- Page 1 LITHIUM-ION GAUGE STRAIGHT SHEAR TSSLI20308,TSSLI203083,TSSLI203083E,TSSLI203083X,TSSLI203083-X, TSSLI203083S,TSSLI203083H,TSSLI203083M,TSSLI203083A UTSSLI203083,UTSSLI203083X,UTSSLI203083-X (X stands for 1 to 9) SCAN FOR VIDEO 150+ SAME BATTERY TOOLS TOTAL TOOLS WORLD...
- Page 2 Original Instructions Double insulated for additional protection. Read the instruction manual before using. CE conformity. Wear safety glasses, hearing protection and dust mask. Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or retailer for recycling advice.
- Page 3 GENERAL POWER TOOL SAFETY WARNINGS WARNING Read all safety warnings, instructions, illustrations and specifications provided with this power tool. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference. The term "power tool"...
- Page 4 3) Personal safety a) Stay alert, watch what you are doing and use common sense when operating a power tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or medication. A moment of inattention while operating power tools may result in serious personal injury.
- Page 5 c) Disconnect the plug from the power source and/or remove the battery pack, if detachable, from the power tool before making any adjustments, changing accessories, or storing power tools. Such preventive safety measures reduce the risk of starting the power tool accidentally. d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with the power tool or these instructions to operate the power tool.
- Page 6 like paper clips, coins, keys, nails, screws or other small metal objects, that can make a connection from one terminal to another. Shorting the battery terminals together may cause burns or a fire. d) Under abusive conditions, liquid may be ejected from the battery; avoid contact.
-
Page 7: Packing List
Precautions: when using pruning shears, please ensure that and other human body parts are not within the working scope of the blade. The operator shall be responsible for the damage caused by the operator's violation of the cautions. Packing List Included in the case: Gauge Straight Shear Product Overview... -
Page 8: Product Operation
Product Description This product is a battery-driven electric pruning shear, comprises a blade, a movable blade, lithium battery, battery charger, work vest, tool and other components. designed for cutting or trimming 30mm or less branches in fruit or orchards, vineyards, etc. Simple and easy to operate, it also has 8-10 times the ef of traditional manual pruners. - Page 9 5.Before operation , in order to see if the pruner performances well , please press the trigger to close and release the trigger to open the blades without cutting anything. Repeat this for a few times. 2 gear Level 1 Ø: 0-30mm Level 2 Ø: Brushless...
-
Page 10: Operation Precautions
Operation Precautions Usage and Care for Pruning Shear 1.Do not cut branches beyond the diameter indicated, do not cut hard items such as metals, stone or any other non-plant materials. If the blades are worn or damaged, please replace the blades. 2.Keep the pruning shear clean, use a clean cloth to clean the pruning shear, battery and charger(do not use any abrasive or solvent-based cleaning agent), use a soft brush or a dry to clean the dust off the pruning shear head. -
Page 11: Safety Notes
Safety Notes Warning! Please read all instructions carefully, not complying with instruction may lead Workplace Safety Keep work area clean and bright, messy and dimmed workplace may cause Keep CHILDREN and bystander away before operating the pruning shear to Electrical Safety Pruning shear battery socket must be compatible with the power cable plug, do not the pruning shear to rain, humid water or any other... - Page 12 1. In the event the pruning shear is not able to cut through an object, released the trigger immediately and the moving blade will return to its open position automatically. 2. In the event the pruning shear is cutting through a branch of particularly hardness, released the trigger immediately and the moving blade will return to its open position automatically.
- Page 13 TSSLI20308,TSSLI203083,TSSLI203083E,TSSLI203083X,TSSLI203083-X, TSSLI203083S,TSSLI203083H,TSSLI203083M,TSSLI203083A UTSSLI203083,UTSSLI203083X,UTSSLI203083-X (X stands for 1 to 9) Exploded view...
- Page 14 TSSLI20308,TSSLI203083,TSSLI203083E,TSSLI203083X,TSSLI203083-X, TSSLI203083S,TSSLI203083H,TSSLI203083M,TSSLI203083A UTSSLI203083,UTSSLI203083X,UTSSLI203083-X (X stands for 1 to 9) Spare part list Part Description Left/right casing Swing gear shaft 30A swing gear Swing tooth magnet Moving blade Fixed blade Circlip 30mm motor reducer Hexagon nut Buckle Hexagon socket bolt Body electrode base Control board Switch display panel Hall plate...
- Page 15 LITHIUM-ION GAUGE STRAIGHT SHEAR www.totalbusiness.com TOTAL TOOLS CO., PTE. LTD. No. 45 Songbei Road , Suzhou Industrial Park , China. MADE IN CHINA T0722.V02...
