ASSEMBLY INSTRUCTIONS GUIDE
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
25" CLOSET TOWER
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number: 1-877-527-0313
needs. Thank you for choosing StyleWell!
ITEM# xxxx
ITEM# xxxx
ITEM# xxxx
HOMEDEPOT.COM
THANK YOU
MODEL# 8583015HD
MODEL# 8583341HD
MODEL# 8583342HD
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for StyleWell 8583015HD
Summary of Contents for StyleWell 8583015HD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
- Page 2 More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. ITEM# xxxx MODEL# 8583015HD Part Description Quantity Part Number Code A23030 CONFIRMAT ONEFIX CONNECTOR, WHITE...
- Page 3 Pre-assembly PLANNING ASSEMBLY ITEM# xxxx MODEL# 8583341HD Part Description Quantity Part Number Code A23030 CONFIRMAT ONEFIX CONNECTOR, CREAM A22832 A21670 DOWEL WOOD 6MM X 30 MM ADJUSTABLE GLIDE 1/4"-20X32 A43020 1/4-20 PROPELL NUT P14208F10 A20330 A80250 SHELF SUPPORT A84050 WALL ANCHOR KIT SCREW 8 X 1-1/4 PH PN, ZINC A13020 SCREW 8 X 7/8 PH PN, ZINC...
-
Page 4: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS ITEM# xxxx MODEL# 8583015HD PARTS LIST PART CODE PART NUMBER DESCRIPTION 38583015010 LEFT PANEL LOWER 38583015020 RIGHT PANEL LOWER 38583015030 LEFT PANEL UPPER 38583015040 RIGHT PANEL UPPER 38583015050 38583015060 BOTTOM 38583015070 MIDDLE SHELF 38583015080 ADJ SHELF... -
Page 5: Parts List
Pre-assembly (continued) PACKAGE CONTENTS ITEM# xxxx MODEL# 8583342HD PARTS LIST PART NUMBER PART CODE DESCRIPTION 38583342010 LEFT PANEL LOWER 38583342020 RIGHT PANEL LOWER 38583342030 LEFT PANEL UPPER 38583342040 RIGHT PANEL UPPER 38583342050 38583342060 BOTTOM 38583342070 MIDDLE SHELF 38583342080 ADJ SHELF 38583342090 APRON 38583342100... - Page 6 Pre-assembly (continued) PACKAGE CONTENTS ITEM# xxxx MODEL# 8583015HD ITEM# xxxx MODEL# 8583341HD ITEM# xxxx MODEL# 8583342HD HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 7 Assembly Arrange Left Panel (A) and Right Panel (B) as shown. In the unfinished edge, insert the nuts into the holes with a hammer. Thread adjustable leveling feet into the nuts. 4 - x4 2 - x6 3 - x4 Insert wood dowels and connectors as shown.
- Page 8 Assembly Arrange the Left Panel (C) and the Right Panel (D) as shown. In the unfinished edge, insert wood dowels as shown. Insert connectors as shown. 2 - x4 3 - x8 Lightly tap with hammer if necessary. C - x1 D - x1 Verify connector is fully seated and straight.
- Page 9 Assembly Insert wood dowels and connectors into Bottom (F) and Stringer (M) as shown. Lightly tap with hammer if necessary. 3 - x6 2 -x8 F - x1 Verify connector is fully seated and straight. M - x1 HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 10 Assembly Insert wood dowels and connectors into Back Panels (K & L) as shown. Lightly tap with hammer if necessary. 2 - x14 3 - x12 Verify connector is fully seated and straight. HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 11 Assembly Connect Back Panels (L) together by inserting dowels into the mating panel. Connect Back Panels (K) together by inserting dowel into the mating panel. Note: Take care not to bend or twist assembled Back Panels when moving. Insert dowel and connectors into Apron (I) as shown. Lightly tap with hammer if necessary.
- Page 12 Assembly Connect Bottom (F) and Stringer (M) to Left Panel (A) by inserting dowels and connectors as shown. Turn three connector screws clockwise to lock in place. finished edge Lock Inlist a helper and carefully lift both Back Panels (K) together and insert dowels and connectors as shown.
- Page 13 Assembly Attach Right Panel (B) by carefully inserting dowels and connectors as shown. Turn seven connector screws clockwise to lock in place. Lock finished edge Attach Kick (J) to Left Panel (A) and Right Panel (B) by inserting connectors as shown.
- Page 14 Assembly Attach Apron (I) to Top (E) by inserting dowel and connectors as shown. Turn two connector screws clockwise to lock in place. Lock finished edge Inlist a helper and carefully move both Back Panels (L) into place. Attach Left Panel (C) and Right Panel (D) as shown by inserting dowels and connectors as shown.
- Page 15 Assembly While your helper holds the Left Panel (C) and Right Panel (D) upright, attach Middle Shelf (G) using two screws. 1 - x2 finished edge Attach Top (E) to Left Panel (C) and Right Panel (D) by inserting dowels and connectors as shown.
- Page 16 Assembly With a helper attach the bottom unit to the top unit by inserting dowels and connectors as shown. Turn four connector screws clockwise to lock in place. Lock HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 17 Assembly Warning All units MUST be fastened to the wall. Place unit inside closet (allow 30" to 48" on each side for clothing rod). Use a level and adjust adjustable leveling feet to be sure it is square. Place L-bracket on top of the unit with bracket screw using existing hole location. Mark hole location on wall.
- Page 18 Assembly Insert Wire Rail (13) into holes in Adjustable Shelf (H). 13 - x4 H - x4 HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 19 Assembly Select the desired shelf heights and insert shelf supports into the Left and Right panels (A,B,C & D). Ensure that each is positioned so that both the left and right shelf supports are evenly placed. Insert Adjustable Shelf (H) into the unit. H - x4 6 - x8 12 - x8...
- Page 20 Assembly Choose "double hang" and "single hang" side. If the pre-drilled hole locations are not suitable for your needs, you can mark and drill pilot holes at your desired location. Please use a 1/16" drill bit and be careful not to drill too deep. Double hanging rod: We suggest placing top rod at 77"...
- Page 21 Assembly Secure each Adjustable Rod with two screws. 9 - x6 11 - x3 HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 22 Assembly Extend rod to the wall and hold in place. Be sure rod is level and mark hole locations on wall. Repeat for all bracket locations. Screw in wall anchors at marked locations and secure each rod to the wall with screws. 8 - x6 10 - x6 wall...
- Page 23 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday PHONE NUMBER 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. HOMEDEPOT.COM...
