REA 100.0 PLUS
2 - 33
Instruction Manual
33 - 68
Manual de instrucciones
WARNING
Read Instruction Manual thoroughly before use and
follow all safety precautions – improper use can cause
serious or fatal injury.
ADVERTENCIA
Antes de usar la máquina lea y siga todas las precauciones
de seguridad dadas en el manual de instrucciones – el uso
incorrecto puede causar lesiones graves o mortales.

Advertisement

loading
Need help?

Need help?

Do you have a question about the REA 100.0 PLUS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Stihl REA 100.0 PLUS

Summary of Contents for Stihl REA 100.0 PLUS

  • Page 1 REA 100.0 PLUS 2 - 33 Instruction Manual 33 - 68 Manual de instrucciones WARNING Read Instruction Manual thoroughly before use and follow all safety precautions – improper use can cause serious or fatal injury. ADVERTENCIA Antes de usar la máquina lea y siga todas las precauciones de seguridad dadas en el manual de instrucciones –...

  • Page 2: Table Of Contents

    Thank you for your purchase. The information contained in this manual will help you receive maximum performance and satisfaction from your STIHL pressure washer and, if followed, reduce the risk of injury from its use. SAVE THIS MANUAL! Because this pressure washer is...

  • Page 3: Main Parts

    3 Main Parts English Main Parts 11 Locking Lever Secures the battery in the battery compart‐ Pressure Washer and Battery ment. 12 Rotary Control For adjusting the operating pressure and the flow rate of the high-pressure jet. 13 Pressure Washer LED Indicates the operating status of the pressure washer.

  • Page 4: Safety Symbols On The Products

    Improper use can lead to serious STIHL tool powered by this bat‐ or fatal personal injury or property tery. Improper use can lead to damage.
  • Page 5 ANSI Z87.1. design. – Keep bystanders and animals out of the ■ This power tool may be powered by a STIHL work area. AP series battery. – See rating plate for maximum discharge ®...

  • Page 6: Personal Protective Equipment

    – Safety glasses do not pro‐ ■ Although certain unauthorized attachments vide full protection. may fit your STIHL pressure washer, their use ■ Good footing is very important. To help main‐ may be extremely dangerous. Only attach‐ tain a secure footing and reduce the risk of...

  • Page 7: Using The Pressure Washer

    5 IMPORTANT SAFETY INSTRUCTIONS English approved by STIHL for use with this specific – Do not connect the pres‐ sure washer directly to a model are recommended. potable water system. – Use only attachments supplied or expressly approved by STIHL.
  • Page 8 STIHL servicing – Never leave the pressure washer unatten‐ dealer. Do not use the pressure washer ded when the battery is inserted.
  • Page 9 5 IMPORTANT SAFETY INSTRUCTIONS English cles such as tree stumps, roots, rocks, ■ Spraying certain materials with the water jet holes and ditches to avoid stumbling or may produce dust or a mist containing particu‐ falling. late matter capable of causing respiratory dis‐ –...
  • Page 10 English 5 IMPORTANT SAFETY INSTRUCTIONS – Switch off the motor immediately and damage the pressure washer and/or the sur‐ remove the battery. face being cleaned. ■ To reduce the risk of fire/explosion resulting in – Always use the detergent in the dosage serious or fatal injury or property damage: specified in the detergent manufacturer's instructions for proper preparation and...

  • Page 11: Battery Safety

    – Never store the battery in the power tool. explode. – When storing the battery, maintain a – Never heat the battery charge of 40 % to 60 % for STIHL AP ser‐ above 212 °F (100 °C). ies batteries (2 green LEDs). – Never incinerate or place –...

  • Page 12: Maintenance, Repair And Storage

    – Although water can be used to put out a ■ Use of parts that are not authorized or battery fire, use of a multi-purpose dry approved by STIHL may cause serious or fatal chemical fire extinguisher is preferable. injury or property damage.

  • Page 13: Before Starting Work

    – When storing the battery, maintain a To reduce the risk of short circuit, which could charge of 40 % to 60 % for STIHL AP ser‐ lead to electric shock, fire and explosion, ies batteries (2 green LEDs).

  • Page 14: Led Diagnostics

    Never charge a malfunctioning, dam‐ ► Charge STIHL AP series batteries only with aged, cracked, leaking or deformed battery or genuine STIHL AL 101, AL 301, AL 301-4 or use a charger that has been damaged. Never AL 500 series chargers.

  • Page 15: Bluetooth® Radio Interface

    "BLUETOOTH®“ LED next to symbol flashes blue. ► Then release the push button immediately. ► Connect the battery to the STIHL connected app to confirm that all user-specific data has been deleted. ► Insert 3-in-1 nozzle (1).
  • Page 16 English 12 Assembling the Pressure Washer 12.2 Spray Gun and Lance To remove the spray gun and lance: ► Switch off the pressure washer, 15.2. 12.2.1 Connecting the Spray Gun and Lance ► Remove the battery, 14.2. To connect the spray gun and lance: ►...

  • Page 17: Connecting The Water Supply

    13 Connecting the Water Supply English 13 Connecting the Water Sup‐ ► Pull the spray gun trigger to relieve pressure. ► Lock the spray gun trigger. ► Remove all sand and debris from the connec‐ tions and couplings. 13.1 Connecting the Pressure Washer to the Mains Water Supply WARNING...
  • Page 18 English 13 Connecting the Water Supply The appropriate STIHL suction set must be used. NOTICE The suction set includes a water hose with a ■ Running the pressure washer without water special coupling and an integrated water filter. will cause the pump to overheat, which may Depending on the market, the appropriate STIHL result in permanent damage.

  • Page 19: Inserting And Removing The Battery

    ► Close the battery compartment cover (1) and ensure that it is properly secured in place. WARNING Since a new battery is not fully charged, STIHL recommends that you fully charge the battery ■ To reduce the risk of personal injury or prop‐...

  • Page 20: Switching The Pressure Washer On And Off

    English 15 Switching the Pressure Washer On and Off ► Open the battery compartment cover (1). ► Press the power button (1). ► Compress the locking lever (3) to eject the The LED (2) will glow green. The pressure battery (2) from the battery compartment. washer is ready for operation.

  • Page 21: During Operation

    If the spray gun trigger can be depressed with‐ To lock the spray gun trigger: out first unlocking the retaining latch, take the pressure washer to an authorized STIHL serv‐ icing dealer to be repaired before use. ► Slide the retaining latch to the position.
  • Page 22 English 17 During Operation ► Turn rotary control (1) clockwise until the WARNING desired working pressure is set. ■ To reduce the risk of fluid injection and/or To decrease working pressure severe injury, keep hands, feet and other parts ► Turn rotary control (1) counter-clockwise until of your body away from the water jet at all the desired working pressure is set.

  • Page 23: After Finishing Work

    ► Remove the battery, 14.2. ■ Freezing temperatures can damage compo‐ ► Disconnect the pressure washer from the nents of the pressure washer. STIHL recom‐ water supply. mends storing the pressure washer indoors in ► Press the spray gun trigger to relieve any a dry room where it is protected from freezing remaining pressure in the system.

  • Page 24: Transporting

    ► If you are transporting the battery in a vehicle, ulations and ordinances. secure it and its container to prevent turnover, impact and damage. STIHL batteries comply with the requirements set forth in UN-Manual of Tests and Criteria, Part III, Subsection 38.3. Commercial air, vessel and ground transporta‐...

  • Page 25: Storing

    ► When storing the battery, maintain a charge of Improper storage can result in unauthorized 40 % to 60 % for STIHL AP series batteries (2 use and damage to the pressure washer, green LEDs).

  • Page 26: Cleaning

    To clean the nozzle and spray lance: – For maximum battery life, store the bat‐ tery with a charge between 40 % and 60 % for STIHL AP series batteries (2 green LEDs). – If storing the battery in the charger, dis‐...

  • Page 27: Inspection And Maintenance

    ► Inspect battery compartment cover, hoses, couplings, connectors and O-rings periodically ► Grease the O-rings (1) with food-safe fitting and have a worn component replaced. grease. ► Have worn, missing or damaged safety labels replaced by an authorized STIHL servicing dealer. 0458-047-8601-A...

  • Page 28: Troubleshooting Guide

    24.3. The high-pres‐ There is a leak in ► Have the pressure washer inspected and sure pump the high-pres‐ repaired by an authorized STIHL servicing repeatedly sure pump, high- dealer. switches on and pressure hose or off without pulling spray attach‐...

  • Page 29: Specifications

    ► Clean water intake screen, 21.4. screen or water ► Clean water filter, 21.5. filter is blocked. The high-pres‐ ► Ask a STIHL servicing dealer to inspect the sure pump, high- pressure washer. pressure hose or spray attachment is leaking. The shape of the The nozzle is ►...

  • Page 30: Ambient Temperature Limits

    STIHL AP Series Battery Apple and the Apple logo are trademarks of Apple Inc., registered in the U.S. and other coun‐ Approved charger types: STIHL AL 101, AL 300, tries. AL 301, AL 301-4, AL 500, AL 501. App Store is a service mark of Apple Inc.
  • Page 31 STIHL battery. Permissible batteries are listed in this User different from that to which the receiver is con‐ STIHL AP Manual. nected, Direct current – consult an authorized STIHL servicing dealer or an experienced radio/TV technician for help. 0458-047-8601-A...

  • Page 32: Replacement Parts And Equipment

    STIHL lection and recycling of spent STIHL lithium ion batteries in the United dealer or the STIHL distributor in your area for States and Canada. assistance. The RBRC seal indicates that STIHL has prepaid 25 Replacement Parts and for battery recycling.
