SimpliFire Scion SF-SCN43 Owner's Manual

Hide thumbs

page of 33

/ 33
Bookmarks

Quick Links

Download this manual

Scion Series:

Models:

SF-SCN43

SF-SCN55

• Important operating

a n d m a i n t e n a n c e

instructions included.

Congratulations!

Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood and gas burning

fireplaces. The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and

efficiency.

READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN

THIS PRODUCT.

PROTECT YOURSELF AND OTHERS BY OBSERVING ALL SAFETY INFORMATION. FAILURE

TO COMPLY WITH INSTRUCTIONS COULD RESULT IN PERSONAL INJURY AND/OR

PROPERTY DAMAGE.

WARNING: To reduce risk of fire, electrical shock, or personal injury, read and understand

all instructions, including safety information before plugging in and using this appliance.

NOTICE

DO NOT DISCARD THIS MANUAL

• Read, understand and follow

these instructions for safe

installation and operation.

SimpliFire, a brand of Hearth & Home Technologies

7571 215

Street West, Lakeville, MN 55044

www.hearthnhome.com

SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25

Owner's Manual

Installation and Operation

• Leave this manual with

party responsible for use

and operation.

Need help?

Do you have a question about the Scion SF-SCN43 and is the answer not in the manual?

Questions and answers

Summary of Contents for SimpliFire Scion SF-SCN43

Page 1 Congratulations! Congratulations on selecting a SimpliFire Electric Fireplace, an elegant and clean alternative to wood and gas burning fireplaces. The SimpliFire electric fireplace you have selected is designed to provide the utmost in safety, reliability, and efficiency. READ CAREFULLY BEFORE ATTEMPTING TO ASSEMBLE, INSTALL, OPERATE, OR MAINTAIN THIS PRODUCT.
Page 2 Return appliance to authorized service facility for examination, electrical or mechanical adjustment or repair. • Do not use outdoors. SAVE THESE INSTRUCTIONS SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 3 C. Servicing........28 D. SimpliFire Troubleshooting Guide ....29 E.
Page 4 Firebox and heat exchanger, HHT Chimney & Terminations, Manifolds 20 years 3 years Firebox and heat exchanger All purchased replacement parts and optional accessories None 1 Year All purchased replacement parts and optional accessories Page 1 of 2 4021-645N 12/23 SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 5 THE EXPRESSED WARRANTY SPECIFIED ABOVE FOR THE APPLICABLE PRODUCT. Some States do not allow limitations on how long an implied warranty lasts, so the above limitation may not apply to you. Page 2 of 2 4021-645N 12/23 SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 6 We recommend that you record the following pertinent information about your fireplace. Model Name: ___________________________________________ Date purchased/installed: __________________ Serial Number: __________________________________________ Location of fireplace: _____________________ Dealership purchased from: _______________________________ Dealer Phone: __________________________ Notes: _______________________________________________________________________________________ SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 7 Consult the dealer or an experienced radio/TV technician for help. The device has been evaluated to meet general RF exposure requirement. The device can be used in portable exposure condition without restriction. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 8 NOTE: A & B dimensions include louver projection on sides and top panels. Model 44-1/2 24-1/16 7-1/2 16-3/8 41-1/2 5-7/8 1-3/8 11/16 12-1/4 SF-SCN43 1130 1055 56-1/4 24-1/16 7-1/2 16-3/8 53-3/8 5-7/8 1-3/8 11/16 12-1/4 SF-SCN55 1429 1355 Figure 3.1 Appliance Dimensions SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 9 Floor......0 in. sides or rear. Top......0 in. See Section 4.A for framing dimensions. Back......0 in. Front.......36 in. Mantel.....5/8 in. Mantel Depth..Unlimited. See Figure 3.2. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 10 WALL SHEATHING Depth Width Height Model Height Width Depth 24-1/4 7-5/8 SF-SCN43 1143 24-1/4 7-5/8 SF-SCN55 1448 Figure 4.1 Framing Dimensions SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 11 (2) on each side. See Figure 4.2. Note: Use protective masking to cover opening of the appliance until the installation is complete. Figure 4.3 Mounting Brackets Figure 4.2 Access Side Trim Figure 4.4 Install Appliance SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 12 If the switch setting is different from how the appliance is wired, the appliance will not function correctly. Figure 4.6 Electrical Connection / Installation Figure 4.5 Heater Input Voltage/Disable Switch SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 13 (1) inch. See Figure 4.9. Figure 4.8 Attached Front Installation SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 14 Figure 4.10 Installed With No Front WALL FINISHING WALL FINISHING STOPS STOPS Figure 4.9 Wall Finishing Stop Locations SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 15 Carefully spread the small clear crystals across the ember bed. Then evenly arrange the large crystals on top of or within the small crystal media. See Figure 4.11. Figure 4.11 Media Installation Figure 4.12 SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 16 Figure 4.13 Media Installation Figure 4.14 Figure 4.15 Figure 4.16 Figure 4.17 Figure 4.18 SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 17 2. Verify that the SimpliFire logo is at the bottom right corner of the installed glass. 3. Install the two (2) glass brackets located in the hardware bag using the three (3) M4x8 screws provided on each side.
Page 18 Press and hold the WiFi button for 3 seconds Button will illuminate WIFI to enter WiFi Pairing Mode. WiFi button will when initiated. illuminate when ON. Figure 5.1 Manual Operating Switches and Indicator Lights SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 19 OFF. THERMOSTAT Use +/- to increase or decrease the temperature set point. Press and hold the THERMOSTAT button for 3 seconds to switch between Celsius and Fahrenheit. Figure 5.2 Remote Control Operation SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 20 If the power is removed while the appliance is operating, the appliances will return to the same settings and operating modes once the power is restored to the appliance. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 21 5. Press the Appliance icon (1), 6. Enter the password (2) for the selected Wi-Fi network (1), and then once it appears on the screen. press Next (3). Application begins connecting to the appliance. WIFI NAME Password SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 22 • Press the Pencil icon (3) to view and edit the appliance details. • Press the Settings button (4) to view and edit the appliance’s settings. NOTE: See the Wi-Fi Settings section for a complete list of the available options. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 23 Off, Warm, Cool Down Light Brightness Setting 1 – 5 Sound Effect Off, Sound 1 (Active), Sound 2 (Mature) Sound Level Setting 1 – 5 Timer Off, 30 min, 1 – 9 Hours SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 24 5. Turn ON the appliance (1 & 2), and then press and select Bluetooth Mode (2). hold the WIFI button (3) until 3 beeps are heard. The ember bed (4) turns red and starts blinking quickly. WIFI SOUND EMBER HEATER FLAME POWER SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 25 NOTE: If the application is unable to connect to the appliance using the Add Device - Bluetooth Mode, see the Add Device - Wi-Fi Mode section to pair the appliance. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 26 (1), confirm the ember bed is slowly blinking red (2), and then press Next (3). (3 beeps, then 5 beeps). The ember bed (4) turns red and starts blinking slowly. WIFI SOUND EMBER HEATER FLAME POWER SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 27 10. See the Wi-Fi Operation section for details bed turns a solid green and a on using the SimpliFire screen for wireless green check mark (1) appears. and remote control of the appliance. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 28 Do not attempt to service the appliance No user serviceable parts inside. Always turn heater off yourself. and disconnect power before performing maintenance, service, or removal from the framed wall opening. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 29 Flame rotisserie contacting other Ensure rod is straight and mounted properly and is internal components when spinning spinning freely without spindles hitting other components. Flame shudder Defective flame rotisserie motor Replace rotisserie motor. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 30 Heater input voltage/disable switch on setting for 120V or 240V wiring and not in the OFF incorrect setting “noH” error code position. (120V /OFF/240V) Bad PCB or Heater Replace PCB, and if problem persists, replace Heater. SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 31 Hardwire Junction Block Replacement SF-SPKR Speaker System SF-POWER LED Power Supply Internal Side Panels Left & Right PANELS-SCN Electric Hardware Pack (Glass Retaining Brackets, ST4x8 HDWR-SCN screws, M4x8 screws, Hand-Bend Mounting Brackets) SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 32 Hardwire Junction Block Replacement SF-SPKR Speaker System SF-POWER LED Power Supply Internal Side Panels Left & Right PANELS-SCN Electric Hardware Pack (Glass Retaining Brackets, ST4x8 HDWR-SCN screws, M4x8 screws, Hand-Bend Mounting Brackets) SimpliFire • SF-SCN43, SF-SCN55 • SF-SCN-MAN-C • 3/25...
Page 33 SimpliFire, a brand of Hearth & Home Technologies 7571 215 Street West, Lakeville, MN 55044 www.hearthnhome.com Please contact your SimpliFire dealer or customer / technical support (877-320-0730) with any questions or concerns. For the location of your nearest SimpliFire dealer, please visit www.hearthnhome.com.
