quickstart guide
AT-10
IP INDOOR VIDEO ENTRY PHONE
10" IP indoor video entry phone with IPS screen, Wi-Fi, resolution
1280x800 and the ability to connect alarm sensors.
The indoor video entry phone works on the Android 6.0 operating
system.
It comes in 3 color variations: White, Gold, Black and has two installation
options: wall mount and flush mount, using a special bracket.
4
Microphone
Full User Manual
1
Camera
2
Loudspeaker
3
Screen
5
MicroSD slot
6
MicroUSB port
wiki.bas-ip.com
Advertisement
Table of Contents
Related Manuals for basIP AT-10
Summary of Contents for basIP AT-10
- Page 1 AT-10 IP INDOOR VIDEO ENTRY PHONE Full User Manual 10" IP indoor video entry phone with IPS screen, Wi-Fi, resolution 1280x800 and the ability to connect alarm sensors. The indoor video entry phone works on the Android 6.0 operating system.
-
Page 2: Main Screen
Main screen An indoor video phone (monitor) home screen consists of the main desktop and 2 additional (by default). In addition, you can add an unlimited number of custom desktops and flexibly configure them (set the number of application icons and their layout). - Page 3 Adding a new desktop and apps How to change an application on the main desktop You can change the main sections of the monitor menu (calls, messages, entrance panel monitoring menu, IP camera viewing menu) into any other app. To do this you must: •...
-
Page 4: Navigation Bar
Navigation bar The navigation bar is used for quick access to some features. To open the bar, you need to swipe down at the top of the screen or press any empty space. In the bar, you have access to the following features: concierge quick call Concierge quick call to specified number of concierge, another monitor, or SIP... - Page 5 Call menu Call menu On the main desktop, next to the call icon, you can check the number of missed calls. When the Motion detection feature is enabled, missed calls are displayed in the right corner of the call icon, and notifications of videos recorded when motion sensors are triggered are displayed in the left corner.
-
Page 6: Call Display
Call display During the incoming call, the following screen will be displayed this screen. Icons meaning: • - to answer a call; • - to decline a call/end a conversation; • - to open the keyboard; • - to open the lock/s; •... -
Page 7: Number Formats
Number formats: An inner number of a multi-apartment An inner number of an individual panel consists of Building No., Unit No., Floor No., panel consists of Building No., Unit No., and Device No. For example, 0001-01-1 Apartment No., and Device No. For example, 0001-01-02-04-1 is the number of the first is the number of the panel located in the 1st unit of building No. - Page 8 You also have several additional options: • to add the contact to favorites and it will be displayed at the top of the list; • to add the contact to the blacklist and not receive notifications about calls from this contact (but a call will be displayed as missed in the list);...
- Page 9 Devices This menu displays additional monitors that have the same logical address, but different device numbers. If you press the button in the upper left corner near the device, the menu for editing the name will be displayed. In the new window, you can enter the name of the additional monitor you want to display.
-
Page 10: Messages Menu
Messages menu This menu displays messages received from the concierge or management company (via the Link). When a message is got, you will hear a notification sound and when unlocking the screen, the counter above the application icon will change. If you go to the Messages menu, the following interface will be displayed: You can select showing all messages, only new or read ones at the top of the screen. -
Page 11: Monitoring Menu
Monitoring menu In this menu, you can monitor the cameras of the entrance panels. When you save an entrance panel to contacts and enable the Use as default camera option, an image from this panel will be displayed first in this menu. If you have several individual and multi-apartment panels and by default, you need to connect to one of them, then the Use as default camera option must be enabled only for this panel. - Page 12 IP cameras viewing menu In this menu, you can view streams from IP cameras. Adding IP cameras or changing their settings is possible in the web interface or monitor settings. Icons meaning: • - start stream display; • - pause stream display. To select another camera display, press the name of the current one and select the required from the list.
-
Page 13: Security Menu
Security menu In the menu, you can enable/disable previously configured alarm scenes. There are 3 available scenes (Out, Home, Sleep) for various occasions. In the monitor settings or web interface, you can enable sensors for each scene, and when the active scene sensor is triggered, the alarm will turn on. Services menu This menu displays icons that open links in the built-in browser. -
Page 14: Monitor Settings Menu
Monitor settings menu You can configure the monitor using the corresponding menu, which can be accessed by swiping down or tapping a place at the top of the main screen. After opening the navigation bar, go to the Settings menu. There is access to general and advanced settings of the network, security, automation, IP cameras, etc. -
Page 15: Intercom Settings
How to configure the Silence mode Silence mode turns off all sounds (except the alarm), but incoming calls will be displayed on the screen. In this tab or in the web interface, you can enable the feature in advance for a specified period of time. - Page 16 Address For correct device functioning, you must enter information about its logical address. The logical address is used to automatically synchronize and search for other devices in the network and is also necessary to provide a connection between them (more information about logical address formation find here).
-
Page 17: Network Settings
DTMF In the menu, you can change the DTMF code, entering which the lock will be opened. Code length is up to 4 characters. In the section you can configure: • Lock #1 name that is displayed during a call. •... - Page 18 Ethernet In this section, you can enable/disable DHCP connection and get network settings automatically or enter it manually. For correct monitor work you must enter: • panel IP address; • subnet mask; • the main gateway; • DNS server address; Here you also can check the current IP By default, a device can have a static IP address of 192.168.1.90 or 192.168.1.91.
-
Page 19: Security Settings
MQTT protocol configuration If you select MQTT, you must enter: • Management system broker address and port for server field. • Password for interaction with the management system. Also, you can enable / disable a secured connection. Sending of heartbeat (current status: online/offline) is done by default here without the ability to enable/disable it. - Page 20 Alarm zones setting You can connect 8 alarm sensors to the monitor. The number of sensors can be increased up to 16 using the SH-16 module. This menu allows you to specify pecularities and configure the operation of each sensor separately. The table with sensor settings consists of the following parameters: •...
-
Page 21: Motion Detection
Motion detection Motion detection is the feature of recording video from the specified camera when the motion sensor is triggered. You can enable / disable and configure the feature in this section and in the web interface. The feature requires connected motion sensors (up to 4) and an SD card. -
Page 22: Admin Password
Admin password In this section, you can change the administrator password that is used to enter the web interface and monitor settings. To do it: • Enter the current (previous) password. • Create a new password and enter it in the appropriate field. -
Page 23: Smart Settings
Smart settings In the menu, you can configure home automation services for Rooms and Lights. Rooms In this section, you can configure the rooms for displaying in the home automation control menu. Warning! The adding rooms feature is only available on the main monitor (with 0 device number). -
Page 24: Call Ringtone
Call ringtone Here you select a ringtone for an incoming call. You can select a ringtone from the list of standard ones or from the monitor file system or SD card. Theme In this section, you can select a theme that is displayed behind all the icons on the monitor screen. -
Page 25: Screen Saver
Announcement When setting the standby mode, you can enable/disable the display of announcements or ads in the mode. For the feature to work, you must: • Enable an announcement display. • Enter a link to the announcement (it can be either an RTSP stream or a web page). •... -
Page 26: Service References
Service references In this menu, you can enter links that will be opened by pressing the corresponding buttons in the Services menu. Weather The monitor supports several different widgets. One of them is the weather widget, the setting of which consists of: •... -
Page 27: Firmware Updates
<li>Added the ability to replace default apps with custom apps on the main screen</li> <li>Added API endpoint that provides information about read/unread announcements</li> <li>Fixed images displaying in announcement on AT-10</li> <li>Fixed recording video bug during incoming SIP call</li> <li>Fixed a bug that occurred when trailing slash was used in Link server address</li>... -
Page 28: System Settings Menu
How to install an update from an SD card Also, you can update firmware via the web interface and SD card. For that you need: • Download the required firmware from the webpage to one of the folders on the SD card. •...
