level at the main entrance.
Page 299 User’s Manual of IGS-5227-Series • Landmark Landmark or vanity address - Example: Columbia University • Additional location Additional location info - Example: South Wing info • Name Name (residence and office occupant) - Example: Flemming Jahn • Zip code Postal/zip code - Example: 2791 •...
Page 300 User’s Manual of IGS-5227-Series 2. Layer 2 priority value (IEEE 802.1D-2004) 3. Layer 3 Diffserv code point (DSCP) value (IETF RFC 2474) This network policy is potentially advertised and associated with multiple sets of application types supported on a given port. The application types specifically addressed are: 1.
Page 301 User’s Manual of IGS-5227-Series the same network policies apply as those advertised in the Guest Voice application policy. Softphone Voice - for use by softphone applications on typical data  centric devices, such as PCs or laptops. This class of endpoints frequently does not support multiple VLANs, if at all, and are typically configured to use an 'untagged’...
Page 302 User’s Manual of IGS-5227-Series • DSCP DSCP value to be used to provide Diffserv node behavior for the specified application type as defined in IETF RFC 2474. DSCP may contain one of 64 code point values (0 through 63). A value of 0 represents use of the default DSCP value as defined in RFC 2475.
Page 303: Lldp-Med Neighbor
User’s Manual of IGS-5227-Series 4.14.4 LLDP-MED Neighbor This page provides a status overview for all LLDP-MED neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected. The LLDP-MED Neighbor Information screen in Figure 4-14-3 appears.
Page 304 User’s Manual of IGS-5227-Series LLDP-MED Endpoint Device claiming compliance as a Media Endpoint (Class II) also support all aspects of TIA-1057 applicable to Generic Endpoints (Class I), and any LLDP-MED Endpoint Device claiming compliance as a Communication Device (Class III) will also support all aspects of TIA-1057 applicable to both Media Endpoints (Class II) and Generic Endpoints (Class I).
Page 305 User’s Manual of IGS-5227-Series 2. Network Policy 3. Location Identification 4. Extended Power via MDI - PSE 5. Extended Power via MDI - PD 6. Inventory 7. Reserved • Application Type Application Type indicating the primary function of the application(s) defined for this network policy, advertised by an Endpoint or Network Connectivity Device.
Page 306 User’s Manual of IGS-5227-Series  Untagged: The device is using an untagged frame format and as such does not include a tag header as defined by IEEE 802.1Q-2003. Tagged: The device is using the IEEE 802.1Q tagged frame format  •...
Page 307: Neighbor
User’s Manual of IGS-5227-Series 4.14.5 Neighbor This page provides a status overview for all LLDP neighbors. The displayed table contains a row for each port on which an LLDP neighbor is detected. The LLDP Neighbor Information screen in Figure 4-14-4 appears.
Page 308: Port Statistics
User’s Manual of IGS-5227-Series Buttons : Click to refresh the page immediately. Auto-refresh Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. 4.14.6 Port Statistics This page provides an overview of all LLDP traffic. Two types of counters are shown. Global counters are counters that refer to the whole stack, switch, while local counters refers to counters for the currently selected switch.
Page 309 User’s Manual of IGS-5227-Series Entries Aged Out LLDP Statistics Local Counters The displayed table contains a row for each port. The columns hold the following information: Object Description • Local Port The port on which LLDP frames are received or transmitted. The number of LLDP frames transmitted on the port.
Page 310: Network Diagnostics
User’s Manual of IGS-5227-Series 4.15 Network Diagnostics This section provide the Physical layer and IP layer network diagnostics tools for troubleshoot. The diagnostic tools are designed for network manager to help them quickly diagnose problems between point to point and better service customers. Use the Diagnostics menu items to display and configure basic administrative details of the Industrial Managed Switch.
Page 311: Ping
User’s Manual of IGS-5227-Series 4.15.1 Ping This page allows you to issue ICMP PING packets to troubleshoot IP connectivity issues. After you press “Start”, 5 ICMP packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply. The page refreshes automatically until responses to all packets are received, or until a timeout occurs. The ICMP Ping screen in Figure 4-15-1 appears.
Page 312: Ipv6 Ping
User’s Manual of IGS-5227-Series 4.15.2 IPv6 Ping This page allows you to issue ICMPv6 ping packets to troubleshoot IPv6 connectivity issues. After you press “Start”, 5 ICMPv6 packets are transmitted, and the sequence number and roundtrip time are displayed upon reception of a reply.
Page 313 User’s Manual of IGS-5227-Series Figure 4-15-3: Remote IP Ping Test Screenshot The page includes the following fields: Object Description The logical port for the settings. • Port Remote IP Address The destination IP Address. • The payload size of the ICMP packet. •...
Page 314: Cable Diagnostics
User’s Manual of IGS-5227-Series 4.15.4 Cable Diagnostics This page is used for running the Cable Diagnostics. Press to run the diagnostics. This will take approximately 5 seconds. If all ports are selected, this can take approximately 15 seconds. When completed, the page refreshes automatically, and you can view the cable diagnostics results in the cable status table.
Page 315 User’s Manual of IGS-5227-Series Cross B - Abnormal cross-pair coupling with pair B Cross C - Abnormal cross-pair coupling with pair C Cross D - Abnormal cross-pair coupling with pair D Length: The length (in meters) of the cable pair. The resolution is 3 meters Buttons : Click to run the diagnostics.
Page 316: Loop Protection
User’s Manual of IGS-5227-Series 4.16 Loop Protection This chapter describes enabling loop protection function that provides loop protection to prevent broadcast loops in Industrial Managed Switch. 4.16.1 Configuration This page allows the user to inspect the current Loop Protection configurations, and possibly change them as well; screen in Figure 4-16-1 appears.
Page 317: Loop Protection Status
User’s Manual of IGS-5227-Series 604800 seconds (7 days). A value of zero will keep a port disabled (until next device restart). Port Configuration Object Description Port The switch port number of the port. • • Enable Controls whether loop protection is enabled on this switch port. Configures the action performed when a loop is detected on a port.
Page 318 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • Port The Industrial Managed Switch port number of the logical port. • Action The currently configured port action. • Transmit The currently configured port transmit mode. • Loops The number of loops detected on this port.
Page 319: Rmon
User’s Manual of IGS-5227-Series 4.17 RMON RMON is the most important expansion of the standard SNMP. RMON is a set of MIB definitions, used to define standard network monitor functions and interfaces, enabling the communication between SNMP management terminals and remote monitors.
Page 320 User’s Manual of IGS-5227-Series protocol. InNUcastPkts: The number of broad-cast and multi-cast packets delivered  to a higher-layer protocol. InDiscards: The number of inbound packets that are discarded even the  packets are normal. InErrors: The number of inbound packets that contains errors preventing ...
Page 321: Rmon Alarm Status
User’s Manual of IGS-5227-Series 4.17.2 RMON Alarm Status This page provides an overview of RMON Alarm entries. Each page shows up to 99 entries from the Alarm table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Alarm table.
Page 322: Rmon Event Configuration
User’s Manual of IGS-5227-Series 4.17.3 RMON Event Configuration Configure RMON Event table on this page. The entry index key is ID; screen in Figure 4-17-3 appears. Figure 4-17-3: RMON Event Configuration page Screenshot The page includes the following fields: Object Description •...
Page 323: Rmon Event Status
User’s Manual of IGS-5227-Series 4.17.4 RMON Event Status This page provides an overview of RMON Event table entries.Each page shows up to 99 entries from the Event table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Event table.
Page 324: Rmon History Configuration
User’s Manual of IGS-5227-Series 4.17.5 RMON History Configuration Configure RMON History table on this page. The entry index key is ID; screen in Figure 4-17-5 appears. Figure 4-17-5: RMON History Configuration Screenshot The page includes the following fields: Object Description •...
Page 325: Rmon History Status
User’s Manual of IGS-5227-Series 4.17.6 RMON History Status This page provides a detail of RMON history entries; screen in Figure 4-17-6 appears. Figure 4-17-6: RMON History Overview Screenshot The page includes the following fields: Object Description • History Index Indicates the index of History control entry. •...
Page 326: Rmon Statistics Configuration
User’s Manual of IGS-5227-Series • Utilization The best estimate of the mean physical layer network utilization on this interface during this sampling interval is in the hundredths of a percent. Buttons : Click to refresh the page immediately. Auto-refresh Check this box to refresh the page automatically. Automatic refresh occurs every 3 seconds. Updates the table, starting from the first entry in the History table, i.e., the entry with the lowest History Index and Sample Index : Updates the table, starting with the entry after the last entry currently displayed.
Page 327: Rmon Statistics Status
User’s Manual of IGS-5227-Series 4.17.8 RMON Statistics Status This page provides an overview of RMON Statistics entries. Each page shows up to 99 entries from the Statistics table, default being 20, selected through the "entries per page" input field. When first visited, the web page will show the first 20 entries from the beginning of the Statistics table.
Page 328 User’s Manual of IGS-5227-Series The total number of packets (including bad packets) received that were 64 octets • 64 bytes in length. • 65~127 The total number of packets (including bad packets) received that were between 65 to 127 octets in length. •...
Page 329: Ptp
User’s Manual of IGS-5227-Series 4.18 PTP The Precision Time Protocol (PTP) is a protocol used to synchronize clocks throughout a computer network. On a local area network, it achieves clock accuracy in the sub-microsecond range, making it suitable for measurement and control systems. PTP was originally defined in the IEEE 1588-2002 standard, officially entitled "Standard for a Precision Clock Synchronization Protocol for Networked Measurement and Control Systems"...
Page 330 User’s Manual of IGS-5227-Series  Master Only - clock's Device Type is Master Only.  Slave Only - clock's Device Type is Slave Only • 2 Step Flag Static member: defined by the system, true if two-step Sync events and Pdelay_Resp events are used.
Page 331 User’s Manual of IGS-5227-Series Activate this button to synchronize the System Clock to PTP Time. • Synchronize to System Clock • Ports Configuration Click to edit the port data set for the ports assigned to this clock instance. Clock Default Data Set Object Description •...
Page 332 User’s Manual of IGS-5227-Series Priority Code Point value used for PTP frames. • PCP Clock Current Data Set Object Description • stpRm Steps Removed: It is the number of PTP clocks traversed from the grandmaster to the local slave clock. •...
Page 333: Ptp Status
User’s Manual of IGS-5227-Series [1..1000] see above • ‘I’ constant ‘D’ constant [1..1000] see above Unicast Slave Configuration Object Description • Duration The number of seconds a master is requested to send Announce/Sync messages. The request is repeated from the slave each Duration/4 seconds. •...
Page 334 User’s Manual of IGS-5227-Series The page includes the following fields: Object Description • One_pps_mode Shows the current One_pps_mode configured. 1. Output : Enable the 1 pps clock output 2. Input : Enable the 1 pps clock input 3. Disable : Disable the 1 pps clock in/out-put •...
Page 335: Ring
User’s Manual of IGS-5227-Series 4.19 Ring ITU-T G.8032 Ethernet Ring protection switching (ERPS) is a link layer protocol applied on Ethernet loop protection to provide sub-50ms protection and recovery switching for Ethernet traffic in a ring topology. ERPS provides a faster redundant recovery than Spanning Tree topology. The action is similar to STP or RSTP, but the algorithms between them are not the same.
Page 336: Mep Configuration
User’s Manual of IGS-5227-Series 4.19.1 MEP Configuration The Maintenance Entity Point instances are configured here; screen in Figure 4-19-1 appears. Figure 4-19-1: MEP Configuration Screenshot The page includes the following fields: Object Description • Delete This box is used to mark a MEP for deletion in next Save operation. •...
Page 337: Detailed Mep Configuration
User’s Manual of IGS-5227-Series Buttons : Click to add a new MEP entry : Click to refresh the page immediately. : Click to save changes. Click to undo any changes made locally and revert to previously saved values. 4.19.2 Detailed MEP Configuration This page allows the user to inspect and configure the current MEP Instance;...
Page 338 User’s Manual of IGS-5227-Series • Direction See help on MEP to create Web. • Residence Port See help on MEP to create Web. See help on MEP to create Web. • Flow Instance • Tagged VID See help on MEP to create Web. •...
Page 339 User’s Manual of IGS-5227-Series • Peer MEP ID This value will become an expected MEP ID in a received CCM - see 'cMEP'. • Unicast Peer MAC This MAC will be used when unicast is selected with this peer MEP. Also this MAC is used to create HW checking of receiving CCM PDU (LOC detection) from this MEP.
Page 340: Ethernet Ring Protocol Switch
User’s Manual of IGS-5227-Series APS Protocol: Object Description • Enable Automatic Protection Switching protocol information transportation based on transmitting/receiving R-APS/L-APS PDU can be enabled/disabled. Must be able to support ERPS/ELPS implementing APS. This is only valid with one Peer MEP configured.
Page 341 User’s Manual of IGS-5227-Series Figure 4-19-3: Ethernet Ring Protocol Switch Screenshot The page includes the following fields: Object Description • Delete This box is used to mark an ERPS for deletion in next Save operation. • Port 0 This will create a Port 0 of the switch in the ring. •...
Page 342: Ethernet Ring Protocol Switch Configuration
User’s Manual of IGS-5227-Series 4.19.4 Ethernet Ring Protocol Switch Configuration This page allows the user to inspect and configure the current ERPS Instance; screen in Figure 4-19-4 appears. Figure 4-19-4: Ethernet Ring Protocol Switch Configuration Screenshot The page includes the following fields: Instance Data: Object Description...
Page 343 User’s Manual of IGS-5227-Series Green: This ERPS is configured, so it is active. • Guard Time Guard timeout value to be used to prevent ring nodes from receiving outdated R-APS messages. The period of the guard timer can be configured in 10 ms steps between 10 ms and 2 seconds, with a default value of 500 ms The Wait To Restore timing value to be used in revertive switching.
Page 344 User’s Manual of IGS-5227-Series Instance State: Object Description • Protection State ERPS state according to State Transition Tables in G.8032. OK: State of East port is ok • Port 0 SF: State of East port is Signal Fail OK: State of West port is ok •...
Page 345: Ring Wizard
User’s Manual of IGS-5227-Series 4.19.5 Ring Wizard This page allows the user to configure the ERPS by wizard; screen in Figure 4-19-4 appears. Figure 4-19-5: Ring Wizard Screenshot The page includes the following fields: Object Description • All Switch Numbers Set all the switch numbers for the ring group.
Page 346: Ring Wizard Example
User’s Manual of IGS-5227-Series 4.19.6 Ring Wizard Example: Figure 4-19-6: Ring Example Diagram The above topology often occurs on using ERPS protocol. The multi switch constitutes a single ERPS ring; all of the switches only are configured as an ERPS in VLAN 3001, thereby constituting a single MRPP ring. Switch ID Port MEP ID...
Page 347 User’s Manual of IGS-5227-Series Setup steps Set ERPS Configuration on Switch 1 Connect PC to switch 1 directly; don’t connect to ports 1 and 2 Logging on to the Switch 1 and click “Ring > Ring Wizard” Set “All Switch Number” = 3 and “Number ID” = 1; click the “Next” button to set the ERPS configuration for Switch 1. Set “MEP1”...
Page 348 User’s Manual of IGS-5227-Series Set “MEP5” = Port2, “MEP6” = Port1 and VLAN ID = 3001; click the “Set” button to save the ERPS configuration for Switch 3. To avoid loop, please don’t connect Switches 1, 2 and 3 together in the ring topology before configuring the end of ERPS .
Page 349: Switch Operation
User’s Manual of IGS-5227-Series 5. SWITCH OPERATION 5.1 Address Table The Industrial Managed Switch is implemented with an address table. This address table composed of many entries. Each entry is used to store the address information of some node in network, including MAC address, port no, etc. This in-formation comes from the learning process of Industrial Managed Switch.
Page 350: Auto-Negotiation
User’s Manual of IGS-5227-Series 5.5 Auto-Negotiation The STP ports on the Switch have built-in "Auto-negotiation". This technology automatically sets the best possible bandwidth when a connection is established with another network device (usually at Power On or Reset). This is done by detect the modes and speeds at the second of both device is connected and capable of, both 10BASE-T and 100BASE-TX devices can connect with the port in either half- or full-duplex mode.
Page 351: Troubleshooting
User’s Manual of IGS-20040MT 6. TROUBLESHOOTING This chapter contains information to help you solve issues. If the Industrial Managed Switch is not functioning properly, make sure the Industrial Managed Switch was set up according to instructions in this manual. ■ The Link LED is not lit Solution: Check the cable connection and remove duplex mode of the Industrial Managed Switch ■...
Page 352: Appendix A: Networking Connection
User’s Manual of IGS-20040MT APPENDIX A: Networking Connection A.1 Switch's Data RJ45 Pin Assignments - 1000Mbps, 1000BASE-T PIN NO MDI-X BI_DA+ BI_DB+ BI_DA- BI_DB- BI_DB+ BI_DA+ BI_DC+ BI_DD+ BI_DC- BI_DD- BI_DB- BI_DA- BI_DD+ BI_DC+ BI_DD- BI_DC- Implicit implementation of the crossover function within a twisted-pair cable, or at a wiring panel, while not expressly forbidden, is beyond the scope of this standard.
Page 353 User’s Manual of IGS-20040MT The standard cable, RJ45 pin assignment The standard RJ45 receptacle/connector There are 8 wires on a standard UTP/STP cable and each wire is color-coded. The following shows the pin allocation and color of straight cable and crossover cable connection: Straight Cable SIDE 1 SIDE 2...
Page 354: Appendix B: Glossary
User’s Manual of IGS-5227-Series APPENDIX B: GLOSSARY ACE is an acronym for Access Control Entry. It describes access permission associated with a particular ACE ID. There are three ACE frame types (Ethernet Type, ARP, and IPv4) and two ACE actions (permit and deny). The ACE also contains many detailed, different parameter options that are available for individual application.
Page 355 User’s Manual of IGS-5227-Series ACL|Rate Limiters: Under this page you can configure the rate limiters. There can be 15 different rate limiters, each ranging from 1-1024K packets per seconds. Under "Ports" and "Access Control List" web-pages you can assign a Rate Limiter ID to the ACE(s) or ingress port(s).
Page 356 User’s Manual of IGS-5227-Series CC is an acronym for Continuity Check. It is a MEP functionality that is able to detect loss of continuity in a network by transmitting CCM frames to a peer MEP. CCM is an acronym for Continuity Check Message. It is a OAM frame transmitted from a MEP to it's peer MEP and used to implement CC functionality.
Page 357 User’s Manual of IGS-5227-Series Dynamic addressing simplifies network administration because the software keeps track of IP addresses rather than requiring an administrator to manage the task. This means that a new computer can be added to a network without the hassle of manually assigning it a unique IP address.
Page 358 User’s Manual of IGS-5227-Series DSCP DSCP is an acronym for Differentiated Services Code Point. It is a field in the header of IP packets for packet classification purposes. EEE is an abbreviation for Energy Efficient Ethernet defined in IEEE 802.3az. EPS is an abbreviation for Ethernet Protection Switching defined in ITU/T G.8031.
Page 359 User’s Manual of IGS-5227-Series connection to a particular port on a remote host (port 80 by default). An HTTP server listening on that port waits for the client to send a request message. HTTPS HTTPS is an acronym for Hypertext Transfer Protocol over Secure Socket Layer. It is used to indicate a secure HTTP connection.
Page 360 User’s Manual of IGS-5227-Series IMAP IMAP is an acronym for Internet Message Access Protocol. It is a protocol for email clients to retrieve email messages from a mail server. IMAP is the protocol that IMAP clients use to communicate with the servers, and SMTP is the protocol used to transport mail to an IMAP server.
Page 361 User’s Manual of IGS-5227-Series LACP LACP is an IEEE 802.3ad standard protocol. The Link Aggregation Control Protocol, allows bundling several physical ports together to form a single logical port. LLDP LLDP is an IEEE 802.1ab standard protocol. The Link Layer Discovery Protocol(LLDP) specified in this standard allows stations attached to an IEEE 802 LAN to advertise, to other stations attached to the same IEEE 802 LAN, the major capabilities provided by the system incorporating that station, the management address or addresses of the entity or entities that provide management of those capabilities, and the identification of the stations point of attachment to the IEEE 802 LAN required by those...
Page 362 User’s Manual of IGS-5227-Series MD5 is an acronym for Message-Digest algorithm 5. MD5 is a message digest algorithm, used cryptographic hash function with a 128-bit hash value. It was designed by Ron Rivest in 1991. MD5 is officially defined in RFC 1321 - The MD5 Message-Digest Algorithm.
Page 363 User’s Manual of IGS-5227-Series NFS is an acronym for Network File System. It allows hosts to mount partitions on a remote system and use them as though they are local file systems. NFS allows the system administrator to store resources in a central location on the network, providing authorized users continuous access to them, which means NFS supports sharing of files, printers, and other resources as persistent storage over a computer network.
Page 364 User’s Manual of IGS-5227-Series PD is an acronym for Powered Device. In a PoE> system the power is delivered from a PSE ( power sourcing equipment ) to a remote device. The remote device is called a PD. PHY is an abbreviation for Physical Interface Transceiver and is the device that implement the Ethernet physical layer (IEEE-802.3).
Page 365 User’s Manual of IGS-5227-Series Private VLAN In a private VLAN, communication between ports in that private VLAN is not permitted. A VLAN can be configured as a private VLAN. PTP is an acronym for Precision Time Protocol, a network protocol for synchronizing the clocks of computer systems. QCE is an acronym for QoS Control Entry.
Page 366 User’s Manual of IGS-5227-Series QoS class Every incoming frame is classified to a QoS class, which is used throughout the device for providing queuing, scheduling and congestion control guarantees to the frame according to what was configured for that specific QoS class.
Page 367 User’s Manual of IGS-5227-Series Samba can also register itself with the master browser on the network so that it would appear in the listing of hosts in Microsoft Windows "Neighborhood Network". SHA is an acronym for Secure Hash Algorithm. It designed by the National Security Agency (NSA) and published by the NIST as a U.S.
Page 368 User’s Manual of IGS-5227-Series SSH is an acronym for Secure SHell. It is a network protocol that allows data to be exchanged using a secure channel between two networked devices. The encryption used by SSH provides confidentiality and integrity of data over an insecure network.
Page 369 User’s Manual of IGS-5227-Series Common network applications that use TCP include the World Wide Web (WWW), e-mail, and File Transfer Protocol (FTP). TELNET TELNET is an acronym for TELetype NETwork. It is a terminal emulation protocol that uses the Transmission Control Protocol (TCP) and provides a virtual connection between TELNET server and TELNET client.
Page 370 User’s Manual of IGS-5227-Series UDP provides two services not provided by the IP layer. It provides port numbers to help distinguish different user requests and, optionally, a checksum capability to verify that the data arrived intact. Common network applications that use UDP include the Domain Name System (DNS), streaming media applications such as IPTV, Voice over IP (VoIP), and Trivial File Transfer Protocol (TFTP).
Page 371 User’s Manual of IGS-5227-Series WEP is an acronym for Wired Equivalent Privacy. WEP is a deprecated algorithm to secure IEEE 802.11 wireless networks. Wireless networks broadcast messages using radio, so are more susceptible to eavesdropping than wired networks. When introduced in 1999, WEP was intended to provide confidentiality comparable to that of a traditional wired network (Wikipedia).
Page 372 User’s Manual of IGS-5227-Series WRES WRED is an acronym for Weighted Random Early Detection. It is an active queue management mechanism that provides preferential treatment of higher priority frames when traffic builds up within a queue. A frame's DP level is used as input to WRED.

This manual is also suitable for:

Igs-5227-6t Igs-5227-6mt Igs-5227-6mt-x
