AEG EPS742230B User Manual

AEG EPS742230B User Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
EPS742230B
USER
MANUAL
EN
User Manual
Oven

Advertisement

loading
Need help?

Need help?

Do you have a question about the EPS742230B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AEG EPS742230B

Summary of Contents for AEG EPS742230B

  • Page 1 EPS742230B User Manual Oven USER MANUAL...

  • Page 2: Table Of Contents

    FOR PERFECT RESULTS Thank you for choosing this AEG product. We have created it to give you impeccable performance for many years, with innovative technologies that help make life simpler – features you might not find on ordinary appliances. Please spend a few minutes reading to get the very best from it.

  • Page 3: Safety Information

    SAFETY INFORMATION 9. ADDITIONAL FUNCTIONS....... 22 12. TROUBLESHOOTING......31 9.1 How to save: Favourites....22 12.1 What to do if.........32 9.2 Function lock........23 12.2 How to manage: Error codes..32 9.3 Automatic switch-off.......23 12.3 Service data.........33 9.4 Cooling fan........23 13. ENERGY EFFICIENCY......33 10.

  • Page 4: General Safety

    SAFETY INFORMATION Children should be supervised to ensure that they do not • play with the appliance. Keep all packaging away from children and dispose of it • appropriately. WARNING: The appliance and its accessible parts become • hot during use. Keep children and pets away from the appliance when in use and when cooling down.

  • Page 5: Safety Instructions

    SAFETY INSTRUCTIONS WARNING: Ensure that the appliance is switched off before • replacing the lamp to avoid the possibility of electric shock. WARNING: The appliance and its accessible parts become • hot during use. Care should be taken to avoid touching heating elements.

  • Page 6: Electrical Connection

    SAFETY INSTRUCTIONS Cabinet minimum height (Cabinet under the work‐ 578 (600) mm top minimum height) Cabinet width 560 mm Cabinet depth 550 (550) mm Height of the front of the appliance 594 mm Height of the back of the appliance 576 mm Width of the front of the appliance 595 mm...

  • Page 7: Use

    SAFETY INSTRUCTIONS • Use only correct isolation devices: line protecting cut-outs, fuses (screw type fuses removed from the holder), earth leakage trips and contactors. • The electrical installation must have an isolation device which lets you disconnect the appliance from the mains at all poles. The isolation device must have a contact opening width of minimum 3 mm.

  • Page 8: Pyrolytic Cleaning

    SAFETY INSTRUCTIONS • Replace immediately the door glass panels when they are damaged. Contact the Authorised Service Centre. • Be careful when you remove the door from the appliance. The door is heavy! • Clean regularly the appliance to prevent the deterioration of the surface material. •...

  • Page 9: Service

    PRODUCT DESCRIPTION 2.7 Service • To repair the appliance contact the Authorised Service Centre. • Use original spare parts only. 2.8 Disposal WARNING! Risk of injury or suffocation. • Contact your municipal authority for information on how to dispose of the appliance. •...

  • Page 10: How To Turn Oven On And Off

    HOW TO TURN OVEN ON AND OFF Baking tray For cakes and biscuits. Grill- / Roasting pan To bake and roast or as a pan to collect fat. Food sensor To measure the temperature inside food. 4. HOW TO TURN OVEN ON AND OFF 4.1 Control panel ON / OFF Press and hold to turn the oven on and off.

  • Page 11: Display

    HOW TO TURN OVEN ON AND OFF Lamp switch To turn the lamp on and off. Fast Heat Up To turn on and off the function: Fast Heat Up. Press Move Press and hold Touch the surface with finger‐ Slide fingertip over the sur‐ Touch the surface for 3 sec‐...

  • Page 12: Knobs For The Cooking Zones

    BEFORE FIRST USE Display indicators Basic indicators - to navigate on the display. To go one To confirm the selection / set‐ To undo the To turn the options on and level back in ting. last action. off. the menu. Sound alarm function indicators - when the set time of cooking ends, the signal sounds.

  • Page 13: Initial Cleaning

    DAILY USE 5.1 Initial Cleaning Step 1 Step 2 Step 3 Clean the oven and the ac‐ Remove all accessories and Place the accessories and the cessories with a soft cloth, removable shelf supports from removable shelf supports in warm water and a mild deter‐ the oven.

  • Page 14: How To Set: Assisted Cooking

    DAILY USE Step 3 Select the heating function and press: . The display shows: temperature. Step 4 Set: temperature. Press: Step 5 Press: Food Sensor - you can plug the sensor at any time before or during cooking. - press to turn off the heating function. Step 6 Turn off the oven.

  • Page 15: Heating Functions

    DAILY USE Take a shortcut! 6.3 Heating functions STANDARD Heating function Application To grill thin pieces of food and to toast bread. Grill To roast large meat joints or poultry with bones on one shelf position. To make gratins and to brown. Turbo Grilling To bake on up to three shelf positions at the same time and to dry food.
  • Page 16 DAILY USE Heating function Application Use this function to prepare bread and bread rolls with a very good pro‐ fessional-like result in terms of crispiness, colour and crust gloss. Bread Baking To speed up the rising of the yeast dough. It prevents dough surface from drying and keeps the dough elastic.

  • Page 17: Notes On: Moist Fan Baking

    CLOCK FUNCTIONS Heating function Application This function is designed to save energy during cooking. When you use this function, the temperature in the cavity may differ from the set temper‐ ature. The residual heat is used. The heating power may be reduced. For Moist Fan Baking more information refer to "Daily Use"...
  • Page 18 CLOCK FUNCTIONS How to set the clock Step 2 Set the time. Press: How to set cooking time Step 1 Choose the heating function and set the temperature. Step 2 Press: Step 3 Set the time. Press: Take a shortcut! How to choose end option Step 1 Choose the heating function and set the temperature.

  • Page 19: How To Use: Accessories

    HOW TO USE: ACCESSORIES How to delay start of cooking Step 3 Set the cooking time. Step 4 Press: Step 5 Press: Delayed start. Step 6 Choose the value. Step 7 Press: . Repeat the action until the display shows the main screen. How to extend cooking time When 10% of cooking time is left and the food seems not to be ready, you can extend cooking time.

  • Page 20: Food Sensor

    HOW TO USE: ACCESSORIES Wire shelf: Push the shelf between the guide bars of the shelf support. Baking tray / Deep pan: Push the tray between the guide bars of the shelf support. Wire shelf, Baking tray / Deep pan: Push the tray between the guide bars of the shelf support and the wire shelf on the guide bars above.
  • Page 21 HOW TO USE: ACCESSORIES For the best cooking results: Ingredients should be at Do not use it for liquid During cooking it must remain in room temperature. dishes. the dish. The oven calculates an approximate end of cooking time. It depends on the quantity of food, the set oven function and the temperature.

  • Page 22: Additional Functions

    ADDITIONAL FUNCTIONS Step 6 - press to set the preferred option: • Sound alarm - when food reaches the core temperature, the signal sounds. • Sound alarm and stop cooking - when food reaches the core temperature, the sig‐ nal sounds and the oven stops. Step 7 Select the option and repeatedly press: to go to main screen.

  • Page 23: Function Lock

    ADDITIONAL FUNCTIONS 9.2 Function lock This function prevents an accidental change of the heating function. Step 1 Turn on the oven. Step 2 Set a heating function. Step 3 - press at the same time to turn on the function. To turn off the function repeat step 3.

  • Page 24: Hints And Tips

    HINTS AND TIPS 10. HINTS AND TIPS 10.1 Cooking recommendations The temperature and cooking times in the tables are guidelines only. They depend on the recipes and the quality and quantity of the ingredients used. Your oven may bake or roast differently to the oven you had before. The hints below show recom‐ mended settings for temperature, cooking time and shelf position for specific types of the food.

  • Page 25: Moist Fan Baking - Recommended Accessories

    HINTS AND TIPS (°C) (min) Tartlets, 8 baking tray or dripping 15 - 25 pieces 10.3 Moist Fan Baking - recommended accessories Use the dark and non-reflective tins and containers. They have better heat absorption than the light colour and reflective dishes. Ramekins Pizza pan Baking dish...
  • Page 26 HINTS AND TIPS BAKING ON ONE LEVEL. Biscuits Use the third shelf position. (°C) (min) Short bread / Pastry strips True Fan Cooking 25 - 40 Short bread / Pastry strips, Conventional Cooking 20 - 30 preheat the empty oven Small cakes, 20 per tray, True Fan Cooking 20 - 35...

  • Page 27: Care And Cleaning

    CARE AND CLEANING GRILL Preheat the empty oven for 5 minutes. Grill with the maximum temperature setting. (min) Toast Grill 1 - 3 Beef steak, turn halfway Grill 24 - 30 through 11. CARE AND CLEANING WARNING! Refer to Safety chapters. 11.1 Notes on cleaning Clean the front of the oven with a soft cloth with warm water and a mild deter‐...

  • Page 28: How To Remove: Shelf Supports

    CARE AND CLEANING Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a mild detergent. Do not clean the accessories in a dishwash‐ Do not clean the non-stick accessories using abrasive cleaner or sharp-edged Accessories objects.

  • Page 29: Cleaning Reminder

    CARE AND CLEANING Step 1 Step 2 Step 3 Turn on the oven. Select the cleaning mode. Press: / Cleaning. Option Cleaning mode Duration Pyrolytic cleaning, quick Light cleaning Pyrolytic cleaning, normal Normal cleaning 1 h 30 min Pyrolytic cleaning, intense Thorough cleaning When the cleaning starts, the oven door is locked and the lamp is off.

  • Page 30: How To Replace: Lamp

    CARE AND CLEANING Step 1 Fully open the door. Step 2 Lift and press the clamping levers (A) on the two door hinges. Step 3 Close the oven door to the first opening position (approximately 70° angle). Hold the door at both sides and pull it away from the oven at an upwards angle. Put the door with the outer side down on a soft cloth on a stable surface.

  • Page 31: Troubleshooting

    TROUBLESHOOTING Before you replace the lamp: Turn off the oven. Wait until Disconnect the oven from the Put a cloth on the bottom of the oven is cold. mains. the cavity. Top lamp Step 1 Turn the glass cover to remove it. Step 2 Clean the glass cover.

  • Page 32: What To Do If

    TROUBLESHOOTING 12.1 What to do if... The oven does not turn on or does not heat up Possible cause Remedy The oven is not connected to an electrical sup‐ Check if the oven is correctly connected to the ply or it is connected incorrectly. electrical supply.

  • Page 33: Service Data

    Product number (PNC) ......... Serial number (S.N.) ......... 13. ENERGY EFFICIENCY 13.1 Product Information and Product Information Sheet* Supplier's name Model identification EPS742230B 940321394 Energy Efficiency Index 61.2 Energy efficiency class Energy consumption with a standard load, conventional 1.09 kWh/cycle mode 33/40...

  • Page 34: Energy Saving

    ENERGY EFFICIENCY Energy consumption with a standard load, fan-forced 0.52 kWh/cycle mode Number of cavities Heat source Electricity Volume 71 l Type of oven Built-Under Oven Mass 35.0 kg * For European Union according to EU Regulations 65/2014 and 66/2014. For Republic of Belarus according to STB 2478-2017, Appendix G;...

  • Page 35: Menu Structure

    MENU STRUCTURE Moist Fan Baking Function designed to save energy during cooking. When you use this function the lamp automatically turns off after 30 sec. You may turn on the lamp again but this action will reduce the expected energy savings. 14.

  • Page 36: Submenu For: Setup

    MENU STRUCTURE Submenu Application Child Lock Prevents accidental activation of the oven. When the option is on, the text "Child Lock" appears on the display when you turn on the oven. To enable the oven use, choose the code letters in the alphabetical order. When the Child Lock is on and the oven is turned off the oven door is locked.

  • Page 37: S Easy

    IT'S EASY! Submenu Description Reset all settings Restores factory settings. 15. IT'S EASY! Before first use you have to set: Display bright‐ Language Key tones Buzzer volume Time of day ness Familiarize yourself with the basic icons on the control panel and the display: ON / OFF Menu Favourites...

  • Page 38: Take A Shortcut

    IT'S EASY! Get to know how to cook quickly Use the automatic programmes to prepare a dish quickly with the default settings: Assisted Step 1 Step 2 Step 3 Step 4 Cooking Choose the dish. Press: Press: Press: Assis‐ ted Cooking. Use quick functions to set the cooking time 10% Finish assist To extend the cooking time press +1min.

  • Page 39: Environmental Concerns

    TAKE A SHORTCUT! How to cancel: Set Timer How to use: Food Sensor 17. ENVIRONMENTAL CONCERNS Recycle materials with the symbol . Put the packaging in relevant containers to recycle it. Help protect the environment and human health by recycling waste of electrical and electronic appliances.
  • Page 40 www.aeg.com/shop...
