USER MANUAL
JETFLO Lead Free DZR Brass
Pre-Rinse Units
•
Hob Mounted Pre-Rinse Units-
JETFLF1200, JETFLF1200C,
JETFLF4000, JETFLF6000, JETFLF9900
•
Wall Mounted Pre-Rinse Units-
JETFLF3000, JETFLF3000W,
JETFLF5000, JETFLF5600
•
Hand Held Pre-Rinse Units-
JETFLF7000, JETFLF7500
•
Trigger Spray - JETFLF0050
MAR-IM-JETFLF01-JT-20250122
The more
stars the more
water ef cient
WATER RATING
www.waterrating.gov.au
4.0
litres per
minute
WATER RATING
(spray tap)
www.waterrating.gov.au
4.0
In accordance with AS/NZS 6400
Licence No. 1334
GENTEC AUSTRALIA
Second outlet
Second outlet
In accordance with AS/NZS 6400
5 star
Licence No. 1334
5.0 litres per minute
gentecaustralia.com.au
The more
stars the more
water ef cient
litres per
minute
AS 3718
Lic WMKA25617
SAI Global
GENTEC AUSTRALIA
Last updated in January 2025
Advertisement
Table of Contents
Related Manuals for Gentec JETFLO JETFLF1200
Summary of Contents for Gentec JETFLO JETFLF1200
- Page 1 WATER RATING (spray tap) www.waterrating.gov.au In accordance with AS/NZS 6400 litres per Licence No. 1334 minute GENTEC AUSTRALIA AS 3718 Second outlet Second outlet In accordance with AS/NZS 6400 Lic WMKA25617 5 star Licence No. 1334 5.0 litres per minute...
-
Page 2: Table Of Contents
USER MANUAL Table of Contents Scope of Use Technical Information Product Images & Technical Drawings Exploded Drawings Installation Steps Cleaning & Maintenance Spare Parts Troubleshooting Water Quality Responsibly Sourced Scope of Use Installation of all products should adhere to the manufacturer's guidelines, as well as comply with PCA, AS/NZS3500 standards, and any other relevant regulatory provisions. -
Page 3: Technical Information
Technical Information Body: Lead Free Brass, Blade Spray: Stainless Steel Material JETFLF0050- Blade Spray: Stainless Steel, Cover: Engineering Plastic Ceramic Disc / Self Closing Cartridge JETFLF7500: Self Closing JETFLF1200, JETFLF1200C- 40mm JETFLF3000, JETFLF3000W, JETFLF4000, JETFLF5000, Cartridge Size JETFLF5600, JETFLF6000, JETFLF7000, JETFLF9900- 15mm JETFLF0050, JETFLF7500- N/A JETFLF0050, JETFLF9900, JETFLF7000 - 15mm Male (G... -
Page 4: Product Images & Technical Drawings
This drawing is property of JETFLF1200 LAST UPDATE APPROVED BY specified and are to be used as Gentec Australia Pty Ltd a guide only 08/11/24 Lead Free DZR Brass Hob Mounted Pre-Rinse Unit w/ Pot Filler and Mixer 13.7 Ø45 Ø55... - Page 5 Ø56 Ø22 Ø40 Ø28 Ø30 Ø34 17MAX PRODUCT CODE AND DESCRIPTION: Ø54 JETFLF3000 - GENTEC JETFLO Wall Mount Chrome Plated W/ Pot Filler, Recess Adap Spray / Laminar Flow REVISIONS JETFLF3000 6, 20 -28 Ricketty St www.gentecaustralia.com.au REV. DATE DESCRIPTION Mascot, NSW 2020 info@gentecaustralia.com.au...
- Page 6 Ø22 Ø40 Ø34 17MAX Ø54 JETFLF4000 PRODUCT CODE AND DESCRIPTION: JETFLF4000 - GENTEC JETFLO Hob Mounted Lead Free DZR Brass Chrome Plated W/ Pot REVISIONS Valves and 100mm Lever Handles Blade Sp 6, 20 -28 Ricketty St www.gentecaustralia.com.au REV. DATE...
- Page 7 Ø56 351 Ø22 Ø40 Ø30 Ø65 Ø30 Ø45 PRODUCT CODE AND D JETFLF5600 JETFLF5600 - GENTEC JE Chrome Plated W/ Pot F Blade Spray / Laminar Flo REVISIONS 6, 20 -28 Ricketty St www.gentecaustralia.com.au DATE REV. DESCRIPTION Mascot, NSW 2020 info@gentecaustralia.com.au...
- Page 8 Ø38 Ø64 Ø40 PRODUCT CODE AND DESCRIPTION: JETFLF7000 - GENTEC JETFLO Wall Mounted Pre-Rinse Unit Lead Free DZR Brass Chrome Plated W/ Spray Gun. 1m hose REVISIONS and Cistern Tap Blade Spray / Laminar Flow 6, 20 -28 Ricketty St www.gentecaustralia.com.au...
- Page 9 DATE DESCRIPTION Mascot, NSW 2020 info@gentecaustralia.com.au This drawing is the property of Gentec Australia Pty Ltd LAST UPDATE APPROVED BY All dimensions are in mm unless specified 11 Dec 2024 Lead Free DZR Brass Hob Mounted Pre-Rinse Unit w/ Pro Filler, Exposed Mixing Set...
-
Page 10: Exploded Drawings
USER MANUAL Exploded Drawings... - Page 11 Code Description Code Description Mixer handle Check Valve Allen key DN6 check valve JETLF0074W Handle porlug Check valve sleeve M5 grub screw Spring Decorative cap GPJ0060 Spring cap washer Lock nut Spring cap JETF9001 Mixer cartridge JETFLF0070 Hose Mixer body JETFLF0050W Trigger spray JETFLF0082...
-
Page 12: Installation Steps
6,20-28 Ricketty St www.gentecaustralia.com.au Mascot, NSW 2020 info@gentecaustralia.com.au PRODUCT RANGE LAST UPDATE APPROVED BY This drawing is property All dimensions are in mm unless of Gentec Australia Pty Ltd specified and are to be used as a guide only SCALE... - Page 13 JETFLF5600 INSTALLATION STEPS Step 1. Apply adequate thread tape Step 5. Attach the riser to the exposed and screw on the conical wall breech and carefully align the attachments to the wall fitting, grub screw and tighten. adjust centre distance (215) to align with the exposed breech set.
- Page 14 USER MANUAL WALL BRACKET INSTALLATION STEPS FOR ALL UNITS The Wall Bracket installation is an essential For a masonry wall use the wall anchors part for the correct operation and use of provided with screws. the pre rinse unit. Step 1. Measure and cut the wall support bar to a length with a 2 to 5mm gap from the wall.
- Page 15 SPRING AND TRIGGER SPRAY INSTALLATION STEPS FOR ALL UNITS Pre-Rinse Spring & Trigger Spray: Step 6. Screw the Trigger Spray Unit to Step 1. Fit the flat washer into the top of the Hose, tighten firmly using a the Riser to ensure a water tight spanner on the flat section of the seal.
- Page 16 USER MANUAL JETFLF4000, JETFLF6000 INSTALLATION STEPS Step 1. Place the base hob unit on the NOTE: - The slight disalignment of the bench. grub screw may result in water leakage. - The body is made to slide inside the base hob unit in such a way that the grub screw on the hob unit aligns with the hole on the body.
- Page 17 JETFLF3000, JETFLF3000W, JETFLF5000, JETFLF5600 INSTALLATION STEPS Pre-Rinse Arm and Pot Filler Installation: Wall Handles Installation: Step 1. Flush the line thoroughly before Step 1. Unscrew the cover flange from connecting tap fittings. the main body of the cartridge. Also, unscrew the adjustable Step 2.
-
Page 18: Cleaning & Maintenance
Note: The information provided is only a guide, actual product hose). Bending/ Kinking the hose will clarification with Gentec. Gentec reserves the right to make design changes at any time without notification. cause the stainless-steel braiding to *WARRANTY TERMS AND CONDITIONS, please refer to www.gentecaustralia.com.au/page/terms_and_conditions Note: The information provided is only a guide, actual product fray and void warranty. -
Page 19: Spare Parts
Spare Parts There are various spare parts stated below, which can be purchased from GENTEC when required. For more information, refer exploded drawing section in page 10 and 11. Code Spare Parts Code Spare Parts JETF0050 Trigger Spray Gun Allen Key... -
Page 20: Troubleshooting
USER MANUAL Troubleshooting Problem Cause How to Fix • Have you flushed the water line for a minimum of 1 minute before connecting the water • Have you installed the strainer and flow controller if provided • Debris • If debris has gone through the cartridge •... - Page 21 Problem Cause How to Fix • We recommend that you turn the mixer handle to the off position and dismantle the hose from the riser, check the sealing washer is not crushed, turn on • No water is Washer may be the water slightly to make sure water is coming out of crushed during...
-
Page 22: Water Quality
GENTEC is rejuvenating the product- no power, less maintenance and longer life. Rejuvenation Program To learn more about the rejuvenation program, please contact our customer service at info@gentecaustralia.com.au for more information. Ethically and Environmentally Sourced Please refer to GENTEC Business Ethics & Ethical Sourcing Policy at https:// gentecaustralia.com.au/terms-and-conditions/... - Page 23 gentecaustralia.com.au...
- Page 24 Note: The information provided is only a guide, actual product may differ. The information here should not be relied on without clarification with Gentec. Gentec reserves the right to make design changes at any time without notification.
