INTRODUCTION
This chapter describes the various steps necessary to start development using the Z80185/195
evaluation board. The sections covered in this chapter are as follows:
Installing the Software
Setting Up the Hardware
– Serial Channels
– Parallel Channel
– Other Jumper Options
Connecting to Power
Initial Checkout/Sample Session
INSTALLING THE SOFTWARE
Software for the Z80185/195 Development Kit is stored on two diskettes:
1. Z80185 Sample Files and Monitor Source Code Diskette
2. Zilog ZASM Cross Assembler/Zilog MOBJ Object File Util. diskette
Z80185 Source Diskette Installation
1. Select the "Run" command from the "File" menu under Microsoft Windows "Program Manager".
2. Insert the diskette labeled "Z80185 Sample Files and Monitor Source" into drive A (or drive B, if
appropriate).
3. Type "a:\setup" and press ENTER. (Type "b:setup" if drive B is used.)
A dialog box will now prompt you for the directory into which the software will be installed (default
is C:\185). The setup program will copy the files into the target directory, creating an icon in the
Windows environment. After the installation is finished, you can move the icon into any program
group of your choice.
Note: The icon will be created in the window that is currently selected.
4. Remove diskette and store in a safe place when done.
