Summary of Contents for AEG EPS33102ZM
- Page 1 EPS33102ZM User Manual Oven USER MANUAL...
-
Page 2: Table Of Contents
15. ENVIRONMENTAL CONCERNS..............28 FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it. -
Page 3: Safety Information
ENGLISH SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference. - Page 4 This appliance may be used in, offices, hotel guest • rooms, bed & breakfast guest rooms, farm guest houses and other similar accommodation where such use does not exceed (average) domestic usage levels. Only a qualified person must install this appliance and •...
-
Page 5: Safety Instructions
ENGLISH Before pyrolytic cleaning, remove all accessories and • excessive deposits/spills from the appliance cavity. 2. SAFETY INSTRUCTIONS 2.1 Installation Width of the front of 595 mm WARNING! the appliance Only a qualified person must install this appliance. Width of the back of 559 mm the appliance •... - Page 6 • The shock protection of live and insulated parts must be fastened in Connecting to terminal board such a way that it cannot be removed without tools. 1 = 45 mm • Connect the mains plug to the mains...
-
Page 7: Pyrolytic Cleaning
ENGLISH • Do not apply pressure on the open Contact the Authorised Service door. Centre. • Do not use the appliance as a work • Be careful when you remove the door surface or as a storage surface. from the appliance. The door is •... -
Page 8: Internal Lighting
They are not intended to be used in other 3. INSTALLATION 3.1 Building in WARNING! Refer to Safety chapters. www.youtube.com/electrolux www.youtube.com/aeg How to install your AEG/Electrolux Oven with Hob - Built Under installation... -
Page 9: Securing The Oven To The Cabinet
ENGLISH (*mm) min. 550 min. 560 3.2 Securing the oven to the cabinet... -
Page 10: Product Description
4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knobs for the hob Power lamp / symbol Knob for the heating functions Display Control knob (for the temperature) Temperature indicator / symbol Heating element Lamp Shelf support, removable Shelf positions 4.2 Accessories... -
Page 11: Retractable Knobs
ENGLISH 5.4 Retractable knobs To use the appliance press the knob. The knob comes out. 5.5 Sensor fields / Buttons To set the time. To set a clock function. To set the time. 5.6 Display A. Timer / Temperature B. Food Sensor (selected models only) C. -
Page 12: Daily Use
The oven can emit an odour and smoke during preheating. Make sure that the room is ventilated. 7. DAILY USE WARNING! Heating func‐ Application Refer to Safety chapters. tion 7.1 How to set: Heating To bake on up to three... -
Page 13: Clock Functions
ENGLISH 7.4 Notes on: Moist Fan Baking Heating func‐ Application tion This function was used to comply with the energy efficiency class and To prepare very tender ecodesign requirements (according to and juicy roasts. EU 65/2014 and EU 66/2014). Tests Meat according to: To keep food warm. - Page 14 8.2 How to set: Time of day After the first connection to the mains, wait until the display shows: hr, 12:00. 12 - flashes. Step 1 - press to set the hour. Step 2 - press to confirm. The display shows the set hour and: min. 00 - flashes.
- Page 15 ENGLISH 8.4 How to set function: End Time Step 1 Set a heating function. Step 2 - press repeatedly. - starts to flash. Step 3 - press to set the hour. - press to confirm. Step 4 - press to set the minutes. - press to confirm.
-
Page 16: Using The Accessories
8.6 How to set function: Minute Minder Minute minder can be both set when the oven is turned on and off. Step 1 - press repeatedly. , 00 - flash. Step 2 - press to set the seconds and than the minutes. -
Page 17: Additional Functions
ENGLISH Deep pan: Push the tray between the guide bars of the shelf support. 10. ADDITIONAL FUNCTIONS 10.1 How to use: Child lock When the function is on the oven cannot be turned on accidentally. (°C) 120 - 195 Step 1 Ensure the knob for the heat‐... -
Page 18: Hints And Tips
11. HINTS AND TIPS Leave the meat for approximately 15 Refer to Safety chapters. minutes before carving so that the juice does not seep out. To prevent too much smoke in the oven 11.1 Cooking during roasting, add some water into the recommendations deep pan. - Page 19 ENGLISH (°C) (min) Sweet rolls, 16 baking tray or dripping 20 - 30 pieces Rolls, 9 pieces baking tray or dripping 30 - 40 Pizza, frozen, wire shelf 10 - 15 0.35 kg Swiss roll baking tray or dripping 25 - 35 Brownie baking tray or dripping 25 - 30...
-
Page 20: Information For Test Institutes
(°C) (min) Tartlets, 8 pieces baking tray or dripping 20 - 30 Vegetables, baking tray or dripping 35 - 45 poached, 0.4 kg Vegetarian ome‐ pizza pan on wire shelf 25 - 30 lette Mediterranean baking tray or dripping 25 - 30 vegetables, 0.7... - Page 21 ENGLISH ( °C) (min) Fatless Conven‐ Wire shelf 2 40 - 50 Preheat the oven sponge tional for 10 min. cake, Cooking cake mould Ø26 cm Fatless True Fan Wire shelf 2 40 - 50 Preheat the oven sponge Cooking for 10 min.
-
Page 22: Care And Cleaning
12. CARE AND CLEANING WARNING! Refer to Safety chapters. 12.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm wa‐ ter and a mild detergent. Use a cleaning solution to clean metal surfaces. - Page 23 ENGLISH Step 3 Pull the rear end of the shelf support away from the side wall and remove it. Step 4 Install the shelf supports in the opposite sequence. 12.3 How to use: Pyrolysis CAUTION! If a hob is installed above Clean the oven with Pyrolysis.
-
Page 24: Cleaning Reminder
12.4 Cleaning reminder - press at the same time to turn off the reminder. The oven reminds you when to clean the oven with: Pyrolysis. Pyrolysis - flashes in the display for 10 sec after each activation and deactivation of the oven. - Page 25 ENGLISH Step 5 Hold the door trim (B) on the top edge of the door at the two sides and push inwards to release the clip seal. Step 6 Pull the door trim to the front to re‐ move it. Step 7 Hold the door glass panels by their top edge and carefully pull them...
-
Page 26: Troubleshooting
Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until Disconnect the oven from Put a cloth on the bottom of the oven is cold. the mains. the cavity. Back lamp Step 1 Turn the glass cover to remove it. -
Page 27: Service Data
Product number (PNC) ......... Serial number (S.N.) ......... 14. ENERGY EFFICIENCY 14.1 Product Information and Product Information Sheet Supplier's name Model identification EPS33102ZM 949723900 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conven‐ 0.93 kWh/cycle tional mode... -
Page 28: Energy Saving
Energy consumption with a standard load, fan-forced 0.69 kWh/cycle mode Number of cavities Heat source Electricity Volume 72 l Type of oven Built-Under Oven Mass 30.8 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Methods for measuring performance. - Page 32 www.aeg.com/shop...
