StyleWell 8332015HD Assembly Instruction Manual

25" closet tower with drawers & doors
Hide thumbs

Advertisement

Quick Links

Download this manual
ASSEMBLY INSTRUCTIONS GUIDE
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
25" CLOSET TOWER
WITH DRAWERS & DOORS
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number: 1-877-527-0313
needs. Thank you for choosing StyleWell!
ITEM# xxxxxxxxxx
ITEM# xxxxxxxxxx
ITEM# xxxxxxxxxx
ITEM# xxxxxxxxxx
HOMEDEPOT.COM
THANK YOU
MODEL# 8332015HD
MODEL# 8332341HD
MODEL# 8332342HD
MODEL# 8332356HD

Advertisement

loading
Need help?

Need help?

Do you have a question about the 8332015HD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for StyleWell 8332015HD

Summary of Contents for StyleWell 8332015HD

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...

  • Page 2: Pre-Assembly

    Pre-assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer screwdriver HARDWARE INCLUDED...
  • Page 3 Pre-assembly PLANNING ASSEMBLY ITEM# xxxxxxxxxx MODEL# 8332015HD Part Description Quantity Part Number Code A23030 CONFIRMAT QUICKLOC, WHITE A22770 A21670 DOWEL WOOD 6MM X 30 MM ADJUSTABLE GLIDE 1/4"-20X32 A43020 1/4-20 PROPELL NUT P14208F10 A20330 A80250 SHELF SUPPORT A84050 WALL ANCHOR KIT...
  • Page 4 Pre-assembly PLANNING ASSEMBLY ITEM# xxxxxxxxxx MODEL# 8332342HD Part Description Quantity Part Number Code A23030 CONFIRMAT QUICKLOC, WHITE A22770 * NOTE:- THIS UNIT USE QUICKLOC, BROWN A22761 A27761 - BROWN QUICKLOC FOR CABINET & A21670 DOWEL WOOD 6MM X 30 MM A22770- WHITE QUICKLOC ADJUSTABLE GLIDE 1/4"-20X32 A43020...

  • Page 5: Package Contents

    Pre-assembly (continued) PACKAGE CONTENTS ITEM# xxxxxxxxxx MODEL# 8332015HD ITEM# xxxxxxxxxx MODEL# 8332341HD Part Part Description Description Part Number Part Number Code Code 35607015010 LEFT PANEL LOWER 35607341010 LEFT PANEL LOWER 35607015020 RIGHT PANEL LOWER 35607341020 RIGHT PANEL LOWER 32959015030 LEFT PANEL UPPER...
  • Page 6 Pre-assembly (continued) PACKAGE CONTENTS HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 7 Pre-assembly (continued) PACKAGE CONTENTS RIGHT LEFT SIDE SIDE BACK HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 8 Disassembling slides (A56900): Extend each section as shown. Press the black lever upward and separate the two parts of the slide. Lever Outer slide section will attach to the Left Side (A) and Right Side (B). Use holes marked with arrows to fasten. Inner slide section will attach to the drawer sides.
  • Page 9 Disassembling Hinge (A65700): Separate hinges by depressing the end of the hinge and removing the hinge plate from the hinge arm. Press to release hinge plate. Hinge plate HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 10 Assembly Arrange Left Panel (A) and Right Panel (B) as shown. In the unfinished edge, insert the nuts (5) into the holes with a hammer. Thread adjustable leveling feet into the nuts. 4 - x4 2 - x6 5 - x4 Insert quicklocs as shown.
  • Page 11 Assembly Arrange the Left Panel (C) and the Right Panel (D) as shown. In the unfinished edge, insert wood dowels as shown. Insert quicklocs as shown. 2 - x4 3 - x4 18 - x4 Lightly tap with hammer if necessary. Assemble hinge plate (18).
  • Page 12 Assembly Insert wood dowels and quicklocs into Bottom (F) as shown. Lightly tap with hammer if necessary. Note:Quickloc must be pressed 2 -x6 all the way into the hole. F - x1 Note: Edge of quickloc to be flush with edge of the board.
  • Page 13 Assembly Insert wood dowels and quicklocs into Back Panels (K & L) as shown. Lightly tap with hammer if necessary. 2 - x14 3 - x4 Note:Quickloc must be pressed all the way into the hole. Note: Edge of quickloc to be flush with edge of the board.
  • Page 14 Assembly Connect Back Panels (L) together by inserting dowels into the mating panel. Connect Back Panels (K) together by inserting dowel into the mating panel. Note: Take care not to bend or twist assembled Back Panels when moving. Insert quicklocs into Apron (I) as shown. Lightly tap with hammer if necessary.
  • Page 15 Assembly Connect Bottom (F) to Left Panel (A) by inserting quicklocs as shown. Turn two quickloc screws clockwise to lock in place. finished edge Lock Inlist a helper and carefully lift both Back Panels (K) together, insert quicklocs as shown. Turn four quickloc screws clockwise to lock in place. Lock HOMEDEPOT.COM : # 1-877-5270313...
  • Page 16 Assembly Attach Right Panel (B) by carefully inserting quicklocs as shown. Turn six quickloc screws clockwise to lock in place. finished edge Lock Attach Kick (J) to Left Panel (A) and Right Panel (B) by inserting quicklocs as shown. Turn four quickloc screws clockwise to lock in place. Lock HOMEDEPOT.COM : # 1-877-5270313...
  • Page 17 Assembly Attach Apron (I) to Top (E) by inserting quicklocs as shown. Turn two quickloc screws clockwise to lock in place. finished edge Lock Insert quicklocs into Fixed Shelf (N) as shown. Lightly tap with a hammer if necessary. 2 - x4 HOMEDEPOT.COM : # 1-877-5270313 Please contact...
  • Page 18 Assembly Attach Fixed Sheld (N) to Left Panel (C) by inserting the quicklocs as shown. Turn two quickloc screws clockwise to lock in place. finished edge finished edge Lock Inlist a helper and carefully move both Back Panels (L) into place. Attach Left Panel (C) and Right Panel (D) as shown by inserting quicklocs as shown.
  • Page 19 Assembly While your helper holds the Left Panel (C) and Right Panel (D) upright, attach Middle Shelf (G) using two screws. finished edge 1 - x2 finished edge Attach Top (E) to Left Panel (C) and Right Panel (D) by inserting quicklocs as shown.
  • Page 20 Assembly With a helper attach the bottom unit to the top unit by inserting quicklocs as shown. Turn four quickloc screws clockwise to lock in place. Lock HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 21 Assembly Warning All units MUST be fastened to the wall. Place unit inside closet (allow 30" to 48" on each side for clothing rod). Use a level and adjust adjustable leveling feet to be sure it is square. Place L-bracket on top of the unit with bracket screw using existing hole location. Mark hole location on wall.
  • Page 22 Assembly Position the Left Drawer Side and Right RIGHT DWR LEFT DWR Drawer Side as shown. 2 - x12 SIDE- x3 SIDE- x3 Insert two quicklocs (2) into each Drawer Side as shown. Note: Edge of quickloc to be flush with RIGHT edge of the board.
  • Page 23 Assembly Make sure the orientation of the parts are as LEFT DWR RIGHT DWR DRAWER shown (Grove towards bottom). SIDE- x3 BACK - x3 SIDE- x3 Engage the quicklocs on Drawer back to the Left and Right Drawer sides. Turn the screws on quicklocs (2) clockwise to lock in place.
  • Page 24 Assembly Engage the quicklocs on Left and Right Drawer side into the the Drawer front. Z- x3 Turn the screw on quicklocs clockwise to lock in place. SIDE BACK SIDE Lock Install the Inner slide using Screw (14) as shown. Refer page 5 for Slide disassembly details.
  • Page 25 Assembly Engage the inner slides (17b) of the drawer with the outer slide (17a), and then push firmly in. HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 26 Assembly Insert four shelf supports (6) into the desired locations in the Left & Right Panel (C & D). Ensure that each is positioned so that both the left and right shelf supports are evenly placed. Insert the Adjustable Shelf (H) in the unit. 6 - x4 H - x1 HOMEDEPOT.COM...
  • Page 27 Assembly Assemble the hinges (18), the handle (16) and door bumpers (19) to each Door (O). 20 - x4 16 - x2 18 - x4 19 - x4 O - x4 HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 28 Assembly Assemble the two Doors (O) to the Left & Right Panels (C & D). HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 29 Assembly Information on Door Adjustment (if needed). Remove cover to adjust hinge To adjust the vertical height: Loosen the screws "A" on both hinges. They are usually in slotted holes which allows you to adjust up or down by a few mm.
  • Page 30 Assembly Choose "double hang" and "single hang" side. If the pre-drilled hole locations are not suitable for your needs, you can mark and drill pilot holes at your desired location. Please use a 1/16" drill bit and be careful not to drill too deep. Double hanging rod: We suggest placing top rod at 77"...
  • Page 31 Assembly Secure each Adjustable Rod with two screws. 9 - x6 11 - x3 HOMEDEPOT.COM : # 1-877-5270313 Please contact for further assistance.
  • Page 32 Assembly Extend rod to the wall and hold in place. Be sure rod is level and mark hole locations on wall. Repeat for all bracket locations. Screw in wall anchors at marked locations and secure each rod to the wall with screws. 8 - x6 10 - x6 wall...

  • Page 33: Maximum Loads

    Maximum Loads This unit has been designed to support the maximum loads shown. Exceeding these load limits could cause sagging, instability, product collapse, and/or serious injury. 10 lbs 4.5 kg 25 lbs 11.3 kg adj shelf 30 lbs 13.6 kg 50 lbs fixed shelf 22.6 kg...
  • Page 34 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday PHONE NUMBER 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. HOMEDEPOT.COM...
