USE AND CARE GUIDE
BUFFET WITH HUTCH
Questions, problems, missing parts?
Before returning to the store, call Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this buffet with hutch. We strive to continually create
quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank
you for choosing StyleWell!

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SK16949r2 and is the answer not in the manual?

Questions and answers

Summary of Contents for StyleWell SK16949r2

  • Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this buffet with hutch. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs. Thank...
  • Page 2: Table Of Contents

    Table of Contents   Table of Contents ............2   Tools Required .................4   Safety Information ............2   Hardware Included ..............4   Warranty ................. 3   Pre-assembly (continued) ..........5   1 Year Warranty ...............3   Package Contents ..............5  ...
  • Page 3: Warranty

    Warranty 1 YEAR WARRANTY WHAT IS COVERED We guarantee this product to be free of manufacturing defects to the original purchaser for one year. WHAT IS NOT COVERED This warranty does not cover commercial use, acts of nature, and abusive use. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 4: Pre-Assembly

    Pre-installation PLANNING INSTALLATION Keep children and pets away from build area, make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity...
  • Page 5: Pre-Assembly (Continued)

    Pre-installation (continued) PACKAGE CONTENTS Part Description Quantity Part Description Quantity Hutch top panel Hutch bottom back panel Hutch left side panel Buffet left side panel Hutch right side panel Buffet right side panel Hutch left divider Buffet left partition Hutch right divider Buffet right partition Hutch left fixed panel Buffet fixed panel...
  • Page 6: Assembly

    Assembly Attaching the magnet □ Attach magnet (GG) to partitions (P) and (Q) with screw (FF) as shown.
  • Page 7 Assembly (continued) Attaching the buffet fixed panel to buffet right partition □ □ a) Install dowel (AA) and bolt (BB) into partition (Q). c) Join panel (R) to the partition (Q) with dowel (AA). □ □ b) Insert lock (CC) into panel (R). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 8 Assembly (continued) Attaching the buffet left partition □ □ a) Install dowel (AA) and bolt (BB) into partition (P). c) Join partition (P) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panel (R). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 9 Assembly (continued) Joining the front cross bar to buffet both side panels □ Join bar (H) to the panels (N) and (O) with dowel (AA) as shown. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 10 Assembly (continued) Attaching buffet bottom panel □ □ a) Install dowel (AA) and bolt (BB) into panel (T). c) Join panel (T) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panels (N) and (O), and partitions d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 11 Assembly (continued) Attaching buffet top panel □ □ a) Install dowel (AA) and bolt (BB) into panel (K). c) Join panel (K) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panels (N) and (O), and partitions d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 12 Assembly (continued) Attaching the hutch dividers □ □ a) Install dowel (AA) and bolt (BB) into panel (J). c) Join dividers (D) and (E) to the panel (J) with dowel (AA). □ □ b) Insert lock (CC) into dividers (D) and (E). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 13 Assembly (continued) Attaching hutch left fixed panel and hutch right fixed panel □ □ a) Install dowel (AA) and bolt (BB) into dividers (E) and (D). c) Join panel (F) to the divider (D) with dowel (AA). Join panel (G) to the divider (E) with dowel (AA). □...
  • Page 14 Assembly (continued) Attaching hutch right side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (C). c) Join panel (C) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into panels (G) and (J), and bar (I). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 15 Assembly (continued) Attaching hutch left side panel and the front cross bar □ □ a) Install dowel (AA) and bolt (BB) into panel (B). c) Join panel (B) and bar (H) to the assembled body with dowel (AA). □ □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 16 Assembly (continued) Attaching hutch top panel □ □ a) Install dowel (AA) and bolt (BB) into panel (A). c) Join panel (A) to the assembled body with dowel (AA) . □ □ b) Insert lock (CC) into panels (B) and (C), and dividers (D) d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
  • Page 17 Assembly (continued) Assembling the hutch □ □ a) Install dowel (AA) and bolt (BB) into panel (K). c) Join panels (B) and (C) to the assembled body with dowel (AA). □ □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. b) Insert lock (CC) into panels (B) and (C).
  • Page 18 Assembly (continued) Assembling the back panel □ a) Install wire plug (LL) into panel (M) as shown. □ b) Tighten panels (L), (M), (W), and (X) to the assembled body with screws (FF) and metal plates (NN) as shown.
  • Page 19 Assembly (continued) Assembling the adjustable shelf □ Insert shelf supports (JJ) in desired positions and place shelf (S) on the supports. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 20 Assembly (continued) Attaching the door □ a) Attach left door (U) and right door (V) to the assembled body with screw (KK) as shown. NOTE: Metal plate needs to be to the top. □ b) Attach handle (HH) to door (U) and door (V) with the bolt (II). NOTE: A helper who can hold the door in position makes the door installation easier.
  • Page 21 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
  • Page 22 Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
