- Page 1 XF6 Series SYS T E M U S E R G U I D E X F 6 S E R I E S F I R E C O N T R O L P A N E L...
- Page 3 HOW TO HANDLE AN ALARM While the fire alarm horns, strobes, or sirens are going off, use the following methods to silence the alarm: Press the SILENCE key. Enter your User Code, then press COMMAND. Note: You may silence an alarm using the above methods on the Remote Fire Command Center too.
-
Page 4: Table Of Contents
TABLE OF CONTENTS Get to Know the Fire Command Center ..1 System Status ............17 System Test ..............18 Select Areas ..............2 User Codes ..............19 Data Entry Keys ............2 Setting the Date and Time ........23 Back Arrow Key ............2 Display Events ............25 Command Key ............ - Page 5 FIRE CONTROL PANEL FEATURES Alarm LED Indicator Dealer Logo microSD Card Slot System Events Carousel Menu Status Indicators Press the Navigation Arrows or touch and drag the menu to scroll Figure 1: Fire Control Panel Features...
-
Page 6: Get To Know The Fire Command Center
The Command Keypad is also available in a remote version. Figure 1 and its descriptions highlight some features of the Fire Command Keypad. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 7: Select Areas
Command Key The COMMAND key allows you to advance through the displays or User Menu. You can also use the COMMAND key to complete a data entry function. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 8: Status Display
This indicator turns blue when a supervisory alarm is triggered. Alarm Indicator This indicator is on when any alarm currently displays in the status list. This indicator is off when no alarm currently displays in the status list. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 9: Entering Alpha Characters
Press abc to enter lowercase letters. Entering Non-Alpha Characters • Press !@# to enter special characters. • Press 123 to enter numbers and to return to the number pad. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 10: Using The Keypad
NO, press the third top row Select Key. The display changes to NO. Press the COMMAND key to go to the next option. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 11: User Options
The keypad model number, firmware left and right Select Keys to make the version, and date display in the upper tone lower or higher. right of the screen but can’t be changed. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 12: Four Function Keys
Pressing the DRILL key displays a prompt SURE? YES NO. Press YES to begin the fire drill. Press NO to return to the status list. TEST Key Pressing the TEST key performs a system test. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 13: Special Fire Command Center Displays
User codes can be required The system is performing another task for silencing alarms, performing sensor of a higher priority. This usually only resets, etc. takes a few moments. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 14: Special Fire Command Tones
Press a Select Key to silence. Note: Silencing the trouble tone by pressing any key only silences the keypad and does not correct the condition that originally caused the trouble. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 15: User Menu
SYSTEM STATUS that have latched due to an alarm condition. Displays the current condition of the system AC power, backup battery, optional panel tamper, and keypad model and version numbers. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. - Page 16 Allows you to change the Day, Date, or Time that is currently programmed in the system. DISPLAY EVENTS Allows you to view the last 2,000 system events that occurred on your system. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide...
-
Page 17: Accessing The User Menu
Press the COMMAND key until MENU? NO YES displays. Select YES. The keypad displays ENTER CODE. Enter your user code and press COMMAND. You can now scroll down through the list of system features available to you. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 18: Alarm Silence
Access the User Menu. The keypad displays ALARM SILENCE?. Press any Select Key to silence the bells and exit the User Menu. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 19: Sensor Reset
Select RESET on the carousel menu. If using a 630F Remote Annunciator, press the RESET button on the left side of the keypad. The keypad displays SENSORS OFF for five seconds followed by SENSORS ON. The keypad automatically exits the User Menu. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 20: Outputs On/Off
Select the type of output you want to turn ON or OFF by pressing the Select Key under OUTPUTS. Enter the output number you want to turn ON or OFF. The output number displays. The range for outputs is 1-6, 500-999. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... - Page 21 Press the COMMAND key to end the four second display. The system automatically returns to the output prompt to allow you to select a new output to turn ON or OFF. Refer back to step 4. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc.
-
Page 22: System Status
These are followed by either OKAY or TRBL (trouble). If TRBL displays, call the service department for assistance. The system then displays its firmware version, the panel model, and then exits the User Menu. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 23: System Test
TEST END to indicate the System Test is complete You can press the Back Arrow key to end the transmit test * The transmit test does not occur on local systems. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 24: User Codes
Master Each code may also be programmed authority from your system. with the user name. You may enter up to 32 characters for the name. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... - Page 25 Enter the new name and press COMMAND. At the PROFILE display, press a select area and then select MASTER or STANDARD. Press COMMAND. The displays shows USER # ADDED. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc.
- Page 26 At the USER NUMBER prompt, enter the user number you want to delete and press COMMAND. The display changes to USER # DELETED. The display then changes back to USER NUMBER allowing you to delete another user. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide...
- Page 27 After entering the profile, the keypad displays USER # CHANGED for 5 seconds followed by USER NUMBER. This display allows you to change another user code. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc.
-
Page 28: Setting The Date And Time
SUN MON TUE WED. Press the COMMAND key to display THU FRI SAT. Press the Select Key under the correct day. Use the Back Arrow key to toggle between the different day of the week displays. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... - Page 29 Enter up to 2 digits for the year. Press CMD. The display returns to the TIME DAY DATE display. Press the Back Arrow key to exit the User Menu. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc.
-
Page 30: Display Events
While in the Display Events function, use the COMMAND and Back Arrow keys to navigate through the list of events. To view more information about each display, press the Select Key as directed in the explanations. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... - Page 31 FRST DATE: 8/21. Press any Select Key and enter a 4-digit beginning date for the sort. Press COMMAND. The keypad displays LAST DATE: 10/17. Press any Select Key and enter a 4-digit ending date for the sort. Press COMMAND. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc.
- Page 32 After the last event type displays, the keypad again displays FRST LST PRT SRT. You can now view or print the sorted Display Events or press SRT to define a new sort. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide...
-
Page 33: Service Request
Select key when SERVICE REQUEST? displays and have the system send a “Request for Service” message to the central station. The REQUEST MADE display confirms your request was sent. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. -
Page 34: Fire Drill
Enter your code at the keypad and press COMMAND to end the Fire Drill. The Fire Drill test automatically ends with ALARM SILENCE or the programmed Bell Cutoff time. Digital Monitoring Products, Inc. XF6 Series Fire Control Panel User Guide... -
Page 35: Common Keypad Displays
There is a ground fault on the system. Check the system for a grounded TROUBLE connection. Disconnect one circuit at a time and read the resistance between the circuit and ground with an Ohmmeter. XF6 Series Fire Control Panel User Guide Digital Monitoring Products, Inc. - Page 36 Information furnished is believed to be accurate and reliable. This information is subject to change without notice.
- Page 37 I N T R U S I O N • F I R E • A C C E S S • N E T W O R K S DESIGNED, ENGINEERED, AND MANUFACTURED IN SPRINGFIELD, MISSOURI USING U.S. AND GLOBAL COMPONENTS. DMP.COM | LT-2792 | 23462...
