OVERVIEW
The Z80185/195 Development Kit (Z8018500ZCO) provides all the necessary hardware, software,
and documentation to properly evaluate and begin design development using the Z80185/195 Smart
Peripheral Controller. The kit includes a monitor program shipped in EPROM and a software monitor
program (TZ.EXE) that runs on a PC. The monitor program enables you to do the following: download
and run programs from a PC—with or without breakpoints, display and fill memory locations, compare
contents of memory, and read/write from the I/O Ports. The kit also comes with P1284 IEEE Centronics
and ASCI UART device drivers and some working sample codes. A full schematic of the board is also
included in this manual.
The Z80185/195 Development Kit is carefully engineered to provide the best balance between
reasonable cost and useful features to shorten your development time for products using the Z80185/
195 (see Figure 1-1 for Functional Block Diagram). The Z80185/195 Development Board is an
excellent hardware example of how to design with the Z80185/195 Smart Peripheral Controller.
KEY FEATURES OF THE Z80185/195 DEVELOPMENT KIT
Complete Start-Up Kit Capabilities for Developers.
Provides Hands-On Access to the Z80185/195 Smart Peripheral Controller.
Serves as a Developmental Platform for Trial Implementation of a Specific Application.
Configured to Operate as a Standalone Unit.
Includes All Necessary Cabling for Power Supply Connection.
SUPPORTED ZILOG DEVICES
Device
Z80185/195
UM951800100
Packaging
100-Pin QFP
