- Page 1 USER MANUAL AT-07L IP INDOOR VIDEO ENTRY PHONE...
- Page 2 Main features Display: 7” IPS LCD, capacitive touchscreen. Screen resolution: 1024 x 600. Built-in camera: No. Power: PoE and + 12 Volts. Power consumption: 6 W, standby 2.5 W. Dimensions: 236 x 128 x 26,5 mm. Colors: Black, White, Gold. Body: Aluminum.
-
Page 3: Electrical Connection
EAN: 5060514913567 (BLACK) EAN: 5060514913574 (GOLD) EAN: 5060514913550 (WHITE) Completness check of the product Before installing the monitor, be sure to check that it is complete and all components are available. The monitor kit includes: Monitor 1 pc Wall / flush mounting bracket... -
Page 4: Mechanical Mounting
Mechanical mounting Before mounting the monitor, a hole or recess in the wall with dimensions of 222 × 114 x 60 mm (for flush mounting) must be provided. It is necessary for switching of wires and installation of the monitor. Attach the bracket in the outlet box using set screws and a phillips head screwdriver. -
Page 5: Warranty Conditions
EAN: 5060514913567 (BLACK) EAN: 5060514913574 (GOLD) EAN: 5060514913550 (WHITE) Warranty The warranty card number Model name Serial number Seller name With following stated terms of warranty is familiar, functional test was performed in my presence: Customer signature Warranty conditions The warranty period of the product — 36 (thirty-six) months from the date of sale. - Page 6 Notes...
- Page 7 EAN: 5060514913567 (BLACK) EAN: 5060514913574 (GOLD) EAN: 5060514913550 (WHITE) Notes...
- Page 8 www.bas-ip.com...
