- Page 1 UltraDish™ 29 WB User Guide UD29WB Installation Video If you need further assistance, reach out to us on our webpage or on social media.
- Page 2 UltraDish™ WB Contents UltraDish™ 29 WB - English User Guide............3 WEAR PROTECTIVE GLOVES/ USAR GUANTES PROTECTORES www.rfelements.com...
- Page 3 UltraDish™ WB Package Contents Number Description Quantity UltraDish™ 29 UltraDish™ Base Bracket Base UBR Subreflector Bracket Ring UBR Pole Mount Bracket M8 x 80 mm DIN 912 Screw M6 x 20 mm DIN 6921 Screw M8 x 14 mm DIN 7991 Screw 3 x 16 mm Lock Screw www.rfelements.com...
- Page 4 UltraDish™ WB Installation Guide Use 5 mm Hex Key when assembling the UltraDish™ Base www.rfelements.com...
- Page 5 UltraDish™ WB Installation Guide Use 5 mm Hex Key when assembling the Bracket Ring UBR www.rfelements.com...
- Page 6 UltraDish™ WB Installation Guide Continue turning the Subreflector in either direction until the spring latch engages. www.rfelements.com...
- Page 7 UltraDish™ WB Installation Guide Use 13 mm Ratchet Wrench when assembling the Bracket. www.rfelements.com...
- Page 8 UltraDish™ WB Installation Guide Install the Pole Mount Bracket as shown for pole diameter range 40 - 57 mm. Install the Pole Mount Bracket as shown for pole diameter range 58 - 80 mm. www.rfelements.com...
- Page 9 UltraDish™ WB Installation Guide www.rfelements.com...
- Page 10 UltraDish™ WB Installation Guide Use 13 mm Ratchet Wrench when tightening the azimuth bolts. www.rfelements.com...
- Page 11 UltraDish™ WB Installation Guide Use 13 mm Ratchet Wrench when tightening the elevation bolts. www.rfelements.com...
- Page 12 UltraDish™ WB Radio Installation Guide Optional: Install the 3 x 16 locking screw. Tighten the locking screw to secure the TwisPort™ lock mechanism. www.rfelements.com...
- Page 13 UltraDish™ WB Radio Uninstallation Guide If the locking screw was used, unscrew it by about 10 mm before unlocking the TwisPort™ mechanism. www.rfelements.com...
- Page 14 UltraDish™ WB Pre - Installation Optional: Right side of the pole mounting. Use 5 mm Hex Key to enable the Handle www.rfelements.com...
- Page 15 UltraDish™ WB Pre - Installation Optional: Right side of the pole mounting. www.rfelements.com...
- Page 16 UltraDish™ WB Pre - Installation Optional: Right side of the pole mounting. Use 5 mm Hex Key to secure the Handle in position. www.rfelements.com...
- Page 17 RF elements®, TwistPort™ and SIMPER™ are trademarks of RF elements s.r.o., Slovakia. All rights of trademark owners reserved. RF elements s.r.o. +421 2 7333 7733 info@rfelements.com www.rfelements.com User Guide Part No. UG-UD29WB-v1 Rev 07-2024...
