Summary of Contents for Bryton Rider 320

  • Page 1 User Manual Rider 320...

  • Page 2: Table Of Contents

    Accessories ........5 Altitude ........28 Status Icons ........5 Personalize User Profile ....29 Step 1: Charge Your Rider 320 ..6 Personalize Bike Profile ....30 Step 2: Turn On Rider 320 ....6 Step 3: Initial Setup ....... 6...
  • Page 3 Video Tutorial For a step-by-step demonstration of device and Bryton Active App, please scan QR code below to check Bryton Video Tutorials. https://www.youtube.com/brytonactive...

  • Page 4: Getting Started

    Getting Started This section will guide you through the basic preparations before you start using your Rider 320. Your Rider 320 Power/Backlight ( • Press to turn the device on. • Press to turn on/off the backlight while the device is on.

  • Page 5: Accessories

    Accessories The Rider 320 comes with the following accessories: • USB cable • Bike mount Optional items: • Smart Heart Rate Sensor • Smart Speed Sensor • Smart Cadence Sensor • Smart Speed / Cadence Dual Sensor • Race Mount-Rider •...

  • Page 6: Step 1: Charge Your Rider 320

    Press to turn on the device. Step 3: Initial Setup When turning Rider 320 on for the first time, you will need to follow on screen instructions to complete setup. 1. Select the display language. 2. Select the unit of measurement.

  • Page 7: Step 4: Acquire Satellite Signals

    Step 4: Acquire Satellite Signals Once the Rider 320 is turned on, it will automatically search for satellite signals. It may take 30 to 60 seconds to acquire signals. Please make sure you acquire the satellite signal for the first time use.

  • Page 8: Share Your Records

    Register a new account or use your current account to log in. 2. Connect to PC Turn on your Rider 320 and connect it to your computer by USB cable. 3. Share Your Records a. Click "+" on the upper right corner.

  • Page 9: Auto Sync Tracks To Bryton Active App

    You can find it on the back of the device. NOTE: Bryton Active App syncs with Brytonactive.com. If you already have brytonactive.com account, please use the same account to log in to Bryton Active App and vice versa. Getting Started...

  • Page 10: Bryton Update Tool

    2. Follow the on-screen instructions to install Bryton Update Tool. Update Firmware Bryton releases a new firmware version on irregular basis to add new functions or correct bugs for better and more stable performance. It is recommended that you update firmware once new firmware available.

  • Page 11: View History

    You can veiw exercise record on your device right after your ride, and delete any unwanted record to gain more storage. View Exercise/Training Record Rider 320 provides graphical track summary, detail workout data , lap data and graphical analysis for you to have a better idea of your workout performance. To view your history:...

  • Page 12: History Flow

    History Flow ride = Ride Time 09/19 21:44 Lap 01 00:49 00:02:25 75.6 75.6 0.25 ride 3.69 81.4 kcal kcal laps More 1/20 Record#/Total records The arrow appears only when there is lap in this record.. View History...

  • Page 13: Settings

    Sensors Data Page You can set the display settings for the Meter and Lap or you can customize data page via Bryton Active App. Please refer to page 32 to learn how to do it. Meter Display Data Page Ride Time...
  • Page 14 NOTE: The number of data fields shown on the screen depends on the “Data fields“ selection. 2-grid display 3-grid display NOTE: If Data Page is set to Auto, Rider 320 will automatically adjust its data field display when detecting the paired sensors. Speed RTime Dist.

  • Page 15: Smart Lap

    Smart Lap With Smart Lap feature, you can use your device to automatically mark the lap at a specific location or after you have traveled a specific distance. Lap by Location to enter Exercises. 1. In the Settings menu, press By Location to select Smart Lap.

  • Page 16: Set Alert

    Set Alert With the Alert feature, the device displays a message to notify you if: • your heart rate exceeds or drops below a specific number of beats per minute (bpm). • you excees or drop below a custom speed setting during your side. •...

  • Page 17: Data Record

    Data Record With Data Record function, you can set your odometer and activate 1 second mode to get more accurate data. Set ODO 1. In the Settings menu, press to enter ODO Setup Exercises. Press. and then to select O DO Setup Data Record.

  • Page 18: Gps System

    GPS System Rider 320 has full GNSS (Global Navigation Satellite System) support including GPS , GLONASS (Russia), BDS (China), QZSS (Japan) and Galileo (EU). You can select the suitable GPS Mode according to your location to enhance accuracy or suit your needs.

  • Page 19: Change System Settings

    Change System Settings You can customize the device system setting such as backlight off, key tone, sound, time/ unit, on-screen display language. Backlight off 1. In the Settings menu, press and then press Backlight Off to select General. 2. Press to enter System.
  • Page 20 Sound 1. In the Settings menu, press and then press Sound to select General. to enter System. 2. Press 3. Press to select Sound and press confirm. 4. Press to select desired setting and press to confirm. 5. Press to exit this menu. Time/Unit Dlight Save Date Format...
  • Page 21 Contrast You can adjust contrast on your device. 1. In the Settings menu, press and then press Contrast to select General. 2. Press to enter System. to select Contrast and press 3. Press confirm. 4. Press to adjust desired contrast. 5.

  • Page 22: Bluetooth

    Bluetooth Before pairing Rider 320 with your bluetooth enabled mobile phone, make sure the bluetooth function of your mobile phone and Rider 320 is turned on. Enable Bluetooth 1. In the Settings menu, press and then press Enable to select General.

  • Page 23: Cofigure Auto Scroll

    Configure Auto Scroll When the feature is enabled, the device will automatically switch pages at the preset time. Auto Scroll 1. In the Settings menu, press and then press to select General. Auto Scroll 2. Press to select Auto Scroll and press confirm.

  • Page 24: Start Reminder

    Start Reminder When Rider 320 detects the motion of your bike, it would pop up a reminder to ask you if you would like to record or not. You can set the frequency of start reminder. 1. In the Settings menu, press...

  • Page 25: Reset Data

    Reset Data You can restore your Rider 320 to factory settings. 1. In the Settings menu, press and then press General to select General. Perform 2. Press to select Data Reset and press factory Once confirm. reset ? 3. Press to select “YES”...

  • Page 26: Ant+/ Ble Sensors

    ANT+/ BLE Sensors Rider 320 is compatible with both ANT+ and BLE sensors. You can customize the respective sensor settings such as rescan the sensor to pair with your device or enable/ disable the function. Heart Rate Sensors Heart Rate Settings >...
  • Page 27 • While pairing your speed/cadence sensor/the heart rate belt and power meter, please make sure there is no other cadence/speed sensor/power meter within 5m. • Bryton smart sensors can only be paired when they are awake, or they would go back to sleep to preserve power.

  • Page 28: Altitude

    NOTE: The value of altitude on the meter mode will be changed once current altitude is adjusted. NOTE: Current Altitude can also be adjusted via Bryton Active App. Please go to page 33 tollearn how to calibrate altitude. Other Location Altitude With other locations altitude setting, you can save a value of altitude of your planned location, and do calibration once you are in the appointed position.

  • Page 29: Personalize User Profile

    Persnalize User Profile You can change your personal information. 1. In the Settings menu, press and then press User to select Profile. Gender 2. Press to enter User Profile. A message of“Input correct profile as it might affect Male analysis.”pops up. Press to confirm after Birthday reading message.

  • Page 30: Personalize Bike Profile

    Personalize Bike Profile You can customize and view your bicycle(s) profile. Bike 1 1. In the Settings menu, press and then press to select Profile. Spd Source 2. Press to select Bike Profile and press to enter. 3. Press to select setting that you want to edit Weight and press to enter its submenu.
  • Page 31 Adjust Odometer 1. In the Settings menu, press and then press Bike 1+2 to select Profile. to select Bike Profile and then press 2. Press 1033km to enter. Ride Time 3. Press to select Overview and press enter its submenu. 89:23:28 4.

  • Page 32: Bryton Active App Advanced Settings

    3. Turn on your prefered pages and enter the page. 4. Tap < or > to change the number of grids. 5. Tap data grid to change ride data. NOTE: To learn how to pair Rider 320 with Bryton Active App, please check page 9. Bryton Active App...

  • Page 33: Altitude Calibration

    Press OK to calibrate altitude data on the device. 2-2. Auto Calibrate Altitude via Bryton Active App a. In Bryton Active App, select Settings > Auto Cal. Alt. NOTE: To learn how to pair Rider 320 with Bryton Active App, please check page 9. Bryton Active App...

  • Page 34: Notifications

    Notifications After pairing your compatible smartphone using Bluetooth Smart wirelessly technology with Rider 320 , you can receive phone call, text and email notifications on your Rider 320. 1. IOS Pairing a. Go to Settings > General > Bluetooth to turn on Bluetooth on Rider 320.

  • Page 35: Appendix

    Appendix Specifications Rider 320 Item Description Display 2.3” FSTN positive transflective dot-matrix LCD Physical Size 49.9 X 83.9 X 16.9mm Weight Operating -10°C ~ 60°C Temperature Battery Charging 0°C ~ 40°C Temperature Battery Li polymer rechargeable battery Battery Life 35 hours with open sky Featuring certified wireless ANT+ connectivity.

  • Page 36: Battery Information

    Smart Cadence Sensor Item Description Physical size 36.9 x 31.6 x 8.1 mm Weight Water Resistance Incidental exposure to water of up to 1 meter for up to 30 minutes. Transmission range Battery life Up to 1 year Operating temperature -10°C ~ 60°C 2.4GHz / Bluetooth 4.0 and Dynastream ANT+ Sport wireless Radio frequency/protocol...
  • Page 37 To replace the battery: 1. Locate the circular battery cover on the back of sensors. 2. Use your finger to press and twist cover counter-clockwise so the indicator on the cover points to unlock icon ( ). 3. Remove the battery and insert new battery with positive connector first into the battery chamber.

  • Page 38: Install Rider 320

    Install Rider 320 Use Bike Mount to Mount Rider 320 (Optional) Appendix...

  • Page 39: Install Speed/Cadence/Dual Sensor (Optional)

    Install Speed/Cadence/Dual Sensor (Optional) Speed Sensor Cadence Sensor NOTE: • Once sensors waken, the LED blinks twice. The LED continues to blink when you continue to pedal for pairing. After around 15 blinks, it will stop blinking. If not used for 10 minutes, sensor would go into sleep mode to preserve power.

  • Page 40: Install Heart Rate Belt (Optional)

    • Adjust the sensor position to the middle part of the body (wear it slightly below the chest). The Bryton logo shown on the sensor should be facing upward. Tighten the elastic belt firmly so that it will not turn loose during the exercise.

  • Page 41: Wheel Size And Circumference

    Wheel Size and Circumference The wheel size is marked on both sides of the tires. Wheel Size L (mm) Wheel Size L (mm) 12x1.75 26x3.00 2170 12x1.95 26x1-1/8 1970 14x1.50 1020 26x1-3/8 2068 14x1.75 1055 26x1-1/2 2100 16x1.50 1185 650C Tubular 26x7/8 1920 16x1.75 1195...

  • Page 42: Basic Care For Your Rider 320

    Basic Care For Your Rider 320 Taking good care of your device will reduce the risk of damage to your device. • Do not drop your device or subject it to severe shock. • Do not expose your device to extreme temperatures and excessive moisture.

  • Page 43: Data Fields

    Data Fields Category Data Fields Description of Data Fields Calorie The number of total calories burned. Energy The accumulated power output in kilojoules for the current Kilojoules activity. Altitude The height of your current location above or below sea level. The highest height of your current location above or below Max Altitude sea level which the rider achieved for the current activity.
  • Page 44 Category Data Fields Description of Data Fields The number of times your heart beats per minute. It requires Heart Rate compatible HR sensor pairing connection to your device. Avg HR The average heart rate for current activity. Max HR The maximum heart rate for current activity. Your current heart rate divided by Maximum Heart Rate.
  • Page 45 Category Data Fields Description of Data Fields The current range of your Maximum Aerobic Power Pecentage MAP Zone (Zone 1 to Zone 7). MAP% The current power divided by your Maximum Aerobic Power. FTP% The current power divided by your functional threshold power. Lap NP Normalized power of the current lap Last Lap NP...
  • Page 46 20 cm separation distance to the user. Hereby, Bryton Inc. declares that the radio equipment type Bryton product is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available at the following internet address: http://www.brytonsport.com/download/Docs/CeDocs_Rider320.pdf...
