Summary of Contents for Bryton Rider 750 SE
-
Page 2: Table Of Contents
Step 3: Initial Setup .....10 Profile ......45 Step 4: Acquire Satellite Signals Bryton Advanced Settings ..46 Step 5: Ride with Rider 750 SE . 11 Notifications ....... 46 Step 6: Share Your Records ..12 Appendix ......47 Firmware Update . -
Page 3: Australian Consumer Law
Video Tutorial For a step-by-step demonstration of device and Bryton Active app, please scan the QR code below to check out Bryton Tutorial Videos. http://www.youtube.com/c/BrytonActive... -
Page 4: Getting Started
Getting Started This section will guide you through basic preparations before the first use with your Rider 750 SE Rider 750 SE Key Functions POWER/LOCK ( x Long press to turn the device ON. x Long press to turn the device OFF. -
Page 5: Touch Screen
Touch Screen Speed Speed Speed Speed 23.2 23.2 23.2 21:35 23.2 Cadence Cadence ence ence Cadence Cade Ride Time Ride Time Time Time Ride Time Ride 03:21:38 03:21:38 1:38 1:38 03:21:38 03:2 3S Power Trip Time Trip Time 3S Power 3S Power 3S Power 3S Power... -
Page 6: Gui Display
GUI Display Outer Rings Average value Inner Rings Current value when using a Speed or a Cadence sensor. Current value when using a Heart Rate Monitor or a Power sensor. The colors will change by different zones, which are based on the settings. Speed Distance 16.5... -
Page 7: Quick Status
Quick Status Menu Simply with a tap on the meter page, the “Quick Status” menu will pop out.You can check the notification you received and the status of connected sensors and even control the light mode here. . QUICK STATUS 1. -
Page 8: Custom Alert
Cutom Alert Custom Alerts allow you to configure your Rider 750 SE to alert you based on various conditions such as workout time, duration, distance, or calories burned. You can edit the alert message via Bryton Active. 1.Select Menu > Settings > Alert ALERTS 2.select an Alert in the list. -
Page 9: Status Icons
Status Icons NOTE: When you see this for the GPS signal, it means the device keeps the ephemeris data, helping the device acquire the GPS signal faster. The data remains good for 1 to 2 weeks and needs to be updated afterward. 9 Getting Started Back to Top... -
Page 10: Step 1: Charge Your Rider 750 Se
1. Select the display language. 2. Choose the units of measurement. 750 SE 3. Download Bryton Active app and pair the Rider with your cellphone. 4. Go through the starting tutorial before riding. LANGUAGES UNIT... -
Page 11: Step 4: Acquire Satellite Signals
4. Tap on or press to continue recording. 5. Rider 750 SE supports resume recording when the ride was interrupted. You can turn off the computer to save battery when taking a break and turn it back on to resume recording. -
Page 12: Step 6: Share Your Records
Go to https://active.brytonsport.com. b. Register for a new account. 2. Connect to PC Turn on your Rider 750 SE and connect it to a computer by USB cable. 3. Share Your Records a. Click “+” in the right upper corner. - Page 13 Bryton Active App.. and try again. NOTE: Bryton Active App syncs with Brytonactive.com. If you already have a brytonactive. com account, please use the same account to log in to Bryton Active App and vice versa. 13 Getting Started Back to Top...
-
Page 14: Firmware Update
Firmware Update Bryton Update Tool Bryton Update Tool is the tool for you to update GPS data, firmware and download Bryton Test. 1. Go to http://www.brytonsport.com/#/supportResult?tag=BrytonTool and download Bryton Update Tool. 2. Follow the on-screen instructions to install Bryton Update Tool. - Page 15 Adapter with Bryton original cable. Make sure the smartphone is connected to the device. Select the “BRYTON” root folder to allow Bryton Active app gets permission to access the device for downloading new firmware. NOTE: You will need a lightning to USB adapter with Bryton original cable.
- Page 16 Profile Settings c. Choose to upadte the firmware with Bryton cable or with Bluetooth. If you are using the cable, please give the app permission to access phone storage. You will need a USB-C to USB Adapter with Bryton original cable.
-
Page 17: Course
Route Create Track Rider 750 SE provides 3 ways to create tracks: 1. Plan trip via Bryton Active App. 2. Import routes from 3rd party platforms. 3. Auto sync routes from Strava, Komoot and RideWithGPS. Plan Trips via Bryton Active App 1. - Page 18 Peak in Route mode, allowing you to make the right decision based on your status and stay motivated along the way. 1. Go to Course > My Routes in Bryton Active App. 2. Select the route you would like to add POIs.
-
Page 19: Route Guidance
After downloading routes to the Rider 750 SE, you are able to follow the route guidance. Rider 750 SE supports advanced features to help you stay on track and get the most out of your rides, such as auto-rerouting, on-screen POIs, and reverse downloaded routes. - Page 20 Navigate to the Start/Nearest Point on route When you start to follow a route, Rider 750 SE will ask if you want to navigate to the start or the nearest point of the route. Once you get on the route, Rider 750 SE will guard you to the route finish.
-
Page 21: Climb Challenge
Climb Challenge When you approach a climb, the Rider 750 SE will change to the Climb Section page, providing an overview of a route’s climb segments. The Climb Challenge screen shows a color-coded altitude map based on the gradient, distance remaining, and ascent remaining, giving you the climb information at-a-glance. -
Page 22: Workout
Workout Create a Workout Rider 750 SE provides 2 ways to create workout: 1. Plan workout via Bryton Active App. 2. Import workout from 3rd party platforms. Plan workout via Bryton Active App 1. In Bryton Active App, select Course >... - Page 23 Train with a Workout plan L6 Intensive Anaberoic 1. Select Menu > Training 2. Select Workout. Description Overview 3. You can see the workout plans, which are synced from the app. Delete Workout 1. To delete the workout, click then select the workout(s) and click again to delete.
-
Page 24: Bryton Test
Bryton Test Bryton Test includes test courses to help you evaluate your MHR, LTHR and FTP. Knowing your MHR, LTHR and FTP gives you a benchmark of your overall efficiency. It also helps you check progress over time and analyze your exercise intensity. -
Page 25: Group Ride
2. Turn on the Rider 750 SE and enter Menu and select Group Ride. 3. Press to start riding. Group Chat Rider 750 SE and Bryton Active app allow you to send messages to the members in the group. MESSAGES Lewis B.D. 16:34 9:41... -
Page 26: Live Track
Share your real-time location with friends and family using the Live Track feature. Before using, please ensure that Rider 750 SE is already recording a ride by pressing the record button and then open the Bryton Active app on our smartphone. This feature will not work properly if the device is not recording. -
Page 27: Smart Trainer
2. Select to confirm. Note: To see how to create tracks: 1. Plan trip via Bryton Active App. 2. Import routes from 3rd party platforms. 3. Auto sync routes from Strava, Komoot and RideWithGPS. Please go to Page17. - Page 28 Smart Workout Training plans can be built with the Bryton Active App and downloaded directly to the Rider 750 SE. With ANT+ FE-C support, the Rider 750 SE will communicate with your smart trainer to control the resistance according to the training plan.
- Page 29 Virtual Ride or the Smart Trainer lost connection. Power Note: You need to connect a smart trainer to the Rider 750 SE before having access to the Virtual Ride, Smart Workout, Resistance, and Power Workout. 29 Course...
-
Page 30: Navigation
Navigation With connection to the internet, you can use your voice to search for locations on the Rider 750 SE in over 100 languages. The voice search features offers a faster, more intuitive and more convenient to find addresses or POIs. Voice Serach 1. -
Page 31: Pin A Location
2. Tap on to start navigation. Navigate on Bryton Active App 1. Pair the Rider 750 SE with Bryton Active App, select Course > Navigation. 2. Input keywords or address or POI type in the search bar then click 3. -
Page 32: Retrace Ride
Retrace Ride When you want to return back to your starting location, the Rider 750 SE can help you double back with just a press of a button at any point during a ride, using the same path you took to retrace your steps and providing turn-by-turn route guidance! 1. -
Page 33: Download Maps
3. Wait until 750SE is shown on the screen and then select “Update Map” Here you will see the maps installed or downloaded on your device. 4. Select “Add Bryton Standard Map” if you want to download other maps by country or region 5. -
Page 34: Results
Results You can view recorded activities on the Rider 750 SE or delete records to save more storage capacity of the device. View Records 1. Select ”last ride” on the home page. Mount Trip 2. Pick a record to view details. -
Page 35: Settings
In addition, you can customize most of the device settings via the Bryton Active app. Bike Setup Rider 750 SE supports up to 3 bike profiles, it is easier than ever to customize your device for any type of setup. Settings for each profile can be completely customized such as GPS system, data fields, and auto features. - Page 36 GPS System Rider 750 SE has full GNSS (Global Navigation Satellite System) support including GPS, GLONASS (Russia), BDS (China), QZSS (Japan) and Galileo (EU). You can select a suitable GPS Mode according to your location to enhance accuracy or better suit your needs.
-
Page 37: Display
Overview Select Overview to view more details of the bike odometer. 1.Select Menu > Settings > Bike Settings OVERVIEW 2. Select a bike profile > Overview. Trip 1 Trip 1 / 2: 675.8 km Cumulative mileage recorded before you reset Trip 2 it. -
Page 38: Pair Sensors
Pair Sensors We suggest that you pair all your sensors with the device beforehead, Rider 750 SE will scan for nearby active sensors from the sensor pool, making switching between bikes and sensors easier and more convenient than ever. 1. Select Menu > Settings. - Page 39 Using Electronic Shifting Systems After pairing electronic shifters, such as Shimano Di2 or SRAM, you can enter the sensor pages for further settings. To customize the data grids on meter pages, please go to page 5 for more instruction. Rear Gear Gear Presets Status Type...
- Page 40 2. Choose any type of sensor that you would like to pair with. 3. To pair sensors with your device, please have Bryton Smart Sensors installed first, then wear a heart rate monitor or rotate the crank and wheel a few times to wake Bryton Smart Sensors up.
- Page 41 Please go to Page 38 to see how to pair a bike radar with Rider 750SE. Using E-bike The Rider 750 SE incorporates Shimano Steps and ANT+ LEV e-bike support for compatible brands to display various e-bike data, including assist mode, assist level shifting mode, E-Bike battery, travel range and rear gear position.
-
Page 42: System
System In System, you can customize System Settings, Recording Settings, Auto Scroll, Start Remind, File Saving, Memory, ODO, and Data Reset. System Settings You can setup Language, Backlight Duration, Meter Color Mode, Key Tone, Sound, Left Key Function, Time/Unit, Auto Lock, and Status Duration. 1.Select Menu >... - Page 43 Recording Settings In Recording Settings, data recording frequency can be customized for higher accuracy / data saving, as well as how data is included depending on user preference. 1.Select Menu > Settings 2. Find Recording Settings. Recording Settings Smart Recording Smart Recording 1.
-
Page 44: Altitude
Altitude With connection to Internet, Rider 750 SE provides altitude information for you to calibrate directly. You can also change altitude manually. Calibrate Altitude 1. Select Menu > Settings. ALTITUDE 2. Find Altitude. 3. Click on the number to change the value. -
Page 45: Profile
2. Select Herat Rate Zone and tap to edit Profile details. Device Name Customize Heart Rate Zone 1. Select MHR. Bryton x Use keyboard to enter MHR . Gender x Press to edit details for each zone. Female x Select to confirm. -
Page 46: Bryton Advanced Settings
Bryton App Advanced Settings After pairing your Rider 750 SE with Bryton Active App, you will have access to Notifications. Notifications After pairing your compatible smartphone with Rider 750SE via BLE, you can receive phone calls, texts, and email notifications on your Rider 750SE. -
Page 47: Appendix
Appendix Specification Rider 750 SE Item Description Display “2.8” color TFT 240x400 capacitive touch screen” Physical Size 52x93x19.4mm Weight 93 g Operating Temperature -10°C ~ 50°C Battery Charging 0°C ~ 40°C Temperature Battery Li-polymer rechargeable battery Battery Life 40 hours with open sky ANT+™... -
Page 48: Install Rider 750 Se
Install Rider 750 SE Use Bike Mount to Mount Rider 750 SE Use Sport Mount to Mount Rider 750 SE Safety Lanyard 48 Appendix Back to Top... -
Page 49: Install The Speed/Cadence/Dual Sensor (Optional)
Install the Speed/Cadence Sensor (Optional) Smart Cadence Sensor Smart Speed Sensor NOTE: x Once sensors are waken, the LED blinks twice. The LED continues to blink when you continue to pedal for pairing. After around 15 times blink, it stops blinking. If not used for 10 minutes, sensor would go into sleep mode to preserve power. -
Page 50: Wheel Size And Circumference
Wheel Size and Circumference The wheel size is marked on both sides of the tires. Wheel Size L (mm) Wheel Size L (mm) 12x1,75 26x3,00 2170 12x1,95 26x1-1/8 1970 14x1,50 1020 26x1-3/8 2068 14x1,75 1055 26x1-1/2 2100 16x1,50 1185 650C Tubular 26 1920 x7/8 16x1,75... -
Page 51: Data Fields
Data Field Category Data Field Description of Data Fields The height of your current location above or below sea Altitude level. The highest height of your current location above or below Max Altitude level which the rider achieved for the current activity. The total altitude distance gained during this current activ- Alt. - Page 52 Category Data Field Description of Data Fields Calories The number of total calories burned. Energy The accumulated power output in kilojoules for the current Kilojoules activity. Time Current GPS Time. Ride Time The time spent on riding for current activity. Trip Time Total time spent for current activity.
- Page 53 Category Data Field Description of Data Fields Power Now Current Power in Watt. Avg Power The average power for the current activity. Max Power The maximum power for the current activity. LapAvgPw The average power for the current lap. LapMaxPw The maximum power for the current lap.
- Page 54 Category Data Field Description of Data Fields CurPB-LR The current left/right power balance. The average left/right power balance for the current AvgPB-LR activity. The current left/right percentage of how efficiently a rider CurTE-LR is pedaling. The maximum left/right percentage of how efficiently a MaxTE-LR rider is pedaling.
- Page 55 Category Data Field Description of Data Fields SPD Ring The current speed rate displays in dynamic coloured graph- ical mode. SPD Bar CAD Ring The current cadence rate displays in dynamic coloured graphical mode. CAD Bar HR Ring The current heart rate displays in dynamic coloured graph- ical mode.
-
Page 56: Basic Care For Your Rider 750 Se
20 cm separation distance to the user. Hereby, Bryton Inc. declares that the radio equipment type Bryton product is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.brytonsport.com/download/Docs/CeDocs_Rider750SE.pdf...
