DMP XF6 Lab Manual

IDENTIFY PANEL COMPONENTS
1. Identify the following panel components using the
panels in front of you, or the on-screen photo of the
XF6.
ê Reset header ê AC Power terminals
ê Programming ê Cellular pins
header ê 1100 Series receiver
ê Outputs connection
POWER UP THE PANEL
1. Connect AC power to terminals 1 & 2
ê Transformer type: 24 VDC 130 VAC
2. Connect battery backup to terminals 3 & 4
3. Connect NAC circuits to terminals 13 & 14 or 15 & 16
ENTER PANEL PROGRAMMER
1. Reset the panel using the RESET JUMPER
2. Enter 6653 (PROG) and press CMD
3. Press CMD to navigate through the panel
programmer menus:
ê Initialization ê Device Setup
ê Communication ê System Options
ê Network Options ê Bell Options
ê Remote Options ê Output Options
ADJUST COMMUNICATION TYPE
1. Navigate to COMMUNICATION and press a top-row
select area
2. Press a top-row select area to clear the default
ACCOUNT NUMBER
3. Enter in an ACCOUNT NUMBER
4. Press CMD to navigate to PATH
5. Press 1 to program PATH 1
6. Press a top-row select area to display the
COMMUNICATION types
7. Select NET
8. Press CMD to navigate to CHECKIN
9. Press a top-row select area and select YES
10. Press a top-row select area and enter your
CHECKIN MINS
11. Press a top-row select area and enter your FAIL
MINS
12. Press CMD to navigate to RECEIVER IP
13. Press a top-row select area and enter in the DMP
Tech Support receiver IP Address
ê 209.248.148.051 (Port 2001)
14. Press CMD to navigate to PATH
15. Press 2 to program PATH 2
16. Press a top-row select area to display the
COMMUNICATION TYPES
XF6 LAB GUIDE
Instructor-Led Training
ê On-board zone
terminals
ê Network connection
ê Output Information
ê Output Groups
ê Zone Information
ê Stop
17. Select CELL
18. Press CMD to navigate to PATH TYPE
19. Press a top-row select area and select PRIMARY or
BACKUP
20. Press CMD to navigate to CHECKIN
21. Press a top-row select area and select YES
22. Press a top-row select area and enter your
CHECKIN MINS
23. Press a top-row select area and enter your FAIL
MINS
24. Press CMD to navigate to RECEIVER IP
25. Press a top-row select area and enter in the DMP
Tech Support receiver IP Address
ê 209.248.148.051 (Port 2001)
26. Press CMD to navigate to ADVANCED
27. Press the fourth top-row select area
28. Press CMD to exit COMMUNICATION
ADD AN ANNUNCIATOR
1. Navigate to DEVICE SETUP and press a top-row
select area
2. Enter a DEVICE NUMBER and press CMD
3. Press a top-row select area and enter a DEVICE
NAME
4. Press CMD to confirm the DEVICE TYPE
5. Press CMD to exit DEVICE SETUP
ADJUST AN ANNUNCIATOR ADDRESS
1. Navigate to OPTIONS on the carousel menu
2. Select INSTALLER OPTIONS
3. Enter 3577 (INST) and CMD
4. Select KEYPAD OPTIONS (KPD OPT)
5. Press a top-row select area to change the keypad
address
6. Press CMD to exit KEYPAD OPTIONS
7. Select STOP to save keypad programming
CONFIGURE SYSTEM OPTIONS
1. Navigate to SYSTEM OPTIONS and press a top-row
select area
2. Press CMD to navigate to HOURS FROM GMT
3. Press a top-row select area, enter in the hours from
GMT for your location and press CMD
4. Using CMD, navigate to HOUSE CODE
5. Press a top-row select area and enter a house code
from 1-50 and press CMD
6. Press CMD to navigate to SEND 16 CHAR NAMES
7. Press the third top-row select area to select NO
8. Press CMD to exit SYSTEM OPTIONS
