ITEM# xxxx
MODEL# 8167015HD
ASSEMBLY INSTRUCTIONS GUIDE
25in Stacker - 3 Shelf
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number: 1-800-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing StyleWell!
Advertisement
Related Manuals for StyleWell Stacker 8167015HD
Summary of Contents for StyleWell Stacker 8167015HD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
- Page 2 Pre-assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer Drill &...
- Page 3 Pre-assembly (continued) PACKAGE CONTENTS ITEM # xxxx / MODEL #8167015HD Part Description Quantity Part Number Code 38167015010 LEFT PANEL 38167015020 RIGHT PANEL 38167015030 38167015040 BOTTOM 38167015050 ADJUSTABLE SHELF 38167015060 LEFT BACK 38167015070 RIGHT BACK HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 4 Assembly Arrange the Left Panel (A) and Right Panel (B) as shown. In the unfinished drilled edge, insert the nuts into the LARGER holes with a hammer. Thread adjustable leveling feet into the nuts. A - x1 B - x1 Insert the connectors as shown.
- Page 5 Assembly Install the safety strap (7) to the Right Back (G). Do not fully tighten the screw in this step. Insert the connectors as shown. Be sure all connectors are fully seated and placed correctly. G - x1 F - x1 You may need to lightly tap connectors with a hammer to fully insert.
- Page 6 Assembly Assemble the Left Back (F) & Right Back (G) by inserting the connectors as shown. Turn three connectors clockwise to lock in place. Lock Install connectors into the Bottom (D). Be sure all connectors are fully seated and placed correctly. You may need to tap connector with a hammer to fully insert.
- Page 7 Assembly Assemble the Left Panel (A) to Left Back (F) by inserting the connectors as shown. Turn three connectors clockwise to lock in place. safety strap finished edge Lock Assemble the Bottom (D) to the Left Panel (A) by inserting the connectors and wood dowels as shown.
- Page 8 Assembly Assemble the Right Panel (B) by inserting the connectors as shown. Turn five connectors clockwise to lock in place. finished edge finished edge Lock HOMEDEPOT.COM : # 1-800-527-0313 Please contact for further assistance.
- Page 9 Assembly If you purchased an additional 25in Stacker - 3 Shelf unit, skip to step 12. If you only have one 25in Stacker - 3 Shelf unit continue to step 9. With the help of another person, carefully assemble the next step as shown. Assemble the Left Panel (A), Right Panel (B) and Back (F) to the Top (C) by inserting the connectors as shown.
- Page 10 Assembly Warning unit MUST be fastened to the wall. Use a level and adjust adjustable leveling feet to be sure it is square. OPTION 1: Attachment into a wall stud (preferred method) Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety strap aligned in this location.
- Page 11 Assembly Insert the shelf supports (6) into the Left & Right Panels (A & B) in the desired locations. Insert the Adjustable Shelf (E). 6 - x4 E - x1 finished edge HOMEDEPOT.COM : # 1-800-527-0313 Please contact for further assistance.
- Page 12 Assembly This step is for purchasing a second 25in Stacker - 3 Shelf unit and stacking it on top of the one that was just assembled. You will want to assemble the second unit the same, EXCEPT without placing the nut insert (4) and adjustable leveling feet (3).
- Page 13 Assembly Assemble the "first" unit assembly to its Top (C) by inserting the connectors as shown. Turn four connectors clockwise to lock in place. Carefully stand the unit upright with the help of another person. Turn two connectors clockwise to lock in place that is on the back of Left Back (F) &...
- Page 14 Assembly Warning unit MUST be fastened to the wall. Use a level and adjust adjustable leveling feet to be sure it is square. OPTION 1: Attachment into a wall stud (preferred method) Using a stud finder, locate a stud in the wall. Place your unit against the wall, with the safety strap aligned in this location.
- Page 15 Assembly Insert the shelf supports (6) into both of the Left & Right Panels (A & B) in the desired locations. Insert the two Adjustable Shelves (E). E - x2 6 - x8 HOMEDEPOT.COM : # 1-800-527-0313 Please contact for further assistance.
- Page 16 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday PHONE NUMBER - 1-800-527-0313 HOMEDEPOT.COM Retain this manual for future use.
