- Page 1 C5-Sport Guide & Manual...
-
Page 3: About Manual
Read it carefully and familiarize yourself Go to page 10 to find your serial numbers with the Himiway Bike before using it to ensure safe use, reduce risk of damage and premature wear, and prevent accidents. Be sure to retain this manual as your convenient Himiway Bike information source. -
Page 4: Safety Information
BEFORE OPERATION above ambient temperatures of -10°C (14°F).” The blanks are to be filled in Before operation of your new Himiway e-bike, it is crucial for your safety and per with the manufacturer’s specified ambient temperature ratings. the manufacturer's requirement, that you thoroughly read and understand this instruction manual. -
Page 5: Range Reference Table
So the weekly mileage for e-bike enthusiasts is 52.4 miles. • Combined with some other factors in riding, Himiway believes that an e-bike that can Loading: Overloading the bike surpassing the stated payload limit, especially reach 60 miles on a single charge is an authentic long-range e-bike. - Page 6 Bike Specification LCD Display Power Switch Throttle Rear Shock Battery Saddle 179.8 cm / cm - Total Length - Effective top tube Rear Brake Front Suspension 123.9 cm 59 cm - Handlebar Height - Wheel Diameter 119.4 cm 17 cm - Wheelbase - Head Tube Length Motor...
- Page 7 Bike Specification Battery 48V20AH LG 21700 Pedal Assist 0~5 level pedal assist Frame front 6061 alloy rear A356 Drive Unit 48V/250W Rearhub motor Taillight Integrated Taillight Display LED display Rotor 180mm Charger 48V 3A Range Brakes JAK-8 60-80 Miles Freewheel 16T single speed Throttle Thumb throttle...
-
Page 8: Preparation Checklist
• Reduce the weight of the ebike to make it easier to maneuver the bike while assembling. • Avoid battery damage during the assembly process. Go to page 11 to learn about removing and charging the battery. *Follow our Youtube channel Himiway Bikes to watch bike assembly tutorials！... -
Page 9: Front Wheel Installation
Assembly Instructions ◆ Mudguard installation Step 1: Align the mudguard holes with the holes at the bottom of the bike frame. ◆ Handlebar Installation(4mm Hex Wrench) Step 2: Insert the screws one by one and tighten them securely. Step 1: Loosen the bolts on your bike stem. - Page 10 Step 2: Remove the plastic axle guards from the front wheel, being careful to avoid contact with the brake rotor set. to find your serial numbers Step 3: Front Wheel Alignment - Position the front wheel so that it aligns with the dropouts of the quick-release front fork.
- Page 11 ◆ Pedals Installation (15mm wrench) Make sure your pedals are installed on the correct side, as installing on the wrong side will damage the threads. Indicators for the right pedal (R) and the left pedal (L) can be found in two places: the stickers on the plastic cover, and the bottom of the pedal threads.
- Page 12 ◆ After Bike Assembly Please write down the serial numbers found on the head tube, battery and motor on the inside front cover of this manual to facilitate failure reporting. Make sure each letter and number is correct. Make sure you take down the serial number here! Make sure you take down the Capital Letters here!
-
Page 13: Charger Use
◆ Modification and Repair Warning Battery Removal and Insertion Do not attempt to modify or repair your Himiway Ebike unless such actions are explicitly Removal instructed in this user manual. Unauthorized modifications or repairs could lead to - Switch off the e-bike power. -
Page 14: Safety Precautions
The following safety notes provide additional information on the safe operation of your Safety Check Basic Steps Himiway bike and should be closely reviewed. Improper operation, or failure to confirm correct installation, compatibility, and maintenance of any component or accessory may o Test front and rear brakes for proper function. - Page 15 Himiway E-Bike Use and Care The following table of contents provides general guidance on Himiway e-bike variable power assist settings and their effects on both range and performance. This content will apply broadly to most riders, but multiple factors will affect individual results including rider fitness and weight, terrain, proper maintenance, etc.
-
Page 16: Function Operations
Basic Display Info ◆ Cycling interface ◆ Control Panel • Gear indication : 0-5 gear, gear indication. Power • Speed display: real-time speed display. • Battery indicator: Six-level battery indicator: 1-5 levels of battery and Function undervoltage prompt ( 1 light flashes). key definitions Power on and off: “... -
Page 17: Battery Display
◆ Power assist gear switching ◆ Battery display When the battery power is normal, the 5-segment battery LCD displays the power according Press the key“ ”or“ ”key to switch the power assist gear and change the power assist mode. There are 4 mode states: 0 / low / medium / high level. to the time and the outer frame lights up. -
Page 18: Battery Charging
Battery Charging ◆ Charging Procedure for On-bike Charging Step 1: Check the battery power indicator on your display. Step 2: Assemble the charger as shown in Figure 1 by inserting the plug (Plug 1) into the transformer. Plug 1 Plug 2 Figure 3 Figure 4 Plug 3... - Page 19 Step 3: Check the battery status (fig. 8): Step 4: Safest way to charge your battery- First, assemble the charger by inserting the plug (Plug 1) into the transformer. Light Status Charging Status Then insert the DC plug (Plug 2) into the battery charging socket. Last, insert the power plug (Plug 3: 110V-240V plug) to the power socket.
- Page 20 If your battery displays abnormal charging behavior, such as: • The Himiway Bike can be safely ridden in light rain. However, riding through very • Longer-than-expected charge time heavy downpours or through flooded streets is not recommended, as the crank •...
-
Page 21: Riding Modes
Himiway Ebike can reach speeds of up to 25 miles/h with throttle mode, which not only allows you to travel faster, but also reassures riders with extra power whenever needed, depending on traffic conditions and rider energy levels. -
Page 22: Moving And Storage Instructions
Riding Limitations ◆ Pedal-only In this mode, the Himiway will perform like a normal bike, as you’ll be riding without any Following are some limitations needing riders’ careful attention to ensure the geared hub assistance from the motor. This mode is especially useful if you run out of battery, or are motor does not overheat or become damaged from excessive loading: looking for more intensive resistance training. -
Page 23: Safety And Care Instructions
◆ Cargo Safe Operation Tips: non-corrosive detergent mixture. Wipe or spray all unpainted parts with anti-rust The following list provides important tips for the safe operation of the Himiway Ebike treatment after being used in coastal areas or areas with salty air or water. -
Page 24: Maintenance
We recommend using a front fork dust cover to protect the inner tube of your front The Himiway Bike can be safely ridden in light rain. However, riding through very fork. This prevents dust from entering as well as hard objects from hitting the inner heavy downpours or through flooded streets is not recommended, as the crank tube. - Page 25 Long Range E-bike Expert...
