EVBox BusinessLine Manual

Charging cable replacement
Hide thumbs Also See for BusinessLine:
Table of Contents

Advertisement

Quick Links

Download this manual
EVBox
BusinessLine
BusinessLine
Charging Cable Replacement
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BusinessLine and is the answer not in the manual?

Questions and answers

Related Manuals for EVBox BusinessLine

Summary of Contents for EVBox BusinessLine

  • Page 1 EVBox BusinessLine BusinessLine Charging Cable Replacement...
  • Page 3 EVBox BusinessLine BusinessLine Charging Cable Replacement...

  • Page 5: Table Of Contents

    Contents 1. Introduction 2. Safety precautions 3. Replacement instructions 3.1. Prepare the work area 3.2. Remove the charging station cover 3.3. Replace the charging cable 3.4. Install the charging station cover 3.5. Test the charging station 4. Disclaimer...

  • Page 7: Introduction

    This Maintenance Manual tells you how to replace the charging cables on the EVBoxBusinessLine charging station. You must carefully read the safety information before you start. This Maintenance Manual is applicable only to BusinessLine G2 and G3 models. Only a qualified electrician is permitted to do the maintenance procedures described in this manual.

  • Page 8: Safety Precautions

    2. Safety precautions 2. Safety precautions DANGER: Servicing and repair of the charging station by a non-qualified person will result in the risk of electric shock, which will cause severe injury or death. • Only a qualified electrician is permitted to install, service, repair and relocate the charging station.

  • Page 9: Replacement Instructions

    4. For a double charging station remove the second cover in the same way. 3.3. Replace the charging cable Note: The following procedure shows a 3-phase BusinessLine model. Although quantities and connection points may be different in other BusinessLine models, the procedure order and techniques will be the same for all models.
  • Page 10 3. Replacement instructions 1. Inside the charging station, identify the wires of the charging cable and their connection points. Note: Write down the wire colors and the terminal numbers to which the wires connect. 2. Using a screwdriver, push in the indicator on the PE/G terminal block to release the PE/G wire.
  • Page 11 3. Replacement instructions 4. Loosen the screws on the contactor to release the power wires. 5. Fully loosen the cable gland nut and slide it down the charging cable. 6. Gently pull the charging cable through the cable gland.
  • Page 12 3. Replacement instructions 7. Remove the cable gland nut from the charging cable. 8. Slide the cable gland nut over the new charging cable. 9. Insert the charging cable through the cable gland into the charging station. Note: Make sure that the cable is inserted far enough to easily connect the wires.
  • Page 13 3. Replacement instructions 10. Tighten the cable gland to secure the charging cable. 11. Insert the power wires into the contactor terminals and tighten the terminal screws. 12. Push the control pilot wire into its terminal block. Pull on the wire to make sure it is correctly connected. The indicator on the terminal block must be in the locked position.

  • Page 14: Install The Charging Station Cover

    3. Replacement instructions 13. Push the PE/G wire into its terminal block. Pull on the wire to make sure it is correctly connected. The indicator on the terminal block must be in the locked position. 3.4. Install the charging station cover 1.

  • Page 15: Test The Charging Station

    1. Remove the warning signs from the power supply. 2. Switch on electrical power to the charging station. 3. Test the charging station using the EVBox Test Box or by charging a vehicle as described in the applicable charging station User Manual.

  • Page 16: Disclaimer

    4. Disclaimer The present document is drawn up by way of information only and does not constitute an offer binding upon EVBox. EVBox has compiled the contents of this document to the best of its knowledge. No express or implied warranty is given for the completeness, accuracy, reliability or fitness for particular purpose of its content and the products and services presented therein.
  • Page 18 EVBIM_122020 © EVBox Manufacturing B.V.
