Blue Ox BX1141 Installation Instructions Manual

Please visit
Attachment Tab Height: 19.5"
Attachment Tab Width: 37"
Please read BOTH these Installation Instructions and the General Information sheet prior to
1. Blue Ox towing products and accessories are
®
intended to be installed by Blue Ox
who are familiar with our products and have the
equipment and knowledge necessary to do "fit
work". If needed, Blue Ox
at www.blueox.com
Service Department at (402) 385-3051.
2. Many Blue Ox baseplates are designed to
®
use existing holes and hardware to mount the
baseplate to the towed vehicle. Even though bolts
are there, do not assume they are adequate for
baseplate mounting. Always use the hardware
supplied in the hardware kit and existing hardware
as specified in the installation instructions.
If the front of your vehicle looks different than
this, please contact us at (402)385-3051.
Reference your vehicle owner's
manual for manufacturer's towing
specifications.
405-0645 Rev D
www.blueox.com for the latest version of these installation instructions.
2019-2020 Jeep Cherokee Aluminum Bumper
installing or operating this equipment.
Dealers
®
Dealers can be found
®
or by contacting our Technical
BX1141
w/out Tow Hooks
(Includes Adaptive Cruise Control) (2-Speed Transfer Case)
Installation Instructions
Serial Number
Bolt Torque Specifications
Torque in Foot-Pounds for Inch Bolts
Bolt Size
1/4"
5/16"
3/8"
7/16"
1/2"
5/8"
3/4"
Bolt Torque Specifications
Torque in Foot-Pounds for Metric Bolts
Bolt Size
6MM
8MM
10MM
12MM
14MM
16MM
18MM
!
Failure to read and follow these instructions
could result in separation of the towed vehicle
from the tow bar, causing property damage,
loss of towed vehicle, personal injury or death.
Page 1 of 8
Grade 5 Grade 8
10
19
33
54
78 119
154 230
257 380
Grade 8.8 Grade 10.9
6
16
31
54
89
161
222
WARNING
14
29
47
78
8
22
40
70
117
230
318
9/5/19
