Blue Ox BX3772 Installation Instructions Manual

Please read BOTH the Installation Instructions and the General
Towing Instructions before attempting to install or operate this equipment.
1. Blue Ox
®
are intended to be installed by Blue Ox
Dealers who are familiar with our products and
have the equipment and knowledge to do "fit
work." When necessary, Blue Ox
be found at www.blueox.com or by contacting
our Customer Care Department at (402)
385-3051.
2. Many Blue Ox
use existing holes and hardware to mount
the baseplate to the towed vehicle. Even
though bolts are there, do not assume they
are adequate for baseplate mounting. Always
use hardware supplied in the hardware kit
or existing hardware specified in the
Baseplate Towing Installation Instructions.
Confirm the towability and pre-towing
procedures for your vehicle with
the owner's manual or contact the
vehicle's manufacturer for specific
If the front of your vehicle looks different
than this, call us at (402) 385-3051.
292-2933 Rev. J
towing products and accessories
Baseplates are designed to
®
towing procedures.
BX3772
2010 Lexus LX570
Installation Instructions
Attachment Tab Height:
Attachment Tab Width:
®
Dealers can
®
!
Failure to read and follow these instructions
could result in separation of the towed vehicle
from the tow bar, causing property damage,
loss of towed vehicle, personal injury or death.
Page 1 of 7
12 3/4"
Bolt Torque Specifications
Torque in Foot-Pounds for Metric Bolts
Bolt Size Grade 8.8 Grade 10.9
6MM 6
8MM 16
10MM 31
12MM 54
14MM 89
Bolt Torque Specifications
Torque in Foot-Pounds for Inch Bolts
Bolt Size Grade 5
1/4" 10
5/16" 19
3/8" 33
7/16" 54
1/2" 78
5/8" 154
WARNING
32 1/2"
8
22
40
70
117
Grade 8
14
29
47
78
119
230
6/23/17
