ZiLOG C12 ICEBOX Manual

QUICK START
1
Check Support Package Contents
(See Other Side)
2 Load Software
1. Select the "Run" command from the "File" menu, located under Microsoft Windows
"Program Manager".
a. Insert the disk labeled "Zilog ZASM Cross Assembler/Zilog MOBJ Object File Util."
in drive A (or drive B, if appropriate.)
b. Type "a:\setup" and press ENTER. (Type "b:\setup" if drive B is used.)
c. Follow on-screen instructions.
d. Remove diskette and store in a safe place when done.
For more information on assembling source code, refer to the C12 ICEBOX
User's Manual and the Zilog Cross Assembler and File Utilities User Guides.
2. Select the "Run" command from the "File" menu, located under Microsoft
Windows "Program Manager".
a. Insert disk labeled "Z8 GUI S/W" in drive A (or drive B, if appropriate.)
b. Type "a:\setup" and press ENTER. (Type "b:\setup" if drive B is used.)
c. Follow on-screen instructions.
d. Remove diskette and store in a safe place when done.
3
Make Connections
Power Supply, PC, and Your Design
Refer to C12 ICEBOX
Emulator User's Manual
Observe Electrical Safeguards
(See C12 ICEBOX User's Manual)
Run Zilog ICEBOX GUI Software
4
1. Double click the Z8-ICE icon.
2. Select the microcontroller and ROM size
to be emulated in the Configuration Dialog Box.
3. Use the "File" menu to download sample files to
Z8 Code Memory.
4. Refer to C12 ICEBOX User's Manual,
"Chapter 3: Z8 Emulator Sample Session".
1
R T
EAD HIS
P
RODUCT
C12 ICEBOX
Your Power
Supply
5V
Connect to
Power Supply
or
PC Power
P
RODUCT
F !
IRST
I
NFORMATION
™
Emulation Cable
Your Design
Serial Cable
COM1–4
100-Percent Compatible PC
PI96DZ80101
C12 ICEBOX
I
NTORMATION
Spare Disk
Power Connector
