en Installation instructions
25.3 Installation below a worktop
Observe the installation dimensions and the installation
instructions when installing below a worktop.
25.4 Installing below a hob
If the appliance is installed below a hob, the following
minimum dimensions must be adhered to (including
substructure, if applicable).
Hob type
Induction hob
Full-surface induction hob
Gas hob
Electric hob
25.5 Installation in a tall unit
Observe the installation dimensions and the installation
instructions when installing in a tall unit.
38
a raised in mm
37
47
30
27
¡ To ventilate the appliance, the intermediate floor
must have a ventilation cut-out.
¡ In combination with induction hobs, the gap
between the worktop and appliance must not be
sealed using additional strips.
¡ The worktop must be secured to the fitted unit.
¡ Observe any available installation instructions for the
hob.
¡ Observe different national installation instructions for
the hob.
The minimum worktop thickness
quired minimum clearance
a flush in mm
38
48
38
30
¡ To ventilate the appliance, the intermediate floors
must have a ventilation cut-out.
¡ If the tall unit has another back panel in addition to
the element back panels, this must be removed.
¡ Only fit the appliance up to a height which allows
accessories to be easily removed.
is based on the re-
⁠ .
b in mm
5
5
5
2
