Assa Abloy SARGENT 1130 Series Installation Instructions Manual

1130 Series
Non Handed Door Closer
Regular Arm
Installation
See Page 2
Right Hand Door - RH
Left Hand Reverse - LHR
Top Jamb
Installation
See Page 5
Left Hand Door - LH
Right Hand Reverse - RHR
Parallel Arm
Installation
See Pages
Left Hand Door - LH
Right Hand Reverse - RHR
Spring Power Adjustment
Screw 1131 Series
"BC" Valve
1-6
Closer
Size
Stamp
Pinion Cap
All manuals and user guides at all-guides.com
Installation Instructions
80-9311-0011-021 Rev 2
An Incorrectly installed or improperly adjusted
door closer can cause property damage or
personal injury. These installation instructions
should be followed to avoid the possibility of
misapplication or misadjustment.
Doors should be hung on ball bearing or
anti-friction hinges.
A separate door stop is recommended.
Door and frame must be properly
reinforced.
Adjust closing time speed between 3 and 7
seconds from 90° to 0°.
These door closers should NOT be
installed on the exposed side (weather
side) of exterior doors.
3 & 4
#7
Metal
Standard Components
Closer Body
"L"Valve
"S"Valve
3/16"
1/4-20
Wood
Regular Arm/Top
Jamb Shoe
Connecting Rod
Soffit Plate
RU Soffit Plate
Used with Parallel
Arm Closers Only
Copyright © 2016, Sargent Manufacturing Company, an ASSA ABLOY Group company, All rights reserved. Reproduction
in whole or in part without the express written permission of Sargent Manufacturing Company is prohibited.
Non Hold Open Models
(Sizes 1 thru 6)
Regular Arm
Installation
See Page 2
Left Hand Door - LH
Right Hand Reverse - RHR
Top Jamb
Installation
See Page 5
Right Hand Door - RH
Left Hand Reverse - LHR
Parallel Arm
Installation
See Pages
3 & 4
Self Drilling Screws
Wood and Metal
For Wood drill 3/16 hole
Machine Screws
#7 Drill, 1/4-20 Tap
Arm Assembly Optional Components
Main Arm
Forearm
Arm Slide
Screw
Adjustable
1131
Right Hand Door - RH
Left Hand Reverse - LHR
(Optional)
Sleeve Nut and Bolt
Drill 9/32 thru from Closer Side
3/8 Drill other side
C o
v e
r
A7674C
