Rack Adapter Panel
GRA-455
Assembly Manual
GW INSTEK PART NO. 82RA-45500M01
This assembly manual contains proprietary information, which is protected by copyrights. All rights are
reserved. No part of this manual may be photocopied, reproduced or translated to another language
without prior written consent of Good Will company.
The information in this manual was correct at the time of printing. However, Good Will continues to
improve products and reserves the rights to change specification, equipment, and maintenance
procedures at any time without notice.
Good Will Instrument Co., Ltd.
No. 7-1, Jhongsing Rd., Tucheng Dist., New Taipei City 236, Taiwan.
ISO-9001 CERTIFIED MANUFACTURER
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for GW Instek GRA-455
Summary of Contents for GW Instek GRA-455
- Page 1 Rack Adapter Panel GRA-455 Assembly Manual GW INSTEK PART NO. 82RA-45500M01 This assembly manual contains proprietary information, which is protected by copyrights. All rights are reserved. No part of this manual may be photocopied, reproduced or translated to another language without prior written consent of Good Will company.
- Page 2 GRA-454 Assembly Manual GRA-455 Overview The GRA-455 rack mount is suited for several models including of DAQ-9600. The GRA-455 is specifically designed to hold one or two units and fits in a standard 19” 2U rack. Rack Mount Adapter Component List Description Please check to make sure all the components of the GRA-455 rack mount kit are well provided as listed below.
- Page 3 GRA-454 Assembly Manual Rack Adaptor Assembly Step 1 - 1. Rotate the handler upward followed by pulling out the preparation bases of handler from both left and right sides to remove the handler away from unit. See the figure below of the model DAQ-9600 for example.
- Page 4 GRA-454 Assembly Manual Step 2 – for Connect the front plate with unit in parallel with fastening the single unit plastic rivets firmly. Step 3 – for Place the unit along with front plate combined into the single unit bottom cover of rack mount followed by tightening the M4*12 screws in the front end as the following figure shown.
- Page 5 GRA-454 Assembly Manual Step 4 – for Put the top cover onto the rack mount followed by fastening single unit the M3*5 screws in the 2 sides as the following figure shown. The rack mount is completely assembled with unit.
-
Page 6: Multiple Applications
GRA-454 Assembly Manual Multiple Applications The GRA-455 rack mount provides, in addition to the single unit assembly, up to 2 types of assembly for both dual units and hybrid units applications. See the following figures respectively for reference. Dual units... - Page 7 GRA-454 Assembly Manual Rack Adaptor Dimension All dimensions are shown in millimeters.
