Other Jumpering
The following modem control signals can be interconnected with PIA16-10 I/Os on the Z80185/195
or INT0-2 inputs on the Z80185/195 and the HOSTHI and PERIPHI lines of J3 and J4, using the J14
jumper block as follows.
Pin
Jumper Numbers
J14 1
J14 2
J14 3
J14 4
J14 5
J14 6
J14 7
J14 8
J14 9
J14 10
J14 11
J14 12
J14 13
J14 14
J14 15
J14 16
J14 17
UM951800100
Description
INT0
INT1
HOSTHI (J4)
PIA16
INT2
PERIPHI (J3, J4)
PIA15
ESCC DxR in
PIA14
ESCC DCD out
PIA13
ASCI0 DxR out
PIA12
ASCI0 DxR in
PIA11
ASCI0 DCD out
PIA10
