- Page 1 EN User Manual | Oven EPB335060M EPB43509BB EPB43509BM...
-
Page 2: Table Of Contents
Access your full user manual at aeg.com/manuals Get usage advice, brochures, trouble shooter, service and repair information at aeg.com/support For more recipes, hints, troubleshooting download My AEG Kitchen app. Subject to change without notice. CONTENTS 1. SAFETY INFORMATION................2 2. - Page 3 the use of the appliance in a safe way and understand the hazards involved. Children of less than 8 years of age and persons with very extensive and complex disabilities shall be kept away from the appliance unless continuously supervised. •...
-
Page 4: Safety Instructions
• The control panel must be connected to specified heating unit with matching colours of connectors, to avoid possible hazard. • The means for disconnection must be incorporated in the fixed wiring in accordance with the wiring rules. • WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. - Page 5 • Connect the mains plug to the mains socket only at the end of the installation. Cabinet width 560 mm Make sure that there is access to the Cabinet depth 550 (550) mm mains plug after the installation. • If the mains socket is loose, do not Height of the front of the 594 mm connect the mains plug.
- Page 6 2.5 Pyrolytic cleaning WARNING! Risk of damage to the appliance. WARNING! Risk of Injury / Fires / Chemical • To prevent damage or discoloration to the Emissions (Fumes) in Pyrolytic Mode. enamel: – do not put ovenware or other objects •...
-
Page 7: Product Description
• Concerning the lamp(s) inside this product • Use original spare parts only. and spare part lamps sold separately: 2.8 Disposal These lamps are intended to withstand extreme physical conditions in household appliances, such as temperature, WARNING! vibration, humidity, or are intended to Risk of injury or suffocation. -
Page 8: Control Panel
Combi pan For cakes and biscuits. To bake and roast or as a pan to collect fat. 4. CONTROL PANEL 4.1 Retractable knobs To use the appliance press the knob. The knob comes out. 4.2 Knobs for the cooking zones WARNING! Refer to Safety chapters in the hob user manual. -
Page 9: Before First Use
Timer Fast Heat Up Light Lock Confirm setting 4.7 Display Display with key functions. Display indicators Basic indicators Lock Assisted Cooking Cleaning Settings Fast Heat Up Timer indicators Minute minder Time Delay Uptimer End time Progress bar - for temperature or time. The bar is fully red when the appliance reaches the set tem‐... -
Page 10: Daily Use
Step 1 Remove all accessories and removable shelf supports from the oven. Step 2 Set the maximum temperature for the function: Let the oven operate for 1 h. Step 3 Set the maximum temperature for the function: Let the oven operate for 15 min. Step 4 Set the maximum temperature for the function: Let the oven operate for 15 min. - Page 11 Heating function Application To defrost food (vegetables and fruit). The defrosting time depends on the amount and size of the frozen food. Defrost This function is designed to save energy during cooking. When you use this function, the temperature in the cavity may differ from the set temperature. The residual heat is used.
- Page 12 6.5 Assisted Cooking Legend Legend Shelf level. Weight Automatic available. The display shows P and a number of the dish that you can check in the table. Preheat the appliance before you start cooking. Dish Weight Shelf level / Accessory Roast Beef, rare 2;...
- Page 13 Dish Weight Shelf level / Accessory Spare Ribs 2 - 3 kg; use raw, 2 3; deep pan - 3 cm thin spare Add liquid to cover the bottom of a dish. Turn the meat af‐ ribs ter half of the cooking time. Lamb leg with bones 1.5 - 2 kg;...
-
Page 14: Clock Functions
Dish Weight Shelf level / Accessory Loaf cake 2; loaf pan on wire shelf Baked potatoes 1 kg 2; baking tray Put the whole potatoes with skin on baking tray. Wedges 1 kg 3; baking tray lined with baking paper Use your favourite spices. - Page 15 Clock Function Application Maximum is 23 h 59 min. This function has no effect on the operation of the oven. To turn on and off the Uptimer select: Menu, Settings. Uptimer 7.2 How to set: Clock functions How to set: Time of day Step 1 Step 2 Step 3...
-
Page 16: Using The Accessories
How to set: Time Delay Step 1 Step 2 Step 3 Step 4 Step 5 Step 6 The dis‐ play The display shows: the shows: time of day --:-- STOP Select the Press repeat‐ START Set the start Set the end heating Press: Press:... -
Page 17: Additional Functions
9. ADDITIONAL FUNCTIONS 9.1 Lock This function prevents an accidental change of the appliance function. Turn it on when the appliance works - the set cooking continues, the control panel is locked. Turn it on when the appliance is off - it cannot be turned on, the control panel is locked. - press and hold to turn on the - press and hold to turn it off. - Page 18 (°C) (min) Pasta gratin 200 - 220 45 - 55 Potato gratin 180 - 200 70 - 85 Moussaka 170 - 190 70 - 95 Lasagne 180 - 200 75 - 90 Cannelloni 180 - 200 70 - 85 Bread pudding 190 - 200 55 - 70 Rice pudding...
- Page 19 °C Apple pie, 2 tins Ø20 cm True Fan Cooking 55 - 65 Apple pie, 2 tins Ø20 cm Conventional Cooking 55 - 65 Short bread True Fan Cooking 25 - 35 Short bread Conventional Cooking 25 - 35 Baking on one level - biscuits Use the third shelf position.
-
Page 20: Care And Cleaning
11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the appliance only with a microfibre cloth with warm water and a mild de‐ tergent. Use a cleaning solution to clean metal surfaces. Clean stains with a mild detergent. - Page 21 11.3 How to use: Pyrolytic Cleaning CAUTION! Clean the oven with Pyrolytic Cleaning. If a hob is installed above the oven or if there are other appliances installed in the WARNING! same cabinet, do not use them at the There is a risk of burns. same time as this function.
- Page 22 CAUTION! Carefully handle the glass, especially around the edges of the front panel. The glass can break. Step 1 Fully open the door. Step 2 Lift and press the clamping levers (A) on the two door hinges. Step 3 Close the oven door to the first opening position (approximately 70° angle). Hold the door at both sides and pull it away from the oven at an upwards angle.
-
Page 23: Troubleshooting
Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven. Wait until the Disconnect the oven from the Put a cloth on the bottom of the cav‐ oven is cold. mains. ity. Top lamp Step 1 Turn the glass cover to remove it. -
Page 24: Energy Efficiency
13.1 Product Information and Product Information Sheet according to EU Ecodesign and Energy Labelling Regulations Supplier's name EPB335060M 940321399 Model identification EPB43509BB 940321400 EPB43509BM 940321397 Energy Efficiency Index 81.2 Energy efficiency class Energy consumption with a standard load, conventional mode 1.09 kWh/cycle... -
Page 25: Menu Structure
71 l Type of oven Built-Under Oven EPB335060M 33.0 kg Mass EPB43509BB 33.5 kg EPB43509BM 33.5 kg IEC/EN 60350-1 - Household electric cooking appliances - Part 1: Ranges, ovens, steam ovens and grills - Meth‐ ods for measuring performance. 13.2 Energy saving the residual heat. -
Page 26: Environmental Concerns
Select the option Adjust the value and from Menu structure - select to enter - press to con‐ Select the setting. the Menu. firm setting. press and press Turn the knob for the heating functions to the off position to exit the Menu. Menu structure Assisted Cooking Cleaning... - Page 28 867371661-C-222023...
