We appreciate the trust and confidence you have placed in StyleWell through the purchase of this kitchen storage cabinet. We strive to continually
create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
USE AND CARE GUIDE
KITCHEN STORAGE CABINET
Questions, problems, missing parts?
Before returning to the store, call Customer Service.
8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday
HOMEDEPOT.COM
Thank you for choosing StyleWell!
1-877-527-0313
THANK YOU
Item # 1004237615
Model # SK19311Ar1-V
Item # 1004237619
Model # SK19311Ar1-C
Item # 1004237620
Model # SK19311Ar1-B
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for StyleWell SK19311Ar1-B
Summary of Contents for StyleWell SK19311Ar1-B
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this kitchen storage cabinet. We strive to continually create quality products designed to enhance your home. Visit us online to see our full line of products available for your home improvement needs.
-
Page 2: Table Of Contents
Table of Contents Tools Required .................4 Table of Contents ............2 Safety Information ............2 Hardware Included ..............4 Warranty ................. 3 Pre-assembly (continued) ..........5 1 Year Warranty ...............3 Package Contents ..............5 ... -
Page 3: Warranty
Warranty 1 YEAR WARRANTY WHAT IS COVERED We guarantee this product to be free of manufacturing defects to the original purchaser for one year. WHAT IS NOT COVERED This warranty does not cover commercial use, acts of nature, and abusive use. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance. -
Page 4: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Keep children and pets away from build area. Make sure your area is large enough to unpack, sort and assemble the unit. TOOLS REQUIRED Large head Small head Phillips Phillips screwdriver screwdriver HARDWARE INCLUDED NOTE: Hardware not shown to actual size. Part Description Quantity... -
Page 5: Pre-Assembly (Continued)
Pre-assembly (continued) PACKAGE CONTENTS Part Description Quantity Part Quantity Description Bottom panel Hutch top panel Door Hutch side panel Top back panel Top crossbar Middle back panel Top fixed panel Bottom back panel Middle fixed panel Drawer front panel Partition Drawer left side panel Bottom left side panel Drawer right side panel... -
Page 6: Assembly
Assembly Attaching the hutch side panel to the top fixed panel □ □ a) Install dowel (AA) and bolt (BB) into panel (B). c) Join panel (B) to the panel (D) with dowel (AA). □ b) Insert lock (CC) into panel (D). □... - Page 7 Assembly (continued) Attaching the hutch side panel □ □ a) Install dowel (AA) and bolt (BB) into the panel (B). c) Join panel (B) to the panel (D) with dowel (AA). □ □ b) Insert lock (CC) into panel (D). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 8 Assembly (continued) Attaching the hutch top panel and top crossbar □ □ a) Join bar (C) to the panel (A) with dowel (AA). d) Join panel (A) to the assembled body with dowel (AA). □ b) Tighten bar (C) with screw (GG). Install dowel (AA) and bolt (BB) into panel (A).
- Page 9 Assembly (continued) Attaching the partition to the bottom fixed panel □ □ a) Install dowel (AA) and bolt (BB) into panel (J). c) Join partition (F) to the panel (J) with dowel (AA). □ □ b) Insert lock (CC) into partition (F). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 10 Assembly (continued) Attaching the bottom panel and bottom left side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (G). c) Join panels (J) and (L) to the panel (G) with dowel (AA). □ b) Insert lock (CC) into the panels (J) and (L). □...
- Page 11 Assembly (continued) Attaching the bottom right side panel □ □ a) Install dowel (AA) and bolt (BB) into panel (H). c) Join panel (H) to the assembled body with dowel (AA). □ □ b) Insert lock (CC) into the panels (J) and (L). d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes.
- Page 12 Assembly (continued) Attaching the middle fixed and bottom crossbar □ □ a) Join bar (I) to the panel (E) with dowel (AA). d) Join panel (E) to the assembled body with dowel(AA). □ b) Tighten bar (I) with screw (GG). Insert dowel (AA) and bolt (BB) into panel (E).
- Page 13 Assembly (continued) Attaching the hutch □ □ a) Install dowel (AA) and bolt (BB) into panel (E). c) Join panels (B) to the assembled body with dowel (AA). □ d) Tighten bolt (BB) with lock (CC) in the pre-drilled holes. □...
- Page 14 Assembly (continued) Attaching the back panel □ Tighten panels (N),(O) and (P) to the assembled body with screws (FF) and plates (NN) as shown.
- Page 15 Assembly (continued) Attaching the adjustable shelf □ Insert shelf supports (HH) in desired positions and place shelf (K) on the supports. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 16 Assembly (continued) Attaching the door □ a) Attach hinge (MM) to door (M) with screw (LL). □ b) Attach door (M) to the assembled body with screw (LL) as shown. Attach handle (II) to door (M) with the bolt (JJ). NOTE: A helper who can hold the door in position makes the door installation easier.
- Page 17 Assembly (continued) Assembling the drawer □ □ a) Tighten panels (R) and (S) to panel (Q) with screw (EE). c) Tighten panel (T) to the assembled body with screw (EE). □ d) Tighten knob (KK) to panel (Q) with bolt (JJ). □...
- Page 18 Assembly (continued) Inserting the drawer □ Insert the drawer into the assembled body as shown. NOTE: Make sure the slide piece is at the front end of the glide when installing the drawer into the body. SAFETY RELEASE TAB NOTE: When removing the drawer, tip-up the safety release tab to remove the drawer from the body.
- Page 19 Assembly (continued) Finalizing the assembly □ Install the anti-tipping hardware as shown. HOMEDEPOT.COM Please contact 1-877-527-0313 for further assistance.
- Page 20 Questions, problems, missing parts? Before returning to the store, call Customer Service 8 a.m. – 7 p.m., EST, Monday – Friday, 9 a.m. – 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use.
