Summary of Contents for Banner B25
- Page 1 B25 Wide Beam Retroreflective Sensor Product Manual Original Instructions p/n: 243320 Rev. A 27-Feb-25 © Banner Engineering Corp. All rights reserved. www.bannerengineering.com...
-
Page 2: Table Of Contents
B25 Wide Beam Retroreflective Sensor Product Manual Contents Chapter 1 Product Description ....................3 1.1 Models ........................................3 1.2 Product Overview ....................................3 1.3 Features and Indicators................................... 4 Chapter 2 Installation Instructions ..................5 2.1 Mount the Device..................................... 5 2.2 Wiring ........................................5 Chapter 3 Configuration Instructions.................. -
Page 3: Chapter 1 Product Description
Product Overview The B25 is an industrial retroreflective sensor that utilizes a 25 mm wide beam to reliably detect targets. The wide beam is capable of detecting targets as small as 3 mm anywhere within the 25 mm beam. This is vital for leading edge applications which include targets that may have an inconsistent edge, such as mailers or polybags. -
Page 4: Features And Indicators
B25 Wide Beam Retroreflective Sensor Product Manual Product Description Link. The multi-channel cable routing on the bottom cleanly routes the cable away from the sensor, regardless of how the sensor is mounted. "Configuration Instructions" on page 6 to set up the sensor. A sensor is in standard sensitivity by default, and the output switches when the LED next to the "Stnd"... -
Page 5: Chapter 2 Installation Instructions
B25 Wide Beam Retroreflective Sensor Product Manual Chapter Contents 2.1 Mount the Device ......................................5 2.2 Wiring ..........................................5 Chapter 2 Installation Instructions Mount the Device If a bracket is needed, mount the device onto the bracket. Mount the device (or the device and the bracket) to the machine or equipment at the desired location. Do not tighten the mounting screws at this time. ... -
Page 6: Chapter 3 Configuration Instructions
B25 Wide Beam Retroreflective Sensor Product Manual Chapter Contents 3.1 TEACH Button Overview....................................6 3.2 Remote Input........................................7 3.3 TEACH Procedures......................................7 3.4 Reset the Sensor to Factory Default Settings .............................. 14 Chapter 3 Configuration Instructions Quickly set up and configure the sensor using the push button on the sensor, a remote input wire, or IO-Link. -
Page 7: Remote Input
Configuration Instructions B25 Wide Beam Retroreflective Sensor Product Manual Remote Input The remote input provides limited programming options. When the polarity selection is push-pull or PNP, remote input is Active High. When the polarity selection is NPN, remote input is Active Low. -
Page 8: Static Teach
B25 Wide Beam Retroreflective Sensor Product Manual Configuration Instructions 3.3.1 Static TEACH Use the following procedure to statically configure the sensor. The Static TEACH method configures the sensor to detect beam blockage in excess of the taught condition. For example, if the sensor is above a surface and is taught with no part of the beam blocked, then the sensor will detect when a large enough object is present anywhere in the beam. -
Page 9: Adjust The Sensitivity
Configuration Instructions B25 Wide Beam Retroreflective Sensor Product Manual Method Action Result Push Button Press the TEACH button twice. The bar graph LEDs cycle up and down the graph, the green LED is on, and the amber LED Remote Input Pulse the remote input twice. -
Page 10: Set Light Operate (Lo) Or Dark Operate (Do)
B25 Wide Beam Retroreflective Sensor Product Manual Configuration Instructions Continued from page 9 Method Action Result Pulse the remote input to select the desired level. Pulses Sensitivity Level The green and amber LEDs flash twice and the Remote Input sensor returns to Run mode. -
Page 11: Set A Delay
Configuration Instructions B25 Wide Beam Retroreflective Sensor Product Manual Method Action Result The LO/DO LED (top bar) on the bar graph Press the TEACH button to cycle between LO and DO to Push Button shows the selected setting. See "LO/DO select the desired setting. -
Page 12: Input/Output Configuration For Channel 2
B25 Wide Beam Retroreflective Sensor Product Manual Configuration Instructions Continued from page 11 Method Action Result Pulse the remote to select the desired setting. Pulses Setting The green and amber LEDs flash twice and the Remote Input Enabled sensor returns to Run mode. -
Page 13: Enable Or Disable The Drift Filter
Configuration Instructions B25 Wide Beam Retroreflective Sensor Product Manual Action Result The LEDs on the bar graph show the current setting and Press the TEACH button six times. the green (power) LED flashes. See "Configuration Options" on page Select the desired setting. -
Page 14: Reset The Sensor To Factory Default Settings
B25 Wide Beam Retroreflective Sensor Product Manual Configuration Instructions Method Action Result The green (power) LED flashes, the amber Press the TEACH button to cycle between enabled and (output status) LED is off, and the bar graph Push Button disabled to select the desired setting. -
Page 15: Chapter 4 Io-Link Interface
This information can be easily read and processed by the user. Each device can be unambiguously identified via the IODD as well as via an internal device ID. Download the B25's IO-Link IODD package (p/n 242307) from Banner Engineering's website at www.bannerengineering.com. -
Page 16: Chapter 5 Specifications
B25 Wide Beam Retroreflective Sensor Product Manual Chapter Contents 5.1 Dimensions........................................17 Chapter 5 Specifications Supply Voltage Response Speed 10 V DC to 30 V DC ≤ 0.5 ms Supply Protection Circuitry Minimum Detectable Object Protected against reverse polarity and transient overvoltages... -
Page 17: Dimensions
Specifications B25 Wide Beam Retroreflective Sensor Product Manual Dimensions All measurements are listed in millimeters, unless noted otherwise. The measurements provided are subject to change. Receiver Lens Center Emitter Lens Center 27-Feb-25 © Banner Engineering Corp. All rights reserved. page 17 of 22 www.bannerengineering.com... -
Page 18: Chapter 6 Accessories
B25 Wide Beam Retroreflective Sensor Product Manual Chapter Contents 6.1 Cordsets ........................................18 6.2 Brackets ........................................19 6.3 Reflectors ........................................19 Chapter 6 Accessories Cordsets 4-Pin Single-Ended M12 Female Cordsets Model Length Style Dimensions Pinout (Female) 44 Typ. MQDC-406 2 m (6.56 ft) ... -
Page 19: Brackets
Accessories B25 Wide Beam Retroreflective Sensor Product Manual Brackets SMBB25P • Zinc plated, Cold Rolled Steel 4X Ø3.5 Ø20 SMBB25RA • Zinc plated, Cold Rolled Steel 8X Ø3.5 2X Ø6.3 Reflectors BRT-51X51BM • Square, acrylic target • Reflectivity Factor: 1.5 •... -
Page 20: Chapter 7 Product Support
Contact Banner Engineering for troubleshooting of this device. Do not attempt any repairs to this Banner device; it contains no field-replaceable parts or components. If the device, device part, or device component is determined to be defective by a Banner Applications Engineer, they will advise you of Banner's RMA (Return Merchandise Authorization) procedure. IMPORTANT: If instructed to return the device, pack it with care. Damage that occurs in return shipping is not covered by warranty. ... -
Page 21: Contact Us
Engineering Corp. will repair or replace, free of charge, any product of its manufacture which, at the time it is returned to the factory, is found to have been defective during the warranty period. This warranty does not cover damage or liability for misuse, abuse, or the improper application or installation of the Banner product. - Page 22 LinkedIn X (formerly Twitter) Facebook © 2025. All rights reserved. www.bannerengineering.com...
