Blue Ox BRK2512 Operating Instructions

To Open:
1. Place your thumb on top of the claw and place your pointer finger under the back ledge (right).
Pinch your fingers together until the claw locks in place (left).
To Lock:
4. If the claw is open, you can turn the knob one quarter
turn to the left to lock it open.
If the claw is closed, you can turn the knob one
quarter turn to the left to prevent it from locking open.
If the claw is locked, turn the knob one quarter turn to
the right to unlock it.
405-0392
Patriot Adjustable/Locking Brake Claw
®
Operating Instructions
To Close:
2. Position the claw onto the brake pedal.
NOTE: You can adjust the size of the claw by changing
where the top fangs are mounted.
3. Press the button on top of the claw to close the claw or
push the front button against the brake pedal.
Caution: Make sure your fingers are not between the
upper and lower half of the claw when you press the
button.
Page 1 of 2
BRK2512
1/15/14
