ITEM# xxxx
MODEL# 8974015HD
ASSEMBLY INSTRUCTIONS GUIDE
SMALL 25" DRAWER
Questions, problems, missing parts?
Before returning to the store, call Customer Service
8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday
Phone Number:1-877-527-0313
HOMEDEPOT.COM
THANK YOU
We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually
create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement
needs. Thank you for choosing StyleWell!
Advertisement
Table of Contents
Related Manuals for StyleWell 8974015HD
Summary of Contents for StyleWell 8974015HD
- Page 1 THANK YOU We appreciate the trust and confidence you have placed in StyleWell through the purchase of this closet tower kit. We strive to continually create quality products designed to enhance your home.Visit us online to see our full line of products available for your home improvement...
-
Page 2: Pre-Assembly
Pre-assembly PLANNING ASSEMBLY Read all instructions before assembly. To avoid damaging this product, assemble it on a soft, non-abrasive surface such as carpet or cardboard. NOTE: More than one person may be required to assemble this product. TOOLS REQUIRED Phillips Claw hammer screwdriver HARDWARE INCLUDED... - Page 3 Disassembling slides (A56100): Extend each section as shown. Press the black lever upward and separate the two parts of the slide. Lever Front of unit Outer slide section will attach to the Left Side (A) and Right Side (B). Use holes marked with arrows to fasten. Inner slide section will attach to the drawer sides.
-
Page 4: Package Contents
Pre-assembly (continued) PACKAGE CONTENTS ITEM # xxxx / MODEL #8974015HD LEFT RIGHT BACK SIDE SIDE LEFT SIDE BACK RIGHT SIDE PARTS LIST ITEM PART NUMBER DESCRIPTION 38974015260 DRAWER FRONT ASSEMBLY 3999311334678L DRAWER LEFT SIDE 3999311334678R DRAWER RIGHT SIDE 3999311353873B DRAWER BACK... -
Page 5: Correct Orientation
Assembly Position the Left Drawer Side and Right Drawer Side as shown. Insert two connector (1) into each Drawer Side as shown. LEFT DWR RIGHT DWR 1 - x4 Insert one dowels (2) into each SIDE - x1 SIDE - x1 2 - x2 Drawer Side as shown. - Page 6 Assembly Make sure the orientation of the parts are as shown(Grove towards bottom) Engage the connector on Drawer back to the Left and Right Drawer sides. DRAWER Turn the screw on connector (1) clockwise to lock in place. BACK- x1 LEFT DWR RIGHT SIDE - x1...
- Page 7 Assembly Engage the connector on Left and Right Drawer side guided by the dowels to the the Drawer front Turn the screw on connector (1) clockwise to lock it in place. A - x1 RIGHT SIDE BACK LEFT SIDE HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 8 Assembly Install the Inner slide using Screw (3) as show. Refer page 3 for Slide disassembling details. 7 - x2 3 - x4 BACK RIGHT SIDE LEFT SIDE Note: The black release lever will point down. HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 9 Assembly Attach knob (6) to Drawer Front (A) with screw (4) as shown. 4 - x1 6 - x1 HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 10 Assembly Position Drawer into your unit to determine the slide mounting holes. You will use two screws (5) per slide to attach to each cabinet side. RIGHT LEFT CABINET CABINET SIDE SIDE Orientation of slide Orientation of slide attaching to right attaching to left cabinet side.
- Page 11 Assembly Insert Drawer so inner slide engage the outer slide. Push firmly in. HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
- Page 12 Questions, problems, missing parts? Before returning to the store, call StyleWell Customer Service 8 a.m. - 7 p.m., EST, Monday - Friday, 9 a.m. - 6 p.m., EST, Saturday 1-877-527-0313 HOMEDEPOT.COM Retain this manual for future use. HOMEDEPOT.COM : # 1-877-527-0313 Please contact for further assistance.
