for purchasing a SwayPro™ from Blue Ox®. Please read the manual to insure
your installation is as simple and trouble-free as possible. Keep your sales
405-0290 Rev A
SwayPro
Owner's Manual
550 lbs. maximum tongue weight capacity
750 lbs. maximum tongue weight capacity
1000 lbs. maximum tongue weight capacity
1500 lbs. maximum tongue weight capacity
NOTE: A minimum tongue weight of 350 lbs. is required
receipt and the manual in a safe place for future reference.
Page 1 of 12
BXW0553
BXW0753
BXW1003
BXW1503
THANK YOU
™
9/20/12
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Blue Ox SwayPro BXW0553
Summary of Contents for Blue Ox SwayPro BXW0553
- Page 1 NOTE: A minimum tongue weight of 350 lbs. is required THANK YOU for purchasing a SwayPro™ from Blue Ox®. Please read the manual to insure your installation is as simple and trouble-free as possible. Keep your sales receipt and the manual in a safe place for future reference.
-
Page 2: Features And Benefits
Features and Benefits What is gross trailer weight? Answer: Weight of trailer (dry) + liquids (water, propane, sewage) + cargo. Measure • Open Head gross trailer weight with a fully loaded trailer Open head provides easy access for on a level surface, preferably on a public truck tightening the hitch ball. - Page 3 ® Congratulations! You are now the proud owner of a SwayPro™. Welcome to the Blue Ox® Family. The weight distributing hitch combines quality components with the latest in technology and style. We are confident that these design features will provide you with the conveniences you expect during your travels. Your SwayPro™ is backed by a three (3) year limited warranty. Any unauthorized modifications to your SwayPro™...
- Page 4 Tools Required BXW4005 Kit, 550 lb Spring Bars Torque Wrench BXW4006 Kit, 750 lb Spring Bars Tape Measure BXW4007 Kit, 1,000 lb Spring Bars 1-1/16” Socket BXW4008 Kit, 1,500 lb Spring Bars 1-1/8” Socket BXW4001 BXW4002 BXW4000 RECEIVER HITCH MOUNT, RECEIVER HITCH MOUNT, RECEIVER HITCH MOUNT, 7 HOLE - 12 IN...
- Page 5 Note: Items #3 thru #6 depend on your SwayPro™ model Item number Description Part number Qty. 1......61-6014 ....... Receiver Hitch Mount Weldment, 7 Hole ......1 2......61-7067 ....... Hitch Head Assembly ............1 3......62-3536 ....... 1,000 Lb. Assembly Bar ..........2 4......62-3537 ....... 750 Lb. Assembly Bar .............2 5......62-3538 .......
-
Page 6: Installation
Installation 1. Park the towing vehicle and trailer in a straight line on firm, level ground. Air-ride shock absorbers, air springs, or automatic leveling systems on towing vehicle should be disabled or deflated to the manufacture’s minimum recommended pressure prior to SwayPro™ installation. 2. Insert the hitch mount receiver shank into the towing vehicle receiver and secure with 5/8” x 3” pin and clip. 3. Couple the trailer to the hitch head by placing the trailer coupler onto the hitch ball per the manufacturer’s instructions. -
Page 7: Operation
Repeat the above steps until the towing vehicle is level. 10. If the trailer is not level, determine how much and in which direction. Each hole raises or lowers the front of the trailer 1-1/2”. Level the trailer by: A. Support the weight of the trailer tongue B. -
Page 8: Troubleshooting
2. Disconnect spring bars by turning 90 degrees or pull out the pins to remove . 3. Unhook the trailer coupler from the hitch. 4. Remove the hitch pin and clip from the hitch receiver. 5. Remove the hitch mount receiver from the receiver tube. Troubleshooting Issue: After coupling the trailer to the hitch head, the pickup squats and the front of the trailer dips. - Page 9 405-0290 Rev A Page 9 of 12 9/20/12...
- Page 10 405-0290 Rev A Page 10 of 12 9/20/12...
- Page 11 405-0290 Rev A Page 11 of 12 9/20/12...
- Page 12 Blue Ox® also offers educational seminars at rallies and through our Parks and Resort teams. In addition, Blue Ox® customers visiting our factory may take advantage of free use of the well-equipped Blue Ox® RV park at no charge to you, our valued and Blue Ox • One Mill Road, Industrial Park • Pender, Nebraska 68047 ©...
