MOTORIZED SMART UNDER DESK
BIKE FOR LEGS AND ARMS
SF-B0960 SMART
USER MANUAL
DO NOT STAND ON THE UNIT!
IMPORTANT! Please retain owner's manual for maintenance and adjustment instructions.
Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE
CONTACTED US: support@sunnyhealthfitness.com or 1- 877 - 90SUNNY (877-907-8669).
0

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SF-B0960 SMART and is the answer not in the manual?

Questions and answers

Related Manuals for Sunny SF-B0960 SMART

Summary of Contents for Sunny SF-B0960 SMART

  • Page 1 MOTORIZED SMART UNDER DESK BIKE FOR LEGS AND ARMS SF-B0960 SMART USER MANUAL DO NOT STAND ON THE UNIT! IMPORTANT! Please retain owner’s manual for maintenance and adjustment instructions. Your satisfaction is very important to us, PLEASE DO NOT RETURN UNTIL YOU HAVE...

  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION Thank you for purchasing the Motorized Smart Under Desk Bike For Legs And Arms. Please read the operating instructions carefully before use, especially the safety precautions. When using an electrical appliance, basic precautions should always be followed, including the following: Read all instructions before using this appliance.
  • Page 3 PRE-ASSEMBLY CHECK LIS 11-1 7L/R HARDWARE PACKAGE SF-B0960/SF-B0960 SMART STEP2 STEP1 #18 M6*16 3PCS #14 M8*42 2PCS #17 M8 2PCS #15 ID8.2*OD16*1.5 2PCS #39 S13-S14-S15 1PC #40 S17-S19 1PC Description Spec. Qty. Description Spec. Qty. Main Frame Rear Fixed Bottom Plate...

  • Page 4: Hardware Package

    HARDWARE PACKAGE #14 M8*42 2PCS #17 M8 2PCS #39 S13-S14-S15 1PC #18 M6*16 3PCS #15 ID8.2*OD16*1.5 2PCS #40 S17-S19 1PC Ordering Replacement Parts (U.S. and Canadian Customers only) Please provide the following information in order for us to accurately identify the part(s) needed: ...
  • Page 5 ASSEMBLY INSTRUCTIONS We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 1: #18 M6*16 3PCS Attach Rear Fixed Bottom Plate (No. 19) to the Main Frame (No.
  • Page 6 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 3: NOTE: The Left & Right Pedals (No. 7L & No. 7R) are marked “L” and “R” for Left and #21R 1/2"-20 1PC...
  • Page 7 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 4: 41-1 7L-1 41-1 Insert the fixing hole (#A) of the Pedal Strap (#41-1) into the card slot (#7L-1) of the Left Pedal (#7L).
  • Page 8 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 5: 41-1 41-1 Insert the fixing hole (#A) of the Pedal Strap (#41-1) into the card slot (#7R-1) of the Right Pedal (#7R).
  • Page 9 We value your experience using Sunny Health and Fitness products. For assistance with parts or troubleshooting, please contact us at support@sunnyhealthfitness.com or 1-877-90SUNNY (877- 907-8669). STEP 6: Plug the Power Cord (No. 4) into the Outlet (No. 13) on the Main Frame (No.

  • Page 10: Important Electrical Information

    IMPORTANT ELECTRICAL INFORMATION WARNING: This cycle requires a power source of 120V in order to properly operate. For your safety as well as the safety of others, please verify that the power source is correct before powering in the equipment. Any power supply source above or below this level could cause significant damage to the equipment and/or user.

  • Page 11: Battery Installation And Replacement

    BATTERY INSTALLATION & REPLACEMENT BATTERY INSTALLATION: 1. Press point a with a pen or other something sharp, then push down the battery cover on the back of the Remote Control (No. 11-1) to remove the battery cover.(as shown by the arrow b) 2.

  • Page 12: Display Console

    DISPLAY CONSOLE BLUETOOTH 1. The Bluetooth icon will flash when the console is on. If no Bluetooth connection is established within 3 minutes, the Bluetooth icon will turn off. 2. The Bluetooth icon will stay on when it is connected. WIRELESS HEART RATE 1.

  • Page 13: Function Keys

    FUNCTION KEYS Start/Pause Start and pause bike Mode Changes between automatic and manual Direction Changes the direction forward or backward Speed+/- Select key for increasing or decreasing speed (18 speed levels) WARNINGS AND INSTRUCTIONS  Do not stand on the bike. Only use while seated in a chair. ...
  • Page 14 OPERATING INSTRUCTIONS 1. Plug in the Power Cable (No. 4). Turn on the Power Switch (No. 5). The bike will beep and LED display will show “OFF“. This is standby mode. 2. Press the Start/Pause button on the console or the remote control to start the bike, it will begin in manual mode.
  • Page 15 P1 MODE ： Based on speed Level 1, the pedals move 13 times forward, 13 times backwards, 13 times forward based, 13 times backwards and so on. P2 MODE: The pedals move forward first then the speed will be increasing from Level 1 to Level 9 gradually.
  • Page 16 DISPLAY REMOTE CONTROL FUNCTION KEYS Start/Pause: Start and pause machine Mode: Changes between automatic and manual Direction: Changes the direction forward or backward Speed: Select+ key for increasing or -key for decreasing speed (18 speed levels) Pause REMOTE CONTROL NOTICE: If the Remote Control (No.
  • Page 17 1. Restart the Motorized Smart Under Desk Bike for Legs and Arms, press and hold down the Mode button and Direction button at the same time, you will hear three “beep” sounds. 2. Press and hold down the Mode button on the Remote Control (No. 11-1) immediately for about 3 seconds.

  • Page 18: User-Maintenance Instruction

    USER-MAINTENANCE INSTRUCTION Caution：There are no serviceable parts in the appliance, any servicing should be performed by an authorized service person. When the appliance is not in use, disconnect the power supply, storage of the power cord and the total appliance in a dry location where children cannot touch or in play area(s). WARNING The machine is intended to use in a sitting position only.

  • Page 19: App Connection

    APP CONNECTION: Connect Smart Equipment to SunnyFit App: 1. Scan to download SunnyFit from the app store: 2. Ensure that the Bluetooth function is turned on from your mobile device. 3. If this is your first time using the SunnyFit app, follow the in-app instructions to register for your free SunnyFit account and log in.

  • Page 20: Parts List

    PARTS LIST Description Spec. Description Spec. Main Frame Left Nylon Nut 1/2”-20 Front Stabilizer Right Nylon Nut 1/2”-20 Left Crank Screw ST3.5*15 Right Crank Non-Slip Pad Power Cord Screw ST4.2*15 Power Switch Flange Nut Rubber Pad End Cap Left Pedal Spring Washer Φ2.2*Φ3.4*0.8 Right Pedal...

  • Page 21: Exploded Diagram

    EXPLODED DIAGRAM 41-1 11-1 41-1 Version 1.2...
